•High beam Assist does not recognize
road users:
–Who have no lights, e.g. pedestrians.
–Who have low intensity lighting, e. g.
cyclists.
–Whose lighting is blocked, e.g. by a
barrier.
•In very rare cases, High beam Assist rec-
ognizes road users too late or not at all.
In this, or in similar situations, the auto-
matic high beam headlights will not be
deactivated or activated regardless.
There is a risk of an accident.
•Always carefully observe the traffic
conditions and switch off the high beam
headlights in good time.
CAUTION
High beam Assist cannot compensate for
road and weather circumstances while
driving. The system saves the driver from
having to operate the switch. The driver
always remains responsible for choosing
the correct light setting.
Specific situations in which to operate the
headlight switch manually:
•In heavy rain, snowy conditions. (gen-
eral poor visibility and bad weather con-
ditions).
•When the vehicle sensors are dirty, cov-
ered or broken.
Switching High Beam Assist on/off
To switch on:
Turn the light switch to and press
the combination switch beyond the pressure
point in the direction of arrow
3. Theindicator light in the vehicle information dis-
play lights up when it is dark and the light
sensor switches on the low-beam headlights.
If you are driving at speeds above approxi-
mately 28 MPH (45 km/h) the headlight
range is set automatically depending on the
distance between the vehicle and other road
users.
NIC2618
2-70Instruments and controls

If you are driving at speeds above approxi-
mately 34 MPH (55 km/h) and no other road
users are detected, the high beam headlights
are switched on automatically. The
indicator light in the combination meter also
lights up.
If you are driving at speeds below approxi-
mately 28 MPH (45 km/h) or other road
users are detected or the roads are ad-
equately lit The high beam headlights are
switched off automatically. The
indica-
tor light in the combination meter goes out.
The
indicator light in the vehicle infor-
mation display remains lit.
To deactivate:
Move the combination switch back to its nor-
mal position The
indicator light in the
vehicle information display goes out.
HEADLIGHTS MISTED UP ON
THE INSIDE
Certain climatic and physical conditions may
cause moisture to form in the headlight. This
moisture does not affect the functionality of
the headlight.
INSTRUMENT BRIGHTNESS
CONTROL
The light sensor in the combination meter
automatically controls the brightness of the
instrument panel
In daylight, the displays in the combination
meter are not illuminated
The lighting in the combination meter, dis-
plays and controls in the vehicle interior can
be adjusted using the brightness control
knob.
The brightness control knob
1is located
behind the steering wheel.
Turn the brightness control knob clockwise or
counterclockwise. If the light switch is set to
orthe brightness is dependent
upon the brightness of the ambient light.
FRONT FOG LIGHTS
In conditions where visibility is poor due to
fog, snow or rain, the fog lights improve vis-
ibility as well as making it easier for other
road users to see you. They can be operated
together with the side lights or together with
the side lights and low beam headlights.
To switch on the fog lights:
•Turn the ignition switch to the ON position
or start the engine.
•Turn the light switch toor.
•Press thebutton. The greenindicator light in the combination meter
lights up
NIC2615NIC2699
FOG LIGHT SWITCH (IF SO
EQUIPPED)
Instruments and controls2-71

Press and hold thebutton until the side
windows are fully closed.
To interrupt convenience closing: release the
button.
You can also use the keyless locking feature
to activate convenience closing:
Touch recessed sensor surface
1on the
door handle until the side windows are fully
closed.
NOTE
Make sure you only touch recessed sensor
surface
1.
To interrupt convenience opening: release
the recessed sensor surface
1on the door
handle.
Resetting the side windows
If a side window can no longer be closed fully,
you must reset it.
1. Switch the ignition switch to the ON po-
sition.
2. Close the door.3. Pull the corresponding switch on the door
control panel until the side window is
completely closed
4. Hold the switch for an additional second.
If the side window opens again slightly:
1. Immediately pull the corresponding switch
on the door control panel until the side
window is completely closed.
2. Hold the switch for an additional second.
3. If the corresponding side window remains
closed after the button has been released,
the side window has been reset correctly.
If this is not the case, repeat the steps
above again.
If the power window automatic function
does not operate properly after performing
the procedure above, have your vehicle
checked. It is recommended you visit an
INFINITI retailer for this service.
NPA1478
Instruments and controls2-77

