Light INFINITI QX56 2004 Factory Workshop Manual

IVIS (INFINITI VEHICLE IMMOBILIZER SYSTEM-NATS)
BL-139
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: August 20072004 QX56
System DescriptionEIS002TM
IVIS (Infiniti Vehicle Immobilizer System-NATS) has the following immobilizer functions:

Since only IVIS (NATS) ignition keys, whose IDs have been registered into the ECM and BCM, allow the
engine to run, operation of a stolen vehicle without an IVIS (NATS) registered key is prevented by IVIS
(NATS).
IVIS (NATS) will immobilize the engine if someone tries to start it without the registered key of IVIS
(NATS).

All of the originally supplied ignition key IDs have been IVIS (NATS) registered.
If requested by the vehicle owner, a maximum of five key IDs can be registered into the IVIS (NATS) com-
ponents.

The security indicator blinks when the ignition switch is in OFF or ACC position. IVIS (NATS) warns out-
siders that the vehicle is equipped with the anti-theft system.

When IVIS (NATS) detects a malfunction, the security indicator lamp lights up while ignition key is in the
ON position.

IVIS (NATS) trouble diagnoses, system initialization and additional registration of other IVIS (NATS) igni-
tion key IDs must be carried out using CONSULT-II hardware and CONSULT-II IVIS (NATS) software.
When IVIS (NATS) initialization has been completed, the ID of the inserted ignition key is automatically
IVIS (NATS) registered. Then, if necessary, additional registration of other IVIS (NATS) ignition key IDs
can be carried out.
Regarding the procedures of IVIS (NATS) initialization and IVIS (NATS) ignition key ID registration, refer
to CONSULT-II Operation Manual NATS-IVIS/NVIS.

When servicing a malfunction of the IVIS (NATS) (indicated by lighting up of Security Indicator
Lamp) or registering another IVIS (NATS) ignition key ID, it may be necessary to re-register origi-
nal key identification. Therefore, be sure to receive ALL KEYS from vehicle owner.
System CompositionEIS0 02 T N
The immobilizer function of the IVIS (NATS) consists of the following:

NATS ignition key

NATS antenna amp. located in the ignition key cylinder

Body control module (BCM)

Engine control module (ECM)

Security indicator
NOTE:
The communication between ECM and BCM uses the CAN communication system.
PIIA1121E

BL-146
IVIS (INFINITI VEHICLE IMMOBILIZER SYSTEM-NATS)
Revision: August 20072004 QX56
Trouble DiagnosesEIS002TT
SYMPTOM MATRIX CHART 1
Self-diagnosis related item
*: When IVIS (NATS) detects trouble, the security indicator lights up while ignition key is in the “ON” position.SymptomDisplayed “SELF-DIAG
RESULTS” on CON-
SULT-II screen.Diagnostic Procedure
(Reference page)System
(Malfunctioning part or
mode)Reference Part No. Of
Illustration On System
Diagram

Security indicator
lighting up*

Engine cannot be
startedCHAIN OF ECM-IMMU
[P1612]PROCEDURE 1
(BL-148
)In rare case, “CHAIN OF
ECM-IMMU” might be
stored during key regis-
tration procedure, even if
the system is not mal-
functioning.—
Open circuit in battery
voltage line of BCM cir-
cuitC1
Open circuit in ignition
line of BCM circuitC2
Open circuit in ground
line of BCM circuitC3
Open or short circuit
between BCM and ECM
communication lineC4
ECM B
BCM A
DIFFERENCE OF KEY
[P1615]PROCEDURE 2
(BL-149
)Unregistered key D
BCM A
CHAIN OF IMMU-KEY
[P1614]PROCEDURE 5
(BL-152
)Malfunction of key ID
chipE5
Communication line
between ANT/ AMP and
BCM:
Open circuit or short cir-
cuit of battery voltage
line or ground lineE1
E2
Open circuit in power
source line of ANT/ AMP
circuitE3
Open circuit in ground
line of ANT/ AMP circuitE4
NATS antenna amp. E6
BCM A
ID DISCORD, IMM-ECM
[P1611]PROCEDURE 3
(BL-150
)System initialization has
not yet been completed.F
ECM B
LOCK MODE
[P1610]PROCEDURE 4
(BL-151
)LOCK MODE D
Security indicator light-
ing up*DON'T ERASE
BEFORE CHECKING
ENG DIAGWORK FLOW
(BL-145
)Engine trouble data and
IVIS (NATS) trouble data
have been detected in
ECM—

