Page 1970 of 3383
CYLINDER BLOCKEM-79
C
DE
F
G H
I
J
K L
M A
EM
Revision: November 2009 2006 QX56
* Refer to GI-46, "Recommended Chemical Products and Sealants" .
DISASSEMBLY
NOTE:
Explained here is how to disassemble with engine stand supporting transmission surface. When using differ-
ent type of engine stand, some steps may be different.
1. Remove engine assembly and mount to engine stand. Refer to EM-74, "
Removal and Installation" .
CAUTION:
Before removing the hanging chains, make sure engine stand is stable and there is no risk of over-
turning.
2. Drain engine oil. Refer to LU-8, "
Changing Engine Oil" .
3. Drain engine coolant by removing the cylinder block drain plugs “A”, “B ”, “C” and “D ” as shown.
4. Remove the following components and associated parts (the parts referred to in step 1 are not included here).
Oil pan (upper and lower) and oil strainer. Refer to EM-24, "Removal and Installation" .
Crankshaft pulley, front cover and timing chain. Refer to EM-37, "Removal and Installation" .
Camshaft. Refer to EM-46, "Removal and Installation" .
Cylinder head. Refer to EM-64, "Removal and Installation" .
5. Remove knock sensor and sub harness.
CAUTION:
Carefully handle sensor, avoiding shocks.
6. Check connecting rod side clearance. Refer to EM-94, "
CONNECTING ROD SIDE CLEARANCE" .
7. Remove piston and connecting rod assembly as follows.
a. Position the crankshaft pin corresponding to the connecting rod to be removed onto bottom dead center.
1. Knock sensor sub-harness 2. Knock sensor 3. Cylinder block
4. Main bearing upper 5. Top ring 6. Second ring
7. Oil ring 8. Crankshaft key 9. Piston
10. Connecting rod 11. Snap ring 12. Piston pin
13. Connecting rod bearing 14. Connecting rod bearing cap 15. Main bearing cap
16. Thrust bearing lower 17. Main bearing lower 18. Crankshaft
19. Pilot converter 20. Thrust bearing upper 21. Side bolt
22. Drive plate 23. Reinforcement plate 24. Rear oil seal retainer
25. Rear oil seal 26. Transmission 27. O-ring
28. Crankshaft position sensor (POS) 29. Gasket 30. Cylinder block heater
31. Connector cap
WBIA0419E
KBIA2549E
Page 1973 of 3383
EM-82Revision: November 2009
CYLINDER BLOCK
2006 QX56
18. Remove pilot converter using Tool if necessary.
ASSEMBLY
1. Fully air-blow the coolant and oil passages in the cylinder block, cylinder bore, and crankcase to removeany foreign material.
CAUTION:
Use goggles to protect your eyes.
2. Install each plug to the cylinder block (only screw-type plugs are shown).
Apply liquid gasket.
Use Genuine Thread Sealant or equivalent. Refer to GI-
46, "Recommended Chemical Products and Sealants".
Replace copper washers with new ones.
Tighten each plug as specified below.
3. Install main bearings and thrust bearings.
a. Remove any dust, dirt, and oil on the bearing mating surfaces of the cylinder block and main bearing caps.
b. Install thrust bearings to both sides of the No. 3 journal housing on the cylinder block and main bearing caps
Install thrust bearings with the oil groove facing the crankshaft
arm (outside).
Install thrust bearings with a protrusion in the center on the
main bearing caps.
c. Install main bearings paying attention to the direction.
Install the one with oil holes onto the cylinder block and the
one without oil holes onto the main bearing cap.
Before installing bearings, apply engine oil to bearing surface
(inside). Do not apply oil to the back surface, but thoroughly
clean it.
When installing, align the bearing stopper to the notch.