To unlock the vehicle:touch the inner surface
of the door handle.
To lock the vehicle:touch sensor surface
1.
or
2.
Make sure that you do not touch the inner
surface of the door handle.
Convenience closing feature:touch recessed
sensor surface
1for an extended period.
(See "Convenience closing feature").To unlock the lift gate: press the lift gate
switch
1.
When unlocking, the turn signals flash once
When locking, they flash three times.
NOTE
When the locator lighting is activated, it
lights up when it is dark after the vehicle is
unlocked with the Intelligent Key (see sepa-
rate operating instructions).
You can also set an audible signal to confirm
that the vehicle has been locked. The audible
signal can be activated or deactivated using
the on-board computer (see "Activating/
deactivating the acoustic locking confirma-
tion")LOCKING WITH THE
MECHANICAL KEY
The driver's door can be locked/unlocked
from outside using the mechanical key if the
battery is dead.
To lock the door, insert the mechanical key
into the driver's door key cylinder and turn it
towards the front of the vehicle
1.
To unlock the door, turn the key towards the
rear of the vehicle
2.
See "Mechanical key" earlier in this section for
instructions on accessing the Intelligent Key
system mechanical key.
NPA1489NPA1479SPA2602Z
Pre-driving checks and adjustments3-5

When the Intelligent Key battery is dis-
charged or strong radio waves are present
near the operating location, the Intelligent
Key operating range becomes narrower, and
the Intelligent Key may not function properly.
The operating range is within 31.5 in (80 cm)
from each request switch
1.
If the Intelligent Key is too close to the door
glass, handle or rear bumper, the request
switches may not function.
When the Intelligent Key is within the operat-
ing range, it is possible for anyone, even
someone who does not carry the Intelligent
Key, to push the request switch to lock/
unlock the doors.
DOOR LOCKS/UNLOCKS
PRECAUTION
•Do not touch the door handle request
switch with the Intelligent Key held in your
hand as illustrated. The close distance to
the door handle will cause the Intelligent
Key system to have difficulty recognizing
that the Intelligent Key is outside the ve-
hicle.
•To prevent the Intelligent Key from being
left inside the vehicle, make sure you carry
the Intelligent Key
INFINITI INTELLIGENT KEY
OPERATION
You can lock or unlock the doors without
taking the Intelligent Key out of your pocket
or bag.
When you carry the Intelligent Key with you,
you can lock or unlock all doors by pushing
the door handle request switch within the
range of operation.
Locking doors
1. Push the P (Park) button to engage the P
(Park) position, place the ignition switch in
the LOCK position and make sure you
carry the Intelligent Key with you.
2. Close all doors.
3. Touch any sensor surface
1or2.
WPD0375ZNPA1489
3-10Pre-driving checks and adjustments

4. All doors and the lift gate will lock.
5. The turn signals flash three times.
NOTE
•Doors do not lock by pushing the door
handle request switch while any door is
open. However, doors lock with the me-
chanical key even if any door is open.
•The driver's door and the door at which
the handle is used, must both be closed.
•The doors may not lock when the Intelli-
gent Key is in the same hand that is oper-
ating the request switch to lock the door.
Put the Intelligent Key in a purse, pocket
or your other hand.
CAUTION
•When locking the doors using the re-
quest switch, make sure to have the In-
telligent Key in your possession before
operating the request switch to prevent
the Intelligent Key from being left in the
vehicle.
•The request switch is operational only
when the Intelligent Key has been de-
tected by the Intelligent Key system.
Unlocking doors
1. Carry the Intelligent Key.
2. Touch the inner surface of the door
handle.
3. All doors and the lift gate will unlock.
4. The turn signals flash once.
Deactivating and activating
If you do not intend to use the vehicle for an
extended period of time, you can deactivate
the Intelligent Key. The key will then use very
little power, thereby conserving battery
power. For the purposes of activation/
deactivation, the vehicle does not have to be
nearby.
To deactivate:press the
button on the
key twice in rapid succession The battery
check lamp of the key lights up twice briefly
and Intelligent Key is deactivated.
To activate:press any button on the key or
insert the key into the ignition lock. The Intel-
ligent Key and all of its associated features
are available again.
CHANGING THE SETTINGS OF
THE LOCKING SYSTEM
You can change the settings of the locking
system. This means that only the driver's door
and the fuel-filler lid are unlocked when the
vehicle is unlocked. This is useful if you fre-
quently travel alone.To change the setting:simultaneously
press theandbuttons for approxi-
mately 6 seconds.
NOTE
If the setting of the locking system is
changed within the signal range of the ve-
hicle, pressing the
andbutton will
lock or unlock the vehicle.
The key now functions as follows:
To unlock the driver's door:press the
button once.
To unlock centrally:press the
button
twice.
To lock centrally:press the
button.
The Intelligent Key function is changed as
follows:
To unlock the driver's door:touch the inner
surface of the door handle on the driver's
door.
To unlock centrally:touch the inner surface
of the door handle on the front passenger
door or the rear door.
To lock centrally:touch the outer sensor sur-
face on one of the door handles
To restore the factory settings:
simultane-
ouslypress theandbutton for ap-
proximately 6 seconds.
Pre-driving checks and adjustments3-11

