AV-22
AUDIO
Revision: August 20072004 QX56
Terminals and Reference Value for BOSE Speaker Amp.EKS007KF
71 (B) 69 (W)Voice guide
signal (with
NAVI)Output ONPress the
"GUIDE/VOICE"
button.Only route guide and
operation guide are
not heard.
72 (W/B) GroundCD eject
signalInput ONOperate EJECT
button0V→5VCD will not eject from
audio unit.
73 (Y/B) GroundCD load sig-
nalInput ONOperate LOAD
button0V→5VCD will not load into
audio unit. Te r m i n a l
(Wire color)
ItemSignal
input/
outputCondition
Reference value
(Approx.)Example of symptom
+–Ignition
switchOperation
SKIA0171J
Te r m i n a l
(wire color)
ItemSignal
input/
outputCondition
Reference value
(Approx.)Example of
symptom
+–Ignition
switchOperation
1 (Y) Ground Battery Input – – Battery voltageSystem does not
work properly.
9 (SB) 10 (B/Y)Rear door
speaker LH
and rear door
tweeter LHOutput ONReceive audio
signalNo sound from
rear door speaker
LH or rear door
tweeter LH.
11 (O/L) 12 (R/L)Rear door
speaker RH
and rear door
tweeter RHOutput ONReceive audio
signalNo sound from
rear door speaker
RH or rear door
tweeter RH.
13 (L/W) 14 (L/R)Front door
speaker LH
and front
tweeter LHOutput ONReceive audio
signalNo sound from
front door speaker
LH or front tweeter
LH.
15 (W/B) 16 (L/B)Front door
speaker RH
and front
tweeter RHOutput ONReceive audio
signalNo sound from
front door speaker
RH or front tweeter
RH.
17 (B) Ground Ground – ON – – –
SKIA0177E
SKIA0177E
SKIA0177E
SKIA0177E

AUDIO
AV-23
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: August 20072004 QX56
18 (V) 2 (R)Center
speakerOutput ONReceive audio
signalNo sound from
center speaker.
19 (W) 3 (B) Subwoofer Output ONReceive audio
signalNo sound from
subwoofer.
22
(W/G)GroundSubwoofer ON
signalInput ON – More than 6.5VSubwoofer does
not work properly.
24 (L) 23 (B/W)Audio sound
signal rear RHInput ONReceive audio
signalNo sound from
rear door speaker
RH or rear door
tweeter RH.
26 (BR) 25 (B/R)Audio sound
signal rear LHInput ONReceive audio
signalNo sound from
rear door speaker
LH or rear door
tweeter LH.
28 (Y) 27 (BR)Audio sound
signal front RHInput ONReceive audio
signalNo sound from
front door speaker
RH or front tweeter
RH.
30 (W) 29 (B)Audio sound
signal front LHInput ONReceive audio
signalNo sound from
front door speaker
LH or front tweeter
LH.
31 (G/W) GroundAmp. ON sig-
nalInput ON – More than 6.5VSystem does not
work properly. Terminal
(wire color)
ItemSignal
input/
outputCondition
Reference value
(Approx.)Example of
symptom
+–Ignition
switchOperation
SKIA0177E
SKIA0177E
SKIA0177E
SKIA0177E
SKIA0177E
SKIA0177E

AV-24
AUDIO
Revision: August 20072004 QX56
Terminals and Reference Value for Rear Audio Remote Control UnitEKS007KG
Te r m i n a l
(Wire color)
ItemSignal
input/
outputCondition
Reference value
(Approx.)Example of symptom
+–Ignition
switchOperation
2 (G) 1 (B)Audio sound
signal LHInput ONReceive audio
signalNo sound from LH
headphone channel.
4 (W) 3 (R)Audio sound
signal RHInput ONReceive audio
signalNo sound from RH
headphone channel.
5 – Shield – – – 0VInterference and dis-
tortion heard from
headphones or rear
audio remote control
unit switches not
operating properly.
6 (R/L) Ground Illumination Input ONLighting switch
ON12V
Rear audio remote
control unit does not
illuminate. Lighting switch
OFF0V
7 (LG) –Remote
control
ground–– – 0VRear audio remote
control unit switches
do not function.
8 (O) GroundRemote
control
enable sig-
nalInput ON Audio unit ON 5VRear audio remote
control unit does not
operate.
9 (V) GroundRemote
control AInput ON Audio unit ON 5VRear audio remote
control unit does not
operate properly.
10 (P) GroundRemote
control BInput ON Audio unit ON 5VRear audio remote
control unit does not
operate properly.
11 ( B R /
Y)GroundRemote
control CInput ON Audio unit ON 5VRear audio remote
control unit does not
operate properly.
12 (L) GroundRemote
control DInput ON Audio unit ON 5VRear audio remote
control unit does not
operate properly.
13 (V) GroundRemote
control
switch
power sup-
plyInput ON Audio unit ON 12VRear audio remote
control does not
operate.
15 (B) – Ground – ON – 0V –
SKIA0177E
SKIA0177E