Ensure the oil holes on the cylinder block and those on the
corresponding bearing are aligned. Tool number : ST16610001 (J-23907)
WBIA0596E
Part Washer
Tightening torque
A Yes 53.9 N·m (5.5 kg-m, 40 ft-lb)
BNo 19.6 N ·m (2.0 kg-m, 15 ft-lb)
C Yes 62.7 N·m (6.4 kg-m, 46 ft-lb)
D Yes 62.7 N·m (6.4 kg-m, 46 ft-lb)
WBIA0419E
PBIC0093E
PBIC0094E
Page 2148 of 3383
PRECAUTIONSGW-3
C
DE
F
G H
J
K L
M A
B
GW
Revision: November 2009 2006 QX56
PRECAUTIONSPFP:00001
Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT
BELT PRE-TENSIONER”
EIS004TI
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER ”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WARNING:
To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance must be per-
formed by an authorized NISSAN/INFINITI dealer.
Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the SRS section.
Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
harness connectors.
Handling for Adhesive and PrimerEIS004TJ
Do not use an adhesive which is past its usable date. Shelf life of this product is limited to six months after
the date of manufacture. Carefully adhere to the expiration or manufacture date printed on the box.
Keep primers and adhesive in a cool, dry place. Ideally, they should be stored in a refrigerator.
Open the seal of the primer and adhesive just before application. Discard the remainder.
Before application, be sure to shake the primer container to stir the contents. If any floating material is
found, do not use it.
If any primer or adhesive contacts the skin, wipe it off with gasoline or equivalent and wash the skin with
soap.
When using primer and adhesive, always observe the precautions in the instruction manual.
Page 2411 of 3383
LT-4
PRECAUTIONS
Revision: November 20092006 QX56
PRECAUTIONS PFP:00011
Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT
BELT PRE-TENSIONER”
EKS00B7P
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER ”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WARNING:
To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance must be per-
formed by an authorized NISSAN/INFINITI dealer.
Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the SRS section.
Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
harness connectors.
General precautions for service operationsEKS00B7Q
Never work with wet hands.
Xenon headlamp includes high voltage generating part. Be sure
to disconnect battery negative cable (negative terminal) or
power fuse before removing, installing, or touching the xenon
headlamp (including lamp bulb).
Turn the lighting switch OFF before disconnecting and connect-
ing the connector.
When turning the xenon headlamp on and while it is illuminated,
never touch the harness, bulb, and socket of the headlamp.
When checking the headlamp on/off operation, check it on vehi-
cle and with the power connected to the vehicle-side connector.
Do not touch the headlamp bulb glass surface with bare hands or allow oil or grease to get on it. Do not
touch the headlamp bulb just after the headlamp is turned off, because it is very hot.
Install the xenon headlamp bulb socket correctly. If it is installed
improperly, high-voltage leak or corona discharge may occur
that can melt the bulb, connector, and housing. Do not illuminate
the xenon headlamp bulb out of the headlamp housing. Doing
so can cause fire and harm your eyes.
When the bulb has burned out, wrap it in a thick vinyl bag and
discard. Do not break the bulb.
Leaving the bulb removed from the headlamp housing for a long
period of time can deteriorate the performance of the lens and
reflector (dirt, clouding). Always prepare a new bulb and have it
on hand when replacing the bulb.
Do not use organic solvent (paint thinner or gasoline) to clean
lamps and to remove old sealant.
WKIA0460E
EL-3422D
Page 2413 of 3383
LT-6
HEADLAMP (FOR USA)
Revision: November 20092006 QX56
to BCM terminal 70.
With the ignition switch in the ON or START position, power is supplied
to ignition relay, located in the IPDM E/R, and
through 10A fuse (No. 59, located in the fuse and relay box)
to BCM terminal 38.
Ground is supplied
to BCM terminal 67
through grounds M57, M61 and M79, and
to IPDM E/R terminals 38 and 59
through grounds E9, E15 and E24.