The bird's-eye view shows the overhead view
of the vehicle, which helps confirm the vehicle
position.
The vehicle icon
1shows the position of the
vehicle.
NOTE
The size of the vehicle icon on the bird's-eye
view may differ somewhat from the actual
vehicle.
The areas that the cameras cannot cover
2are indicated in black.
The non-viewable area
2is highlighted in
yellow for several seconds after the bird's-
eye view is displayed. It will be shown only the
first time after the ignition switch is placed in
the ON position.
When the corner of the vehicle moves closer
to an object, the corner sensor indicator
3appears.Front-side view:
Guiding lines that indicate the approximate
width and the front end of the vehicle are
displayed on the monitor.
The front-of-vehicle line
1shows the front
part of the vehicle.
The side-of-vehicle line
2shows the ap-
proximate vehicle width including the outside
mirrors.
The extensions
3of both the front1and
side
2lines are shown with a green dotted
line.
The corner sensor indicator
4will appear
when a corner of the vehicle moves closer to
an object.
DIFFERENCE BETWEEN
PREDICTED AND ACTUAL
DISTANCES
The displayed guidelines and their locations
on the ground are for approximate reference
only. Objects on uphill or downhill surfaces or
projecting objects will be actually located at
distances different from those displayed in
the monitor relative to the guidelines (refer to
illustrations). When in doubt, turn around and
view the objects as you are backing up, or
park and exit the vehicle to view the position-
ing of objects behind the vehicle.
NAA1681SAA1842Z
Left-Hand Drive (LHD) models*
Display screen, heater and air conditioner, and audio system4-15

A[Settings] key
B

MOD SYSTEM OPERATION
The MOD system will activate automatically
under the following conditions:
•When the shift lever is in the R (Reverse)
position. When the shift lever is moved to
the R (Reverse) position to activate the
Around View Monitor and MOD, the icons
and the messages may not be displayed
immediately.
•When thebutton is pressed
to switch from a different screen to the
camera view on the display.
•When vehicle speed decreases below ap-
proximately 5 MPH (8 km/h).
•When the ignition switch is placed in the
OFF position and then back to the ON
position.
NOTE
•The MOD system does not detect moving
objects in the front-side view. The MOD
icon is not displayed on the screen when in
this view.
•While the parking sensor warning tone is
sounding, the MOD system does not chime.
The MOD system operates in the following
conditions when the camera view is dis-
played:
When the shift lever is in the R (Reverse)
position and the vehicle speed is approxi-
mately 5 MPH (8 km/h ) or less, the MOD
system detects moving objects in the camera
view. The MOD system will not operate if the
lift gate is open.
When the MOD system detects moving ob-
jects near the vehicle, a chime will be heard
and a yellow frame
1will be displayed on
the monitor.
While the MOD system continues to detect
moving objects, the yellow frame continues
to be displayed.
The yellow frame
1is displayed on each
view in the rear view modes.
A blueicon is displayed in the view
where the MOD system is operative. A gray
MOD icon is displayed in the view where the
MOD system is not operative.
NAA1781
Bird's-eye view
NAA1782
Front view / rear view
Display screen, heater and air conditioner, and audio system4-25

Cruise control.......................5-46
Cruise control operations..............5-47
Intelligent Cruise Control (ICC) system
(Full speed range) (if equipped)............5-49
ICC system operation................5-50
ICC switch (cruise control lever)..........5-51
ICC system display and indicators.........5-52
Operating ICC.....................5-53
ICC Limitations....................5-56
Tips for driving with the ICC system.......5-58
System temporarily unavailable..........5-60
System maintenance.................5-62
Forward emergency braking (FEB) system
(if equipped)........................5-62
FEB system operation................5-63
Turning the FEB system on/off..........5-66
FEB system limitations................5-67
System temporarily unavailable..........5-67
System maintenance.................5-68
FCC Notice.......................5-69
Active sound enhancement...............5-69
Active sound enhancement.............5-70
Intelligent Parking Assist (IPA) (if equipped). . . .5-70
Important safety notes...............5-70
Detecting parking spaces..............5-71
Parking.........................5-73
Exiting a parking space...............5-74Canceling IPA.....................5-75
Camera Aiding Sonar (parking sensor) function
(if equipped)........................5-76
Sonar function overview...............5-77
Range of the sensors.................5-81
Sonar function OFF switch.............5-81
Sonar function settings...............5-82
Sonar function limitations..............5-82
Problems with sonar function...........5-83
System maintenance.................5-84
Break-in schedule.....................5-84
Fuel efficient driving tips................5-85
Increasing fuel economy.................5-86
Four-Wheel Drive (4WD) (if equipped)........5-86
Parking...........................5-87
Switching off the engine..............5-88
Extended parking...................5-89
Electric power steering system............5-89
Brake system........................5-90
Brake precautions..................5-90
Anti-lock Braking System (ABS)..........5-91
Vehicle Dynamic Control (VDC) system.......5-92
Traction Control System (TCS)..........5-94
Characteristics of VDC...............5-94
EBD (electronic brake force distribution). . . .5-95
Steer Control......................5-95
Hill Start Assist (HSA)..................5-95
