BCM (BODY CONTROL MODULE)
BCS-7
C
D
E
F
G
H
I
J
L
MA
B
BCS
Revision: October 20052005 QX56

BCM is activated with low current consumption mode.

CAN communication is not active.

When CAN communication operation is detected, it switches to CAN communication status.

When a state of the following switches changes, it switches to CAN communication state:
–Key switch
–Hazard switch
–Door lock/unlock switch
–Front door switch (LH, RH)
–Rear door switch (LH, RH)
–Back door switch
–Combination switch (passing, lighting switch 1st position, front fog lamp)
–Keyfob (lock/unlock signal)
–Door lock assembly LH (key cylinder switch)

When control performed only by BCM is required by switch, it shifts to CAN communication inactive
mode.

Status of combination switch reading function is changed.
SYSTEMS CONTROLLED BY BCM DIRECTLY

Power door lock system. Refer to BL-16, "POWER DOOR LOCK SYSTEM" .

Remote keyless entry system. Refer to BL-44, "REMOTE KEYLESS ENTRY SYSTEM" .

Power window system. Refer to GW-15, "POWER WINDOW SYSTEM" . NOTE

Sunroof system. Refer to RF-10, "SUNROOF" . NOTE

Room lamp timer. Refer to LT- 1 2 9 , "INTERIOR ROOM LAMP" .

Warning chime system. Refer to DI-42, "WARNING CHIME" .

Turn signal and hazard warning lamps system. Refer to LT-80, "TURN SIGNAL AND HAZARD WARNING
LAMPS" .
NOTE:
Power supply only. No system control.
SYSTEMS CONTROLLED BY BCM AND IPDM E/R

Panic system. Refer to BL-44, "REMOTE KEYLESS ENTRY SYSTEM" .

IVIS (NATS) system. Refer to BL-137, "IVIS (INFINITI VEHICLE IMMOBILIZER SYSTEM-NATS)" .

Headlamp, tail lamp, front fog lamp, auto light and battery saver control systems. Refer to LT- 6 , "HEAD-
LAMP (FOR USA)" , LT- 3 3 , "HEADLAMP (FOR CANADA) - DAYTIME LIGHT SYSTEM -" , LT-108,
"PARKING, LICENSE PLATE AND TAIL LAMPS" , LT-69, "FRONT FOG LAMP" or LT-47, "AUTO LIGHT
SYSTEM" .

Front wiper and washer system. Refer to WW-4, "FRONT WIPER AND WASHER SYSTEM" .

Rear wiper and washer system. Refer to WW-35, "REAR WIPER AND WASHER SYSTEM" .

Rear window defogger system. Refer to GW-77, "REAR WINDOW DEFOGGER" .
MAJOR COMPONENTS AND CONTROL SYSTEM
System Input Output
Remote keyless entry system Keyfob

All-door locking actuator

Back door opener actuator

Turn signal lamp (LH, RH)
Power door lock systemFront power door lock/unlock
switch (LH, RH)All-door locking actuator
Power supply (IGN) to power window
and sunroofIgnition power supply Power supply to power window and sunroof system
Power supply (BAT) to power window
and sunroofBattery power supply Power supply to power window and sunroof system