IVIS (INFINITI VEHICLE IMMOBILIZER SYSTEM-NATS)
BL-147
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: August 20072004 QX56
SYMPTOM MATRIX CHART 2
Non self-diagnosis related item
*: CONSULT-II self-diagnostic results display screen “no malfunction is detected”.
DIAGNOSTIC SYSTEM DIAGRAM
SymptomDiagnostic Procedure
(Reference page)System
(Malfunctioning part or mode)Reference Part No. Of Illustra-
tion On System Diagram
Security indicator does not light
up*.PROCEDURE 6
(BL-155
)Combination meter (security
indictor lamp)—
Open circuit between fuse and
BCM—
BCM A
WIIA0550E

IVIS (INFINITI VEHICLE IMMOBILIZER SYSTEM-NATS)
BL-155
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: August 20072004 QX56
Diagnostic Procedure 6EIS002TZ
“SECURITY INDICATOR LAMP DOES NOT LIGHT UP”
1. CHECK FUSE
Check 10A fuse [No.19, located in the fuse block (J/B)]
OK or NG
OK >> GO TO 2.
NG >> If fuse is blown, be sure to eliminate cause of malfunction before installing new fuse.
2. CHECK SECURITY INDICATOR LAMP
1. Start engine and turn ignition switch OFF.
2. Check the security indicator lamp lights up.
OK or NG
OK >> Inspection End.
NG >> GO TO 3.
3. CHECK SECURITY INDICATOR LAMP POWER SUPPLY CIRCUIT
1. Disconnect security indicator lamp.
2. Check voltage between security indicator lamp connector M24
terminal 8 and ground.
OK or NG
OK >> GO TO 4.
NG >> Repair or replace harness.
4. CHECK BCM (NATS CONTROL UNIT) FUNCTION
1. Connect security indicator lamp.
2. Disconnect BCM.
3. Check voltage between BCM connector M18 terminal 23 and
ground.
OK or NG
OK >> BCM is malfunctioning.

Replace BCM.
Ref. part No. A

Perform initialization with CONSULT-II.

For initialization, refer to “CONSULT-II Operation
Manual NATS-IVIS/NVIS”.
NG >> Check the following:

Harness for open or short between security indicator lamp and BCM (NATS control unit).

Indicator lamp condition Security indicator lamp should light up.
8 (Y/R) - Ground : Battery voltage
LIIA1072E
23 (G/O) - Ground : Battery voltage
LIIA0523E

BL-158
HOMELINK UNIVERSAL TRANSCEIVER
Revision: August 20072004 QX56
Trouble DiagnosesEIS0 02 U2
DIAGNOSTIC PROCEDURE
SYMPTOM: Transmitter does not activate receiver.
Before conducting the procedure given below, make sure that system receiver (garage door opener, etc.)
operates with original, hand-held transmitter. If NG, receiver or hand-held transmitter is at fault, not vehicle
related.
1. ILLUMINATE CHECK

Turn ignition switch OFF.

Does amber light (LED) of transmitter illuminate when any but-
ton is pressed?
YES or NO
YES >> GO TO 2.
NO >> GO TO 3.
2. TRANSMITTER CHECK
Check transmitter with Tool. For details, refer to Technical Service Bulletin.
OK or NG
OK >> Receiver or hand-held transmitter malfunction, not vehicle related.
NG >> Replace transmitter.
3. POWER SUPPLY CHECK
1. Disconnect transmitter.
2. Check voltage between HomeLink® universal transceiver connector R106 terminal 1 and ground.
OK or NG
OK >> GO TO 4.
NG >> Repair or replace fuse or harness.
4. GROUND CIRCUIT CHECK
Check continuity between HomeLink® universal transceiver connector R106 terminal 2 (B) and body ground.
OK or NG
OK >> Replace HomeLink® universal transceiver.
NG >> Repair or replace harness.
LIIA1466E
1 (Y/R) - Ground : Battery voltage
LIIA1467E
2 (B) - Ground : Continuity should exist.
LIIA2039E

BRC-4
[VDC/TCS/ABS]
PRECAUTIONS
Revision: August 20072004 QX56

If YES, GO TO 2.

