•After a short time, hill start assist will no
longer brake your vehicle and it could
roll away There is a risk of an accident
and injury. Therefore, quickly move your
foot from the brake pedal to the accel-
erator pedal. Never leave the vehicle
when it is held by hill start assist.
Hill start assist helps you when pulling away
forwards or in reverse on an uphill gradient. It
holds the vehicle for a short time after you
have removed your foot from the brake
pedal. This gives you enough time to move
your foot from the brake pedal to the accel-
erator pedal and depress it before the vehicle
begins to roll.
Hill start assist is not active if
•You are pulling away on a level road or a
downhill gradient.
•On vehicles with automatic transmission,
the transmission is in position N.
•The electric parking brake is applied.
•VDC is malfunctioning.
FREEING A FROZEN DOOR LOCK
To prevent a door lock from freezing, apply
deicer through the key hole. If the lock be-
comes frozen, heat the key before inserting it
into the key hole, or use the INFINITI Intelli-
gent Key.
ANTIFREEZE
In the winter when it is anticipated that the
temperature will drop below 32°F (0°C),
check the antifreeze to assure proper winter
protection. For additional information, see
"Engine cooling system".
BATTERY
If the battery is not fully charged during ex-
tremely cold weather conditions, the battery
fluid may freeze and damage the battery. To
maintain maximum efficiency, the battery
should be checked regularly. For details, see
"Battery" of this manual.
DRAINING OF ENGINE COOLANT
If the vehicle is to be left outside without
antifreeze, drain the cooling system, including
the engine block. Refill before operating the
vehicle. For details, see "Changing engine
coolant" of this manual.
TIRE EQUIPMENT
1. SUMMER tires have a tread designed to
provide superior performance on dry
pavement. However, the performance of
these tires will be substantially reduced in
snowy and icy conditions. If you operate
your vehicle on snowy or icy roads,
INFINITI recommends the use of MUD &
SNOW or ALL SEASON TIRES on all four
wheels. It is recommended that you visit
an INFINITI retailer for the tire type, size,
speed rating and availability information.
2. For additional traction on icy roads, stud-
ded tires may be used. However, some
U.S. states and Canadian provinces pro-
hibit their use. Check local, state and pro-
vincial laws before installing studded tires.
Skid and traction capabilities of studded
snow tires, on wet or dry surfaces, may be
poorer than that of non-studded snow tires.
COLD WEATHER DRIVING
5-96Starting and driving

•When a replacement tire is mounted or a
wheel is replaced, the TPMS will not
function and the low tire pressure warn-
ing light will flash for approximately
1 minute. The light will remain on after
1 minute. It is recommended you Con-
tact an INFINITI retailer as soon as pos-
sible for tire replacement and/or system
resetting.
•Replacing tires with those not originally
specified by INFINITI could affect the
proper operation of the TPMS.
•If you used Emergency Tire Sealant to
repair a minor tire puncture, the TPMS
sensor should be checked when repair-
ing or replacing the tire. It is recom-
mended you visit an INFINITI retailer for
this service.
The Tire Pressure Monitoring System (TPMS)
monitors tire pressure of all tires. When the
low tire pressure warning light is lit, and a tire
pressure-related warning (if equipped) ap-
pears in the vehicle information display, one
or more of your tires is significantly under-
inflated. If the vehicle is being driven with low
tire pressure, the TPMS will activate and
warn you of it by the low tire pressure warn-
ing light (in the meter panel). This system willactivate only when the vehicle is driven at
speeds above 16 MPH (25 km/h).
For more details about the TPMS, see "Tire
Pressure Monitoring System (TPMS)".
STOPPING VEHICLE
WARNING
•Be sure to apply the parking brake
firmly.
•Be sure that P (Park) is engaged.
•Never change tires when the vehicle is
on a slope, ice or slippery area. This is
hazardous.
•Never change tires when the oncoming
traffic is close to your vehicle. Call for
professional road assistance.
1. Safely move the vehicle off the road away
from traffic.
2. Turn on the hazard indicator flasher lights.
3. Park on a level surface.
4. Apply the parking brake.
5. Press the P (Park) button.
6. Turn off the engine.7. Open the hood and set up the triangle
reflector (if equipped):
•To warn other traffic.
•To signal professional road assistance
personnel that you need assistance.
8. Have all passengers get out of the vehicle
and stand in a safe place, away from
other traffic and clear of the vehicle.
In case of emergency6-3