BL-1
BODY, LOCK & SECURITY SYSTEM
I BODY
CONTENTS
C
D
E
F
G
H
J
K
L
M
SECTION BL
A
B
BL
Revision: October 20052005 QX56 PRECAUTIONS .......................................................... 4
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” .................................................................. 4
Precautions for work ................................................ 4
PREPARATION ........................................................... 5
Special service tool .................................................. 5
Commercial Service Tool ......................................... 5
SQUEAK AND RATTLE TROUBLE DIAGNOSES ..... 6
Work Flow ................................................................ 6
CUSTOMER INTERVIEW ..................................... 6
DUPLICATE THE NOISE AND TEST DRIVE ....... 7
CHECK RELATED SERVICE BULLETINS ........... 7
LOCATE THE NOISE AND IDENTIFY THE
ROOT CAUSE ...................................................... 7
REPAIR THE CAUSE ........................................... 7
CONFIRM THE REPAIR ....................................... 8
Generic Squeak and Rattle Troubleshooting ........... 8
INSTRUMENT PANEL .......................................... 8
CENTER CONSOLE ............................................. 8
DOORS ................................................................. 8
TRUNK .................................................................. 9
SUNROOF/HEADLINING ..................................... 9
OVERHEAD CONSOLE (FRONT AND REAR) ..... 9
SEATS ................................................................... 9
UNDERHOOD ....................................................... 9
Diagnostic Worksheet ............................................ 10
HOOD ....................................................................... 12
Fitting Adjustment .................................................. 12
CLEARANCE AND SURFACE HEIGHT
ADJUSTMENT .................................................... 13
HOOD LOCK ADJUSTMENT ............................. 13
Removal and Installation of Hood Assembly .......... 13
Removal and Installation of Hood Lock Control ..... 14
REMOVAL ........................................................... 14
INSTALLATION ................................................... 15
Hood Lock Control Inspection ................................ 15
POWER DOOR LOCK SYSTEM .............................. 16
Component Parts and Harness Connector Location ... 16
System Description ................................................ 17OUTLINE ............................................................. 18
Schematic ............................................................... 19
Wiring Diagram — D/LOCK — ............................... 20
Terminals and Reference Value for BCM ............... 25
Work Flow ............................................................... 25
CONSULT–II Function (BCM) ................................ 26
CONSULT–II INSPECTION PROCEDURE ......... 26
DATA MONITOR ................................................. 27
ACTIVE TEST ..................................................... 28
Trouble Diagnoses Symptom Chart ....................... 29
BCM Power Supply and Ground Circuit Check ...... 29
Door Switch Check ................................................. 31
Key Switch (Insert) Check ...................................... 33
Door Lock/Unlock Switch Check ............................ 34
Glass Hatch Switch Circuit Inspection .................... 36
Front Door Lock Assembly LH (Actuator) Check .... 38
Front Door Lock Actuator RH Check ...................... 39
Rear Door Lock Actuator RH/LH Check ................. 40
Glass Hatch Lock Actuator Check .......................... 41
Front Door Lock Assembly LH (Key Cylinder Switch)
Check ..................................................................... 42
REMOTE KEYLESS ENTRY SYSTEM ..................... 44
Component Parts and Harness Connector Location ... 44
System Description ................................................. 45
INPUTS ............................................................... 45
OPERATING PROCEDURE ................................ 46
CAN Communication System Description .............. 48
Schematic ............................................................... 49
Wiring Diagram — KEYLES — ............................... 50
............................................................................ 50
............................................................................ 51
............................................................................ 52
Terminals and Reference Value for BCM ............... 53
Terminals and Reference Value for IPDM E/R ....... 54
CONSULT-II Function (BCM) ................................. 55
CONSULT-II Inspection Procedure ......................... 55
“MULTI REMOTE ENT” ....................................... 55
CONSULT-II Application Items ............................... 56
“MULTI REMOTE ENT” ....................................... 56
Trouble Diagnosis Procedure ................................. 59

SQUEAK AND RATTLE TROUBLE DIAGNOSES
BL-9
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: October 20052005 QX56
TRUNK
Trunk noises are often caused by a loose jack or loose items put into the trunk by the owner.
In addition look for:
1. Trunk lid bumpers out of adjustment
2. Trunk lid striker out of adjustment
3. The trunk lid torsion bars knocking together
4. A loose license plate or bracket
Most of these incidents can be repaired by adjusting, securing or insulating the item(s) or component(s) caus-
ing the noise.
SUNROOF/HEADLINING
Noises in the sunroof/headlining area can often be traced to one of the following:
1. Sunroof lid, rail, linkage or seals making a rattle or light knocking noise
2. Sun visor shaft shaking in the holder
3. Front or rear windshield touching headliner and squeaking
Again, pressing on the components to stop the noise while duplicating the conditions can isolate most of these
incidents. Repairs usually consist of insulating with felt cloth tape.
OVERHEAD CONSOLE (FRONT AND REAR)
Overhead console noises are often caused by the console panel clips not being engaged correctly. Most of
these incidents are repaired by pushing up on the console at the clip locations until the clips engage.
In addition look for:
1. Loose harness or harness connectors.
2. Front console map/reading lamp lense loose.
3. Loose screws at console attachment points.
SEATS
When isolating seat noise it's important to note the position the seat is in and the load placed on the seat when
the noise is present. These conditions should be duplicated when verifying and isolating the cause of the
noise.
Cause of seat noise include:
1. Headrest rods and holder
2. A squeak between the seat pad cushion and frame
3. The rear seatback lock and bracket
These noises can be isolated by moving or pressing on the suspected components while duplicating the con-
ditions under which the noise occurs. Most of these incidents can be repaired by repositioning the component
or applying urethane tape to the contact area.
UNDERHOOD
Some interior noise may be caused by components under the hood or on the engine wall. The noise is then
transmitted into the passenger compartment.
Causes of transmitted underhood noise include:
1. Any component mounted to the engine wall
2. Components that pass through the engine wall
3. Engine wall mounts and connectors
4. Loose radiator mounting pins
5. Hood bumpers out of adjustment
6. Hood striker out of adjustment
These noises can be difficult to isolate since they cannot be reached from the interior of the vehicle. The best
method is to secure, move or insulate one component at a time and test drive the vehicle. Also, engine RPM
or load can be changed to isolate the noise. Repairs can usually be made by moving, adjusting, securing, or
insulating the component causing the noise.

