Page 3211 of 3383
TF-106
TROUBLE DIAGNOSIS FOR SYSTEM
Revision: November 20092006 QX56
DIAGNOSTIC PROCEDURE
1. CHECK CLUTCH PRESSURE SWITCH SIGNAL
With CONSULT-II
1. Start engine.
2. Select “DATA MONITOR ” mode for “ALL MODE AWD/4WD ” with CONSULT-II.
3. Read out ON/OFF switching action of the “CL PRES SW ” while
operating 4WD shift switch.
Without CONSULT-II
1. Start engine.
2. Check voltage between transfer control unit harness connector terminals and ground.
OK or NG
OK >> GO TO 5.
NG >> GO TO 2.
2. CHECK HARNESS BETWEEN TRANSFER CONTROL UNIT AND CLUTCH PRESSURE SWITCH
1. Turn ignition switch “ OFF”. (Stay for at least 5 seconds.)
2. Disconnect transfer control unit harness connector and the transfer terminal cord assembly harness con- nector.
3. Check continuity between transfer control unit harness connec- tor E143 terminal 34 and transfer terminal cord assembly har-
ness connector F56 terminal 7
Also check harness for short to ground and short to power.
OK or NG
OK >> GO TO 3.
NG >> Repair or replace damaged parts.
Condition Display value
Ignition switch: ON
A/T selector lever “D ”
position 4WD shift switch: AUTO or 4H
(
“ Wait ” function is not operating.) ON
Ignition switch: ON 4WD shift switch: 2WD (
“Wait ”
function is not operating.) OFF
Connector Terminal ConditionVoltage
(Approx.)
E143 34 -
Ground
Ignition switch: ON
A/T selector lever
“ D ” position 4WD shift switch:
AUTO or 4H
(
“ Wait ” function is
not operating.) 0V
Ignition switch: ON 4WD shift switch:
2WD (
“Wait ” func-
tion is not operat-
ing.) Battery
voltage
WDIA0141E
SDIA2746E
Continuity should exist.
SDIA2747E
Page 3212 of 3383
TROUBLE DIAGNOSIS FOR SYSTEMTF-107
CE F
G H
I
J
K L
M A
B
TF
Revision: November 2009 2006 QX56
3. CHECK TRANSFER CONTROL UNIT
Check transfer control unit input/output signal. Refer to TF-54, "
TRANSFER CONTROL UNIT TERMINALS
AND REFERENCE VALUE" .
OK or NG
OK >> GO TO 4.
NG >> Check transfer control unit pin terminals for damage or loose connection with the harness connec- tor. If any items are damaged, repair or replace damaged parts.
4. CHECK CLUTCH PRESSURE SWITCH
1. Turn ignition switch “OFF”. (Stay for at least 5 seconds.)
2. Remove clutch pressure switch. Refer to TF-22, "
Location of Electrical Parts" .
3. Push and release clutch pressure switch and check continuity between transfer terminal cord assembly terminal 7 and ground.
OK or NG
OK >> GO TO 5.
NG >> Replace clutch pressure switch. Refer to TF-22, "
Loca-
tion of Electrical Parts" .
5. CHECK DTC
Perform the self-diagnosis, after driving a vehicle for a while.
OK or NG
OK >> GO TO 6.
NG >> Replace transfer control unit. Refer to TF-132, "
Removal and Installation" .
6. CRUISE TEST
Perform cruise test. Refer to TF-33, "
CRUISE TEST" .
OK or NG
OK >> Inspection End.
NG >> Perform the applicable trouble diagnosis.
COMPONENT INSPECTION
1. Turn ignition switch “OFF”. (Stay for at least 5 seconds.)
2. Remove clutch pressure switch. Refer to TF-22, "
Location of Electrical Parts" .
3. Push and release clutch pressure switch and check continuity between transfer terminal cord assembly terminal 7 and ground.
4. If NG, replace the clutch pressure switch. Refer to TF-22, "
Loca-
tion of Electrical Parts" .
