COMBINATION METERS
DI-23
C
D
E
F
G
H
I
J
L
MA
B
DI
Revision: August 20072004 QX56
4. CHECK HARNESS FOR OPEN OR SHORT CIRCUIT
1. Turn the ignition switch OFF.
2. Disconnect combination meter connector M24.
3. Check continuity between combination meter harness connector
M24 terminal 15 (Y/L) and fuel level sensor unit and fuel pump
harness connector C5 terminal 2 (Y/L).
4. Check continuity between fuel level sensor unit and fuel pump
harness connector C5 terminal 2 (Y/L) and ground.
OK or NG
OK >> GO TO 5.
NG >> Repair harness or connector.
5. CHECK FUEL LEVEL SENSOR CIRCUIT
1. Check continuity between combination meter harness connector
M24 terminal 16 (B/P) and fuel level sensor unit and fuel pump
harness connector C5 terminal 5 (B/P).
2. Check continuity between fuel level sensor unit and fuel pump
harness connector C5 terminal 5 (B/P) and ground.
OK or NG
OK >> GO TO 6.
NG >> Repair harness or connector.
6. CHECK FUEL LEVEL SENSOR UNIT
Check the fuel level sensor unit. Refer to DI-25, "
FUEL LEVEL SENSOR UNIT CHECK" .
OK or NG
OK >> GO TO 7.
NG >> Replace the fuel level sensor unit. Refer to FL-5, "
Removal and Installation" .
7. CHECK INSTALLATION CONDITION
Check fuel level sensor unit installation, and determine whether the float arm interferes or binds with any of the
internal components in the fuel tank.
OK or NG
OK >> Replace the combination meter. Refer to IP-13, "Combination Meter" .
NG >> Install the fuel level sensor unit properly.Continuity should exist.
Continuity should not exist.
WKIA2070E
Continuity should exist.
Continuity should not exist.
WKIA2071E
Page 1127 of 3371
DI-24
COMBINATION METERS
Revision: August 20072004 QX56
Fuel Gauge Fluctuates, Indicates Wrong Value, or VariesEKS007E0
1. CHECK FUEL GAUGE FLUCTUATION
Test drive vehicle to see if gauge fluctuates only during driving or just before or just after stopping.
Does the indication value vary only during driving or just before or just after stopping?
YES >> The fluctuation may be caused by fuel level change in the fuel tank. Condition is normal.
NO >> Ask the customer about the situation when the symptom occurs in detail, Refer to DI-22, "
Fuel
Level Sensor Unit Inspection" .
Fuel Gauge Does Not Move to Full-positionEKS007E1
1. CHECK POINTER MOVEMENT TO FULL-POSITION
Does it take a long time for the pointer to move to full-position?
YES or NO
YES >> GO TO 2.
NO >> GO TO 3.
2. CHECK IGNITION SWITCH POSITION
Was the vehicle fueled with the ignition switch ON?
YES or NO
YES >> Be sure to fuel the vehicle with the ignition switch OFF. Otherwise, it will take a long time for the
pointer to move to full-position because of the characteristic of the fuel gauge.
NO >> GO TO 3.
3. OBSERVE VEHICLE POSITION
Is the vehicle parked on an incline?
YES or NO
YES >> Check the fuel level indication with vehicle on a level surface.
NO >> GO TO 4.
4. CHECK POINTER MOVEMENT TO EMPTY-POSITION
During driving, does the fuel gauge move gradually toward empty-position?
YES or NO
YES >> Check the fuel level sensor unit. Refer to DI-25, "FUEL LEVEL SENSOR UNIT CHECK" .
NO >> Check fuel level sensor unit installation, and determine whether the float arm interferes or binds
with any of the internal components in the fuel tank.
Page 1129 of 3371
DI-26
COMPASS AND THERMOMETER
Revision: August 20072004 QX56
COMPASS AND THERMOMETERPFP:24835
System DescriptionEKS007E4
This unit displays the following items:
Earth magnetism and heading direction of vehicle.
Outside air temperature.
Caution for frozen road surfaces.
OUTSIDE TEMPERATURE DISPLAY
Push the mode switch when the ignition switch is in the ON position. The outside temperature will be displayed
in “°F”.
Selecting the indication range
Push the mode switch to change from °F → °C → OFF → °F.
The indicated temperature on the thermometer is not readily affected by engine heat. It changes only
when one of the following conditions is present.
–The temperature detected by the ambient sensor is lower than the indicated temperature on the thermom-
eter.