Low Beam Operation
With the lighting switch in 2ND position, the BCM receives input requesting the headlamps to illuminate. This
input is communicated to the IPDM E/R across the CAN communication lines. The CPU of the IPDM E/R con-
trols the headlamp low relay coil. When energized, this relay directs power
through 15A fuse (No. 41, located in the IPDM E/R)
through IPDM E/R terminal 54
to front combination lamp RH terminal 5, and
through 15A fuse (No. 40, located in the IPDM E/R)
through IPDM E/R terminal 52
to front combination lamp LH terminal 5.
Ground is supplied
to front combination lamp LH and RH terminal 1
through grounds E9, E15 and E24.
With power and ground supplied, low beam headlamps illuminate.
High Beam Operation/Flash-to-Pass Operation
With the lighting switch in 2ND position and placed in HIGH or PASS position, the BCM receives input request-
ing the headlamp high beams to illuminate. This input is communicated to the IPDM E/R across the CAN com-
munication lines. The CPU of the combination meter controls the ON/OFF status of the HIGH BEAM indicator.
The CPU of the IPDM E/R controls the headlamp high relay coil. When energized, this relay directs power
through 10A fuse (No. 34, located in the IPDM E/R)
through IPDM E/R terminal 56
to front combination lamp RH terminal 6, and
through 10A fuse (No. 35, located in the IPDM E/R)
through IPDM E/R terminal 55
to front combination lamp LH terminal 6.
Ground is supplied
to front combination lamp LH and RH terminal 2
through grounds E9, E15 and E24.
With power and ground supplied, the high beam headlamps illuminate.
XENON HEADLAMP
Xenon type headlamp is adopted to the low beam headlamps. Xenon bulbs do not use a filament. Instead,
they produce light when a high voltage current is passed between two tungsten electrodes through a mixture
of xenon (an inert gas) and certain other metal halides. In addition to added lighting power, electronic control
of the power supply gives the headlamps stable quality and tone color.
Following are some of the many advantages of the xenon type headlamp.
The light produced by the headlamps is a white color comparable to sunlight that is easy on the eyes.
Light output is nearly double that of halogen headlamps, affording increased area of illumination.
The light features a high relative spectral distribution at wavelengths to which the human eye is most sen-
sitive. This means that even in the rain, more light is reflected back from the road surface toward the vehi-
cle, for added visibility.
Page 2600 of 3383
MA-1
MAINTENANCE
L MAINTENANCE
CONTENTS
C
DE
F
G H
I
J
K
M
SECTION
A
B
MA
Revision: November 2009 2006 QX56
PRECAUTIONS .....................................................
..... 3
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” ............................................................. ..... 3
PREPARATION ...................................................... ..... 4
Special Service Tools .......................................... ..... 4
Commercial Service Tool .................................... ..... 4
GENERAL MAINTENANCE .................................. ..... 5
General Maintenance .......................................... ..... 5
PERIODIC MAINTENANCE .................................. ..... 7
Introduction of Periodic Maintenance .................. ..... 7
Maintenance For Off-road Driving (4WD only) .... ..... 7
Schedule 1 .......................................................... ..... 7
EMISSION CONTROL SYSTEM MAINTE-
NANCE ............................................................. ..... 7
CHASSIS AND BODY MAINTENANCE .......... ..... 8
Schedule 2 .......................................................... ..... 9
EMISSION CONTROL SYSTEM MAINTE-
NANCE ............................................................. ..... 9
CHASSIS AND BODY MAINTENANCE .......... ... 10
RECOMMENDED FLUIDS AND LUBRICANTS ... ....11
Fluids and Lubricants .......................................... .... 11
SAE Viscosity Number ........................................ ... 12
GASOLINE ENGINE OIL ................................. ... 12
ANTI-FREEZE COOLANT MIXTURE RATIO .. ... 12
ENGINE MAINTENANCE ...................................... ... 13
Checking Drive Belts ........................................... ... 13
DRIVE BELT TENSION ................................... ... 13
Changing Engine Coolant ................................... ... 13
DRAINING ENGINE COOLANT ...................... ... 13
REFILLING ENGINE COOLANT ..................... ... 14
FLUSHING COOLING SYSTEM ...................... ... 15
Checking Fuel Lines ............................................ ... 16
Changing Fuel Filter ............................................ ... 16
Changing Engine Air Cleaner Filter ..................... ... 16
VISCOUS PAPER TYPE .................................. ... 16
Changing Engine Oil ........................................... ... 17
Changing Oil Filter .............................................. ... 17
REMOVAL ........................................................ ... 17
INSTALLATION ................................................ ... 17INSPECTION AFTER INSTALLATION .............