WARNING
Always follow the instructions below. Fail-
ure to do so could result in damage to the
charging system and cause personal injury.1. If the booster battery is in another vehicle,
position the two vehicles to bring their
batteries near each other.
Do not allow the two vehicles to touch.2. Check if the parking brake is applied.
If not, after connecting the vehicle with
the booster battery (after step 8), apply
the parking brake.
The vehicle has an electric parking brake,
for more information see, "Parking brake"
3. Press the P (Park) button.
4. Switch off all unnecessary electrical sys-
tems (headlights, hazard lights etc,).
5. Ensure that the ignition switch of the ve-
hicle being jump-started is in the OFF po-
sition.
6. Open the hood. For details, see "Hood".
7. Remove the vent caps (if equipped) on the
battery and cover the battery with an old
cloth.
8. Connect the jump leads in the sequence
(
1→2→3→4) as illustrated.
CAUTION
•Always connect positive+to positive
+and negative-to body ground (for
example, strut mounting bolt, engine lift
bracket, etc.) – not to the battery's
negative
-.
NDI1595
In case of emergency6-11

WARNING
•Do not continue to drive if your vehicle
overheats. Doing so could cause engine
damage or a vehicle fire.
•To avoid the danger of being scalded,
never remove the radiator or coolant
reservoir cap while the engine is hot.
When the radiator or coolant reservoir
cap is removed, pressurized hot water
will spurt out, possibly causing serious
injury.
•Do not open the hood if steam is coming
out.
If
the engine of your vehicle is overheating
(indicated by the engine coolant temperature
gauge) or if you feel a lack of engine power,
detect unusual noise, etc., proceed as follows:
1. Move and park the vehicle safely off the
road and away from traffic.
2. Turn on the hazard warning flasher lights.
3. Apply the parking brake.
4. Press the P (Park) button.
DO NOT STOP THE ENGINE.
5. Open all windows.6. Switch off the air conditioner system (if
equipped).
7. Set the heater or air conditioner tempera-
ture control to maximum “HOT” and fan
speed control to maximum speed.
8. Exit the vehicle.
9. Visually inspect and listen for steam or
coolant escaping from the radiator before
opening the hood.
WARNING
Ifsteam or water is coming from the engine,
stand clear to prevent getting burned.
10. Open the hood. For details, see "Hood".
11.
Visually check if the cooling fan is running.
12. Visually check the radiator and radiator
hoses for leakage.
WARNING
Be careful not to allow your hands, hair,
jewelry or clothing to come into contact
with, or get caught in, engine belts or the
engine cooling fan. The engine cooling fan
can start at any time.13. After the engine cools down, check the
coolant level in the engine coolant reser-
voir with the engine running.Do not
open the radiator cap (if equipped).
14. If the level is low, remove the engine
coolant reservoir cap and add coolant
slowly into the reservoir. After refilling
the reservoir to the MAX level, install the
reservoir cap.
15. Close the hood.
Have your vehicle inspected or repaired. It is
recommended you visit an INFINITI retailer.
IF YOUR VEHICLE OVERHEATS
In case of emergency6-13

8 Do-it-yourself
Maintenance precautions.................8-2
Engine compartment check locations.........8-3
2.0L Gasoline engine.................8-3
Engine cooling system...................8-3
Checking engine coolant level............8-4
Changing engine coolant...............8-4
Engine oil...........................8-5
Checking engine oil level...............8-5
Changing engine oil..................8-5
Changing engine oil filter...............8-6
Automatic Transmission Fluid (ATF)..........8-7
Brake fluid..........................8-7
Window washer fluid...................8-8
Battery............................8-9
Accessing Vehicle battery...............8-9
Maintenance free battery..............8-10
Models with Idle Stop/Start System.......8-10
Battery replacement.................8-10
Reinitialisation procedure after battery
reconnection......................8-12
Jump-starting.....................8-12
Drive belt..........................8-12
Spark plugs.........................8-12
Air cleaner filter......................8-13
Wiper blades........................8-13Cleaning.........................8-13
Replacing front window wiper blades......8-14
Replacing rear window wiper blade.......8-16
Brakes............................8-17
Self-adjusting brakes.................8-17
Fuses.............................8-17
Before replacing a fuse...............8-17
Engine compartment.................8-18
Passenger compartment..............8-19
Intelligent Key battery replacement........
.8-20
Checking the battery.................8-21
Replacing the battery.................8-21
Lights............................8-23
Exterior and interior lights..............8-23
Replacement procedures..............8-25
Wheels and tires......................8-27
Tire Pressure......................8-27
Tire inflation pressure................8-30
Tire labeling......................8-30
Types of tires.....................8-32
Tire chains.......................8-33
Tire wear and damage................8-33
Tire rotation......................8-34
Replacing wheels and tires.............8-34
Wheel balance.....................8-36

