WW-24
FRONT WIPER AND WASHER SYSTEM
Revision: November 20092006 QX56
ONLY FRONT WIPER HIGH DOES NOT OPERATE
1. CHECK IPDM E/R TO FRONT WIPERS
With CONSULT-II
1. Select "IPDM E/R" with CONSULT-II, and select "ACTIVE TEST" on "SELECT DIAG MODE" screen.
2. Select "FRONT WIPER" on "SELECT TEST ITEM" screen.
3. Select "HI" on "ACTIVE TEST" screen.
4. Confirm front wiper high operation.
Without CONSULT-II
1. Turn on front wipers using auto active test. Refer to PG-24,
"Auto Active Test" .
2. Confirm front wiper operation.
OK or NG
OK >> GO TO 4.
NG >> GO TO 2.
2. IPDM E/R TO FRONT WIPERS CIRCUIT INSPECTION
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R connector and front wiper motor connector.
3. Check continuity between IPDM E/R harness connector terminal and front wiper motor harness connector terminal.
OK or NG
OK >> GO TO 3.
NG >> Check for short circuit or open circuit in harness between IPDM E/R and front wiper motor.
SKIA3486E
Terminals Continuity
Connector Terminal Connector Terminal
E121 35 E232Yes
WKIA2087E
Page 3352 of 3383
FRONT WIPER AND WASHER SYSTEMWW-25
C
DE
F
G H
I
J
L
M A
B
WW
Revision: November 2009 2006 QX56
3. IPDM E/R INSPECTION
With CONSULT-II
1. Connect IPDM E/R connector and front wiper motor connector.
2. Turn ignition switch ON.
3. Select "HI" on "ACTIVE TEST" screen.
4. When front wiper high relay is operating, check voltage between IPDM E/R terminals.
Without CONSULT-II
1. Connect IPDM E/R connector and front wiper motor connector.
2. Turn on front wipers using the auto active test. Refer to PG-24, "
Auto Active Test" .
3. When front wiper high relay is operating, check voltage between IPDM E/R terminals.
OK or NG
OK >> Replace the wiper motor. Refer to WW-29, "Wiper Motor
and Linkage" .
NG >> Replace IPDM E/R. Refer to PG-30, "
Removal and Installation of IPDM E/R" .
4. COMBINATION SWITCH TO BCM INSPECTION
Select "BCM" on CONSULT-II. With "WIPER" data monitor, check
that "FR WIPER HI" turns ON-OFF according to operation of wiper
switch.
OK or NG
OK >> Replace BCM. Refer to BCS-20, "BCM" .
NG >> Replace wiper switch. Refer to WW-30, "
Wiper and
Washer Switch" .
ONLY FRONT WIPER INTERMITTENT DOES NOT OPERATE
1. COMBINATION SWITCH TO BCM INSPECTION
Select "BCM" on CONSULT-II. With "WIPER" data monitor, check
that "FR WIPER INT" turns ON-OFF according to operation of wiper
switch.
OK or NG
OK >> Replace BCM. Refer to BCS-20, "BCM" .
NG >> Replace wiper switch. Refer to WW-30, "
Wiper and
Washer Switch" .
Te r m i n a l s
Vo l ta g e
(Approx.)
(
– )(+)
Connector Terminal Connector Terminal E122 38
E121 35Battery
voltage
E124 59
WKIA3200E
WKIA1018E
WKIA1018E
Page 3354 of 3383
FRONT WIPER AND WASHER SYSTEMWW-27
C
DE
F
G H
I
J
L
M A
B
WW
Revision: November 2009 2006 QX56
2. IPDM E/R TO FRONT WIPER MOTOR AUTO STOP CIRCUIT INSPECTION
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R connector and front wiper motor connector.
3. Check continuity between IPDM E/R harness connector terminal and front wiper motor harness connector terminal.
4. Check continuity between IPDM E/R harness connector terminal and ground.
OK or NG
OK >> Connect connectors. GO TO 3.
NG >> Repair harness or connector.
3. IPDM E/R TO FRONT WIPER MOTOR AUTO STOP CIRCUIT VOLTAGE
1. Turn ignition switch ON.
2. While front wiper motor is stopped and while operating, measure voltage between IPDM E/R terminal 43 and ground.
OK or NG
OK >> Replace IPDM E/R. Refer to PG-30, "Removal and
Installation of IPDM E/R" .
