ignition INFINITI QX56 2004 Factory Service Manual

ATC-132
TROUBLE DIAGNOSIS
Revision: August 20072004 QX56
DIAGNOSTIC PROCEDURE FOR OPTICAL SENSOR
SYMPTOM: Optical sensor circuit is open or shorted. [50 (Driver) or
52 (Passenger) is indicated as a result of conducting self-diagnosis.]
1. CHECK CIRCUIT CONTINUITY BETWEEN OPTICAL SENSOR AND FRONT AIR CONTROL
1. Turn ignition switch OFF.
2. Disconnect front air control connector M50 and optical sensor
connector M402.
3. Check continuity between optical sensor harness connector
M402 terminal 1 (W/V) and 2 (G/O) and front air control harness
connector M50 terminal 31 (W/V) and 40 (G/O).
4. Check continuity between optical sensor harness connector
M402 terminal 1 (W/V) and 2 (G/O) and ground.
OK or NG
OK >> GO TO 2.
NG >> Repair harness or connector.
2. CHECK CIRCUIT CONTINUITY BETWEEN OPTICAL SENSOR AND BCM
1. Disconnect BCM connector M18.
2. Check continuity between optical sensor harness connector
M402 terminal 3 (P) and BCM harness connector M18 terminal
18 (P).
3. Check continuity between optical sensor harness connector
M402 terminal 3 (P) and ground.
OK or NG
OK >> Replace optical sensor. Refer to ATC-138, "OPTICAL SENSOR" .
NG >> Repair harness or connector.
WJIA0826E
1 - 31 : Continuity should exist.
2 - 40 : Continuity should exist.
1, 2 - Ground. : Continuity should not exist.
WJIA0827E
3 - 18 : Continuity should exist.
3 - Ground : Continuity should not exist.
WJIA0828E

TROUBLE DIAGNOSIS
ATC-133
C
D
E
F
G
H
I
K
L
MA
B
AT C
Revision: August 20072004 QX56
Intake Sensor CircuitEJS002CV
COMPONENT DESCRIPTION
Intake Sensor
The intake sensor is located on the front heater & cooling unit. It con-
verts temperature of air after it passes through the evaporator into a
resistance value which is then input to the front air control.
DIAGNOSTIC PROCEDURE FOR INTAKE SENSOR
SYMPTOM: Intake sensor circuit is open or shorted. (56 or 57 is indi-
cated as a result of conducting self-diagnosis).
1. CHECK VOLTAGE BETWEEN INTAKE SENSOR AND GROUND
1. Disconnect intake sensor connector M146.
2. Turn ignition switch ON.
3. Check voltage between intake sensor harness connector M146
terminal 2 (L/B) and ground.
OK or NG
OK >> GO TO 2.
NG >> GO TO 4.
2. CHECK CIRCUIT CONTINUITY BETWEEN INTAKE SENSOR AND FRONT AIR CONTROL
1. Turn ignition switch OFF.
2. Disconnect front air control connector M49.
3. Check continuity between intake sensor harness connector
M146 terminal 1 (V/R) and front air control harness connector
M49 terminal 21 (V/R).
OK or NG
OK >> GO TO 3.
NG >> Repair harness or connector.
WJIA0571E
WJIA0464E
2 - Ground : Approx. 5V
WJIA0829E
1 - 21 : Continuity should exist.
WJIA0830E

ATC-134
TROUBLE DIAGNOSIS
Revision: August 20072004 QX56
3. CHECK INTAKE SENSOR
Refer to ATC-134, "
Intake Sensor" .
OK or NG
OK >> 1. Replace front air control. Refer to ATC-135, "FRONT AIR CONTROL" .
2. Go to self-diagnosis ATC-53, "
A/C System Self-diagnosis Function" and perform self-diagno-
sis.
NG >> 1. Replace intake sensor. Refer to ATC-139, "
INTAKE SENSOR" .
2. Go to self-diagnosis ATC-53, "
A/C System Self-diagnosis Function" and perform self-diagno-
sis.
4. CHECK CIRCUIT CONTINUITY BETWEEN INTAKE SENSOR AND FRONT AIR CONTROL
1. Turn ignition switch OFF.
2. Disconnect front air control connector M49.
3. Check continuity between intake sensor harness connector
M146 terminal 2 (L/B) and front air control harness connector
M49 terminal 9 (L/B).
4. Check continuity between intake sensor harness connector
M146 terminal 2 (L/B) and ground.
OK or NG
OK >> 1. Replace front air control. Refer to ATC-135, "FRONT AIR CONTROL" .
2. Go to self-diagnosis ATC-53, "
A/C System Self-diagnosis Function" and perform self-diagno-
sis.
NG >> Repair harness or connector.
COMPONENT INSPECTION
Intake Sensor
After disconnecting intake sensor connector, measure resistance
between terminals 1 and 2 at sensor harness side, using the table
below.
If NG, replace intake sensor.2 - 9 : Continuity should exist.
2 - Ground : Continuity should not exist.
WJIA0831E
Temperature °C (°F) Resistance kΩ
−15 (5) 209.0
−10 (14) 160.0
−5 (23) 123.0
0 (32) 95.8
5 (41) 74.9
10 (50) 58.9
15 (59) 46.7
20 (68) 37.3
25 (77) 30.0
30 (86) 24.2
35 (95) 19.7
40 (104) 16.1
45 (113) 13.2
WJIA0832E

ATC-182
SERVICE DATA AND SPECIFICATIONS (SDS)
Revision: August 20072004 QX56
SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030
Service Data and Specifications (SDS)EJS002DZ
COMPRESSOR
LUBRICANT
REFRIGERANT
ENGINE IDLING SPEED
Refer to EC-32, "Idle Speed and Ignition Timing Check" .
BELT TENSION
Refer to MA-12, "DRIVE BELT TENSION" .
MakeZEXEL VALEO CLIMATE CONTROL
ModelDKS-17D
Ty p eSwash plate
Displacement
cm
3 (cu in) / revolution175.5 (10.7) / revolution
Cylinder bore × stroke
mm (in)30.5 (1.20) x 24.0 (0.94)
Direction of rotation Clockwise (viewed from drive end)
Drive beltPoly V
NameNISSAN A/C System Lubricant Type S (DH-PS)
Part number KLH00-PAGS0
Capacity
m (US fl oz, lmp fl oz)Total in system 290 (9.8, 10.2)
Compressor (service part) charging amountRefer to AT C - 2 2 , "
Lubricant Adjustment Procedure
for Compressor Replacement" .
Ty p eHFC-134a (R-134a)
Capacity
kg (lb)1.08 ± 0.05 (2.38 ± 0.11)