... 18
Changing Spark Plugs ......................................... ... 18
REMOVAL ........................................................ ... 19
INSPECTION AFTER REMOVAL .................... ... 19
INSTALLATION ................................................ ... 19
Checking EVAP Vapor Lines ............................... ... 20
CHASSIS AND BODY MAINTENANCE ................ ... 21
Changing In-cabin Microfilter ............................... ... 21
Checking Exhaust System ................................... ... 22
Checking Automatic Transmission Fluid (ATF) .... ... 22
Changing Automatic Transmission Fluid (ATF) ... ... 24
Changing Transfer Fluid ...................................... ... 24
DRAINING ........................................................ ... 24
FILLING ............................................................ ... 25
Checking Transfer Fluid ...................................... ... 25
FLUID LEAKAGE AND FLUID LEVEL ............. ... 25
Checking Propeller Shaft ..................................... ... 25
Checking Final Drive Oil ...................................... ... 25
Changing Final Drive Oil ...................................... ... 26
Balancing Wheels ................................................ ... 26
REMOVAL ........................................................ ... 26
WHEEL BALANCE ADJUSTMENT .................. ... 26
Tire Rotation ........................................................ ... 28
Checking Brake Fluid Level and Leaks ............... ... 28
Checking Brake Lines and Cables ...................... ... 28
Checking Disc Brake ........................................... ... 28
ROTOR ............................................................. ... 28
CALIPER .......................................................... ... 29
PAD .................................................................. ... 29
Checking Steering Gear and Linkage .................. ... 29
STEERING GEAR ............................................... 29
STEERING LINKAGE ......................................... 29
Checking Power Steering Fluid and Lines ........... ... 29
CHECKING FLUID LEVEL ............................... ... 29
CHECKING LINES ........................................... ... 30
Checking Axle and Suspension Parts ................. ... 30
FRONT AND REAR AXLE AND SUSPENSION
PARTS .............................................................. ... 30
DRIVE SHAFT .................................................. ... 30
Page 2610 of 3383
RECOMMENDED FLUIDS AND LUBRICANTSMA-11
C
DE
F
G H
I
J
K
M A
B
MA
Revision: November 2009 2006 QX56
RECOMMENDED FLUIDS AND LUBRICANTSPFP:00000
Fluids and LubricantsELS001BN
*1: For further details, refer to MA-12, "SAE Viscosity Number" .
*2: Using automatic transmission fluid other than Genuine NISSAN Matic J ATF will cause deterioration in driveability and automatic
transmission durability, and may damage the automatic transmission, which is not covered by the NISSAN new vehicle limited warr anty.
*3: For Canada, NISSAN Automatic Transmission Fluid (ATF), DEXRON
TM III or MERCONTM or equivalent ATF may also be used.
*4: Available in mainland U.S.A. through your NISSAN dealer.
*5: For further details, see “Air conditioner specification label ”.
*6: For hot climates, viscosity SAE 90 is suitable for ambient temperatures above 0 ° C (32° F).
*7: DEXRON
TM III, MERCONTM or equivalent may also be used. Outside the continental United States and Alaska contact a NISSAN
dealership for more information regarding suitable fluids, including recommended brand(s) of DEXRONTM III or MERCONTM Automatic
Transmission Fluid.
