AUTOMATIC DRIVE POSITIONER
Revision: October 20052005 QX56
Manual OperationEIS004XC
The driving position [seat position, steering wheel, pedal position (accelerator, brake) and door mirror position]
can be adjusted with the power seat switch LH, pedal adjusting switch, door mirror remote control switch or
ADP steering switch.
NOTE:

The door mirrors can be manually operated with the ignition switch turned to ACC or ON.

Adjustable pedals can only operate when A/T shift lever is in P position (except when ignition switch
turned to OFF).

If A/T device (detent switch) error is detected, manual adjustable pedal operation cannot be performed
when ignition switch turns ON.
Automatic OperationEIS004XD
NOTE:

Disconnecting the battery erases the stored memory.

After connecting the battery, insert the key into the ignition cylinder and turn the front door switch LH ON (open)→OFF (close)→ON
(open), the Entry/ Exiting function becomes possible.

After Exiting operation is carried out, return operation can be operated.
NOTE:
During automatic operation, if the ignition switch is turned ON→START, the automatic operation is suspended. When the ignition switch
returns to ON, it resumes.
System DescriptionEIS004XE

The system automatically moves the driver seat and steering wheel to facilitate entry/exit to/from the vehi-
cle. The driver seat control unit can also store the optimum driving positions (driver seat, steering wheel,
pedal position and door mirror position) for 2 people. One-touch operation allows changing between driv-
ing positions.
7. Pedal adjusting switch M96 8. A. Door mirrror LH D4, RH D107
B. Front door switch LH B8
C. Front door lock assembly LH (key
cylinder switch) D149. A. A/T selector lever
B. A/T device (detent switch) M203
10. A. Sliding motor LH P4 (driver seat
view), reclining motor LH P5, lifting
motor (front) P6, lifting motor (rear)
P7
B. Driver seat control unit P2, P3
C. Power seat switch LH P811. A. ADP steering switch M16
B.Tilt motor M68, M69
Function Description
Memory operation The seat, steering wheel, pedals (accelerator, brake) and door mirrors move to the
stored driving position by pushing seat memory switch (1 or 2).
Entry/Exit-
ing functionExiting operation At exit, the seat moves backward and the steering wheel raises. (Exiting position)
Entry operationAt entry, the seat and steering wheel return from Exiting position to the previous driv-
ing position before the Exiting operation.
Keyfob interlock operationPerform memory operation, turnout operation and return operation by pressing key-
fob unlock button.
Auto operation temporary stop
conditions.When ignition switch is turned to START during seat memory switch operation and return
operation, seat memory switch operation and return operation is stopped.
Auto operation stop conditions.

When the vehicle speed becomes 7 km/h (4 MPH) or higher (memory switch operation
and entry operation).

When the setting switch, seat memory switch 1, or 2 are pressed.

When A/T shift lever is in any position other than P.

When the door mirror remote control switch is operated (when ignition switch turned to
ON).

When power seat switch turned ON.

When pedal adjusting switch turned ON.

When front seat sliding Entry/Exiting setting is OFF (entry/exiting operation).

SE-32
AUTOMATIC DRIVE POSITIONER
Revision: October 20052005 QX56
Terminals and Reference Values for Automatic Drive Positioner Control UnitEIS004XL
31 L/Y Sensor ground — 0
32 B Ground — 0
33 L/B Battery power supply — Battery voltage
35 V/WSliding motor FORWARD out-
put signalSliding switch FORWARD opera-
tion (Motor operated)Battery voltage
Other than above 0
36 Y/GReclining motor FORWARD out-
put signalReclining switch FORWARD oper-
ation (Motor operated)Battery voltage
Other than above 0
37 BRFront lifting motor DOWN output
signalFront lifting switch DOWN opera-
tion (Motor operated)Battery voltage
Other than above 0
38 B/WRear lifting motor UP output sig-
nalRear end lifting switch UP opera-
tion (Motor operated)Battery voltage
Other than above 0
39 YRear lifting motor DOWN output
signalRear end lifting switch DOWN
operation (Motor operated)Battery voltage
Other than above 0
40 Y/R Battery power supply — Battery voltage
42 O/BSliding motor BACKWARD out-
put signalSliding switch BACKWARD oper-
ation (Motor operated)Battery voltage
Other than above 0
44 Y/RReclining motor BACKWARD
output signalReclining switch BACKWARD
operation (Motor operated)Battery voltage
Other than above 0
45 GRFront lifting motor UP output sig-
nalFront lifting switch UP operation
(Motor operated)Battery voltage
Other than above 0
48 B/W Ground — 0 TERMINALWIRE
COLORITEM CONDITIONVOLTAGE (V)
(Approx.)
TERMINAL WIRE
COLORITEM CONDITIONVOLTAGE (V)
(Approx.)
1 W/G ADP steering switch TILT UPADP steering switch in UP position 0
Other than above 5
2 LG Changeover switch RH signalChangeover switch in RH position 0
Other than above 5
3 Y/B Mirror switch UP signalMirror switch in UP position 0
Other than above 5
4 V/W Mirror switch LEFT signalMirror switch in LEFT position 0
Other than above 5
5R/BMirror sensor (RH vertical) sig-
nalMirror motor RH is operated UP or
DOWNChanges between 3.4 (close to
peak) 0.6 (close to valley)
6L/YMirror sensor (LH vertical) sig-
nalMirror motor LH is operated UP or
DOWNChanges between 3.4 (close to
peak) 0.6 (close to valley)
7 Y/R Tilt sensor inputTilt position TOP 2
Tilt position BOTTOM 4

