BLOWER MOTORPFP:27226
ComponentsEJS003YB
Front Blower Motor
Rear Blower Motor
Removal and InstallationEJS003YC
FRONT BLOWER MOTOR
Removal
1. Remove the glove box assembly. Refer to IP-14, "Lower Instrument Panel RH and Glove Box" .
2. Disconnect the front blower motor electrical connector.
3. Remove the three screws and remove the front blower motor.
Installation
Installation is in the reverse order of removal.
LJIA0136E
1. Front heater and cooling unit assembly 2. Front blower motor 3. Variable blower control
LJIA0055E
1. Rear blower motor2. Rear blower motor case 3. Rear blower motor resistor

IN-CABIN MICROFILTERATC-151
C
DE
F
G H
I
K L
M A
B
AT C
Revision: November 2009 2006 QX56
IN-CABIN MICROFILTERPFP:27277
Removal and InstallationEJS003YD
FUNCTION
The air inside the passenger compartment is filtered by the in-cabin
microfilters when the heater or A/C controls are set on either the
recirculation or fresh mode. The two in-cabin microfilters are located
in the front heater and cooling unit assembly. The rear heater and
cooling unit assembly only draws in air from the passenger compart-
ment to recirculate into the passenger compartment, so the rear
heater and cooling unit assembly is not equipped with in-cabin
microfilters.
REPLACEMENT TIMING
Replacement of the two in-cabin microfilters is recommended on a regular interval depending on the driving
conditions. Refer to MA-7, "
PERIODIC MAINTENANCE" . It may also be necessary to replace the two in-cabin
microfilters as part of a component replacement if the in-cabin microfilters are damaged.
REPLACEMENT PROCEDURE
1. Remove the two lower glove box hinge pins to remove the glove
box from the instrument panel and let it hang from the cord.
2. Remove the screw and remove the in-cabin microfilter cover.
3. Remove the in-cabin microfilters from the front heater and cool- ing unit assembly housing.
4. Insert the first new in-cabin microfilter into the front heater and cooling unit assembly housing and slide it over to the right.
Insert the second new in-cabin microfilter into the front heater
and cooling unit assembly housing.
NOTE:
The in-cabin microfilters are marked with air flow arrows. The
end of the microfilter with the arrow should face the rear of the
vehicle. The arrows should point downward.
LJIA0012E
WLIA0027E
LJIA0134E
LJIA0148E

HEATER & COOLING UNIT ASSEMBLYATC-153
C
DE
F
G H
I
K L
M A
B
AT C
Revision: November 2009 2006 QX56
HEATER & COOLING UNIT ASSEMBLYPFP:27110
ComponentsEJS003YE
Front Heater and Cooling Unit Assembly
WJIA0957E
1. High-pressure A/C pipe2. Front expansion valve3. Low-pressure A/C pipe
4. Front heater core pipe 5. Front heater core hose6. A/C drain hose
7. Front heater and cooling unit assembly

ATC-154
HEATER & COOLING UNIT ASSEMBLY
Revision: November 20092006 QX56
Rear Heater and Cooling Unit Assembly
Removal and InstallationEJS003YF
FRONT HEATER AND COOLING UNIT ASSEMBLY
Removal
1. Move the two front seats to the rearmost position on the seat track.
2. Disconnect the battery negative terminal and battery positive terminal.
3. Discharge the refrigerant from the A/C system. Refer to ATC-171, "
Discharging Refrigerant" .
WJIA2315E
1. Rear heater and cooling unit assembly 2. Rear A/C pipes 3. Rear A/C heater core pipes
4. Rear heater core hose 5. Rear blower motor6. Underfloor rear A/C pipes
7. Underfloor rear heater core pipes A. Bolt torque specifications B. Leak checking order (l - r)
C. Tightening torque D. Wrench sizeE. O-ring size
⇐ Front
NOTE: The O-ring size 8 is the high-side and the O-ring size 16 is the low-side.

HEATER & COOLING UNIT ASSEMBLYATC-155
C
DE
F
G H
I
K L
M A
B
AT C
Revision: November 2009 2006 QX56
4. Drain the coolant from the engine cooling system. Refer to MA-13, "DRAINING ENGINE COOLANT" .
5. Disconnect the front heater hoses from the front heater core.
6. Disconnect the high/low pressure pipes from the front expansion valve.
7. Remove the instrument panel and console panel. Refer to IP-10, "
INSTRUMENT PANEL ASSEMBLY" .
8. Remove the steering column. Refer to PS-10, "
STEERING COLUMN" .
9. Disconnect the instrument panel wire harness at the RH and LH in-line connector brackets, and the fuse block (J/B) electrical connectors. Refer to PG-4, "
POWER SUPPLY ROUTING CIRCUIT" .
10. Disconnect the steering member from each side of the vehicle body.
11. Remove the front heater and cooling unit assembly with it attached to the steering member, from the vehi- cle.
CAUTION:
Use care not to damage the seats and interior trim panels when removing the front heater and
cooling unit assembly with it attached to the steering member.
12. Remove the front heater and cooling unit assembly from the steering member.
Installation
Installation is in the reverse order of removal.
CAUTION:

Replace the O-ring of the low-pressure pipe and high-pressure pipe with a new one, and apply
compressor oil to it when installing it.

