TROUBLE DIAGNOSISPFP:00004
DTC Inspection Priority ChartECS00CE9
If some DTCs are displayed at the same time, perform inspections one by one based on the following priority
chart.
NOTE:
If DTC U1000 is displayed with other DTCs, first perform the trouble diagnosis for DTC U1000. Refer to
AT-9 5
.
Fail-SafeECS00CEA
The TCM has an electrical fail-safe mode. This mode makes it possible to operate even if there is an error in a
main electronic control input/output signal circuit. In fail-safe mode the transmission is fixed in 2nd, 4th or 5th
(depending on the breakdown position), so the customer should feel “slipping” or “poor acceleration”.
Even when the electronic circuits are normal, under special conditions (for example, when slamming on the
brake with the wheels spinning drastically and stopping the tire rotation), the transmission can go into fail-safe
mode. If this happens, switch “OFF” the ignition switch for 10 seconds, then switch it “ON” again to return to
the normal shift pattern. Therefore, the customer's vehicle has returned to normal, so handle according to the
“diagnostics flow” (Refer to AT-44, "
WORK FLOW" ).
FAI L-S AFE FUN CT ION
If any malfunction occurs in a sensor or solenoid, this function controls the A/T to mark driving possible.
Vehicle Speed Sensor

Signals are input from two systems - from vehicle speed sensor A/T (revolution sensor) installed on the
transmission and from combination meter so normal driving is possible even if there is a malfunction in
one of the systems. And if vehicle speed sensor A/T (revolution sensor) has unusual cases, 5th gear is
prohibited.
Accelerator Pedal Position Sensor

If there is a malfunction in one of the systems, the accelerator opening angle is controlled by ECM accord-
ing to a pre-determined accelerator angle to make driving possible. And if there are malfunctions in tow
systems, the engine speed is fixed by ECM to a pre-determined engine speed to make driving possible.
Throttle Position Sensor

If there is a malfunction in one of the systems, the accelerator opening angle is controlled by ECM accord-
ing to a pre-determined accelerator angle to make driving possible. And if there are malfunctions in tow
systems, the accelerator opening angle is controlled by the idle signal sent from the ECM which is based
on input indicating either idle condition or off-idle condition (pre-determined accelerator opening) in order
to make driving possible.
PNP Switch

In the unlikely event that a malfunction signal enters the TCM, the position indicator is switched “OFF”, the
starter relay is switched “OFF” (starter starting is disabled), the back-up lamp relay switched “OFF” (back-
up lamp is OFF) and the position is fixed to the “D” range to make driving possible.
Starter Relay

The starter relay is switched “OFF”. (Starter starting is disabled.)
Priority Detected items (DTC)
1 U1000 CAN communication line
2 Except above

AT-82
TROUBLE DIAGNOSIS
Revision: October 20052005 QX56
TCM Input/Output Signal Reference ValuesECS00CEO
A/T ASSEMBLY HARNESS CONNECTOR TERMINAL LAYOUT
TCM INSPECTION TABLE
Data are reference value and are measured between each terminal and ground.
SCIA1658E
Terminal
No.Wire
colorItem Condition Data (Pyrex.)
1PPower supply
(Memory back-up)Always Battery voltage
2PPower supply
(Memory back-up)Always Battery voltage
3 L CAN-H – –
4VK-line (CONSULT-
II signal)The terminal is connected to the data link connector for CONSULT-II. –
5 B Ground Always 0V
6Y/RPower supply– Battery voltage
–0V
7RBack-up lamp
relaySelector lever in “R” position. 0V
Selector lever in other positions. Battery voltage
8 P CAN-L – –
9 B/R Starter relaySelector lever in “N”,“ P” positions. Battery voltage
Selector lever in other positions. 0V
10 B Ground Always 0V

