TROUBLE DIAGNOSIS FOR SYMPTOMS
AT-229
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: August 20072004 QX56
4. CHECK CONTROL CABLE
Check the control cable.

Refer to AT- 2 3 4 , "Checking of A/T Position" .
OK or NG
OK >> GO TO 5.
NG >> Adjust control cable. Refer to AT-234, "
Adjustment of A/
T Position" .
5. CHECK A/T FLUID CONDITION
1. Remove oil pan. Refer to AT-241, "
Control Valve With TCM and A/T Fluid Temperature Sensor 2" .
2. Check A/T fluid condition. Refer to AT- 5 8 , "
Fluid Condition
Check" .
OK or NG
OK >> GO TO 6.
NG >> GO TO 9.
6. DETECT MALFUNCTIONING ITEM

Check the malfunction items. If any items are damaged, repair or replace damaged parts. Refer to AT-68,
"Symptom Chart" (Symptom No.17).
OK or NG
OK >> GO TO 7.
NG >> Repair or replace damaged parts.
7. CHECK SYMPTOM
Check again. Refer to AT- 6 6 , "
Cruise Test - Part 3" .
OK or NG
OK >>INSPECTION END
NG >> GO TO 8.
8. PERFORM TCM INSPECTION
1. Perform TCM input/output signals inspection. Refer to AT-90, "
TCM Input/Output Signal Reference Val-
ues" .
2. If NG, recheck A/T assembly harness connector terminals for damage or loose connection with harness
connector.
OK or NG
OK >>INSPECTION END
NG >> Repair or replace damaged parts.
LCIA0324E
SCIA5199E

AT-230
TROUBLE DIAGNOSIS FOR SYMPTOMS
Revision: August 20072004 QX56
9. DETECT MALFUNCTIONING ITEM

Check the malfunction items. If any items are damaged, repair or replace damaged parts. Refer to AT-68,
"Symptom Chart" (Symptom No.17).
OK or NG
OK >> GO TO 7.
NG >> Repair or replace damaged parts.
Vehicle Does Not Decelerate By Engine BrakeUCS002J 2
SYMPTOM:
No engine brake is applied when the gear is shifted from the 22 to 11 .
DIAGNOSTIC PROCEDURE
1. CHECK SELF-DIAGNOSIS RESULTS
Perform self-diagnosis.
Do the self-diagnosis results indicate PNP switch, ATF pressure switch 5?
YES >> Check the malfunctioning system. Refer to AT-109, "DTC P0705 PARK/NEUTRAL POSITION
SWITCH" , AT-181, "DTC P1845 ATF PRESSURE SWITCH 5" .
NO >> GO TO 2.
2. CHECK 1ST POSITION SWITCH CIRCUIT
With CONSULT-II
1. Turn ignition switch “ON”.
2. Select "ECU INPUT SIGNALS" in "DATA MONITOR" mode for
"A/T" with CONSULT-II.
3. Read out "OVERDRIVE SW" switch moving selector lever to
each position.
Without CONSULT-II
1. Turn ignition switch “ON”. (Do not start engine)
2. Check voltage between A/T device harness connector terminal
and ground.
OK or NG
OK >> GO TO 3.
NG >> Repair or replace damaged parts.
Monitor item Condition Display value
1 POSITION SWWhen setting the selector
lever to "1" position.ON
When setting selector
lever to other positions.OFF
LCIA0339E
Item Connector No.Te r m i n a l N o .
(Wire color)ConditionData
(Approx.)
1st position
switchM2037 (Y/G) -
GroundWhen setting
the selector
lever to "1"
position.0V
When setting
selector lever
to other posi-
tions.Battery volt-
age
LCIA0341E

TROUBLE DIAGNOSIS FOR SYMPTOMS
AT-231
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: August 20072004 QX56
3. CHECK A/T FLUID LEVEL
Check the A/T fluid level again. Refer to AT-13, "
Checking A/T Fluid"
.
OK or NG
OK >> GO TO 4.
NG >> Refill ATF.
4. CHECK CONTROL CABLE
Check the control cable.