NG >> Replace front wiper motor. Refer to WW-29, "
Wiper Motor and Linkage" .
Terminals
Continuity
Connector Terminal Connector Terminal
E122 43 E236Yes
WKIA2084E
Terminals
Continuity
Connector Terminal
E122 43Ground No
WKIA2088E
IPDM E/R
(– ) Condition Voltage
(Approx.)
(+)
Connector Terminal
E122 43 Ground Wiper operating
Battery
voltage
Wiper stopped 0V
WKIA2085E
Page 3359 of 3383
WW-32
REAR WIPER AND WASHER SYSTEM
Revision: November 20092006 QX56
REAR WIPER AND WASHER SYSTEMPFP:28710
Components Parts and Harness Connector LocationEKS00BEB
System DescriptionEKS00BEC
The wiper switch (combination switch) is composed of a combination of 5 output terminals and 5 input ter-
minals. Terminal combination status is read by the BCM (body control module) when switch is turned ON.
The BCM controls rear wiper ON and INT (intermittent) operation.
Power is supplied at all times
through 50A fusible link (letter f , located in fusible link box)
to BCM terminal 70.
With the ignition switch in ON or START position, power is supplied
through 10A fuse [No. 9, located in fuse block (J/B)]
to combination switch terminal 14, and
through 10A fuse (No. 59, located in the fuse and relay box)
to BCM terminal 38.
Ground is supplied
to BCM terminal 67 and
to combination switch terminal 12
through grounds M57, M61 and M79.
WKIA3462E
Page 3360 of 3383
REAR WIPER AND WASHER SYSTEMWW-33
C
DE
F
G H
I
J
L
M A
B
WW
Revision: November 2009 2006 QX56
REAR WIPER OPERATION
When the ignition switch is in the ON or START position, and the rear wiper switch is in the ON position, the
BCM detects a rear wiper ON request through the combination switch (wiper switch) reading function.
The BCM will first check the status of the glass hatch ajar switch before supplying power to the rear wiper
motor. If the glass hatch ajar switch is closed (ground) the BCM will not turn on the rear wiper motor. If the
glass hatch ajar switch is open (not grounded) the BCM will control the rear wiper motor as follows.
The BCM controls rear wiper motor operation by switching direction of current flow between the two rear wiper
motor output circuits.
Power is supplied to output circuit 1 for forward operation (counterclockwise sweep),
through BCM terminal 55
to rear wiper motor terminal 4.
Ground is supplied
to rear wiper motor terminal 6
through BCM terminal 54
through BCM terminal 67
through grounds M57, M61 and M79.
With output circuit 1 power and ground supplied, the rear wiper motor operates in a counterclockwise sweep
direction until auto stop switch 1 closes (full sweep position). Auto stop switch 1 supplies ground
to BCM terminal 44
through rear wiper motor terminal 2
through rear wiper motor terminal 5
through grounds B117 and B132.
When the BCM receives this ground signal it turns off output circuit 1 and turns on output circuit 2.
Power is supplied to output circuit 2 for reverse operation (clockwise sweep),
through BCM terminal 54
to rear wiper motor terminal 6.
Ground is supplied
to rear wiper motor terminal 4
through BCM terminal 55
through BCM terminal 67
through grounds M57, M61 and M79.
With output circuit 2 power and ground supplied the rear wiper motor operates in a clockwise sweep direction
until auto stop switch 2 closes (full sweep position). Auto stop switch 2 supplies ground
to BCM terminal 26
through rear wiper motor terminal 1
through rear wiper motor terminal 3
through grounds B117 and B132.
When the BCM receives this ground signal it turns off output circuit 2 and turns on output circuit 1. This pro-
cess repeats until the rear wiper switch or ignition switch is turned off.
If the ignition switch is turned to OFF during operation, the rear wiper motor will immediately stop. If the igni-
tion switch is turned ON after this condition, and the BCM does not receive a rear wiper switch ON or INT sig-
nal, the BCM will operate the rear wiper to the auto stop position.
If the BCM does not receive a change in status in either auto stop switch 1 or auto stop switch 2 within a 5 sec-
ond period of output circuit 1 or output circuit 2 operation, the BCM will turn off output circuit 1 and output cir-
cuit 2.