2.0L GASOLINE ENGINE
1. Engine coolant reservoir (P. 8-3)
2. Engine oil dipstick (P. 8-5)
3. Engine oil filler cap (P. 8-5)
4. Brake fluid reservoir (P. 8-7)5. Engine air cleaner filter (P. 8-13)
6. Battery (P. 8-9)
7. Fuse box (P. 8-17)
8. Window washer fluid reservoir (P. 8-8)
WARNING
The engine cooling system is filled at the
factory with a high-quality, year-round,
antifreeze coolant solution. The antifreeze
solution contains rust and corrosion inhibi-
tors, therefore additional cooling system
additives are not necessary.
•Never remove the radiator or coolant
reservoir cap when the engine is hot.
Wait until the engine and radiator cool
down. Serious burns could be caused by
high-pressure fluid escaping from the
radiator. For additional information on
precautions, refer to "If your vehicle
overheats"
•The engine coolant reservoir tank is
equipped with a pressure type cap. To
prevent engine damage, use only a
genuine INFINITI pressure cap.
CAUTION
•Never use any cooling system additives
such as radiator sealer. Additives may
clog the cooling system and cause dam-
age to the engine, transmission and/or
cooling system.NIC2833
ENGINE COMPARTMENT CHECK
LOCATIONSENGINE COOLING SYSTEM
Do-it-yourself8-3

•When adding or replacing coolant, be
sure to use only INFINITI Genuine En-
gine Coolant, BASF Glysantin G40 or
equivalent in its quality. The use of other
types of engine coolant may damage the
engine cooling system.
CHECKING ENGINE COOLANT
LEVEL
NOTE
The coolant level must only be checked and
corrected when the engine is cold.
1. Park the vehicle on a level surface.
Only check the coolant level if the vehicle
is on a level surface and the engine is cold.2. Slowly turn cap
1half a turn counter-
clockwise to allow excess pressure to es-
cape.
3. Turn cap
1further counter-clockwise
and remove it.
If the coolant is at the level of marker bar
3in the filler neck when cold, there is
enough coolant in coolant expansion tank
2.
4. If necessary, top up with INFINITI Genu-
ine Engine Coolant, BASF Glysantin G40
or equivalent in its quality.
5. Replace cap
1and turn it clockwise as
far as it will go.
If the cooling system frequently requires
coolant, have it checked. It is recommended
that you visit an INFINITI retailer for this
service.
CHANGING ENGINE COOLANT
An INFINITI retailer can change the engine
coolant.
Improper servicing can result in reduced
heater performance and engine overheating.
WARNING
•To avoid being scalded, never change
the coolant when the engine is hot.
•Never remove the radiator cap when the
engine is hot. Serious burns could be
caused by high pressure fluid escaping
from the radiator.
•Avoid direct skin contact with used
coolant. If skin contact is made, wash
thoroughly with soap or hand cleaner as
soon as possible.
•Keep coolant out of reach of children
and pets.
Engine coolant must be disposed of properly.
Check your local regulations.
NDI1602
8-4Do-it-yourself