–The vehicle speed is greater than 20 km/h (13 MPH).
(This is to prevent the indicated temperature from being affected by engine heat during low-speed driv-
ing.)
–The ignition switch has been turned to the OFF position for more than 2 hours. (The engine is cold.)
DIRECTION DISPLAY
Push the mode switch when the ignition switch is in the ON position. The direction will be displayed.
WKIA1817E
Page 1131 of 3371
DI-28
COMPASS AND THERMOMETER
Revision: August 20072004 QX56
Trouble DiagnosesEKS007E6
PRELIMINARY CHECK FOR THERMOMETER
1. COOL DOWN CHECK
1. Turn the ignition switch to the ON position.
2. Cool down the ambient sensor with water or ice.
Does the indicated temperature drop?
Yes >> GO TO 2.
No >> The system is malfunctioning. Refer to DI-28, "
INSPECTION/COMPASS AND THERMOMETER"
.
2. WARM UP CHECK
1. Leave the vehicle for 10 minutes.
2. With the ignition switch in the ON position, disconnect and reconnect the ambient sensor connector.
Does the indicated temperature rise?
Yes >> The system is OK.
No >> The system is malfunctioning. Refer to DI-28, "
INSPECTION/COMPASS AND THERMOMETER"
.
NOTE:
The indicated temperature on the thermometer is not readily affected by engine heat. It changes only
when one of the following conditions is present.
–The temperature detected by the ambient sensor is lower than the indicated temperature on the thermom-
eter.
–The vehicle speed is greater than 20 km/h (13 MPH).
(This is to prevent the indicated temperature from being affected by engine heat during low-speed driv-
ing.)
–The ignition switch has been turned to the OFF position for more than 2 hours. (The engine is cold.)
INSPECTION/COMPASS AND THERMOMETER
Symptom Possible causes Repair order
No display at all 1. 10A fuse
2. Ground circuit
3. Compass and thermometer1. Check 10A fuse [No. 12, located in fuse block (J/B)].
Turn the ignition switch ON and verify that battery positive volt-
age is at terminal 2 of compass and thermometer.
2. Check ground circuit for compass and thermometer.
3. Replace compass and thermometer.
Forward direction indi-
cation slips off the mark
or incorrect.1. In manual correction mode (Bar and
display vanish.)
2. Zone variation change is not done.1. Drive the vehicle and turn at an angle of 90°.
2. Perform the zone variation change.
Compass reading
remains unchanged.1. Vehicle speed signal is not entered.
2. Compass and thermometer1. Check harness for open or short between combination meter
terminal 29 and compass and thermometer terminal 8.
2. Replace compass and thermometer.
Displays wrong tem-
perature when ambient
temperature is between
−40°C (−40°F) and
55°C (130°F). (See
NOTE above.)1. Check operation
2. Ambient sensor circuit
3. Vehicle speed signal is not entered.
4. Ambient sensor
5. Compass and thermometer1. Perform preliminary check shown above.
2. Check harness for open or short between ambient sensor and
compass and thermometer.
3. Check harness for open or short between combination meter
terminal 29 and compass and thermometer terminal 8.
4. Replace ambient sensor.
5. Replace compass and thermometer.
Displays SC or OC. 1. Ambient sensor circuit.
2. Ambient sensor.
3. Compass and thermometer.1. Check harness for open or short between ambient sensor and
compass and thermometer.
2. Replace ambient sensor.
3. Replace compass and thermometer.
Page 1132 of 3371
COMPASS AND THERMOMETER
DI-29
C
D
E
F
G
H
I
J
L
MA
B
DI
Revision: August 20072004 QX56
Calibration Procedure for CompassEKS007E7
The difference between magnetic North and geographical North can sometimes be great enough to cause
false compass readings. In order for the compass to operate accurately in a particular zone, it must be cali-
brated using the following procedure.
Zone Variation Chart
1. Determine your location on the zone map.
2. Turn the ignition switch to the ON position.
3. Press and hold the mode switch for about 5 seconds. The current zone number will appear in the display.
4. Press the mode switch repeatedly until the desired number appears in the display.
Once the desired zone number is displayed, stop pressing the mode switch and the display will show a com-
pass direction after a few seconds.
NOTE:
Use zone number 5 for Hawaii.
CORRECTION FUNCTIONS OF COMPASS
The direction display is equipped with automatic correction function.
If the direction is not shown correctly, carry out initial correction.