*8: For improved vehicle performance, NISSAN recommends the use of unleaded premium gasoline with an octane rating of at least 91
AKI (RON 96). For further details, refer to GI-5, "
Precautions for Fuel (Unleaded Premium Gasoline Required)" .
*9: See your INFINITI dealer for service for synthetic oil. Description
Capacity (Approximate)
Recommended Fluids/Lubricants
Metric US measure Imp measure
Fuel 105.8 28 gal 23 1/4 gal Unleaded gasoline with octane rating of
at least 87 AKI (RON 91) *8
Engine oil
Drain and refill With oil filter
change
6.2
6 1/2 qt 5 1/2 qt
API Certification Mark *1
API grade SG, Energy Conserving II or
API grade SH, SJ or SL *1
ILSAC grade GF-II and GF-III *1
Without oil filter
change
5.9
6 1/4 qt 5 1/4 qt
Dry engine (engine overhaul) 7.6 8 qt
6 3/4 qt
Cooling system With reservoir
at MAX level
14.4
3 3/4 gal 3 1/8 gal Genuine NISSAN Long Life Anti-freeze
coolant or equivalent
Automatic transmission fluid (ATF) 10.6 11 1/4 qt 9 3/8 qt Genuine NISSAN Matic J ATF *2
Rear final drive oil 1.75 3 3/4 pt 3 1/8 pt API GL-5 Synthetic 75W-90 Gear Oil
(Part No. 999MP-DF200p) or equivalent
*9
Transfer fluid 3.0 3 1/8 qt 2 5/8 qt Genuine NISSAN Matic D ATF (Conti-
nental U.S and Alaska) or Canada NIS-
SAN Automatic Transmission Fluid *7
Front final drive oil 1.6 3 3/8 pt 2 7/8 pt API GL-5 Viscosity SAE 80W-90 *6
Power steering fluid (PSF) 1.0 2 1/8 pt 1 3/4 pt Genuine NISSAN PSF or equivalent *3
Brake fluid ——— Genuine NISSAN Super Heavy Duty
Brake Fluid or equivalent,
DOT 3 (US FMVSS No. 116) *4
Brake grease ——— PBC (poly butyl cuprysil) grease or
equivalent
Multi-purpose grease ——— NLGI No. 2 (lithium soap base)
Windshield washer fluid 4.5 1 1/4 gal 1 gal Genuine NISSAN Windshield Washer
Concentrate Cleaner & Anti-freeze or
equivalent
Air conditioning system refrigerant 1.08 ± 0.05 kg 2.38 ± 0.11 lb 2.38 ± 0.11 lb HFC-134a (R-134a) *5
Air conditioning system oil 290 m9.8 fl oz 10.2 fl oz NISSAN A/C System Oil Type S or
equivalent *5
Page 2611 of 3383
MA-12
RECOMMENDED FLUIDS AND LUBRICANTS
Revision: November 20092006 QX56
SAE Viscosity NumberELS001BO
GASOLINE ENGINE OIL
SAE 5W-30 viscosity oil is preferred for all temperatures. If 5W-
30 is not available, select the viscosity from the chart that is suit-
able for the outside temperature range.
ANTI-FREEZE COOLANT MIXTURE RATIO
The engine cooling system is filled at the factory with a high-quality, long life, year-round, anti-freeze coolant
solution. The anti-freeze solution contains rust and corrosion inhibitors. Therefore, additional cooling system
additives are not necessary.
CAUTION:
When adding or replacing coolant, be sure to use only Genuine NISSAN Long Life Anti-freeze
coolant or equivalent with the proper mixture ratio of 50% anti-freeze and 50% demineralized water
or distilled water.
Other types of coolant solutions may damage your cooling system.
