Page 187 of 3371
AT-116
DTC P0725 ENGINE SPEED SIGNAL
Revision: August 20072004 QX56
2. CHECK DTC WITH TCM
With CONSULT-II
1. Start engine.
2. Select “ECU INPUT SIGNALS” in “DATA MONITOR” mode for
“A/T” with CONSULT-II.
3. While monitoring engine speed, check for engine speed change
corresponding to wide-open throttle position signal.
With GST
Follow the procedure “With CONSULT-II”.
OK or NG
OK >> GO TO 3.
NG >> Check the ignition signal circuit.
Refer to EC-583, "IGNITION SIGNAL" .
3. CHECK TCM
Perform TCM input/output signals inspection. Refer to AT- 9 0 , "
TCM Input/Output Signal Reference Values" .
OK or NG
OK >> GO TO 4.
NG >> GO TO 6.
4. CHECK DTC
Perform “DTC Confirmation Procedure”.
Refer to AT-115, "DTC Confirmation Procedure" .
OK or NG
OK >>INSPECTION END
NG >> GO TO 5.
5. DETECT MALFUNCTIONING ITEM
Check the following items:
The A/T assembly harness connector terminals for damage or loose connection with harness connector.
OK or NG
OK >> Replace the control valve with TCM. Refer to AT-241, "Control Valve With TCM and A/T Fluid
Temperature Sensor 2" .
NG >> Repair or replace damaged parts.
6. DETECT MALFUNCTIONING ITEM
Check the following items:
Power supply and ground circuit for TCM.
The A/T assembly harness connector terminals for damage or loose connection with harness connector.
OK or NG
OK >> GO TO 7.
NG >> Repair or replace damaged parts.
Item name Condition Display value (rpm)
ENGINE SPEED Engine running Closely matches the tachometer reading.
PCIA0041E
Page 188 of 3371
DTC P0725 ENGINE SPEED SIGNAL
AT-117
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: August 20072004 QX56
7. CHECK DTC
Perform “DTC Confirmation Procedure”.
Refer to AT- 11 5 , "DTC Confirmation Procedure" .
OK or NG
OK >>INSPECTION END
NG >> GO TO 3.
Page 190 of 3371
DTC P0740 TORQUE CONVERTER CLUTCH SOLENOID VALVE
AT-119
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: August 20072004 QX56
Diagnostic ProcedureUCS002EC
1. CHECK INPUT SIGNAL
With CONSULT-II
1. Turn ignition switch “ON”. (Do not start engine.)
2. Select “MAIN SIGNALS” in “DATA MONITOR” mode for “A/T”
with CONSULT-II.
3. Start the engine.
4. Read out the value of “TCC SOLENOID” while driving.
OK or NG
OK >> GO TO 6.
NG >> GO TO 2.
2. CHECK TCM
Perform TCM input/output signals inspection. Refer to AT-90, "
TCM Input/Output Signal Reference Values" .
OK or NG
OK >> GO TO 3.
NG >> GO TO 5.
3. CHECK DTC
Perform “DTC Confirmation Procedure”.
Refer to AT- 11 8 , "DTC Confirmation Procedure" .
OK or NG
OK >>INSPECTION END
NG >> GO TO 4.
4. DETECT MALFUNCTIONING ITEM
Check the following items:
The A/T assembly harness connector terminals for damage or loose connection with harness connector.
OK or NG
OK >> Replace the control valve with TCM. Refer to AT - 2 4 1 , "Control Valve With TCM and A/T Fluid
Temperature Sensor 2" .
NG >> Repair or replace damaged parts.
5. DETECT MALFUNCTIONING ITEM
Check the following items:
Power supply and ground circuit for TCM.
The A/T assembly harness connector terminals for damage or loose connection with harness connector.
OK or NG
OK >> GO TO 6.
NG >> Repair or replace damaged parts.
Item name Condition Display value (Approx.)
TCC SOLENOIDWhen performing slip lock-up 0.2 - 0.4 A
When performing lock-up 0.4 - 0.6 A
SCIA4793E
Page 191 of 3371
AT-120
DTC P0740 TORQUE CONVERTER CLUTCH SOLENOID VALVE
Revision: August 20072004 QX56
6. CHECK DTC
Perform “DTC Confirmation Procedure”.
Refer to AT-118, "DTC Confirmation Procedure" .
OK or NG
OK >>INSPECTION END
NG >> GO TO 2.
