REMOTE KEYLESS ENTRY SYSTEM
BL-61
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: August 20072004 QX56
Hazard reminder does not activate properly when
pressing lock or unlock button of keyfob.
(Horn reminder OK)1. Check hazard reminder mode with CONSULT-II
NOTE:
Hazard reminder mode can be changed.
First check the hazard reminder mode setting.BL-57
2. Check hazard function with hazard switch —
3. Replace BCM.BCS-19
Horn reminder does not activate properly when
pressing lock or unlock button of keyfob.
(Hazard reminder OK)1. Check horn reminder mode with CONSULT-II
NOTE:
Horn reminder mode can be changed.
First check the horn reminder mode setting.BL-57
2. Check horn function with horn switch —
3. IPDM E/R operation checkBL-68
4. Replace BCM.BCS-19
Back door open/close operation is not carried out
with keyfob operation.
(The automatic back door system is normal.)1. Keyfob battery and function check (use Remote Keyless Entry
Tester J-43241)BL-652. Key switch (insert) checkBL-62
3. Check that glass hatch is closed —
4. Remote keyless entry receiver systemBL-68
5. Replace BCM.BCS-19
Room lamp, ignition keyhole illumination and step
lamp operation do not activate properly.1. Room lamp operation checkBL-70
2. Ignition kehole illumination operation checkBL-70
3.Step lamp operation checkLT- 1 3 0
4. Door switch checkBL-63
5. Replace BCM.BCS-19
Panic alarm (horn and headlamp) does not activate
when panic alarm button is continuously pressed.1. Keyfob battery and function check (use Remote Keyless Entry
Tester J-43241)
NOTE:
If the result of keyfob function check is OK, keyfob is not malfunc-
tioning.BL-65
2. Key switch and key lock solenoid (insert) checkBL-62
3. Replace BCM.BCS-19
Auto door lock operation does not activate properly.
(All other remote keyless entry functions OK.)1. Check auto door lock operation mode with CONSULT-II
NOTE:
Auto door lock operation mode can be changed.
First check the auto door lock operation mode setting.BL-57
2. Replace BCM.BCS-19
Keyless power window down (open) operation does
not activate properly.
(All other remote keyless entry functions OK.)1. Check power window down operation mode with CONSULT-II
NOTE:
Power window down operation mode can be changed.
First check the power window down operation mode setting.BL-57
2. Check power window function with switch —
3. Replace BCM.BCS-19
Symptom Diagnoses/service procedureReference
page

BL-62
REMOTE KEYLESS ENTRY SYSTEM
Revision: August 20072004 QX56
Key Switch (Insert) CheckEIS002S1
1. CHECK KEY SWITCH INPUT SIGNAL
With CONSULT-II
Check key switch "KEY ON SW" in DATA MONITOR mode with CONSULT–II. Refer to BL-27, "
DATA MONI-
TOR" .

When key is inserted to ignition key cylinder:

When key is removed from ignition key cylinder:
Without CONSULT-II
Check voltage between BCM connector M18 terminal 37 and
ground.
OK or NG
OK >> Key switch (insert) circuit is OK.
NG >> GO TO 2.
2. CHECK KEY SWITCH (INSERT)
1. Turn ignition switch OFF.
2. Disconnect key switch and key lock solenoid.
3. Check continuity between key switch terminals 3, 4.
OK or NG
OK >> Repair or replace harness.
NG >> Replace key switch.KEY ON SW : ON
KEY ON SW : OFF
LIIA0169E
ConnectorTerminal
(Wire color)
Condition Voltage (V)
( + ) ( – )
M18 37 (B/R) GroundKey is inserted. Battery voltage
Key is removed. 0
LIIA0567E
Terminals Condition Continuity
3 – 4Key is inserted. Yes
Key is removed. No
LIIA1044E

REMOTE KEYLESS ENTRY SYSTEM
BL-63
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: August 20072004 QX56
Door Switch CheckEIS007WE
1. CHECK DOOR SWITCHES INPUT SIGNAL
With CONSULT-II
Check door switches ("DOOR SW-DR", "DOOR SW-AS", "DOOR SW-RL", "DOOR SW-RR", "BACK DOOR
SW") in DATA MONITOR mode with CONSULT–II.Refer to BL-27, "
DATA MONITOR" .