AT-84
TROUBLE DIAGNOSIS
Revision: October 20052005 QX56
ATF PRES SW 1Front brake engaged. Refer to AT- 1 9ON
Front brake disengaged. Refer to AT- 1 9
OFF
ATF PRES SW 2Low coast brake engaged. Refer to AT-1 9
ON
Low coast brake disengaged. Refer to AT- 1 9
OFF
ATF PRES SW 3Input clutch engaged. Refer to AT- 1 9
ON
Input clutch disengaged. Refer to AT- 1 9
OFF
ATF PRES SW 5Direct clutch engaged. Refer to AT- 1 9
ON
Direct clutch disengaged. Refer to AT- 1 9
OFF
ATF PRES SW 6High and low reverse clutch engaged. Refer to AT- 1 9
ON
High and low reverse clutch disengaged. Refer to AT- 1 9
OFF
I/C SOLENOIDInput clutch disengaged. Refer to AT- 1 9
0.6 - 0.8 A
Input clutch engaged. Refer to AT- 1 9
0 - 0.05 A
FR/B SOLENOIDFront brake engaged. Refer to AT- 1 9
0.6 - 0.8 A
Front brake disengaged. Refer to AT- 1 9
0 - 0.05 A
D/C SOLENOIDDirect clutch disengaged. Refer to AT- 1 9
0.6 - 0.8 A
Direct clutch engaged. Refer to AT- 1 9
0 - 0.05 A
HLR/C SOLHigh and low reverse clutch disengaged. Refer to AT- 1 9
0.6 - 0.8 A
High and low reverse clutch engaged. Refer to AT- 1 9
0 - 0.05 A
ON OFF SOLLow coast brake engaged. Refer to AT-1 9
ON
Low coast brake disengaged. Refer to AT- 1 9
OFF
STARTER RELAYSelector lever in “N”,“P” position. ON
Selector lever in other position. OFF
ACCELE POSIReleased accelerator pedal. 0.0/8
Fully depressed accelerator pedal. 8/8
THROTTLE POSIReleased accelerator pedal. 0.0/8
Fully depressed accelerator pedal. 8/8
CLSD THL POSReleased accelerator pedal. ON
Fully depressed accelerator pedal. OFF
W/O THL POSFully depressed accelerator pedal. ON
Released accelerator pedal. OFF
BRAKE SWDepressed brake pedal. ON
Released brake pedal. OFF Item name Condition Display value (Approx.)

AT-86
TROUBLE DIAGNOSIS
Revision: October 20052005 QX56
Display Items List
X: Applicable, —: Not applicable
Items (CONSULT-II
screen terms)Malfunction is detected when...TCM self-
diagnosisOBD-II (DTC)
“A/T” with
CONSULT-IIMIL indicator
lamp*1,
“ENGINE” with
CONSULT-II or
GST
CAN COMM CIRCUIT

When a malfunction is detected in CAN communications U1000 U1000
STARTER RELAY/
CIRC

If this signal is ON other than in P or N position, this is judged to be a
malfunction.
(And if it is OFF in P or N position, this too is judged to be a malfunc-
tion.)P0615 —
TCM

TCM is malfunctioning. P0700 P0700
PNP SW/CIRC

PNP switch 1-4 signals input with impossible pattern

“P” position is detected from N position without any other position
being detected in between.P0705 P0705
VEH SPD SEN/CIR AT
(Revolution sensor)

Signal from vehicle speed sensor A/T (Revolution sensor) not input
due to cut line or the like

Unexpected signal input during running

After ignition switch is turned ON, unexpected signal input from vehicle
speed sensor MTR before the vehicle starts movingP0720 P0720
ENGINE SPEED SIG

TCM does not receive the CAN communication signal from the ECM. P0725 —
TCC SOLENOID/CIRC

Normal voltage not applied to solenoid due to cut line, short, or the like P0740 P0740
A/T TCC S/V FNCTN

A/T cannot perform lock-up even if electrical circuit is good.

TCM detects as irregular by comparing difference value with slip rota-
tion.P0744 P0744*2
L/PRESS SOL/CIRC

Normal voltage not applied to solenoid due to cut line, short, or the like

TCM detects as irregular by comparing target value with monitor value.P0745 P0745
TCM·RAM

TCM memory (RAM) is malfunctioning. P1702 —
TCM·ROM

TCM memory (ROM) is malfunctioning. P1703 —
TP SEN/CIRC A/T

TCM does not receive the proper accelerator pedal position signals
(input by CAN communication) from ECM.P1705 P1705
ATF TEMP SEN/CIRC

During running, the ATF temperature sensor signal voltage is exces-
sively high or lowP1710 P0710
TURBINE REV S/CIRC

TCM does not receive the proper voltage signal from the sensor.

TCM detects an irregularity only at position of 4th gear for turbine revo-
lution sensor 2.P1716 P1716
VEH SPD SE/CIR·MTR

Signal (CAN communication) from vehicle speed sensor MTR not input
due to cut line or the like

Unexpected signal input during runningP1721 —
A/T INTERLOCK

Except during shift change, the gear position and ATF pressure switch
states are monitored and comparative judgement made.P1730 P1730
A/T 1ST E/BRAKING

Each ATF pressure switch and solenoid current is monitored and if a
pattern is detected having engine braking 1st gear other than in the "1"
position, a malfunction is detected.P1731 —
I/C SOLENOID/CIRC

Normal voltage not applied to solenoid due to functional malfunction,
cut line, short, or the like