Page 192 of 3371
DTC P0744 A/T TCC S/V FUNCTION (LOCK-UP)
AT-121
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: August 20072004 QX56
DTC P0744 A/T TCC S/V FUNCTION (LOCK-UP)PFP:31940
DescriptionUCS002ED
This malfunction is detected when the A/T does not shift into 5th gear position or the torque converter clutch
does not lock-up as instructed by the TCM. This is not only caused by electrical malfunction (circuits open or
shorted) but also by mechanical malfunction such as control valve sticking, improper solenoid valve operation,
etc.
CONSULT-II Reference ValueUCS002EE
On Board Diagnosis LogicUCS002EF
This is an OBD-II self-diagnostic item.
Diagnostic trouble code “A/T TCC S/V FNCTN” with CONSULT-II or P0744 without CONSULT-II is
detected under the following conditions.
–When A/T cannot perform lock-up even if electrical circuit is good.
–When TCM detects as irregular by comparing difference value with slip rotation.
Possible CauseUCS002EG
Harness or connectors
(The solenoid circuit is open or shorted.)
Torque converter clutch solenoid valve
Hydraulic control circuit
DTC Confirmation ProcedureUCS002EH
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
If “DTC Confirmation Procedure” has been previously performed, always turn ignition switch “OFF”
and wait at least 10 seconds before performing the next test.
After the repair, perform the following procedure to confirm the malfunction is eliminated.
WITH CONSULT-II
1. Start engine and Select “TCC S/V FNCTN CHECK” of “DTC
WORK SUPPORT” mode for “A/T” with CONSULT-II and touch
“START”.
2. Accelerate vehicle to more than 80 km/h (50 MPH) and maintain
the following condition continuously until “TESTING” has turned
to “COMPLETE”. (It will take approximately 30 seconds after
“TESTING” shows.)
ACCELE POSI: More than 1.0/8 (at all times during step 4)
TCC SOLENOID: 0.4 - 0.6 A
Selector lever: “D” position
[Reference speed: Constant speed of more than 80 km/h (50
MPH)]
–Make sure “GEAR” shows “5”.
–For shift schedule, refer to AT- 6 7 , "Vehicle Speed When Performing and Releasing Complete Lock-
up" .
–If “TESTING” does not appear on CONSULT-II for a long time, select “SELF-DIAG RESULTS”. In
case a 1st trip DTC other than P0744 is shown, refer to applicable “TROUBLE DIAGNOSIS FOR
DTC”.
3. Make sure that “OK” is displayed. (If “NG” is displayed, refer to “DIAGNOSTIC PROCEDURE”.)
Refer to AT- 1 2 2 , "
Diagnostic Procedure" .
Refer to shift schedule, AT-67, "
Vehicle Speed When Performing and Releasing Complete Lock-up" .
Item name Condition Display value (Approx.) (A)
TCC SOLENOIDWhen performing slip lock-up 0.2 - 0.4
When performing lock-up 0.4 - 0.6
BCIA0030E
Page 193 of 3371
AT-122
DTC P0744 A/T TCC S/V FUNCTION (LOCK-UP)
Revision: August 20072004 QX56
WITH GST
Follow the procedure “With CONSULT-II”.
Diagnostic ProcedureUCS002EI
1. CHECK INPUT SIGNAL
With CONSULT-II
1. Turn ignition switch “ON”. (Do not start engine.)
2. Select “MAIN SIGNALS” in “DATA MONITOR” mode for “A/T”
with CONSULT-II.
3. Start the engine.
4. Read out the value of “TCC SOLENOID” while driving.
OK or NG
OK >> GO TO 6.
NG >> GO TO 2.
2. CHECK TCM
Perform TCM input/output signals inspection. Refer to AT- 9 0 , "
TCM Input/Output Signal Reference Values" .
OK or NG
OK >> GO TO 3.
NG >> GO TO 5.
3. CHECK DTC
Perform “DTC Confirmation Procedure”.
Refer to AT-121, "DTC Confirmation Procedure" .
OK or NG
OK >>INSPECTION END
NG >> GO TO 4.
4. DETECT MALFUNCTIONING ITEM
Check the following items:
The A/T assembly harness connector terminals for damage or loose connection with harness connector.
OK or NG
OK >> Replace the control valve with TCM. Refer to AT-241, "Control Valve With TCM and A/T Fluid
Temperature Sensor 2" .
NG >> Repair or replace damaged parts.
5. DETECT MALFUNCTIONING ITEM
Check the following items:
Power supply and ground circuit for TCM.
The A/T assembly harness connector terminals for damage or loose connection with harness connector.
OK or NG
OK >> GO TO 6.
NG >> Repair or replace damaged parts.
Item name Condition Display value (Approx.)