AUDIO
AV-25
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: August 20072004 QX56
Terminals and Reference Value for AV SwitchEKS007KH
Te r m i n a l N o .
(Wire color)
ItemSignal
input/
outputCondition
Voltag e
(Approx.)Example of
symptom
+–Ignition
switchOperation
1 (Y) GroundBattery
powerInput OFF – Battery voltageSystem does not
work properly.
2 (V) Ground ACC signal Input ACC – Battery voltageSystem does not
work properly.
3 (R/L) GroundIllumination
signalInput OFFLighting switch is
ON (position 1).Battery voltageAV switch illumi-
nation does not
come on when
lighting switch is
ON (position 1). Turn lighting switch
OFF.Approx. 3.0V or less
4 (BR) GroundIllumination
control signalInput ONIllumination control
switch is operated
by lighting switch in
1st position.Changes between 0 and 12V.AV switch illumi-
nation cannot be
controlled.
5 (B) Ground Ground – ON – 0V –
6 (V) GroundCommunica-
tion signal (+)Input/
outputON –System does not
work properly.
7–Shield
ground–– – –
8 (LG) GroundCommunica-
tion signal (-)Input/
outputON –System does not
work properly.
12 (R) GroundRemote con-
trol AInput ONPress MODE
switch 0V
Steering wheel
audio controls
do not function. Press SEEK UP
switch0.75V
Press VOL UP
switch2V
Except for above 5V
13 (G) GroundRemote con-
trol BInput ONPress POWER
switch 0V
Steering wheel
audio controls
do not function. Press SEEK
DOWN switch0.75V
Press VOL DOWN
switch2V
Except for above 5V
14 (L) –Remote con-
trol ground–– – –Steering wheel
audio controls
do not function.
16 (W/B) GroundCD EJECT
signalOutput ONPressed 0V
CD eject does
not function.
Released 5V
SKIA0175E
SKIA0176E

AV-26
AUDIO
Revision: August 20072004 QX56
17 (Y/B) GroundCD LOAD
signalOutput ONPressed 0V
CD load does
not function.
Released 5V
24 (W/R) GroundVehicle
speed signalInput ON Vehicle is drivenSpeed sensitive
volume function
does not work
properly. Te r m i n a l N o .
(Wire color)
ItemSignal
input/
outputCondition
Voltage
(Approx.)Example of
symptom
+–Ignition
switchOperation
SKIA0175E

AUDIO
AV-27
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: August 20072004 QX56
AV Switch Self-Diagnosis FunctionEKS007KI
It can check ON/OFF operation of each switch in the AV switch and diagnose the input signals from the steer-
ing switch.
STARTING THE SELF-DIAGNOSIS MODE
1. Turn ignition switch from OFF to ACC.
2. Within 10 seconds press and hold the switches “PAUSE/MUTE”
and “PREV” simultaneously for 3 seconds.
Then the self-diagnosis operates. A single beep indicates self-
diagnosis mode is active.
3. Press each switch and listen for beep.
NOTE:
CD player LOAD and EJECT buttons are not included in this test
and will not beep when pressed.
EXITING THE SELF-DIAGNOSIS MODE

Turn ignition switch OFF. Then the self-diagnosis ends.
DIAGNOSIS FUNCTION

It can check for continuity of the switches by sounding the beep when each AV switch and steering switch
is pressed.

It can check for continuity of harness between AV switch and steering switch.
WKIA1489E

AV-30
AUDIO
Revision: August 20072004 QX56
FOR CD ONLY
Noise InspectionEKS007KK
The vehicle itself can be a source of noise if noise prevention parts or electrical equipment is malfunctioning.
Check if noise is caused and/or changed by engine speed, ignition switch turned to each position, and opera-
tion of each piece of electrical equipment, and determine the cause.
NOTE:
The source of the noise can be found easily by listening to the noise while removing the fuses of electrical
components, one by one.
TYPE OF NOISE AND POSSIBLE CAUSE
Power Supply Circuit InspectionEKS007KL
1. CHECK FUSES

Check that the following fuses are not blown.
OK or NG
OK >> GO TO 2.
NG >> If fuse is blown, be sure to eliminate cause of problem before installing new fuse. Refer to PG-4,
"POWER SUPPLY ROUTING CIRCUIT" .
Symptom Possible cause
CD cannot be inserted.