When doors are open:

When doors are closed:
Without CONSULT-II
Check voltage between BCM connector M18 or M19 terminals 12,
13, 43, 47, 48 and ground.
OK or NG
OK >> Door switch circuit is OK.
NG >> GO TO 2.DOOR SW-DR : ON
DOOR SW-AS : ON
DOOR SW-RL : ON
DOOR SW-RR : ON
BACK DOOR SW : ON
DOOR SW-DR : OFF
DOOR SW-AS : OFF
DOOR SW-RL : OFF
DOOR SW-RR : OFF
BACK DOOR SW : OFF
LIIA0665E
Connector ItemTerminals (Wire color)
ConditionVoltage (V)
(Approx.)
( + ) ( – )
M19Back door
latch (door
ajar switch)43 (R/B)
GroundOpen
↓
Closed0
↓
Battery voltage Front door
switch LH47 (SB)
Rear door
switch LH48 (R/Y)
M18Front door
switch RH12 (R/L)
Rear door
switch RH13 (GR)
LIIA1041E

REMOTE KEYLESS ENTRY SYSTEM
BL-65
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: August 20072004 QX56
4. CHECK BACK DOOR SWITCH GROUND
Check continuity between back door latch connector terminal 8 and
ground.
OK or NG
OK >> Back door switch circuit is OK.
NG >> Repair or replace harness.
Keyfob Battery and Function CheckEIS002S3
1. CHECK KEYFOB BATTERY
Remove battery and measure voltage across battery positive and negative terminals, (+) and (−).
NOTE:
Keyfob does not function if battery is not set correctly.
OK or NG
OK >> GO TO 2.
NG >> Replace battery.8 (B) - Ground : Continuity should exist.
LIIA0828E
Voltage : 2.5V - 3.0V
SEL237W

BL-68
REMOTE KEYLESS ENTRY SYSTEM
Revision: August 20072004 QX56
ACC Power CheckEIS002S5
1. CHECK ACC POWER
With CONSULT-II
Check "ACC ON SW" in DATA MONITOR mode with CONSULT–II. Refer to BL-27, "
DATA MONITOR" .
Without CONSULT-II
Check voltage between BCM connector M18 terminal 11 and
ground.
OK or NG
OK >> ACC power circuit is OK.
NG >> Check the following:

10A fuse [No. 4, located in fuse block (J/B)]

Harness for open or short.
IPDM E/R Operation CheckEIS002S6
1. CHECK IPDM E/R INPUT VOLTAGE
Check voltage between IPDM E/R connector E122 terminal 45 and
ground.
OK or NG
OK >> Replace IPDM E/R.
NG >> GO TO 2.
Monitor Item Condition
ACC ON SWIgnition switch position ACC : ON
Ignition switch position OFF : OFF
PIIA3367E
ConnectorTe r m i n a l
(Wire color)
ConditionVoltage (V)
(Approx.)
( + ) ( – )
M18 11 (O) GroundACC Battery voltage
OFF 0
PIIA7002E
ConnectorTe r m i n a l
(Wire color)Voltage (V)
(Approx.)
( + ) ( – )
E122 45 (G/W) Ground Battery voltage
LIIA1053E

BL-74
REMOTE KEYLESS ENTRY SYSTEM
Revision: August 20072004 QX56
NOTE:

If a keyfob is lost, the ID code of the lost keyfob must be erased to prevent unauthorized use. A specific ID
code can be erased with CONSULT-II. However, when the ID code of a lost keyfob is not known, all con-
troller ID codes should be erased. After all ID codes are erased, the ID codes of all remaining and/or new
keyfobs must be re-registered.
To erase all ID codes in memory, register one ID code (keyfob) five times. After all ID codes are erased,
the ID codes of all remaining and/or new keyfobs must be re-registered.