If the BCM detects the rear door glass ajar signal during rear wiper motor operation, the BCM will operate the
rear wiper motor to the auto stop position. Once the rear door glass ajar signal returns to open (not grounded)
for 5 or more seconds, the BCM will resume rear wiper motor operation.
INTERMITTENT OPERATION
The rear wiper motor operates the wiper arm at low speed approximately every 7 seconds.
When the wiper switch is in the rear wiper INT position, the BCM detects a rear wiper INT request through the
combination switch (wiper switch) reading function.
Page 3361 of 3383
WW-34
REAR WIPER AND WASHER SYSTEM
Revision: November 20092006 QX56
The BCM controls rear wiper motor operation by switching direction of current flow between the two rear wiper
motor output circuits.
Power is supplied to output circuit 1 for forward operation (counterclockwise sweep),
through BCM terminal 55
to rear wiper motor terminal 4.
Ground is supplied
to rear wiper motor terminal 6
through BCM terminal 54
through BCM terminal 67
through grounds M57, M61 and M79.
With output circuit 1 power and ground supplied, the rear wiper motor operates in a counterclockwise sweep
direction until auto stop switch 1 closes (full sweep position). Auto stop switch 1 supplies ground
to BCM terminal 44
through rear wiper motor terminal 2
through rear wiper motor terminal 5
through grounds B117 and B132.
When the BCM receives this ground signal it turns off output circuit 1 and turns on output circuit 2.
Power is supplied to output circuit 2 for reverse operation (clockwise sweep),
through BCM terminal 54
to rear wiper motor terminal 6.
Ground is supplied
to rear wiper motor terminal 4
through BCM terminal 55
through BCM terminal 67
through grounds M57, M61 and M79.
With output circuit 2 power and ground supplied the rear wiper motor operates in a clockwise sweep direction
until auto stop switch 2 closes (full sweep position). Auto stop switch 2 supplies ground
to BCM terminal 26
through rear wiper motor terminal 1
through rear wiper motor terminal 3
through grounds B117 and B132.
When the BCM receives this ground signal it turns off output circuit 2 and starts the timing function of 7 sec-
onds. After approximately 7 seconds the BCM turns on output circuit 1. This process repeats until the rear
wiper switch or ignition switch is turned off.
AUTO STOP OPERATION
When the rear wiper switch is turned off, the BCM will continue the cycle of output circuit 1 or output circuit 2
until auto stop switch 1 and auto stop switch 2 are both in the closed position. When the BCM receives ground
signals from auto stop switch 1 and auto stop switch 2 simultaneously, output circuit 1 and output circuit 2 are
both turned off.
REAR WASHER OPERATION
When the ignition switch is in the ON or START position, and the front and rear washer switches are OFF, the
front and rear washer motor is supplied power
through 10A fuse (No. 9, located in the fuse block J/B)
through combination switch (wiper switch) terminal 14
through combination switch (wiper switch) terminal 11
to front and rear washer motor terminal 2, and
through combination switch (wiper switch) terminal 13
to front and rear washer motor terminal 1.
When the rear wiper switch is in rear washer position, the BCM detects a rear washer signal by BCM wiper
switch reading function. Combination switch ground is supplied
to front and rear washer motor terminal 1
Page 3365 of 3383
WW-38
REAR WIPER AND WASHER SYSTEM
Revision: November 20092006 QX56
Terminals and Reference Values for BCMEKS00BEE
Te r m i -
nal No. Wire
color Signal name Measuring condition
Reference Value (V)
(Approx.)