CD

Audio unit CD cannot be ejected.
The CD cannot be played.
The sound skips, stops suddenly, or is distorted.
Occurrence condition Possible cause
Occurs only when engine is ON.A continuous growling noise occurs. The speed of
the noise varies with changes in the engine speed.

Ignition components
A whistling noise occurs while the engine speed is
high. A booming noise occurs while the engine is
running and the lighting switch is ON.

Generator
The occurrence of the noise is linked with the operation of the fuel pump.

Fuel pump condenser
Noise only occurs when various
electrical components are oper-
ating.A cracking or snapping sound occurs with the
operation of various switches.

Relay malfunction, audio unit malfunction
The noise occurs when various motors are operat-
ing.

Motor case ground

Motor
The noise occurs constantly, not just under certain conditions.

Rear defogger coil malfunction

Open circuit in printed heater

Poor ground of antenna amplifier or
antenna feeder line
A cracking or snapping sound occurs while the vehicle is being driven, especially
when it is vibrating excessively.

Ground wire of body parts

Ground due to improper part installation

Wiring connections or a short circuit
Unit Terminals Signal name Fuse No.
Audio unit6 Battery power 31
10 Ignition switch ACC or ON 4
AV s w i t c h1 Battery power 31
2 Ignition switch ACC or ON 4
BOSE speaker amp. 1 Battery power 31
Subwoofer 6 Battery power 17

AV-32
AUDIO
Revision: August 20072004 QX56
Steering Switch CheckEKS007KM
1. AV SWITCH SELF-DIAGNOSIS FUNCTION CHECK
1. Start AV switch self-diagnosis function. Refer to AV- 2 7 , "
AV Switch Self-Diagnosis Function" .
2. Operate steering switch.
Does steering switch operate normally?
YES >> Inspection End.
NO >> GO TO 2.
2. CHECK HARNESS
1. Turn ignition switch OFF.
2. Disconnect AV switch connector and spiral cable connector.
3. Check continuity between spiral cable harness connector terminal and AV switch harness connector ter-
minal.
4. Check continuity between AV switch and ground.
OK or NG
OK >> GO TO 3.
NG >> Repair harness.
3. SPIRAL CABLE CHECK
1. Disconnect spiral cable connector.
2. Check continuity between spiral cable terminals.
OK or NG
OK >> GO TO 4.
NG >> Replace spiral cable. Refer to SRS-47, "
Removal and Installation" .
Te r m i n a l s
Continuity Spiral cable AV switch
Connector Terminal Connector Terminal (Wire color)
M3032 (G)
M9813 (G)
Ye s 31 (L) 14 (L)
24 (R) 12 (R)
Te r m i n a l s
Continuity AV s w i t c h
—
Connector Terminal (Wire color)
M9812 (R)
Ground No 13 (G)
14 (L)
WKIA1600E
Terminals
Continuity Spiral cable
Terminal Terminal
32 16
Ye s 31 17
24 20
WKIA3489E

AUDIO
AV-35
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: August 20072004 QX56
2. FRONT SPEAKER SIGNAL CHECK
1. Connect BOSE speaker amp. connector M113 and suspect speaker connector.
2. Turn ignition switch to ACC.
3. Push “POWER” switch.
4. Check the signal BOSE speaker amp. harness connector M113
terminal with CONSULT-II or oscilloscope.
OK or NG
OK >> Replace suspect speaker. Refer to AV- 4 5 , "Removal
and Installation of Front Door Speaker" or AV- 4 6 ,
"Removal and Installation of Front Tweeter" .
NG >> GO TO 3.
Te r m i n a l s
Condi-
tionReference
signal (+) (-)
Con-
nectorTe r m i n a l
(Wire
color)Con-
nectorTe r m i -
nal
(Wire
color)
M11313 (L/W)
M11314 (L/R)
Receive
audio
signal 15 (W/B) 16 (L/B)
SKIA4283E
SKIA0177E

AUDIO
AV-37
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: August 20072004 QX56
4. FRONT SPEAKER SIGNAL CHECK
1. Connect audio unit connector and BOSE speaker amp. connector.
2. Turn ignition switch ACC.
3. Push “POWER” switch.
4. Check the signal audio unit harness connector terminal with
CONSULT-II or oscilloscope.
OK or NG
OK >> Replace BOSE speaker amp. Refer to AV- 4 6 , "Removal
and Installation of BOSE Speaker Amp." .
NG >> Replace audio unit. Refer to AV- 4 5 , "
Removal and
Installation for Audio Unit" .
Te r m i n a l s
Condi-
tionReference
signal (+) (-)
Con-
nectorTe r m i -
nal
(Wire
color)Con-
nectorTe r m i -
nal
(Wire
color)
M432 (W)
M431 (B)
Receive
audio
signal 4 (Y) 3 (BR)
SKIA4278E
SKIA0177E