When registering an additional keyfob, the existing ID codes in memory may or may not be erased. If five
ID codes are stored in memory, when an additional code is registered, only the oldest code is erased. If
less than five ID codes are stored in memory, when an additional ID code is registered, the new ID code is
added and no ID codes are erased.

If you need to activate more than two additional new keyfobs, repeat the procedure “Additional ID code
entry” for each new keyfob.

Entry of maximum five ID codes is allowed. When more than five ID codes are entered, the oldest ID code
will be erased.

Even if same ID code that is already in the memory is input, the same ID code can be entered. The code
is counted as an additional code.
Keyfob Battery ReplacementEIS002SC
LIIA1514E

VEHICLE SECURITY (THEFT WARNING) SYSTEM
BL-85
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: August 20072004 QX56
Terminals and Reference Value for BCMEIS002SI
Te r m i n a l Wire
ColorItem ConditionVoltage (V)
(Approx.)
11 O Ignition switch (ACC or ON) Ignition switch (ACC or ON position) Battery voltage
12 R/L Front door switch RH Door open (ON) → Door close (OFF) 0 → Battery voltage
13 GR Rear door switch RH Door open (ON) → Door close (OFF) 0 → Battery voltage
22 W/V Power window serial linkWhen ignition switch is ON or power
window timer operates
23 G/OCombination meter (security
indicator lamp)Goes off → Illumiates (Every 2.4 sec-
onds) Battery voltage → 0
39 W CAN-H — —
40 R CAN-L — —
42 GR Glass hatch ajar switchGlass hatch open (ON) → Glass
hatch close (OFF)Battery voltage → 0
43 R/BBack door latch (door ajar
switch)Door open (ON) → Door close (OFF) 0 → Battery voltage
47 SB Front door switch LH Door open (ON) → Door close (OFF) 0 → Battery voltage
48 R/Y Rear door switch LH Door open (ON) → Door close (OFF) 0 → Battery voltage
57 Y/R Battery power supply — Battery voltage
67 B Ground — 0
70 W/B Battery power supply — Battery voltage
PIIA2344E

BL-86
VEHICLE SECURITY (THEFT WARNING) SYSTEM
Revision: August 20072004 QX56
Terminals and Reference Value for IPDM E/REIS002SJ
*1: when horn reminder is ON.
*2: L/W is for USA.
*3: Y is for Canada.
CONSULT-II Function (BCM)EIS002SK
CONSULT-II can display each diagnostic item using the diagnostic test modes shown following.
Terminal Wire
ColorItem ConditionVoltage (V)
(Approx.)
38 B Ground — 0
39 W CAN-H — —
40 R CAN-L — —
41 Y/B Hood switchHood closed OFF Battery voltage
Hood open ON 0V
45 G/W Horn relayWhen doors locks are operated
using keyfob (OFF → ON) *1Battery voltage → 0V
52 L Headlamp low (LH)Ignition
SW ONLighting
switch
2ND posi-
tionOFF 0V
ON Battery voltage
54 R/Y Headlamp low (RH)Ignition
SW ONLighting
switch
2ND posi-
tionOFF 0V
ON Battery voltage
55 G Headlamp high (LH)Ignition
SW ONLighting
switch
HIGH or
PA S S
positionOFF 0V
ON Battery voltage
56L/W *2
Y *3Headlamp high (RH)Ignition
SW ONLighting
switch
HIGH or
PA S S
positionOFF 0V
ON Battery voltage
59 B Ground — 0
BCM
diagnostic test itemDiagnostic mode Description
Inspection by partWORK SUPPORTSupports inspections and adjustments. Commands are transmitted to the
BCM for setting the status suitable for required operation, input/output sig-
nals are received from the BCM and received date is displayed.
DATA MONITOR Displays BCM input/output data in real time.
ACTIVE TESTOperation of electrical loads can be checked by sending drive signal to
them.
SELF-DIAG RESULTS Displays BCM self-diagnosis results.
CAN DIAG SUPPORT MNTRThe result of transmit/receive diagnosis of CAN communication can be
read.
ECU PART NUMBER BCM part number can be read.
CONFIGURATION Performs BCM configuration read/write functions.

