torque INFINITI QX56 2006 Factory Service Manual

TF-168
TRANSFER ASSEMBLY
Revision: November 20092006 QX56
6. Align the dowel pin hole and bolt hole of the sub oil pump
assembly with the center case. Install the sub oil pump cover.
Then tighten to the specified torque. Refer to TF-146, "
COMPO-
NENTS" .
7. Apply ATF to the new O-ring and install it to the transfer motor. CAUTION:
Do not reuse O-ring.
8. Fit the double-flat end of the transfer motor shaft into the slot of the sub-oil pump assembly. Then tighten to the specified torque.
Refer to TF-146, "
COMPONENTS" .
CAUTION:
Be sure to install connector bracket.
9. Assemble the control valve assembly with the following procedure. CAUTION:

Do not reuse any part that has been dropped or damaged.

Make sure valve is assembled in the proper direction.

Do not use a magnet because residual magnetism stays during assembly.
a. Clean the upper body, control valves and springs with cleaning agent, and dry with compressed air.
b. Dip the control valves in ATF, and apply ATF to the valve-mount- ing area of the upper body.
c. Install each control valve, spring, and plug to the upper body, and install retainer plates to hold them in place.
CAUTION:

To insert control valves into upper body, place upper
body on a level surface in order to prevent flaw or dam-
age.

Make sure each control valve is smoothly inserted.
SDIA2328E
SDIA2787E
SDIA3317E
SDIA2127E

TF-170
TRANSFER ASSEMBLY
Revision: November 20092006 QX56
11. Install the control valve assembly to the center case, and tighten
to the specified torque. Refer to TF-146, "
COMPONENTS" .
CAUTION:

Do not reuse any part that has been dropped or damaged.

Make sure valve is assembled in the proper direction.

Do not use a magnet because residual magnetism stays
during assembly.
12. Install the connector assembly into the center case, and secure with a snap ring.
13. Apply ATF to the new O-rings, and install them on the oil strainer.
CAUTION:
Do not reuse O-rings.
14. Install the oil strainer to the control valve assembly.
15. Tighten the bolts to the specified torque. Refer to TF-146,
"COMPONENTS" .
16. Apply ATF to the new D-rings, and install them to the clutch pis- ton.
CAUTION:
Do not reuse D-rings.
SDIA2121E
SDIA2122E
SDIA2782E
SDIA2119E
SDIA2781E

TRANSFER ASSEMBLYTF-171
CE F
G H
I
J
K L
M A
B
TF
Revision: November 2009 2006 QX56
17. Install the thrust needle bearing race to the clutch piston.
18. Install the clutch piston to the center case as shown.
CAUTION:
Install so the fitting protrusion of clutch piston aligns with
the dent of center case.
19. Remove all the sealant from the oil pressure check port and inside the center case.
CAUTION:
Remove old sealant adhering to mating surfaces. Also
remove any moisture, oil, or foreign material adhering to
application and mating surfaces.
20. Thread the new oil pressure check plug in 1 or 2 pitches and apply sealant to the oil pressure check plug threads. Tighten to
the specified torque. Refer to TF-146, "
COMPONENTS" .

Use Genuine Silicone RTV or equivalent. Refer to GI-46,
"RECOMMENDED CHEMICAL PRODUCTS AND SEAL-
ANTS" .
CAUTION:
Do not reuse oil pressure check plug.
21. Install the new snap ring to the clutch hub using suitable tool. CAUTION:
Do not reuse snap ring.
SDIA2189E
SDIA2190E
SDIA3188E
WDIA0101E

TRANSFER ASSEMBLYTF-175
CE F
G H
I
J
K L
M A
B
TF
Revision: November 2009 2006 QX56
37. Install the inner gear and outer gear in the main oil pump hous-
ing. Then measure the side clearance. Refer to TF-165, "
Main
Oil Pump" .
38. Install the main oil pump housing, outer gear and inner gear to the center case.
39. Install the main oil pump cover to the center case, and tighten to the specified torque. Refer to TF-146, "
COMPONENTS" .
40. Remove all the sealant from the switch mating area and inside the center case.
CAUTION:
Remove old sealant adhering to mating surfaces. Also
remove any moisture, oil, or foreign material adhering to
application and mating surfaces.
41. Thread the ATP switch and neutral-4LO switch in one to two pitches and apply sealant to the threads of the switches. Tighten
to the specified torque. Refer to TF-146, "
COMPONENTS" .