BL-164
BODY REPAIR
Revision: October 20052005 QX56
1. Front fender (RH, LH)
2. Hood assembly
3. Rear hoodledge reinforcement (RH, LH)
4. Outer sill reinforcement (RH, LH)
5. Front pillar hinge brace (RH, LH)
6. Center pillar hinge brace
7. Outer front pillar reinforcement (RH, LH)
8. Center inner pillar (RH, LH)
9. Front inner pillar upper (RH, LH)
10. Inner roof side rail (RH, LH)
11. Roof with sunroof opening
12. Roof
13. Front roof rail
14. Sunroof reinforcement
15. Roof 1st bow
16. Roof 2nd bow
17. Roof 3rd bow
18. Roof 4th bow
19. Rear roof rail
20. Main back pillar (RH, LH)
21. Back pillar reinforcement (RH, LH)
22. Rear inner side panel (RH, LH)
23. Rear wheel housing (RH, LH)
24. Rear body side outer (RH, LH)
25. Front body side outer (RH, LH)
26. Front door assembly (RH, LH)
27. Rear door assembly (RH, LH)
28. Lift gate assembly

EI-1
EXTERIOR & INTERIOR
I BODY
CONTENTS
C
D
E
F
G
H
J
K
L
M
SECTION EI
A
B
EI
Revision: October 20052005 QX56 PRECAUTIONS .......................................................... 3
Service Notice .......................................................... 3
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” .................................................................. 3
PREPARATION ........................................................... 4
Special Service Tools ............................................... 4
Commercial Service Tools ........................................ 4
SQUEAK AND RATTLE TROUBLE DIAGNOSES ..... 5
Work Flow ................................................................ 5
CUSTOMER INTERVIEW ..................................... 5
DUPLICATE THE NOISE AND TEST DRIVE ....... 6
CHECK RELATED SERVICE BULLETINS ........... 6
LOCATE THE NOISE AND IDENTIFY THE
ROOT CAUSE ...................................................... 6
REPAIR THE CAUSE ........................................... 6
CONFIRM THE REPAIR ....................................... 7
Generic Squeak and Rattle Troubleshooting ........... 7
INSTRUMENT PANEL .......................................... 7
CENTER CONSOLE ............................................. 7
DOORS ................................................................. 7
TRUNK .................................................................. 8
SUNROOF/HEADLINING ..................................... 8
OVERHEAD CONSOLE (FRONT AND REAR) ..... 8
SEATS ................................................................... 8
UNDERHOOD ....................................................... 8
Diagnostic Worksheet .............................................. 9
CLIP AND FASTENER ..............................................11
Description ..............................................................11
FRONT BUMPER ..................................................... 13
Removal and Installation ........................................ 13
REAR BUMPER ....................................................... 15
Removal and Installation ........................................ 15
FRONT GRILLE ........................................................ 17
Removal and Installation ........................................ 17
COWL TOP ............................................................... 18
Removal and Installation ........................................ 18
FRONT FENDER ...................................................... 20
Removal and Installation ........................................ 20OVER FENDER ......................................................... 21
Removal and Installation ........................................ 21
REMOVAL ........................................................... 21
INSTALLATION ................................................... 21
FENDER PROTECTOR ............................................ 23
Removal and Installation ........................................ 23
FRONT ................................................................ 23
LICENSE LAMP FINISHER ...................................... 24
Removal and Installation ........................................ 24
RUNNING BOARDS ................................................. 25
Removal and Installation ........................................ 25
REAR SPOILER ........................................................ 26
Removal and Installation ........................................ 26
REMOVAL ........................................................... 26
INSTALLATION ................................................... 26
ROOF RACK ............................................................. 27
Removal and Installation ........................................ 27
DOOR OUTSIDE MOLDING ..................................... 28
Removal and Installation ........................................ 28
............................................................................ 28
............................................................................ 29
SIDE GUARD MOLDING .......................................... 30
Removal and Installation ........................................ 30
REMOVAL ........................................................... 30
INSTALLATION ................................................... 30
DOOR FINISHER ...................................................... 32
Removal and Installation ........................................ 32
FRONT DOOR .................................................... 32
REAR DOOR ....................................................... 33
BODY SIDE TRIM ..................................................... 35
Removal and Installation ........................................ 35
LOWER DASH SIDE FINISHER ......................... 35
CENTER PILLAR LOWER FINISHER ................ 36
CENTER PILLAR UPPER FINISHER ................. 36
FRONT PILLAR FINISHER ................................. 36
KICKING PLATES ............................................... 36
MUDGUARD FINISHERS ................................... 36
DOOR PARTING SEALS .................................... 36
FLOOR TRIM ............................................................ 37
Removal and Installation ........................................ 37