TerminalCondition Continuity
7 -
Ground Push clutch pressure switch
Yes
Release clutch pressure switch No
WDIA0171E
TerminalCondition Continuity
7 - Ground Push clutch pressure switch
Yes
Release clutch pressure switch No
WDIA0171E
Page 3213 of 3383
TF-108
TROUBLE DIAGNOSIS FOR SYSTEM
Revision: November 20092006 QX56
Line Pressure SwitchEDS002IL
CONSULT-II REFERENCE VALUE IN DATA MONITOR MODE
Data are reference value.
TRANSFER CONTROL UNIT TERMINALS AND REFERENCE VALUE
Data are reference value and are measured between each terminal and ground.
CAUTION:
When using a circuit tester to measure voltage for inspection, be sure not to extend forcibly any connector terminals.Monitored item [Unit]
Content ConditionDisplay value
LINE PRES SW [ON/
OFF] Condition of line pressure
switch
A/T selector lever
“D ” position
4WD shift switch: 2WD, AUTO or 4H ON
Except the above
The vehicle has been
left at room tempera-
ture for 5 minutes and
more with ignition
switch in
“OFF ” posi-
tion.Ignition switch: ON
A/T selector lever: "P"
or "N" position
4WD shift switch: other
than AUTO OFF
Terminal
Wire
color Item
ConditionData (Approx.)
35 BR/W Line pressure switch
Ignition switch: ON
A/T selector lever “D ” posi-
tion4WD shift switch: AUTO 0V
Except the above
The vehicle has been left at
room temperature for 5 min-
utes and more with ignition
switch in “OFF ” position.
Ignition switch: ON
A/T selector lever: "P" or "N"
position
4WD shift switch: other than
AUTO Battery voltage
Page 3214 of 3383
TROUBLE DIAGNOSIS FOR SYSTEMTF-109
CE F
G H
I
J
K L
M A
B
TF
Revision: November 2009 2006 QX56
DIAGNOSTIC PROCEDURE
1. CHECK LINE PRESSURE SWITCH SIGNAL
With CONSULT-II
1. Start engine.
2. Select “DATA MONITOR ” mode for “ALL MODE AWD/4WD ” with CONSULT-II.
3. Read out ON/OFF switching action of “LINE PRES SW ” while
operating 4WD shift switch.
Without CONSULT-II
1. Start engine.
2. Check voltage between transfer control unit harness connector terminals and ground.
OK or NG
OK >> GO TO 5.
NG >> GO TO 2.
2. CHECK HARNESS BETWEEN TRANSFER CONTROL UNIT AND LINE PRESSURE SWITCH
1. Turn ignition switch “OFF”. (Stay for at least 5 seconds.)
2. Disconnect transfer control unit harness connector and the transfer terminal cord assembly harness con- nector.
3. Check continuity between transfer control unit harness connec- tor E143 terminal 35 and transfer terminal cord assembly har-
ness connector F56 terminal 1.
Also check harness for short to ground and short to power.
OK or NG
OK >> GO TO 3.
NG >> Repair or replace damaged parts.
Condition Display value
A/T selector lever “D ” position
4WD shift switch: AUTO ON
Except the above
The vehicle has been left
at room temperature for 5
minutes and more with
ignition switch in “
OFF”
position.Ignition switch: ON
A/T selector lever: "P" or "N"
position
4WD shift switch: other than
AUTO OFF
Connector Terminal Condition Voltage
(Approx.)
E143 35 -
Ground
A/T selector lever
“ D ” position 4WD shift switch:
AUTO
0V
Except the above
The vehicle has
been left at room
temperature for 5
minutes and more
with ignition switch
in
“OFF ” position.
Ignition switch:
ON
A/T selector
lever: "P" or "N"
position
4WD shift
switch: other
than AUTO Battery
voltage
WDIA0142E
SDIA2751E
Continuity should exist.
SDIA2752E
Page 3215 of 3383
TF-110
TROUBLE DIAGNOSIS FOR SYSTEM
Revision: November 20092006 QX56
3. CHECK TRANSFER CONTROL UNIT
Check transfer control unit input/output signal. Refer to TF-35, "
Transfer Control Unit Input/Output Signal Ref-
erence Values" .