TCC SOLENOIDWhen performing slip lock-up 0.2 - 0.4 A
When performing lock-up 0.4 - 0.6 A
SCIA4793E
Page 194 of 3371
DTC P0744 A/T TCC S/V FUNCTION (LOCK-UP)
AT-123
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: August 20072004 QX56
6. CHECK DTC
Perform “DTC Confirmation Procedure”.
Refer to AT- 1 2 1 , "DTC Confirmation Procedure" .
OK or NG
OK >>INSPECTION END
NG >> GO TO 2.
Page 196 of 3371
DTC P0745 LINE PRESSURE SOLENOID VALVE
AT-125
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: August 20072004 QX56
Diagnostic ProcedureUCS002EO
1. CHECK INPUT SIGNAL
With CONSULT-II
1. Turn ignition switch “ON”. (Do not start engine.)
2. Select “MAIN SIGNALS” in “DATA MONITOR” mode for “A/T”
with CONSULT-II.
3. Start the engine.
4. Read out the value of “LINE PRES SOL” while driving.
OK or NG
OK >> GO TO 6.
NG >> GO TO 2.
2. CHECK TCM
Perform TCM input/output signals inspection. Refer to AT-90, "
TCM Input/Output Signal Reference Values" .
OK or NG
OK >> GO TO 3.
NG >> GO TO 5.
3. CHECK DTC
Perform “DTC Confirmation Procedure”.
Refer to AT- 1 2 4 , "DTC Confirmation Procedure" .
OK or NG
OK >>INSPECTION END
NG >> GO TO 4.
4. DETECT MALFUNCTIONING ITEM
Check the following items:
The A/T assembly harness connector terminals for damage or loose connection with harness connector.
OK or NG
OK >> Replace the control valve with TCM. Refer to AT - 2 4 1 , "Control Valve With TCM and A/T Fluid
Temperature Sensor 2" .
NG >> Repair or replace damaged parts.
5. DETECT MALFUNCTIONING ITEM
Check the following items:
Power supply and ground circuit for TCM.
The A/T assembly harness connector terminals for damage or loose connection with harness connector.
OK or NG
OK >> GO TO 6.
NG >> Repair or replace damaged parts.
Item name Condition Display value (Approx.)
LINE PRES SOL During driving 0.2 - 0.6 A
SCIA4793E
Page 197 of 3371
AT-126
DTC P0745 LINE PRESSURE SOLENOID VALVE
Revision: August 20072004 QX56
6. CHECK DTC
Perform “DTC Confirmation Procedure”.
Refer to AT-124, "DTC Confirmation Procedure" .
OK or NG
OK >>INSPECTION END
NG >> GO TO 2.
Page 198 of 3371
DTC P1702 TRANSMISSION CONTROL MODULE (RAM)
AT-127
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: August 20072004 QX56
DTC P1702 TRANSMISSION CONTROL MODULE (RAM)PFP:31036
DescriptionUCS002EP
The TCM consists of a microcomputer and connectors for signal input and output and for power supply. The
TCM controls the A/T.
On Board Diagnosis LogicUCS002EQ
This is not an OBD-II self-diagnostic item.
Diagnostic trouble code “TCM·RAM” with CONSULT-II is detected when TCM memory RAM is malfunc-
tioning.
Possible CauseUCS002ER
TCM.
DTC Confirmation ProcedureUCS002ES
NOTE:
If “DTC Confirmation Procedure” has been previously performed, always turn ignition switch “OFF”
and wait at least 10 seconds before performing the next test.
After the repair, perform the following procedure to confirm the malfunction is eliminated.
WITH CONSULT-II
1. Turn ignition switch “ON”. (Do not start engine.)
2. Select “DATA MONITOR” mode for “A/T” with CONSULT-II.
3. Start engine.
4. Run engine for at least 2 consecutive seconds at idle speed.
5. If DTC is detected, go to AT - 1 2 7 , "
Diagnostic Procedure" .
Diagnostic ProcedureUCS002ET
1. CHECK DTC
With CONSULT-II
1. Turn ignition switch “ON”. (Do not start engine.)
2. Select “SELF-DIAG RESULTS” mode for “A/T” with CONSULT-
II.
3. Touch “ERASE”.
4. Turn ignition switch “OFF” and wait at least 10 seconds.
5. Perform “DTC Confirmation Procedure”, AT-127, "
DTC Confir-
mation Procedure" .
Is the
“TCM·RAM” displayed again?
YES >> Replace the control valve with TCM. Refer to AT-241,
"Control Valve With TCM and A/T Fluid Temperature
Sensor 2" .
NO >>INSPECTION END
BCIA0030E
BCIA0031E