Use Genuine Silicone RTV or equivalent. Refer to GI-46,
"RECOMMENDED CHEMICAL PRODUCTS AND SEAL-
ANTS" .
NOTE:

Neutral-4LO switch harness connector is gray.

ATP switch harness connector is black.
SDIA2174E
SDIA2188E
SDIA2130E
SDIA3435E

TF-180
TRANSFER ASSEMBLY
Revision: November 20092006 QX56
18. Apply liquid gasket to the entire center case mating surface of
the front case assembly as shown.

Use Genuine Anaerobic Liquid Gasket or equivalent.
Refer to GI-46, "
RECOMMENDED CHEMICAL PRODUCTS
AND SEALANTS" .
CAUTION:
Remove all foreign materials such as water, oil and grease
from center case and front case mating surfaces.
19. Install the center case assembly to the front case assembly. CAUTION:
Do not damage mainshaft end.
20. Tap the center case lightly and press-fit the front drive shaft bearing into the front case.
21. Tighten the front case bolts to the specified torque. Refer to TF-
146, "COMPONENTS" .
CAUTION:
Be sure to install harness bracket and air breather hose
clamp.
22. Install the drain plug with a new gasket. CAUTION:
Do not reuse gasket.
23. Align the matching mark on the front drive shaft with the mark on the companion flange, then install the companion flange.
WDIA0157E
SDIA2138E
SDIA2100E
SDIA2779E

TRANSFER ASSEMBLYTF-181
CE F
G H
I
J
K L
M A
B
TF
Revision: November 2009 2006 QX56
24. Install the new companion flange self-lock nut. Tighten to the
specified torque using Tool. Refer to TF-146, "
COMPONENTS" .
CAUTION:
Do not reuse self-lock nut.
25. Remove all the sealant from the check plug, switch mating sur- face and front case.
CAUTION:
Remove old sealant adhering to mating surfaces. Also
remove any moisture, oil, or foreign material adhering to
application and mating surfaces.
26. Install the check ball and check spring to the front case. Apply silicone gasket, to the check plug and wait detection switch and
install them to the front case. Tighten to the specified torque.
Refer to TF-146, "
COMPONENTS" .

Use Genuine Silicone RTV or equivalent. Refer to GI-46,
"RECOMMENDED CHEMICAL PRODUCTS AND SEAL-
ANTS" .
NOTE:
Wait detection switch harness connector is black.
27. Install the new oil seal in the front case using Tool.
CAUTION:

Do not reuse oil seal.

Apply petroleum jelly to seal lip before installing.
28. Install the shift lever to the shift cross.
29. Install the lock pin and lock pin nut. Tighten to the specified torque. Refer to TF-146, "
COMPONENTS" .
Rear Case
1. Apply petroleum jelly to the circumference of the new rear oil
seal. Install the new rear oil seal so that it is flush with the case
tip face using Tool.
CAUTION:

Do not reuse oil seal.

Apply petroleum jelly to seal lip before installing.Tool number : KV40104000 ( — )
WDIA0219E
Tool number : ST22360002 (J-25679-01)
WDIA0158E
SDIA2182E
Tool number : ST30720000 (J-25405)
SDIA2204E

TF-182
TRANSFER ASSEMBLY
Revision: November 20092006 QX56
2. Apply petroleum jelly to the circumference of the new dust cover.
Position the new dust cover using the identification mark as
shown.
CAUTION:

Do not reuse dust cover.

Position the identification mark at the position shown.
3. Install the dust cover using Tool.
4. Install the breather tube into the rear case.
5. Remove all the sealant from the rear case to center case mating surfaces.
CAUTION:
Remove all foreign materials such as water, oil, and grease
from center case and rear case mating surfaces.
6. Apply liquid gasket to the entire rear case mating surface of the center case.