OK or NG
OK >> GO TO 4.
NG >> Check the following. If any items are damaged, repair or replace damaged parts.
Transfer control unit pin terminals for damage or loose connection with harness connector.
Transfer control unit. Refer to TF-132, "Removal and Installation" .
4. CHECK LINE PRESSURE SWITCH
1. Turn ignition switch “ OFF”. (Stay for at least 5 seconds.)
2. Remove line pressure switch. Refer to TF-22, "
Location of Electrical Parts" .
3. Push and release line pressure switch and check continuity between transfer terminal cord assembly terminal 1 and ground.
OK or NG
OK >> GO TO 5.
NG >> Replace line pressure switch. Refer to TF-22, "
Location
of Electrical Parts" .
5. CHECK DTC
Perform the self-diagnosis, after driving a vehicle for a while.
OK or NG
OK >> GO TO 6.
NG >> Replace transfer control unit. Refer to TF-132, "
Removal and Installation" .
6. CRUISE TEST
Perform cruise test. Refer to TF-33, "
CRUISE TEST" .
OK or NG
OK >> Inspection End.
NG >> Perform the applicable trouble diagnosis.
COMPONENT INSPECTION
1. Turn ignition switch “OFF ”. (Stay for at least 5 seconds.)
2. Remove line pressure switch. Refer to TF-22, "
Location of Electrical Parts" .
3. Push and release line pressure switch and check continuity between transfer terminal cord assembly terminal 1 and ground.
4. If NG, replace the line pressure switch. Refer to TF-22, "
Loca-
tion of Electrical Parts" .
TerminalCondition Continuity
1 -
Ground Push line pressure switch
Yes
Release line pressure switch No
WDIA0172E
TerminalCondition Continuity
1 - Ground Push line pressure switch
Yes
Release line pressure switch No
WDIA0172E
Page 3218 of 3383
TROUBLE DIAGNOSIS FOR SYSTEMTF-113
CE F
G H
I
J
K L
M A
B
TF
Revision: November 2009 2006 QX56
CAN Communication LineEDS002IQ
DIAGNOSTIC PROCEDURE
1. CHECK CAN COMMUNICATION CIRCUIT
With CONSULT-II
1. Turn ignition switch “ON” and start engine.
2. Select “SELF-DIAG RESULTS ” mode for “ALL MODE AWD/4WD ” within CONSULT-II.
3. Perform the self-diagnosis.
Is the
“CAN COMM CIRCUIT [U1000]” displayed?
YES >> Print CONSULT-II screen and go to LAN-3, "Precautions
When Using CONSULT-II" .
NO >> Inspection End.
ATP SwitchEDS002IR
CONSULT-II REFERENCE VALUE IN DATA MONITOR MODE
Data are reference value.
TRANSFER CONTROL UNIT TERMINALS AND REFERENCE VALUE
Data are reference value and are measured between each terminal and ground.
CAUTION:
When using a circuit tester to measure voltage for inspection, be sure not to extend forcibly any connector terminals.
SDIA1850E
Monitored item [Unit] Content ConditionDisplay value
ATP SWITCH [ON/OFF] Condition of ATP switch
Vehicle stopped
Engine running
A/T selector lever “ N"
Brake pedal depressed 4WD shift switch
: 4H to 4LO or 4LO to 4H
(While actuator motor is
operating.)
ON
Except the above OFF
TerminalWire
color Item
ConditionData (Approx.)
40 L ATP switch
Vehicle stopped
Engine running
A/T selector
lever “N"
Brake pedal
depressed 4WD shift switch: 4H to 4LO or 4LO to 4H
(While actuator motor is operating.)