Refer to AT- 2 3 4 , "Checking of A/T Position" .
OK or NG
OK >> GO TO 5.
NG >> Adjust control cable. Refer to AT-234, "
Adjustment of A/
T Position" .
5. CHECK A/T FLUID CONDITION
1. Remove oil pan. Refer to AT-241, "
Control Valve With TCM and A/T Fluid Temperature Sensor 2" .
2. Check A/T fluid condition. Refer to AT- 5 8 , "
Fluid Condition
Check" .
OK or NG
OK >> GO TO 6.
NG >> GO TO 9.
6. DETECT MALFUNCTIONING ITEM

Check the malfunction items. If any items are damaged, repair or replace damaged parts. Refer to AT-68,
"Symptom Chart" (Symptom No.53).
OK or NG
OK >> GO TO 7.
NG >> Repair or replace damaged parts.
7. CHECK SYMPTOM
Check again. Refer to AT- 6 6 , "
Cruise Test - Part 3" .
OK or NG
OK >>INSPECTION END
NG >> GO TO 8.
SAT6 3 8A
LCIA0324E
SCIA5199E

AT-232
TROUBLE DIAGNOSIS FOR SYMPTOMS
Revision: August 20072004 QX56
8. PERFORM TCM INSPECTION
1. Perform TCM input/output signals inspection. Refer to AT- 9 0 , "
TCM Input/Output Signal Reference Val-
ues" .
2. If NG, recheck A/T assembly harness connector terminals for damage or loose connection with harness
connector.
OK or NG
OK >>INSPECTION END
NG >> Repair or replace damaged parts.
9. DETECT MALFUNCTIONING ITEM

Check the malfunction items. If any items are damaged, repair or replace damaged parts. Refer to AT-68,
"Symptom Chart" (Symptom No.53).
OK or NG
OK >> GO TO 7.
NG >> Repair or replace damaged parts.

AIR BREATHER HOSE
AT-253
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: August 20072004 QX56
AIR BREATHER HOSEPFP:31098
Removal and InstallationUCS002JD
4X2
Refer to the figure below for air breather hose removal and installation procedure.
CAUTION:

When installing an air breather hose, be careful not to be crushed or blocked by folding or bend-
ing the hose.

When inserting a hose to the transmission tube, be sure to insert it fully until its end reaches the
tube bend portion.
LCIA0331E

AT-254
AIR BREATHER HOSE
Revision: August 20072004 QX56
4X4
Refer to the figure below for air breather hose removal and installation procedure.
CAUTION:

When installing an air breather hose, be careful not to be crushed or blocked by folding or bend-
ing the hose.

When inserting a hose to the transmission tube, be sure to insert it fully until its end reaches the
tube bend portion.
LCIA0332E

AT-256
TRANSMISSION ASSEMBLY
Revision: August 20072004 QX56
8. Remove crankshaft position sensor (POS) from A/T assembly.
9. Remove fluid cooler tube.
10. Remove dust cover from converter housing part.
11. Turn crankshaft, and remove the four tightening bolts for drive
plate and torque converter.
CAUTION:
When turning crankshaft, turn it clockwise as viewed from
the front of the engine.
12. Support A/T assembly with a transmission jack.
CAUTION:
When setting the transmission jack, be careful not to allow
it to collide against the drain plug.
13. Remove cross member with power tool.
14. Remove air breather hose. Refer to AT-253, "
Removal and
Installation" .
15. Disconnect A/T assembly connector.
16. Remove A/T fluid indicator pipe from A/T assembly.
17. Plug up openings such as the fluid charging pipe hole, etc.
18. Remove the A/T assembly to engine bolts with power tool.
19. Remove A/T assembly from vehicle using Tool and a transmis-
sion jack.

Secure torque converter to prevent it from dropping.

Secure A/T assembly to a transmission jack.
INSPECTION
Installation and Inspection of Torque Converter

After inserting a torque converter to a transmission, be sure to
check dimension A to ensure it is within the reference value
limit.
LCIA0334E
Tool number : — (J-47002)
LCIA0335E
SCIA0499E
Dimension A : 24.0 mm (0.94 in) or more
SAT0 1 7B

TRANSMISSION ASSEMBLY
AT-257
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: August 20072004 QX56
INSTALLATION
Installation of the remaining components is in the reverse order of
the removal, while paying attention to the following work.

If removed install drive plate.
–Align dowel pin of crankshaft rear end with pin holes of each
parts to install.
–Install drive plate, reinforcement plate and pilot converter as
shown.
–Face chamfered or rounded edge side to crankshaft.
CAUTION:

When replacing an engine or transmission you must make
sure the dowels are installed correctly during re-assembly.

Improper alignment caused by missing dowels may cause
vibration, oil leaks or breakage of drivetrain components.