WKIA4148E
WKIA1817E
Page 1141 of 3371
DI-38
WARNING LAMPS
Revision: August 20072004 QX56
Oil Pressure Warning Lamp Stays Off (Ignition Switch ON)EKS007EA
1. CHECK OIL PRESSURE SENSOR SIGNAL
1. Turn ignition switch ON.
2. Check voltage between combination meter harness connector
M24 terminal 20 (Y) and ground.
OK or NG
OK >> GO TO 2.
NG >> GO TO 3.
2. CHECK OIL PRESSURE SENSOR GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect combination meter connector M24 and oil pressure
sensor connector F4.
3. Check continuity between combination meter harness connector
M24 terminal 16 (B/P) and oil pressure sensor harness connec-
tor F4 terminal 3 (B/P).
OK or NG
OK >> Replace the combination meter. Refer to IP-13, "Combi-
nation Meter" .
NG >> Repair harness or connector.
3. CHECK OIL PRESSURE SENSOR REFERENCE VOLTAGE
1. Turn ignition switch OFF.
2. Disconnect oil pressure sensor connector F4.
3. Turn ignition switch ON.
4. Check voltage between combination meter harness connector
M24 terminal 22 (GR/L) and ground.
OK or NG
OK >> GO TO 4.
NG >> Replace the combination meter. Refer to IP-13, "
Combi-
nation Meter" .
Terminals
Condition Voltage (V) (+)
(–)
ConnectorTe r m i n a l
(Wire color)
M24 20 (Y) GroundWhen ignition switch is in ON
position. (Engine stopped)Ye s
Engine running. (Idle speed) Yes
WKIA1833E
Continuity should exist.
WKIA1837E
Voltage : Approx. 5V
WKIA1834E
Page 1142 of 3371
WARNING LAMPS
DI-39
C
D
E
F
G
H
I
J
L
MA
B
DI
Revision: August 20072004 QX56
4. CHECK OIL PRESSURE SENSOR POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect combination meter connector M24.
3. Check continuity between combination meter harness connector M24 terminal 22 (GR/L) and oil pressure
sensor harness connector F4 terminal 1 (GR/L).
4. Check continuity between combination meter harness connector
M24 terminal 22 (GR/L) and ground.
OK or NG
OK >> GO TO 5.
NG >> Repair harness or connector.
5. CHECK OIL PRESSURE SENSOR SIGNAL CIRCUIT
1. Check continuity between combination meter harness connector M24 terminal 20 (Y) and oil pressure
sensor harness connector F4 terminal 2 (Y).
2. Check continuity between combination meter harness connector
M24 terminal 20 (Y) and ground.
OK or NG
OK >> GO TO 6.
NG >> Repair harness or connector.
6. CHECK OIL PRESSURE SENSOR GROUND CIRCUIT
Check continuity between combination meter harness connector
M24 terminal 16 (B/P) and ground.
OK or NG
OK >> Replace oil pressure sensor.
NG >> Repair harness or connector.Continuity should exist.
Continuity should not exist.
WKIA1835E
Continuity should exist.
Continuity should not exist.
WKIA1836E
Continuity should not exist.
WKIA2685E
Page 1147 of 3371
DI-44
WARNING CHIME
Revision: August 20072004 QX56
System DescriptionEKS007EF
FUNCTION
Power is supplied at all times
through 50A fusible link (letter f , located in the fuse and fusible link box)
to BCM terminal 70, and
through 10A fuse [No. 19, located in the fuse block (J/B)]
to key switch and key lock solenoid terminal 3.
With ignition switch in ON or START position, power is supplied
through 10A fuse [No. 59, located in the fuse and relay box)
to BCM terminal 38.
Ground is supplied
to BCM terminal 67
through body grounds M57, M61, and M79.
NOTE:
When ignition key warning chime, light warning chime, and seat belt warning chime are required at the same
time, the priorities for each chime are the following.
1. Light warning chime
2. Ignition key warning chime
3. Seat belt warning chime
IGNITION KEY WARNING CHIME
With the key inserted in the ignition switch, the ignition switch in OFF position, and the driver's door open, the
warning chime will sound.
Power is supplied
through key switch and key lock solenoid terminal 4
to BCM terminal 37.
Ground is supplied
to BCM terminal 47
through front door switch LH terminal 2.
Front door switch LH is case grounded.
BCM detects key inserted into the ignition switch, and sends key warning signal to combination meter via CAN
communication lines. When the combination meter receives key warning signal, it sounds warning chime.