0V
Except the above Battery voltage
Page 3219 of 3383
TF-114
TROUBLE DIAGNOSIS FOR SYSTEM
Revision: November 20092006 QX56
DIAGNOSTIC PROCEDURE
1. CHECK ATP SWITCH SIGNAL
With CONSULT-II
1. Start engine.
2. Select “DATA MONITOR ” mode for “ALL MODE AWD/4WD ” with CONSULT-II.
3. Read out the value of “AT P S W I T C H”.
Without CONSULT-II
1. Start engine.
2. Check voltage between transfer control unit harness connector terminal and ground.
OK or NG
OK >> GO TO 5.
NG >> GO TO 2.
2. CHECK HARNESS BETWEEN TRANSFER CONTROL UNIT AND ATP SWITCH
1. Turn ignition switch “ OFF”. (Stay for at least 5 seconds.)
2. Disconnect transfer control unit harness connector and the ATP switch harness connector.
3. Check continuity between transfer control unit harness connec- tor E143 terminal 40 and ATP switch harness connector F55 ter-
minal 8.
Also check harness for short to ground and short to power.
OK or NG
OK >> GO TO 3.
NG >> Repair or replace damaged parts.
Condition Display value
Vehicle stopped
Engine running
A/T selector lever
“N"
Brake pedal
depressed 4WD shift switch
: 4H to 4LO or 4LO to 4H
(While actuator motor is operating.)
ON
Except the above OFF
SDIA2391E
Connector TerminalConditionVoltage
(Approx.)
E143 40 -
Ground
Vehicle stopped
Engine running
A/T selector lever
“ N"
Brake pedal
depressed 4WD shift switch: 4H
to 4LO or 4LO to 4H
(While actuator motor
is operating.)
0V
Except the above Battery
voltage
SDIA2755E
Continuity should exist.
SDIA2756E
Page 3220 of 3383
TROUBLE DIAGNOSIS FOR SYSTEMTF-115
CE F
G H
I
J
K L
M A
B
TF
Revision: November 2009 2006 QX56
3. CHECK GROUND CIRCUIT
1. Turn ignition switch “OFF”. (Stay for at least 5 seconds.)
2. Disconnect ATP switch harness connector.
3. Check continuity between ATP switch harness connector F55 terminal 9 and ground.
Also check harness for short to ground and short to power.
OK or NG
OK >> GO TO 4.
NG >> Repair open circuit or short to ground or short to power in harness or connectors.
4. CHECK ATP SWITCH
1. Turn ignition switch “OFF”. (Stay for at least 5 seconds.)
2. Disconnect ATP switch harness connector.
3. Remove ATP switch. Refer to TF-22, "
Location of Electrical Parts" .
4. Push and release ATP switch and check continuity between ATP switch terminals 8 and 9.
OK or NG
OK >> GO TO 5.
NG >> Replace ATP switch. Refer to TF-22, "
Location of Elec-
trical Parts" .
5. CHECK TRANSFER CONTROL UNIT
Check transfer control unit input/output signal. Refer to TF-35, "
Transfer Control Unit Input/Output Signal Ref-
erence Values" .
OK or NG
OK >> GO TO 6.
NG >> Check transfer control unit pin terminals for damage or loose connection with harness connector. If any items are damaged, repair or replace damaged parts.
6. CHECK ATP WARNING LAMP
1. Turn ignition switch “ON”. (Do not start engine.)
2. Move A/T selector lever to "P" position.
3. Set 4WD shift switch from "4H" to "4LO" or "4LO" to "4H".
Does ATP warning lamp turn ON while switching?
YES >> GO TO TF-125, "ATP Warning Lamp Turns ON" .
NO >> Inspection End.
COMPONENT INSPECTION
1. Turn ignition switch “OFF”. (Stay for at least 5 second.)
2. Disconnect ATP switch harness connector.
3. Remove ATP switch. Refer to TF-22, "
Location of Electrical Parts" .
Continuity should exist.
SDIA2394E
Terminal
Condition Continuity
8 - 9 Push ATP switch
Yes
Release ATP switch No
SDIA2757E
Page 3222 of 3383
TROUBLE DIAGNOSIS FOR SYMPTOMSTF-117
CE F
G H
I
J
K L
M A
B
TF
Revision: November 2009 2006 QX56
TROUBLE DIAGNOSIS FOR SYMPTOMSPFP:00007
4WD Shift Indicator Lamp and 4LO Indicator Lamp Do Not Turn ONEDS002HM
SYMPTOM:
4WD shift indicator lamp and 4LO indicator lamp do not turn ON for approx. 1 second when turning
ignition switch to “ON”.