Ignition
switch Operation or condition
2 SB Combination switch input 5 ON
Light switch and wiper switch OFF
Wiper dial position 4
3 G/Y Combination switch input 4 ON
Light switch and wiper switch OFF
Wiper dial position 4
4 Y Combination switch input 3 ON
Light switch and wiper switch OFF
Wiper dial position 4
5 G/B Combination switch input 2 ON
Light switch and wiper switch OFF
Wiper dial position 4
6 V Combination switch input 1 ON
26 Y/L Rear wiper auto stop
switch 2
ONRise up position (rear wiper arm on
stopper) 0V
A Position (full clockwise stop position) 0V
Forward sweep (counterclockwise direction) Fluctuating
B Position (full counterclockwise stop position) Battery voltage
Reverse sweep (clockwise direction) Fluctuating
32 R/G Combination switch output 5 ON
Light switch and wiper switch OFF
Wiper dial position 4
SKIA5291E
SKIA5292E
SKIA5291E
SKIA5292E
SKIA5291E
Page 3366 of 3383
REAR WIPER AND WASHER SYSTEMWW-39
C
DE
F
G H
I
J
L
M A
B
WW
Revision: November 2009 2006 QX56
33 R/Y Combination switch output 4 ONLight switch and wiper switch OFF
Wiper dial position 4
34 L Combination switch output 3 ON
Light switch and wiper switch OFF
Wiper dial position 4
35 O/B Combination switch output 2 ON
Light switch and wiper switch OFF
Wiper dial position 4
36 R/W Combination switch output 1 ON
38 W/L Ignition switch (ON) ON— Battery voltage
42 GR Glass hatch ajar switch
signal ONHatch glass closed
Battery voltage
Hatch glass open 0V
44 O Rear wiper auto stop
switch 1 ONRise up position (rear wiper arm on
stopper) 0V
A Position (full clockwise stop position) Battery voltage
Forward sweep (counterclockwise direction) Fluctuating
B Position (full counterclockwise stop position) 0V
Reverse sweep (clockwise direction) Fluctuating
54 Y Rear wiper output circuit 2 ON Rise up position (rear wiper arm on
stopper) 0V
A Position (full clockwise stop position) 0V
Forward sweep (counterclockwise direction) 0V
B Position (full counterclockwise stop position) Battery voltage
Reverse sweep (clockwise direction) Battery voltage
Te r m i -
nal No. Wire
color Signal name Measuring condition
Reference Value (V)
(Approx.)
Ignition
switch Operation or condition
SKIA5292E
SKIA5291E
SKIA5292E
Page 3367 of 3383
WW-40
REAR WIPER AND WASHER SYSTEM
Revision: November 20092006 QX56
How to Proceed With Trouble DiagnosisEKS00BEF
1. Confirm the symptoms and customer complaint.
2. Understand operation description and function description. Refer to WW-32, "
System Description" .
3. Perform the Preliminary Check. Refer to WW-40, "
Preliminary Inspection" .
4. Check symptom and repair or replace the cause of malfunction.
5. Does the rear wiper operate normally? If YES: GO TO 6. If NO: GO TO 4.
6. Inspection End.
Preliminary InspectionEKS00BEG
INSPECTION FOR POWER SUPPLY AND GROUND CIRCUIT
Inspection procedure
1. CHECK FUSE
Check if wiper or washer fuse is blown.
OK or NG
OK >> GO TO 2.
NG >> If fuse is blown, be sure to eliminate cause of problem before installing new fuse. Refer to PG-4,
"POWER SUPPLY ROUTING CIRCUIT" .
55 SB Rear wiper output circuit 1 ONRise up position (rear wiper arm on
stopper) 0V (except battery voltage at ini-
tial rear wiper ON to lift arm off
stop)
A Position (full clockwise stop position) Battery voltage
Forward sweep (counterclockwise direction) Battery voltage
B Position (full counterclockwise stop position) 0V
Reverse sweep (clockwise direction) 0V
67 B Ground ON— 0V
70 W/B Battery power OFF— Battery voltage
Te r m i -
nal No. Wire
color Signal name Measuring condition
Reference Value (V)
(Approx.)
Ignition
switch Operation or condition
Unit
Power source Fuse No.
Front and rear washer motor Ignition ON or START 9
BCM Ignition ON or START
59
Battery f
Page 3368 of 3383
REAR WIPER AND WASHER SYSTEMWW-41
C
DE
F
G H
I
J
L
M A
B
WW
Revision: November 2009 2006 QX56
2. CHECK POWER SUPPLY CIRCUIT
1. Disconnect BCM connectors.
2. Check voltage between BCM harness connector terminals and ground.
OK or NG
OK >> GO TO 3.
NG >> Check harness for open or short between BCM and fuse.
3. GROUND CIRCUIT INSPECTION (BCM)
Check for continuity between the BCM terminal and ground.
OK or NG
OK >> Inspection End.
NG >> Repair/replace BCM ground circuit.
Terminals Ignition switch position
(+) (– )O FF O N
Connector Terminal
M18 38 Ground0V
Battery voltage
M20 70 Battery voltage Battery voltage
WKIA2089E
Terminals
Ignition switch
condition Continuity
Connector Terminal
M20 67 Ground OFF Yes
WKIA2090E