If NO, GO TO 5.
2. Is there any indication other than indications relating to CAN communication system in the self-diagnosis
results?

If YES, GO TO 3.

If NO, GO TO 4.
3. Based on self-diagnosis results unrelated to CAN communication, carry out the inspection.
4. Malfunctions may be detected in self-diagnosis depending on control units carrying out CAN communica-
tion. Therefor, erase the self-diagnosis results.
5. Diagnose CAN communication system. Refer to BRC-10, "
CAN COMMUNICATION" .
Precautions for Brake ControlEFS003QD

During ABS operation, the brake pedal may vibrate lightly and a mechanical noise may be heard. This is
normal.

Just after starting vehicle, the brake pedal may vibrate or a motor operating noise may be heard from
engine compartment. This is a normal status of operation check.

Stopping distance may be longer than that of vehicles without ABS when vehicle drives on rough, gravel,
or snow-covered (fresh, deep snow) roads.

When an error is indicated by ABS or another warning lamp, collect all necessary information from cus-
tomer (what symptoms are present under what conditions) and check for simple causes before starting
diagnosis. Besides electrical system inspection, check booster operation, brake fluid level, and fluid leaks.

If incorrect tire sizes or types are installed on the vehicle or brake pads are not Genuine NISSAN parts,
stopping distance or steering stability may deteriorate.

If there is a radio, antenna or related wiring near control module, ABS function may have a malfunction or
error.

If aftermarket parts (car stereo, CD player, etc.) have been installed, check for incidents such as harness
pinches, open circuits or improper wiring.

If the following components are replaced with non-genuine components or modified, the VDC OFF indica-
tor lamp and SLIP indicator lamp may turn on or the VDC system may not operate properly. Components
related to suspension (shock absorbers, struts, springs, bushings, etc.), tires, wheels (exclude specified
size), components related to brake system (pads, rotors, calipers, etc.), components related to engine
(muffler, ECM, etc.), components related to body reinforcement (roll bar, tower bar, etc.).

Driving with broken or excessively worn suspension components, tires or brake system components may
cause the VDC OFF indicator lamp and the SLIP indicator lamp to turn on, and the VDC system may not
operate properly.

When the TCS or VDC is activated by sudden acceleration or sudden turn, some noise may occur. The
noise is a result of the normal operation of the TCS and VDC.

When driving on roads which have extreme slopes (such as mountainous roads) or high banks (such as
sharp curves on a freeway), the VDC may not operate normally, or the VDC warning lamp and the SLIP
indicator lamp may turn on. This is not a problem if normal operation can be resumed after restarting the
engine.

Sudden turns (such as spin turns, acceleration turns), drifting, etc. with VDC turned off may cause the yaw
rate/side G sensor to indicate a problem. This is not a problem if normal operation can be resumed after
restarting the engine.
Precautions for CAN SystemEFS003QE

Do not apply voltage of 7.0V or higher to terminal to be measured.

Maximum open terminal voltage of tester in use must be less than 7.0V.

Before checking harnesses, turn ignition switch OFF and disconnect battery negative cable.

BRC-8
[VDC/TCS/ABS]
SYSTEM DESCRIPTION
Revision: August 20072004 QX56
ABS FunctionEFS003QJ

The Anti-Lock Brake System detects wheel revolution while braking and improves handling stability during
sudden braking by electrically preventing wheel lockup. Maneuverability is also improved for avoiding
obstacles.

If the electrical system malfunctions, the Fail-Safe function is activated, the ABS becomes inoperative and
the ABS warning lamp turns on.

The electrical system can be diagnosed using CONSULT-II.

During ABS operation, the brake pedal may vibrate lightly and a mechanical noise may be heard. This is
normal.