EI-8
SQUEAK AND RATTLE TROUBLE DIAGNOSES
Revision: October 20052005 QX56
TRUNK
Trunk noises are often caused by a loose jack or loose items put into the trunk by the owner.
In addition look for:
1. Trunk lid bumpers out of adjustment
2. Trunk lid striker out of adjustment
3. The trunk lid torsion bars knocking together
4. A loose license plate or bracket
Most of these incidents can be repaired by adjusting, securing or insulating the item(s) or component(s) caus-
ing the noise.
SUNROOF/HEADLINING
Noises in the sunroof/headlining area can often be traced to one of the following:
1. Sunroof lid, rail, linkage or seals making a rattle or light knocking noise
2. Sun visor shaft shaking in the holder
3. Front or rear windshield touching headliner and squeaking
Again, pressing on the components to stop the noise while duplicating the conditions can isolate most of these
incidents. Repairs usually consist of insulating with felt cloth tape.
OVERHEAD CONSOLE (FRONT AND REAR)
Overhead console noises are often caused by the console panel clips not being engaged correctly. Most of
these incidents are repaired by pushing up on the console at the clip locations until the clips engage.
In addition look for:
1. Loose harness or harness connectors.
2. Front console map/reading lamp lens loose.
3. Loose screws at console attachment points.
SEATS
When isolating seat noise it's important to note the position the seat is in and the load placed on the seat when
the noise is present. These conditions should be duplicated when verifying and isolating the cause of the
noise.
Cause of seat noise include:
1. Headrest rods and holder
2. A squeak between the seat pad cushion and frame
3. The rear seatback lock and bracket
These noises can be isolated by moving or pressing on the suspected components while duplicating the con-
ditions under which the noise occurs. Most of these incidents can be repaired by repositioning the component
or applying urethane tape to the contact area.
UNDERHOOD
Some interior noise may be caused by components under the hood or on the engine wall. The noise is then
transmitted into the passenger compartment.
Causes of transmitted underhood noise include:
1. Any component mounted to the engine wall
2. Components that pass through the engine wall
3. Engine wall mounts and connectors
4. Loose radiator mounting pins
5. Hood bumpers out of adjustment
6. Hood striker out of adjustment
These noises can be difficult to isolate since they cannot be reached from the interior of the vehicle. The best
method is to secure, move or insulate one component at a time and test drive the vehicle. Also, engine RPM
or load can be changed to isolate the noise. Repairs can usually be made by moving, adjusting, securing, or
insulating the component causing the noise.

HEADLINING
EI-39
C
D
E
F
G
H
J
K
L
MA
B
EI
Revision: October 20052005 QX56
CAUTION:
Disconnect both terminals from battery in advance.
1. Remove body side trim. Refer to EI-35, "
BODY SIDE TRIM" .
2. Remove luggage floor trim. Refer to EI-40, "
LUGGAGE FLOOR TRIM" .
3. Remove sunvisor assemblies.
4. Remove sunvisor clips.
5. Remove sunroof welt (if equipped).
6. Remove front roof console.

Disconnect harnesses.
7. Remove rear roof console.

Disconnect harnesses.
8. Remove assist grips.
9. Remove lamp assembly from rear roof finisher.

Disconnect harness.
10. Remove rear roof finisher.
11. Remove headlining.

Remove clips from rear of headlining.

Disconnect harnesses.
12. Remove rear air control.

Disconnect harness.
13. Remove rear audio control assembly.

Disconnect harness.
14. Remove lamp assemblies.