DIAGNOSTIC PROCEDURE
1. CHECK TRANSFER CONTROL UNIT POWER SUPPLY CIRCUIT
1. Turn ignition switch “OFF”. (Stay for at least 5 seconds.)
2. Connect transfer control unit harness connector.
3. Check voltage between transfer control unit harness connector terminals and ground.
4. Turn ignition switch “ON”. (Do not start engine.)
5. Check voltage between transfer control unit harness connector terminals and ground.
OK or NG
OK >> GO TO 2.
NG >> Check the following. If any items are damaged, repair or replace damaged parts.
10A fuses No. 26 located in fuse and fusible link box and No. 59 located in the fuse and relay
box. Refer to PG-4, "
POWER SUPPLY ROUTING CIRCUIT" .
20A fuse No. 53 located in the IPDM E/R. Refer to PG-4, "POWER SUPPLY ROUTING CIR-
CUIT" .
Harness for short or open between battery and transfer control unit harness connector termi-
nals 47.
Harness for short or open between battery and transfer control unit harness connector terminal
29.
Harness for short or open between battery and transfer shut off relay harness connector E69
terminal 1, and 3.
Harness for short or open between transfer shut off relay harness connector E69 terminal 2
and transfer control unit harness connector terminal 30.
Harness for short or open between transfer shut off relay harness connector E69 terminal 5
and transfer control unit harness connector terminals 16 and 22.
Battery and ignition switch. Refer to PG-4, "POWER SUPPLY ROUTING CIRCUIT" .
Transfer shut off relay. Refer to TF-57, "COMPONENT INSPECTION" .
ConnectorTerminal Voltage (Approx.)
E142 16 - Ground
0V
22 - Ground
E143 29 - Ground
30 - Ground
Battery voltage
47 - Ground
WDIA0165E
Connector Terminal Voltage (Approx.)
E142 16 - Ground
Battery voltage
22 - Ground
E143 29 - Ground
30 - Ground
0V
47 - Ground Battery voltage
WDIA0166E
Page 3223 of 3383
TF-118
TROUBLE DIAGNOSIS FOR SYMPTOMS
Revision: November 20092006 QX56
2. CHECK TRANSFER CONTROL UNIT GROUND CIRCUIT
1. Turn ignition switch “ OFF”. (Stay for at least 5 seconds.)
2. Disconnect transfer control unit harness connector.
3. Check continuity between transfer control unit harness connec- tor E142 terminals 3, 6, E143 terminal 45 and ground.
Also check harness for short to ground and short to power.
OK or NG
OK >> GO TO 3.
NG >> Repair open circuit or short to ground or short to power in harness or connectors.
3. CHECK COMBINATION METER POWER SUPPLY CIRCUIT
1. Turn ignition switch “ OFF”. (Stay for at least 5 seconds.)
2. Disconnect transfer control unit harness connector.
3. Check voltage between combination meter harness connector terminal and ground.
4. Turn ignition switch “ ON”. (Do not start engine.)
5. Check voltage between combination meter harness connector terminal and ground.
OK or NG
OK >> GO TO 4.
NG >> Check the following. If any items are damaged, repair or replace damaged parts.
10A fuse No. 14 located in the fuse block (J/B). Refer
to PG-4, "
POWER SUPPLY ROUTING CIRCUIT" .
Harness for short or open between battery and combination meter harness connector M24 ter-
minal 24.
Ignition switch. Refer to PG-4, "POWER SUPPLY ROUTING CIRCUIT" .
Continuity should exist.
SDIA2691E
Connector
Terminal Voltage (Approx.)
M24 24 - Ground 0V
WDIA0151E
ConnectorTerminal Voltage (Approx.)
M24 24 - Ground Battery voltage
WDIA0152E