Just after starting the vehicle, the brake pedal may vibrate or a motor operating noise may be heard from
engine compartment. This is a normal status of operation check.

Stopping distance may be longer than that of vehicles without ABS when vehicle drives on rough, gravel,
or snow-covered (fresh, deep snow) roads.
EBD FunctionEFS003QK

Electronic Brake Distribution is a function that detects subtle slippages between the front and rear wheels
during braking, and it improves handling stability by electronically controlling the brake fluid pressure
which results in reduced rear wheel slippage.

If the electrical system malfunctions, the Fail-Safe function is activated, the EBD and ABS become inoper-
ative, and the ABS warning lamp and BRAKE warning lamp are turned on.

The electrical system can be diagnosed using CONSULT-II.

During EBD operation, the brake pedal may vibrate lightly and a mechanical noise may be heard. This is
normal.

Just after starting the vehicle, the brake pedal may vibrate or a motor operating noise may be heard from
engine compartment. This is a normal status of operation check.
TCS FunctionEFS003QL

Spinning of the drive wheels is detected by the ABS actuator and electric unit (control unit) using inputs
from the wheel speed sensors. If wheel spin occurs, the drive wheel right and left brake fluid pressure
control and engine fuel cut are activated while the throttle value is restricted to reduce the engine torque
and decrease the amount of wheel spin. In addition, the throttle opening is controlled to achieve the opti-
mum engine torque.

Depending on road condition, the vehicle may have a sluggish feel. This is normal, because optimum trac-
tion has the highest priority during TCS operation.

TCS may be activated during sudden vehicle acceleration, wide open throttle acceleration, sudden trans-
mission shifts or when the vehicle is driven on a road with a varying surface friction coefficient.

The SLIP indicator lamp flashes to inform the driver of TCS operation.
VDC FunctionEFS003QM

In addition to the ABS/TCS function, the driver steering amount and brake operation amount are detected
from the steering angle sensor and front and rear pressure sensors, and the vehicle's driving status
(amount of under steering/over steering) is determined using inputs from the yaw rate sensor/side G sen-
sor, wheel speed sensors, etc. and this information is used to improve vehicle stability by controlling the
braking and engine torque application to the wheels.

The SLIP indicator lamp flashes to inform the driver of VDC operation.

During VDC operation, the vehicle body and brake pedal may vibrate lightly and a mechanical noise may
be heard. This is normal.

The ABS warning lamp, VDC OFF indicator lamp and SLIP indicator lamp may turn on when the vehicle is
subject to strong shaking or large vibration, such as when the vehicle is on a turn table or a ship while the
engine is running or on a steep slope. In this case, restart the engine on a normal road and if the ABS
warning lamp, VDC OFF indicator lamp and SLIP indicator lamp turn off, there is no problem.
Fail-Safe FunctionEFS003QN
CAUTION:
If the Fail-Safe function is activated, perform the Self Diagnosis for ABS/TCS/VDC system.