When installing transmission to the engine, attach the bolts in
accordance with the following standard.
*: No.2 bolt also secures air breather vent.
–Align the positions of tightening bolts for drive plate with those of
the torque converter, and temporarily tighten the bolts. Then,
tighten the bolts with the specified torque.
CAUTION:

When turning crankshaft, turn it clockwise as viewed from the front of the engine.

After converter is installed to drive plate, rotate crankshaft several turns and check to be sure that
transmission rotates freely without binding.

After completing installation, check fluid leakage, fluid level, and the positions of A/T. Refer to AT-13,
"Checking A/T Fluid" , AT-234, "Checking of A/T Position" , AT-234, "Adjustment of A/T Position" .
KBIA2494E
KBIA2537E
Bolt No. 1 2* 3
Number of bolts 4 1 4
Bolt length
“”mm (in)70 (2.76) 70 (2.76) 70 (2.76)
Tightening torque
N·m (kg-m, ft-lb)11 3
(12, 83)11 3
(12, 83)
LCIA0371E
LCIA0335E

TRANSMISSION ASSEMBLY
AT-259
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: August 20072004 QX56
8. Remove crankshaft position sensor (POS) from A/T assembly.
9. Disconnect A/T fluid cooler tube from A/T assembly.
10. Remove dust cover from converter housing part.
11. Turn crankshaft, and remove the four tightening bolts for drive
plate and torque converter.
CAUTION:
When turning crankshaft, turn it clockwise as viewed from
the front of the engine.
12. Support A/T assembly with a transmission jack.
CAUTION:
When setting the transmission jack, be careful not to allow
it to collide against the drain plug.
13. Remove cross member with power tool.
14. Tilt the transmission slightly to keep the clearance between body
and transmission, and then disconnect air breather hose from charging pipe. Refer to AT- 2 5 3 , "
Removal
and Installation" .
15. Disconnect A/T assembly connector and transfer unit connector.
16. Remove A/T fluid indicator pipe.
17. Plug up openings such as the fluid charging pipe hole, etc.
18. Remove A/T assembly to engine bolts with power tool.
19. Remove A/T assembly from vehicle using Tool and a transmis-
sion jack.

Secure torque converter to prevent it from dropping.

Secure A/T assembly to a transmission jack.
NOTE:
The actual special service Tool may differ from Tool shown.
20. Remove transfer from A/T assembly. Refer to TF-109,
"REMOVAL AND INSTALLATION" .
INSPECTION
Installation and Inspection of Torque Converter

After inserting a torque converter to a transmission, be sure to
check dimension A to ensure it is within the reference value
limit.
LCIA0334E
Tool number : — (J-47002)
LCIA0335E
SCIA0499E
Dimension A : 24.0 mm (0.94 in) or more
SAT0 1 7B

AT-260
TRANSMISSION ASSEMBLY
Revision: August 20072004 QX56
INSTALLATION
Installation of the remaining components is in the reverse order of
the removal, while paying attention to the following work.

If removed, install drive plate.
–Align dowel pin of crankshaft rear end with pin holes of each
parts to install.
–Install drive plate, reinforcement plate and pilot converter as
shown.
–Face chamfered or rounded edge side to crankshaft.
CAUTION:

When replacing an engine or transmission you must make
sure the dowels are installed correctly during re-assembly.

Improper alignment caused by missing dowels may cause
vibration, oil leaks or breakage of drivetrain components.

When installing transmission to the engine, attach the bolts in
accordance with the following standard.
*: No.2 bolt also secures air breather vent.
–Align the positions of tightening bolts for drive plate with those of
the torque converter, and temporarily tighten the bolts. Then,
tighten the bolts with the specified torque.
CAUTION:

When turning crankshaft, turn it clockwise as viewed from the front of the engine.

After converter is installed to drive plate, rotate crankshaft several turns and check to be sure that
transmission rotates freely without binding.

After completing installation, check fluid leakage, fluid level, and the positions of A/T. Refer to AT-13,
"Checking A/T Fluid" , AT-234, "Checking of A/T Position" , AT-234, "Adjustment of A/T Position" .
KBIA2494E
KBIA2537E
Bolt No. 1 2* 3
Number of bolts 4 1 4
Bolt length
“”mm (in)70 (2.76) 70 (2.76) 70 (2.76)
Tightening torque
N·m (kg-m, ft-lb)11 3
(12, 83)11 3
(12, 83)
LCIA0371E
LCIA0335E