Disconnect harnesses.
15. Remove air vents.
16. Remove the front roof console bracket.
17. Remove rear roof console front bracket.
18. Remove assist grip brackets from roof.
Installation is in the reverse order of removal.
1. Headlining (without sunroof) 2. Assist grip bracket 3. Assist grip
4. Sunvisor assembly LH 5. Cap LH 6. Sunvisor holder
7. Front roof console 8. Sunglass bin 9. Sunroof welt
10. Cap RH 11. Sunvisor assembly RH 12. Rear roof console bracket
13. Rear storage bin or DVD display 14. Rear air control 15. Rear audio control assembly
16. Rear roof console 17. Rear roof console finisher 18. Rear storage bin
19. Air vent 20. Lamp assembly 21. Plastic clip
22. Headlining (with sunroof) 23. Rear lamp lens 24. Rear lamp
25. Rear roof finisher 26. Plastic clip 27. Metal clip

GW-1
GLASSES, WINDOW SYSTEM & MIRRORS
I BODY
CONTENTS
C
D
E
F
G
H
J
K
L
M
SECTION GW
A
B
GW
Revision: October 20052005 QX56 PRECAUTIONS .......................................................... 3
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” .................................................................. 3
Handling for Adhesive and Primer ........................... 3
Trouble Diagnosis Precaution .................................. 3
PREPARATION ........................................................... 4
Special Service Tool ................................................. 4
Commercial Service Tool ......................................... 4
SQUEAK AND RATTLE TROUBLE DIAGNOSES ..... 5
Work Flow ................................................................ 5
CUSTOMER INTERVIEW ..................................... 5
DUPLICATE THE NOISE AND TEST DRIVE ....... 6
CHECK RELATED SERVICE BULLETINS ........... 6
LOCATE THE NOISE AND IDENTIFY THE
ROOT CAUSE ...................................................... 6
REPAIR THE CAUSE ........................................... 6
CONFIRM THE REPAIR ....................................... 7
Generic Squeak and Rattle Troubleshooting ........... 7
INSTRUMENT PANEL .......................................... 7
CENTER CONSOLE ............................................. 7
DOORS ................................................................. 7
TRUNK .................................................................. 8
SUNROOF/HEADLINER ....................................... 8
OVERHEAD CONSOLE (FRONT AND REAR) ..... 8
SEATS ................................................................... 8
UNDERHOOD ....................................................... 8
Diagnostic Worksheet .............................................. 9
WINDSHIELD GLASS ...............................................11
Removal and Installation .........................................11
REMOVAL ............................................................11
INSTALLATION ....................................................11
REAR WINDOW GLASS AND MOLDING ............... 13
Removal and Installation ........................................ 13
REMOVAL ........................................................... 13
INSTALLATION ................................................... 14
POWER WINDOW SYSTEM .................................... 15
Component Parts and Harness Connector Location ... 15
System Description ................................................ 15
MANUAL OPERATION ....................................... 16AUTO OPERATION ............................................. 18
POWER WINDOW SERIAL LINK ....................... 18
POWER WINDOW LOCK ................................... 18
RETAINED POWER OPERATION ...................... 18
ANTI-PINCH SYSTEM ........................................ 18
POWER WINDOW CONTROL BY THE FRONT
DOOR LOCK ASSEMBLY LH (KEY CYLINDER
SWITCH) ............................................................. 19
CAN Communication System Description .............. 19
Schematic ............................................................... 20
Wiring Diagram — WINDOW — ............................. 22
Terminal and Reference Value for Main Power Win-
dow and Door Lock/Unlock Switch ......................... 30
Terminal and Reference Value for Power Window
and Door Lock/Unlock Switch RH .......................... 30
Terminal and Reference Value for BCM ................. 32
Work Flow ............................................................... 33
CONSULT-II Function (BCM) ................................. 33
CONSULT-II INSPECTION PROCEDURE .......... 33
ACTIVE TEST ..................................................... 34
WORK SUPPORT ............................................... 34
DATA MONITOR ................................................. 34
Trouble Diagnoses Symptom Chart ....................... 35
BCM Power Supply and Ground Circuit Check ...... 37
Main Power Window and Door Lock/Unlock Switch
Power Supply and Ground Circuit Check ............... 38
Power Window and Door Lock/Unlock Switch RH
Power Supply and Ground Circuit Check ............... 39
Front Power Window Motor LH Circuit Check ........ 40
Front Power Window Motor RH Circuit Check ....... 41
Limit Switch Circuit Check Front LH ....................... 42
Limit Switch Circuit Check Front RH ...................... 43
Encoder Circuit Check Front LH ............................. 45
Encoder Circuit Check Front RH ............................ 47
Door Switch Check ................................................. 49
Front Door Lock Assembly LH (Key Cylinder Switch)
Check ..................................................................... 51
Power Window Serial Link Check Front LH and RH ... 53
Rear Power Window Control Unit LH or RH Power
Supply and Ground Circuit Check .......................... 55