DI-1
DRIVER INFORMATION SYSTEM
K ELECTRICAL
CONTENTS
C
D
E
F
G
H
I
J
L
M
SECTION DI
A
B
DI
Revision: August 20072004 QX56 PRECAUTION ............................................................ 3
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” .................................................................. 3
Wiring Diagrams and Trouble Diagnosis .................. 3
PREPARATION ........................................................... 4
Commercial Service Tool ......................................... 4
COMBINATION METERS ........................................... 5
System Description .................................................. 5
UNIFIED METER CONTROL UNIT ...................... 5
POWER SUPPLY AND GROUND CIRCUIT ........ 6
WATER TEMPERATURE GAUGE ........................ 6
ENGINE OIL PRESSURE GAUGE ....................... 6
A/T OIL TEMPERATURE GAUGE ........................ 6
VOLTAGE GAUGE ................................................ 6
TACHOMETER ..................................................... 6
FUEL GAUGE ....................................................... 6
SPEEDOMETER ................................................... 6
CAN COMMUNICATION SYSTEM DESCRIP-
TION ...................................................................... 6
Component Parts and Harness Connector Location ..... 7
Combination Meter ................................................... 8
CHECK .................................................................. 8
Circuit Diagram ........................................................ 9
Wiring Diagram — METER — ................................ 10
Terminals and Reference Value for Combination
Meter ...................................................................... 12
Meter/Gauge Operation and Odo/Trip Meter ......... 13
SELF-DIAGNOSIS FUNCTION .......................... 13
HOW TO INITIATE COMBINATION METER
SELF- DIAGNOSIS MODE ................................. 13
COMBINATION METER SELF-DIAGNOSIS
MODE FUNCTIONS ........................................... 13
How to Proceed With Trouble Diagnosis ................ 17
Diagnosis Flow ....................................................... 17
Power Supply and Ground Circuit Inspection ........ 18
Symptom Chart ...................................................... 19
Vehicle Speed Signal Inspection ............................ 19
Engine Oil Pressure Signal Inspection ................... 19
Water Temperature Signal Inspection .................... 21Engine Speed Signal Inspection ............................. 21
Fuel Level Sensor Unit Inspection .......................... 22
FUEL LEVEL SENSOR UNIT ............................. 22
LOW-FUEL WARNING LAMP ............................. 22
Fuel Gauge Fluctuates, Indicates Wrong Value, or
Varies ...................................................................... 24
Fuel Gauge Does Not Move to Full-position ........... 24
Electrical Components Inspection .......................... 25
FUEL LEVEL SENSOR UNIT CHECK ................ 25
Removal and Installation of Combination Meter ..... 25
COMPASS AND THERMOMETER ........................... 26
System Description ................................................. 26
OUTSIDE TEMPERATURE DISPLAY ................. 26
DIRECTION DISPLAY ......................................... 26
Wiring Diagram — COMPAS — ............................. 27
Trouble Diagnoses ................................................. 28
PRELIMINARY CHECK FOR THERMOMETER ... 28
INSPECTION/COMPASS AND THERMOME-
TER ..................................................................... 28
Calibration Procedure for Compass ....................... 29
CORRECTION FUNCTIONS OF COMPASS ...... 29
INITIAL CORRECTION PROCEDURE FOR
COMPASS ........................................................... 30
WARNING LAMPS .................................................... 31
Schematic ............................................................... 31
Wiring Diagram — WARN — .................................. 32
Oil Pressure Warning Lamp Stays Off (Ignition
Switch ON) ............................................................. 38
Oil Pressure Warning Lamp Does Not Turn Off (Oil
Pressure Is Normal) ................................................ 40
A/T INDICATOR ........................................................ 41
Wiring Diagram — AT/IND — ................................. 41
A/T Indicator Does Not Illuminate ........................... 42
WARNING CHIME ..................................................... 43
Component Parts and Harness Connector Location ... 43
System Description ................................................. 44
FUNCTION .......................................................... 44
IGNITION KEY WARNING CHIME ..................... 44
LIGHT WARNING CHIME ................................... 44
SEAT BELT WARNING CHIME ........................... 44