BL-92
VEHICLE SECURITY (THEFT WARNING) SYSTEM
Revision: August 20072004 QX56
Symptom ChartEIS002SN
*1: Make sure the system is in the armed phase.PROCEDURE
Diagnostic procedure
SYMPTOM
1Vehicle security
system cannot be
set by ····Door switch Refer to BL-93, "
Door Switch Check" .
Lock/unlock switch Refer to BL-100, "
Door Lock/Unlock Switch Check" .
Door outside keyRefer to BL-98, "
Front Door Lock Assembly LH (Key Cylinder Switch)
Check" .
BCM If the above systems are “OK”, replace BCM.
Security indicator does not turn “ON”.Refer to BL-97, "
Combination Meter (Security Indicator Lamp) Check" .
If the above systems are “OK”, replace BCM.
2*1 Vehicle secu-
rity system does
not alarm when
····Any door, hood or glass hatch
is opened.Refer to BL-93, "
Door Switch Check" .
Refer to BL-95, "
Hood Switch Check" .
If the above systems are “OK”, replace BCM.
3Vehicle security
alarm does not
activate.Horn alarmRefer to BL-100, "
Vehicle Security Horn Alarm Check" .
If the above systems are “OK”, check horn system.
Refer to WW-56, "
HORN" .
Headlamp alarmRefer to BL-100, "
Vehicle Security Headlamp Alarm Check" .
If the above systems are “OK”, replace BCM.
4Vehicle security
system cannot be
canceled by ····Door outside keyRefer to BL-98, "
Front Door Lock Assembly LH (Key Cylinder Switch)
Check" .
If the above systems are “OK”, check main power window and door lock/
unlock switch.
KeyfobCheck remote keyless entry function. Refer toBL-65, "
Keyfob Battery and
Function Check"
If the above systems are “OK”, replace BCM.

VEHICLE SECURITY (THEFT WARNING) SYSTEM
BL-93
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: August 20072004 QX56
Door Switch CheckEIS003ES
1. CHECK DOOR SWITCHES INPUT SIGNAL
With CONSULT-II
Check door switches ("DOOR SW-DR", "DOOR SW-AS", "DOOR SW-RL", "DOOR SW-RR", "BACK DOOR
SW", "TRNK OPN MNTR") in DATA MONITOR mode with CONSULT–II.Refer to BL-27, "
DATA MONITOR" .

When doors are open:

When doors are closed:
Without CONSULT-II
Check voltage between BCM connector M18 or M19 terminals 12,
13, 42, 43, 47, 48 and ground.
OK or NG
OK >> Door switch circuit is OK.
NG >> GO TO 2.DOOR SW-DR : ON
DOOR SW-AS : ON
DOOR SW-RL : ON
DOOR SW-RR : ON
BACK DOOR SW : ON
TRNK OPN MNTR : ON
DOOR SW-DR : OFF
DOOR SW-AS : OFF
DOOR SW-RL : OFF
DOOR SW-RR : OFF
BACK DOOR SW : OFF
TRNK OPN MNTR : OFF
WIIA0466E
Connector ItemTerminals (Wire color)
ConditionVoltage (V)
(Approx.)
( + ) ( – )
M19Glass hatch
ajar switch42 (GR)
GroundOpen
↓
Closed0
↓
Battery voltage Back door
latch (door
ajar switch)43 (R/B)
Front door
switch LH47 (SB)
Rear door
switch LH48 (R/Y)
M18Front door
switch RH12 (R/L)
Rear door
switch RH13 (GR)
LIIA1451E