BLIA0001E
For outside temperatures down to:Anti-freeze coolant mixture ratio
° C ° FGenuine NISSAN Long Life
Antifreeze coolant Demineralized water or distilled
water
– 35 ° – 30 ° 50 % 50 %
Page 2623 of 3383
MA-24
CHASSIS AND BODY MAINTENANCE
Revision: November 20092006 QX56
If the ATF contains frictional material (clutches, bands, etc.), replace the radiator and flush the transmis-
sion cooler lines using cleaning solvent and compressed air after repairing the transmission.
9. Install the ATF level gauge in the ATF charging pipe and install the level gauge bolt.
10. Tighten the level gauge bolt to specification.
Changing Automatic Transmission Fluid (ATF)ELS001PR
1. Drive the vehicle to warm up the ATF to 80 ° C (176 ° F).
2. Stop the engine.
3. Remove the ATF level gauge bolt.
4. Drain the ATF from the drain plug hole and then install the drain plug with a new gasket. Refill the transmission with new ATF.
Always refill with the same volume as the drained ATF. Use the
ATF level gauge to check the ATF level as shown. Add ATF as
necessary.
To flush out the old ATF from the coolers, pour new ATF into the charging pipe with the engine idling
and at the same time drain the old ATF from the auxiliary transmission oil cooler hose return line.
When the color of the ATF coming out of the auxiliary transmission oil cooler hose return line is about
the same as the color of the new ATF, flushing out the old ATF is complete. The amount of new trans-
mission ATF used for flushing should be 30% to 50% of the specified capacity.
CAUTION:
Use only the specified ATF. Do not mix with other fluids.
Using an ATF other than the specified ATF will cause deterioration in driveability and automatic
transmission durability, and may damage the automatic transmission, which is not covered by
the warranty.
When filling the transmission with ATF, do not spill the ATF on any heat generating parts such
as the exhaust manifold.
Do not reuse the drain plug gasket.
5. Install the ATF level gauge in the ATF charging pipe and tighten the level gauge bolt to specification.
6. Drive the vehicle to warm up the ATF to 80 ° C (176 ° F).
7. Check the ATF level and condition. Refer to MA-22, "
Checking Automatic Transmission Fluid (ATF)" . If
the ATF is still dirty, repeat steps 2 through 5.
Changing Transfer FluidELS001H0
DRAINING
1. Stop the engine. Level gauge bolt: : Refer to
AT- 2 5 0 , "
Components" .
Drain plug : Refer to AT- 2 5 0 , "
Components" .
WLIA0014E
ATF type and capacity : Refer to MA-11, "Fluids and Lubricants" .
Drain plug : Refer to AT- 2 5 0 , "
Components" .
Level gauge bolt : Refer to AT- 2 5 0 , "
Components" .
Page 2735 of 3383
PS-2
PRECAUTIONS
Revision: November 20092006 QX56
PRECAUTIONSPFP:00001
Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT
BELT PRE-TENSIONER”
EGS000U4
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER ”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WARNING:
To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance must be per-
formed by an authorized NISSAN/INFINITI dealer.
Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the SRS section.
Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
harness connectors.
Precautions for Steering SystemEGS000U5
Before disassembly, thoroughly clean the outside of the unit.
Disassembly should be done in a clean work area. It is important to prevent the internal parts from becom-
ing contaminated by dirt or other foreign matter.
For easier and proper assembly, place disassembled parts in order on a parts rack.
Use nylon cloth or paper towels to clean the parts; common shop rags can leave lint that might interfere
with their operation.
Before inspection or reassembly, carefully clean all parts with a general purpose, non-flammable solvent.
Before assembly, apply a coat of recommended Genuine NISSAN PSF or equivalent to hydraulic parts.
Petroleum jelly may be applied to O-rings and seals. Do not use any grease.
Replace all gaskets, seals and O-rings. Avoid damaging O-rings, seals and gaskets during installation.
Perform functional tests whenever designated.