DI-2Revision: August 20072004 QX56 CAN Communication System Description .............. 45
Wiring Diagram — CHIME — ................................. 46
Terminals and Reference Value for BCM ................ 48
Terminals and Reference Value for Combination
Meter ...................................................................... 49
How to Proceed With Trouble Diagnosis ................ 49
Preliminary Check .................................................. 49
INSPECTION FOR POWER SUPPLY AND
GROUND CIRCUIT ............................................. 49
CONSULT-II Function (BCM) .................................. 51
CONSULT-II BASIC OPERATION PROCEDURE
... 51
DATA MONITOR .................................................. 52
ACTIVE TEST ..................................................... 52
SELF-DIAGNOSTIC RESULTS ........................... 52
All Warning Chimes Do Not Operate ...................... 53
Key Warning Chime and Light Warning Chime Do
Not Operate (Seat Belt Warning Chime Does Oper-
ate) ......................................................................... 53
Key Warning Chime Does Not Operate .................. 54
Light Warning Chime Does Not Operate ................ 56
Seat Belt Warning Chime Does Not Operate ......... 57
REAR SONAR SYSTEM ........................................... 59
Component Parts and Harness Connector Location ... 59
System Description ................................................. 60
FUNCTION .......................................................... 60
REAR SONAR SYSTEM OFF SWITCH .............. 60
SONAR BUZZER ................................................ 60
REAR SONAR SENSOR ..................................... 61
Wiring Diagram — SONAR — ................................ 62
Terminals And Reference Value For Sonar Control
Unit ......................................................................... 64
How to Proceed With Trouble Diagnosis ................ 64
Pre-diagnosis Inspection ........................................ 65
SENSOR STATUS CHECK ................................. 65
Self-diagnosis Function .......................................... 65
ENTERING DIAGNOSTICS MODE .................... 65
REQUESTING NUMBER OF FAULT CODES
MODE .................................................................. 65
REQUESTING FAULT CODES MODE ............... 66
IDLING OR CLEARING FAULT CODES MODE ... 66
Preliminary Check .................................................. 67INSPECTION FOR POWER SUPPLY AND
GROUND CIRCUIT .............................................67
Symptom Chart .......................................................68
Component Inspection ............................................69
SONAR BUZZER .................................................69
REAR SONAR SYSTEM OFF SWITCH ..............69
REAR SONAR SYSTEM OFF INDICATOR .........69
Removal and Installation of Rear Sonar System ....69
REAR SONAR SENSORS ...................................69
SONAR CONTROL UNIT ....................................69
CLOCK ......................................................................70
Wiring Diagram — CLOCK — .................................70
Removal and Installation of Clock ...........................71
REMOVAL ............................................................71
INSTALLATION ....................................................71
REAR VIEW MONITOR .............................................72
System Description .................................................72
POWER SUPPLY AND GROUND .......................72
AV COMMUNICATION LINE ...............................72
REAR VIEW CAMERA OPERATION ..................72
Component Parts and Harness Connector Location ...73
Schematic ...............................................................74
Wiring Diagram — R/VIEW — ................................75
Terminals and Reference Value for Rear View Cam-
era Control Unit .......................................................78
CONSULT-II Function (REARVIEW CAMERA) ......79
CONSULT-II BASIC OPERATION .......................79
WORK SUPPORT ...............................................80
DATA MONITOR ..................................................80
Side Distance Guideline Correction ........................81
SIDE DISTANCE GUIDELINE CORRECTION
PROCEDURE ......................................................81
Power Supply and Ground Circuit Inspection .........83
Rear View Is Not Displayed With The A/T Selector
Lever In R Position ..................................................84
Removal and Installation of Rear View Camera Con-
trol Unit ....................................................................88
REMOVAL ............................................................88
INSTALLATION ....................................................88
Removal and Installation of Rear View Camera .....88
REMOVAL ............................................................88
INSTALLATION ....................................................88

COMBINATION METERS
DI-5
C
D
E
F
G
H
I
J
L
MA
B
DI
Revision: August 20072004 QX56
COMBINATION METERSPFP:24814
System DescriptionEKS007DL
UNIFIED METER CONTROL UNIT

Speedometer, odometer, tachometer, fuel gauge, oil pressure gauge, voltage meter, A/T temperature
gauge, and water temperature gauge are controlled by the unified meter control unit, which is built into the
combination meter.

Warning indicators are controlled by signals drawn from the CAN communication system, BCM (body con-
trol module), and components connected directly to the combination meter.

Digital meter is adopted for odometer/trip meters*, as well as the A/T position indicator display.
*The record of the odometer is kept even if the battery cable is disconnected.

Odometer/trip meters and A/T indicator segments can be checked in diagnosis mode.

Meters/gauges can be checked in diagnosis mode.
Illumination control
The unified meter control unit outputs the speedometer, odometer/trip meters, tachometer, oil pressure gauge,
voltage meter, A/T indicator, A/T temperature gauge, fuel and temperature gauge lighting when the ignition
switch is turned on. When the lighting switch is turned on, the illumination control switch can be used to adjust
the brightness of the combination meter illumination and the odometer/trip meters and meter illumination.
When the ignition switch is turned from the OFF to the ON position, the combination meter dial lighting will
remain off for 0.7 seconds. For additional combination meter illumination control information, refer to LT-152,
"System Description" .