SE-34
AUTOMATIC DRIVE POSITIONER
Revision: October 20052005 QX56
Work Flow EIS004XM
1. Check the symptom and customer's requests.
2. Understand the system description. Refer to SE-12, "
System Description" .
3. Perform the preliminary check. Refer to SE-35, "
Preliminary Check" .
4. Check the self-diagnosis, results using CONSULT-II. Refer to SE-38, "
CONSULT-II Function (AUTO
DRIVE POS.)" .
5. Repair or replace depending on the self-diagnostic results.
6. Based on the trouble diagnosis chart, repair or replace the cause of the malfunction. Refer to SE-42,
"Symptom Chart" .
7. Does the automatic drive positioner system operate normally?
If it is normal, GO TO 8.
If it is not normal, GO TO 3.
8. Inspection End.
30 YMirror motor RH DOWN signalMirror motor RH is operated DOWN 1.5 - Battery voltage
Other than above 0
Mirror motor RH RIGHT signalMirror motor RH is operated RIGHT 1.5 - Battery voltage
Other than above 0
31 R Mirror motor LH UP signalMirror motor LH is operated UP 1.5 - Battery voltage
Other than above 0
32 BR Mirror motor LH LEFT signalMirror motor LH is operated LEFT 1.5 - Battery voltage
Other than above 0
33 W/L Sensor power supply — 5
34 Y/R Battery power supply — Battery voltage
35 R Tilt motor UP signalADP steering switch in UP position Battery voltage
Other than above 0
37 GPedal adjust motor FORWARD
signalPedal adjust motor FORWARD
operation (Motor operated)Battery voltage
Other than above 0
39 L/B Battery power supply — Battery voltage
40 B/W Ground — 0
41 W/G Sensor ground — 0
42 V Tilt motor DOWN signalADP steering switch in DOWN posi-
tionBattery voltage
Other than above 0
45 RPedal adjust motor BACK-
WARD signalPedal adjust motor BACKWARD
operation (Motor operated)Battery voltage
Other than above 0
48 B Ground — 0 TERMINAL WIRE
COLORITEM CONDITIONVOLTAGE (V)
(Approx.)

AUTOMATIC DRIVE POSITIONER
SE-35
C
D
E
F
G
H
J
K
L
MA
B
SE
Revision: October 20052005 QX56
Preliminary CheckEIS004XN
SETTING CHANGE FUNCTION
The settings of the automatic driving positioner system can be changed, using CONSULT-II and the display in
the center of the instrument panel.
×: Applicable –: Not applicable
It is possible to set sliding front seat for entry/exit of vehicle by pressing set switch.
*: Setting of sliding front seat for entry/exit of vehicle is ON at factory-shipment. But if custom settings are reset, setting turns OFF.
NOTE:
After the setting is registered, the new setting is effective, even if the battery is disconnected.
POWER SUPPLY AND GROUND CIRCUIT INSPECTION
1. CHECK BCM FUSES AND FUSIBLE LINK
Check if any of the following fuses in the BCM are blown.
NOTE:
Refer to SE-11, "
Component Parts And Harness Connector Location" .
OK or NG
OK >> GO TO 2.
NG >> If fuse is blown, be sure to eliminate cause of malfunction before installing new fuse. Refer to PG-
63, "ELECTRICAL UNITS LOCATION" .
Setting item ContentCONSULT–II
(WORK SUPPORT)Display unitDefault
settingFactory
setting
SEAT SLIDE
VOLUME SETThe distance at exiting opera-
tion can be selected from the
following 3 modes.40mm
—××
80mm — —
150mm — —
Sliding Front Seat and
Steering Wheel Raise
When Entry/ Exiting
Veh icleThe seat sliding and steering
wheel raise turnout and return
at entry/exit can be selected:
ON (operated)–OFF (not
operated)ON ON: Indicator lamp ON —×
OFF OFF: Indicator lamp OFF×—
Reset custom settings* All settings to default. —Default: Setting button
ON——
Content Setting change operation Indicator LEDs
The seat sliding and steering
wheel raise turnout and return
at entry/exit can be operated.
Press the set switch for more than 10 secondsBlinking twice
The seat sliding and steering
wheel raise turnout and return
at entry/exit can be not oper-
ated.Blinking once
Unit Power source Fuse No.
BCMBattery power supplyf (50A)
ON or START power supply 59 (10A)
ACC or ON power supply 4 (10A)

PRECAUTIONS
SRS-3
C
D
E
F
G
I
J
K
L
MA
B
SRS
Revision: October 20052005 QX56
PRECAUTIONSPFP:00001
Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT
BELT PRE-TENSIONER”
EHS0016A
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WA RN ING:

To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance must be per-
formed by an authorized NISSAN/INFINITI dealer.

Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the SRS section.

Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
harness connectors.
Precautions for SRS “AIR BAG” and “SEAT BELT PRE-TENSIONER” ServiceEHS0016B

Do not use electrical test equipment to check SRS circuits unless instructed to in this Service Manual.

Before servicing the SRS, turn ignition switch OFF, disconnect both battery cables and wait at least 3 min-
utes.
For approximately 3 minutes after the cables are removed, it is still possible for the air bags and seat belt
pre-tensioners to deploy. Therefore, do not work on any SRS connectors or wires until at least 3 minutes
have passed.

The air diagnosis sensor unit must always be installed with the arrow mark “⇐” pointing toward the front of
the vehicle for proper operation. Also check air bag diagnosis sensor unit for cracks, deformities or rust
before installation and replace as required.

The spiral cable must be aligned with the neutral position since its rotations are limited. Do not attempt to
turn steering wheel or column after removal of steering gear.

Handle air bag module carefully. Always place driver and front passenger air bag modules with the pad
side facing upward and seat mounted front side air bag module standing with the stud bolt side facing
down.

Conduct self-diagnosis to check entire SRS for proper function after replacing any components.

After air bag inflates, the front instrument panel assembly should be replaced if damaged.
Occupant Classification System PrecautionEHS0016C
Replace control unit and passenger front seat cushion as an assembly.
Trouble Diagnosis PrecautionEHS0016D
When you read wiring diagrams, refer to the following:

GI-15, "How to Read Wiring Diagrams" in GI section

PG-4, "POWER SUPPLY ROUTING CIRCUIT" in PG section
When you perform trouble diagnosis, refer to the following:

GI-11, "HOW TO FOLLOW TEST GROUPS IN TROUBLE DIAGNOSES" in GI section

GI-27, "How to Perform Efficient Diagnosis for an Electrical Incident" in GI section
Check for any service bulletins before servicing the vehicle.

TF-34
TROUBLE DIAGNOSIS
Revision: October 20052005 QX56
CRUISE TEST
1. CHECK INPUT SIGNAL
1. Warm up engine to normal operating temperature.
2. Park vehicle on flat surface.
3. Move A/T selector lever to “P” position.
4. Set 4WD shift switch to “AUTO” position.
5. Start engine.
6. Drive vehicle for at least 30 seconds at a speed higher than 20 km/h (12 MPH).
Check 4WD warning lamp turned ON?
On steady>>Perform the self-diagnosis. Refer to TF-50, "SELF-DIAGNOSTIC PROCEDURE (WITH CON-
SULT-II)" (with CONSULT-II) or TF-50, "SELF-DIAGNOSTIC PROCEDURE (WITHOUT CON-
SULT-II)" (without CONSULT-II).
Flash rapidly>>GO TO TF-128, "
4WD Warning Lamp Flashes Rapidly" .
Flash slowly>>GO TO TF-129, "
4WD Warning Lamp Flashes Slowly" .
NO >> GO TO 2.
2. CHECK TIGHT CORNER BRAKING SYMPTOM (1)
1. Set 4WD shift switch to “AUTO” position.
2. Drive vehicle at speed lower than 20 km/h (12 MPH) with steering wheel fully turned.
Does tight corner braking symptom occur?
YES >> GO TO TF-130, "Heavy Tight-corner Braking Symptom Occurs" .
NO >> GO TO 3.
3. CHECK TIGHT CORNER BRAKING SYMPTOM (2)
1. Set 4WD shift switch to “4HI” position.
2. Drive vehicle at speed lower than 20 km/h (12 MPH) with steering wheel fully turned.
Does tight corner braking symptom occur?
YES >> Inspection End.
NO >> GO TO TF-131, "
4WD System Does Not Operate" .
Trouble Diagnosis Chart for SymptomsEDS002HI
If 4WD warning lamp turns ON, perform self-diagnosis. Refer to TF-50, "Self-diagnostic Procedure" .
Symptom Condition Check item Reference page
4WD shift indicator lamp and 4LO indicator
lamp do not turn ON
(4WD shift indicator lamp and 4LO indicator
lamp check)Ignition switch: ONPower supply and ground for transfer
control unit
TF-117
Transfer shut off relay
Combination meter
4WD warning lamp does not turn ON
(4WD warning lamp check)Ignition switch: ONPower supply and ground for transfer
control unit
TF-121
Transfer shut off relay
Combination meter