After charging the refrigerant, check for leaks.
NOTE:

Fill the engine cooling system with the specified coolant mixture. Refer to MA-14, "REFILLING ENGINE
COOLANT" .

Recharge the A/C system. Refer to ATC-171, "Evacuating System and Charging Refrigerant" .
REAR HEATER AND COOLING UNIT ASSEMBLY
Removal
1. Discharge the refrigerant from the A/C system. Refer to ATC-171, "Discharging Refrigerant" .
2. Drain the coolant from the engine cooling system. Refer to MA-13, "
DRAINING ENGINE COOLANT" .
3. Disconnect the rear heater core hoses from the rear heater core.
4. Disconnect the rear A/C pipes from the rear expansion valve.
5. Remove the luggage side finisher lower RH. Refer to EI-35,
"BODY SIDE TRIM" .
6. Disconnect the following electrical connectors:

Rear blower motor

Rear blower motor resistor

Rear air mix door motor
7. Disconnect the ducts from the rear heater and cooling unit assembly.
8. Remove the rear heater and cooling unit assembly.
Installation
Installation is in the reverse order of removal.
CAUTION:

Replace the O-ring of the low-pressure pipe and high-pressure pipe with a new one, and apply
compressor oil to it when installing it.

After charging the refrigerant, check for leaks.
NOTE:

Fill the engine cooling system with the specified coolant mixture. Refer to MA-14, "REFILLING ENGINE
COOLANT" .

Recharge the A/C system. Refer to ATC-171, "Evacuating System and Charging Refrigerant" .
LJIA0021E

ATC-156
HEATER CORE
Revision: November 20092006 QX56
HEATER COREPFP:27140
ComponentsEJS003YG
Front Heater and Cooling Unit Assembly
LJIA0138E
1. Heater core cover2. Heater core pipe bracket 3. Heater core
4. Upper bracket 5. Upper heater and cooling unit case 6. A/C evaporator
7. Lower heater and cooling unit case 8. Blower motor 9. Variable blower control

HEATER COREATC-157
C
DE
F
G H
I
K L
M A
B
AT C
Revision: November 2009 2006 QX56
Rear Heater and Cooling Unit Assembly
Removal and InstallationEJS003YH
FRONT HEATER CORE
Removal
1. Remove the front heater and cooling unit assembly. Refer to ATC-154, "FRONT HEATER AND COOLING
UNIT ASSEMBLY" .
2. Remove the four screws and remove the upper bracket.
3. Remove the four screws and remove the heater core cover.
4. Remove the heater core pipe bracket.
LJIA0135E
1. Front cover 2. Evaporator and heater core case 3. Evaporator
4. Side cover 5. Heater core6. Blower motor
7. Blower motor case 8. Blower motor resistor

ATC-158
HEATER CORE
Revision: November 20092006 QX56
5. Remove the heater core.
NOTE:
If the in-cabin microfilters are contaminated from coolant leaking
from the heater core, replace the in-cabin microfilters with new
ones before installing the new heater core.
Installation
Installation is in the reverse order of removal.
REAR HEATER CORE
Removal
1. Partially drain the engine cooling system. Refer to MA-13, "DRAINING ENGINE COOLANT" .
2. Remove the luggage side finisher lower RH. Refer to EI-40, "
LUGGAGE FLOOR TRIM" .
3. Disconnect the rear heater hoses from the heater core.
4. Remove the rear heater core bracket.
5. Remove the heater core.
Installation
Installation is in the reverse order of removal.
LJIA0134E
LJIA0069E
LJIA0071E

DEFROSTER DOOR MOTORATC-159
C
DE
F
G H
I
K L
M A
B
AT C
Revision: November 2009 2006 QX56
DEFROSTER DOOR MOTORPFP:27733
Removal and InstallationEJS003YI
Defroster Door Motor - Front Heater and Cooling Unit Assembly
REMOVAL
1. Remove the BCM. Refer to BCS-20, "BCM" .
2. Remove the Bose speaker amplifier, if equipped. Refer to AV- 5 5 , "
BOSE SPEAKER AMP." .
3. Disconnect the defroster door motor electrical connector.
4. Remove the three screws and remove the defroster door motor.
INSTALLATION
Installation is in the reverse order of removal.
LJIA0139E
1. Front heater and cooling unit assembly 2. Intake door motor 3. Air mix door motor (driver)
4. Variable blower control 5. Air mix door motor (passenger) 6. Mode door motor
7. Defroster door motor

ATC-160
INTAKE DOOR MOTOR
Revision: November 20092006 QX56
INTAKE DOOR MOTORPFP:27730
Removal and InstallationEJS003YJ
Intake Door Motor - Front Heater and Cooling Unit Assembly
REMOVAL
1. Remove the front heater and cooling unit assembly. Refer to ATC-154, "FRONT HEATER AND COOLING
UNIT ASSEMBLY" .
2. Remove the steering member from the front heater and cooling unit assembly.
3. Disconnect the intake door motor electrical connector.
4. Remove the three screws and remove the intake door motor.
INSTALLATION
Installation is in the reverse order of removal.
LJIA0139E
1. Front heater and cooling unit assembly 2. Intake door motor 3. Air mix door motor (driver)
4. Variable blower control 5. Air mix door motor (passenger) 6. Mode door motor
7. Defroster door motor