GW-8
SQUEAK AND RATTLE TROUBLE DIAGNOSES
Revision: October 20052005 QX56
TRUNK
Trunk noises are often caused by a loose jack or loose items put into the trunk by the owner.
In addition look for:
1. Trunk lid bumpers out of adjustment
2. Trunk lid striker out of adjustment
3. The trunk lid torsion bars knocking together
4. A loose license plate or bracket
Most of these incidents can be repaired by adjusting, securing or insulating the item(s) or component(s) caus-
ing the noise.
SUNROOF/HEADLINER
Noises in the sunroof/headliner area can often be traced to one of the following:
1. Sunroof lid, rail, linkage or seals making a rattle or light knocking noise
2. Sun visor shaft shaking in the holder
3. Front or rear windshield touching headliner and squeaking
Again, pressing on the components to stop the noise while duplicating the conditions can isolate most of these
incidents. Repairs usually consist of insulating with felt cloth tape.
OVERHEAD CONSOLE (FRONT AND REAR)
Overhead console noises are often caused by the console panel clips not being engaged correctly. Most of
these incidents are repaired by pushing up on the console at the clip locations until the clips engage.
In addition look for:
1. Loose harness or harness connectors.
2. Front console map/reading lamp lense loose.
3. Loose screws at console attachment points.
SEATS
When isolating seat noise it's important to note the position the seat is in and the load placed on the seat when
the noise is present. These conditions should be duplicated when verifying and isolating the cause of the
noise.
Cause of seat noise include:
1. Headrest rods and holder
2. A squeak between the seat pad cushion and frame
3. The rear seatback lock and bracket
These noises can be isolated by moving or pressing on the suspected components while duplicating the con-
ditions under which the noise occurs. Most of these incidents can be repaired by repositioning the component
or applying urethane tape to the contact area.
UNDERHOOD
Some interior noise may be caused by components under the hood or on the engine wall. The noise is then
transmitted into the passenger compartment.
Causes of transmitted underhood noise include:
1. Any component mounted to the engine wall
2. Components that pass through the engine wall
3. Engine wall mounts and connectors
4. Loose radiator mounting pins
5. Hood bumpers out of adjustment
6. Hood striker out of adjustment
These noises can be difficult to isolate since they cannot be reached from the interior of the vehicle. The best
method is to secure, move or insulate one component at a time and test drive the vehicle. Also, engine RPM
or load can be changed to isolate the noise. Repairs can usually be made by moving, adjusting, securing, or
insulating the component causing the noise.

GW-34
POWER WINDOW SYSTEM
Revision: October 20052005 QX56
4. Touch “BCM”.
If “BCM” is not indicated, refer to GI-39, "
CONSULT-II Data Link
Connector (DLC) Circuit" .
5. Touch “RETAINED PWR”.
6. Select diagnosis mode.
“ACTIVE TEST” and “WORK SUPPORT” are available.
ACTIVE TEST
WORK SUPPORT
DATA MONITOR
BCIA0030E
LIIA0163E
BCIA0031E
Test Item Description
RETAINED PWRThis test is able to supply RAP signal (power) from BCM (body control module) to power window
system and power sunroof system (if equipped). Those systems can be operated when turning on
“RETAINED PWR” on CONSULT-II screen even if the ignition switch is turned OFF.
NOTE:
During this test, CONSULT-II can be operated with ignition switch in OFF position. “RETAINED
PWR” should be turned “ON” or “OFF” on CONSULT-II screen when ignition switch is ON. Then
turn ignition switch OFF to check retained power operation. CONSULT-II might be stuck if
“RETAINED PWR” is turned “ON” or “OFF” on CONSULT-II screen when ignition switch is OFF.
Work item Description
RETAINED PWRRAP signal’s power supply period can be changed by mode setting. Selects RAP signal’s power
supply period between three steps

MODE1 (45 sec.) / MODE2 (OFF) / MODE 3 (2 min.).
Work item Description
IGN ON SW Indicates (ON / OFF) condition of ignition switch