Use Genuine Anaerobic Liquid Gasket or equivalent.
Refer to GI-46, "
RECOMMENDED CHEMICAL PRODUCTS
AND SEALANTS" .
CAUTION:
Do not to allow Liquid Gasket to enter stem bleeder hole.
7. Install the rear case to the center case. Tighten the bolts to the specified torque. Refer to TF-146, "
COMPONENTS" .
SDIA3436E
Tool number : KV40105310 ( — )
SDIA2205E
SDIA2206E
SDIA2092E

WHEEL AND TIRE ASSEMBLYWT-7
C
DF
G H
I
J
K L
M A
B
WT
Revision: November 2009 2006 QX56
c. If calculated balance weight value exceeds 50 g (1.76 oz), install
two balance weight sheets in line with each other as shown.
CAUTION:
Do not install one balance weight sheet on top of another.
3. Start wheel balancer again.
4. Install drive-in balance weight on inner side of road wheel in the wheel balancer indication position (angle).
CAUTION:
Do not install more than two balance weights.
5. Start wheel balancer. Make sure that inner and outer residual imbalance values are 5 g (0.18 oz) each or below.

If either residual imbalance value exceeds 5 g (0.18 oz), repeat installation procedures.
Wheel balance (Maximum allowable imbalance):
RotationEES001Q1
NOTE:
Follow the maintenance schedule for tire rotation service intervals. Refer to MA-7, "
PERIODIC MAINTE-
NANCE" .
1. Rotate the tires on each side from front to back as shown. Do not include the spare tire when rotating the tires.
CAUTION:
When installing wheels, tighten them diagonally by dividing
the work two to three times in order to prevent the wheels
from developing any distortion.
2. Adjust the tire pressure to specification. Refer to WT-38, "
Tire" .
3. After the tire rotation, retighten the wheel nuts after the vehicle has been driven for 1,000 km (600 miles), and also after every
wheel and tire have been installed such as after repairing a flat
tire.
Maximum allowable imbalance Dynamic (At rim flange)
5 g (0.18 oz) (one side)
Static 10 g (0.35 oz)
SMA056D
Wheel nut torque : 133 N·m (14 kg-m, 98 ft-lb)
SMA829C

WW-28
FRONT WIPER AND WASHER SYSTEM
Revision: November 20092006 QX56
Front Wiper Arms EKS00GBH
REMOVAL AND INSTALLATION
Removal
1. Remove wiper arm covers and wiper arm nuts.
2. Remove front RH wiper arm and front LH wiper arm.
3. Remove front RH blade assembly and front LH blade assembly.
Installation
1. Operate wiper motor one full cycle, then turn "OFF" (Auto Stop).
2. Clean up the pivot area as shown. This will reduce possibility of
wiper arm looseness.
3. Install front RH blade assembly and front LH blade assembly.
4. Install front RH wiper arm and front LH wiper arm.
5. Tighten wiper arm nuts to specified torque, and install wiper arm covers.
6. Ensure that wiper blades stop within proper clearance. Refer to WW-28, "
FRONT WIPER ARM ADJUST-
MENT" .
FRONT WIPER ARM ADJUSTMENT
1. Operate wiper motor one full cycle, then turn "OFF" (Auto Stop).
2. Lift the wiper blade up and then rest it onto glass surface, check
the blade clearance "L1" and "L2".
3. Remove wiper arm covers and wiper arm nuts.
4. Adjust front wiper arms on wiper motor pivot shafts to obtain above specified blade clearances.
5. Tighten wiper arm nuts to specified torque, and install wiper arm covers.
SEL024J
Front wiper arm nuts : 23.6 N·m (2.4 kg-m, 17 ft-lb)
Clearance "L1" : 41.5 - 56.5 mm (1.634 - 2.224 in)
Clearance "L2" : 52.5 - 67.5 mm (2.067 - 2.657 in)
SEL543TA
Front wiper arm nuts : 23.6 N·m (2.4 kg-m, 17 ft-lb)