CHECKING ENGINE OIL LEVEL
1. Park the vehicle on a level surface and
apply the parking brake.
2.
Start the engine and let it idle until it reaches
the normal operating temperature.
3. Turn off the engine. Wait more than
15 minutes for the oil to drain back into
the oil pan.
4. Remove the dipstick
1and wipe it clean.
Reinsert it all the way.5. Remove the dipstick and check the oil
level. It should be within the range
2and
3.
If the oil level is below
3, remove the oil
filler cap and pour the recommended oil
into the opening.Do not overfill
2.
It is normal to add some oil between oil main-
tenance intervals or during the break-in pe-
riod, depending on the severity of operating
conditions.
CAUTION
The oil level should be checked regularly.
Operating the engine with an insufficient
amount of oil can damage the engine, and
such damage is not covered by the
warranty.
CHANGING ENGINE OIL
WARNING
•Prolonged and repeated contact with
used engine oil may cause skin cancer.
•Try to avoid direct skin contact with
used oil. If skin contact is made, wash
thoroughly with soap or hand cleaner
and plenty of water as soon as possible.
•Keep used engine oil out of reach of
children.
CAUTION
Be careful not to burn yourself. The engine
oil may be hot.
NDI1596
2.0L gasoline engine
ENGINE OIL
Do-it-yourself8-5

1. Park the vehicle on a level surface and
apply the parking brake.
2. Start the engine and let it idle until it
reaches the normal operating tempera-
ture, then turn it off.
3. Remove the oil filler cap by turning it
counterclockwise.
4. Remove the engine undershield.
5.
Place a large drain pan under the drain plug.
6. Remove the drain plug with a wrench by
turning it counterclockwise and com-
pletely drain the oil. If the oil filter is to be
changed, remove and replace it at this
time. For additional information, refer to
"Changing engine oil filter" later in this
section.
•Waste oil must be disposed of properly.
•Check your local regulations.
7. Clean and reinstall the drain plug and a
new washer. Securely tighten the drain
plug with a wrench. Do not use excessive
force.
Drain plug tightening torque: 22 ft-lb,
30 N•m
8. Refill engine with recommended oil
through the oil filler opening, then install
the oil filler cap securely.
For additional information on drain and
refill capacity, refer to "Recommended
fluids/lubricants and capacities".
The drain and refill capacity depends on the
oil temperature and drain time. Use these
specifications for reference only. Always
use the dipstick to determine when the
proper amount of oil is in the engine.
9. Start the engine. Check for leakage
around the drain plug and oil filter. Correct
as required.
10. Turn the engine off and wait more than
15 minutes. Check the oil level with the
dipstick. Add engine oil if necessary.
CHANGING ENGINE OIL FILTER
1. Park the vehicle on a level surface and
apply the parking brake.
2. Turn the engine off and wait more than
15 minutes.
3. Place a large drain pan under the oil filter
1.
4. Loosen the oil filter
1with an oil filter
wrench by turning it counterclockwise.
Then remove the oil filter by turning it by
hand.
CAUTION
Be careful not to burn yourself. The engine
oil may be hot.
NDI1622NDI1610
2.0L gasoline engine
8-6Do-it-yourself

5. Wipe the engine oil filter sealing surface
with a clean rag.
CAUTION
•Be sure to remove any old gasket mate-
rial remaining on the sealing surface of
the engine. Failure to do so could lead to
an oil leak and engine damage.
•The dipstick must be inserted in place to
prevent oil spillage from the dipstick
hole when filling the engine with oil.
6. Coat the gasket on the new filter with
clean engine oil.
7. Screw on the oil filter until a slight resis-
tance is felt, then tighten an additional
2/3 turn.
Engine oil filter tightening torque: 19 ft-lb,
25 N•m
8. Start the engine and check for leakage
around the oil filter. Correct as required.
9. Turn the engine off and wait more than
15 minutes. Check the oil level. Add engine
oil if necessary.It is recommended that you visit an INFINITI
retailer if checking or replacement is required.
CAUTION
•Use only Shell DCT-M1 or equivalent.
Do not mix with other fluids.
•Using automatic transmission fluid
other than Shell DCT-M1 may cause de-
terioration in driveability and automatic
transmission durability, and may dam-
age the automatic transmission. Dam-
age caused by the use of fluids other
than as recommended is not covered by
the warranty.
WARNING
•Use only new fluid. Old, inferior, or con-
taminated fluid may damage the brake
systems. The use of improper fluids can
damage the brake system and affect the
vehicle's stopping ability.
•Clean the filler cap before removing.
•Brake fluid is poisonous and should be
stored carefully in marked containers
out of the reach of children.
CAUTION
•Do not spill the fluid on painted surfaces.
This will damage the paint. If fluid is
spilled, wash with water.
NDI1599
AUTOMATIC TRANSMISSION FLUID
(ATF)BRAKE FLUID
Do-it-yourself8-7