LIGHT WARNING CHIME
With the key removed from the ignition switch, the driver's door open, and the lighting switch (part of the com-
bination switch) in 1st or 2nd position, the warning chime will sound. [Except when headlamp battery saver
control operates (5 minutes after ignition switch is turned to OFF or ACC position) and headlamps do not illu-
minate.]
Signal is supplied
from combination switch (lighting switch) terminals 1, 2, 3, 4, 5, 6, 7, 8, 9 and 10
to BCM terminals 2, 3, 4, 5, 6, 32, 33, 34, 35 and 36.
NOTE:
BCM detected lighting switch in 1st or 2nd position. Refer to BCS-3, "
COMBINATION SWITCH READING
FUNCTION" .
Ground is supplied
to BCM terminal 47
through front door switch LH terminal 2.
Front door switch LH is case grounded.
BCM detects headlamps are illuminated, and sends light warning signal to combination meter CAN communi-
cation lines. When the combination meter receives light warning signal, it sounds warning chime.
SEAT BELT WARNING CHIME
When the ignition switch is turned ON with the seat belt unfastened (seat belt buckle switch LH unfastened),
warning chime will sound for approximately 6 seconds.
Page 1151 of 3371
DI-48
WARNING CHIME
Revision: August 20072004 QX56
Terminals and Reference Value for BCMEKS007EI
Terminal
No.Wire
colorItem Condition
Reference value (V)
(Approx.) Ignition
switchMeasurement method
2 SB Combination switch input 5 ON
Light switch and wiper switch
OFF
Wiper dial position 4
3 G/Y Combination switch input 4 ON
Light switch and wiper switch
OFF
Wiper dial position 4
4 Y Combination switch input 3 ON
Light switch and wiper switch
OFF
Wiper dial position 4
5 G/B Combination switch input 2
ON
Light switch and wiper switch
OFF
Wiper dial position 4 6 V Combination switch input 1
32 R/G Combination switch output 5 ON
Light switch and wiper switch
OFF
Wiper dial position 4
33 R/Y Combination switch output 4 ON
Light switch and wiper switch
OFF
Wiper dial position 4
34 L Combination switch output 3 ON
Light switch and wiper switch
OFF
Wiper dial position 4
SKIA5291E
SKIA5292E
SKIA5291E
SKIA5292E
SKIA5291E
SKIA5292E
SKIA5291E
Page 1152 of 3371
WARNING CHIME
DI-49
C
D
E
F
G
H
I
J
L
MA
B
DI
Revision: August 20072004 QX56
Terminals and Reference Value for Combination MeterEKS007EJ
How to Proceed With Trouble DiagnosisEKS007EK
1. Confirm the symptom or customer complaint.
2. Understand operation description and function description. Refer to DI-44, "
System Description" .
3. Perform the preliminary check. Refer to DI-49, "
Preliminary Check" .
4. Check symptom and repair or replace the cause of malfunction.
5. Does the warning chime operate properly? If so, go to 6. If not, go to 3.
6. Inspection End.
Preliminary CheckEKS007EL
INSPECTION FOR POWER SUPPLY AND GROUND CIRCUIT
1. CHECK FUSE AND FUSIBLE LINK
Check for blown BCM fuse or fusible link.
Refer to DI-46, "Wiring Diagram — CHIME —" .
OK or NG
OK >> GO TO 2.
NG >> If fuse is blown, be sure to eliminate cause of malfunction before installing new fuse. Refer to PG-
4, "POWER SUPPLY ROUTING CIRCUIT" .
35 O/B Combination switch output 2
ON
Light switch and wiper switch
OFF
Wiper dial position 4 36 R/W Combination switch output 1
37 B/R Key switch signal OFFKey is removed 0
Key is inserted Battery voltage
38 W/L Ignition switch ON or START ON — Battery voltage
39 W CAN-H — — —
40 R CAN-L — — —
47 SB Front door switch LH signal OFFON (open) 0
OFF (closed) 5
67 B Ground OFF — 0
70 W/B Battery power supply OFF — Battery voltage Te r m i n a l
No.Wire
colorItem Condition
Reference value (V)
(Approx.) Ignition
switchMeasurement method
SKIA5292E
Te r m i n a l
No.Wire
colorItem Condition
Reference value (V)
(Approx.) Ignition
switchMeasurement method
11 W C A N - H — — —
12 R CAN-L — — —
27 O/B Seat belt buckle switch LH ONUnfastened (ON) 0
Fastened (OFF) Battery voltage
Unit Power source Fuse or fusible link No.
BCMBatteryf
Ignition switch ON or START 59
