TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMSBRC-39
[VDC/TCS/ABS]
C
DE
G H
I
J
K L
M A
B
BRC
Revision: November 2009 2006 QX56
6. CHECK WIRING HARNESS FOR OPEN CIRCUIT
1. Check continuity between ABS actuator and electric unit (control unit) harness connector E125 and the malfunctioning wheel sensor harness connector E18, E117, C10, or C11.
OK or NG
OK >> Replace the ABS actuator and electric unit (control unit). Refer to BRC-66, "Removal and Installa-
tion" .
NG >> Repair the circuit.
Engine System InspectionEFS004XS
INSPECTION PROCEDURE
1. SELF-DIAGNOSIS RESULT CHECK
Check self-diagnosis results.
Is the above displayed in the self-diagnosis display items?
YES >> GO TO 2.
NO >> Inspection End.
2. ENGINE SYSTEM INSPECTION
1. Perform ECM self-diagnosis and repair as necessary. Refer to EC-118, "
SELF-DIAG RESULTS MODE" .
2. Perform ABS actuator and electric unit (control unit) self-diagnosis again.
OK or NG
OK >> Inspection End.
NG >> Repair or replace as necessary.
Wheel sensor ABS actuator and
electric unit (control unit) Wheel sensor
Continuity
Connector Terminal Connector Terminal
Front LH
E12545
E18 1
Ye s
46
2
Front RH 34
E117 1
33 2
Rear LH 37
C11 2
36 1
Rear RH 42
C10 2
43 1
Continuity should exist.
Self-diagnosis results
ENGINE SIGNAL 1
ENGINE SIGNAL 2
ENGINE SIGNAL 3
ENGINE SIGNAL 4
ENGINE SIGNAL 6

BRC-40
[VDC/TCS/ABS]
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
Revision: November 20092006 QX56
ABS/TCS/VDC Control Unit InspectionEFS004XT
INSPECTION PROCEDURE
1. SELF-DIAGNOSIS RESULT CHECK
Check self-diagnosis results.
Is the above displayed in the self-diagnosis display items?
YES >> Replace ABS actuator and electric unit (control unit). Refer to BRC-66, "Removal and Installation"
.
NO >> Inspection End.
Steering Angle Sensor SystemEFS004XU
INSPECTION PROCEDURE
1. CHECK SELF-DIAGNOSIS RESULT
Check self-diagnosis results.
Is above displayed in self-diagnosis item?
YES >> GO TO 2.
NO >> Inspection End.
2. CHECK CONNECTOR
1. Disconnect steering angle sensor connector M47 and ABS actuator and electric unit (control unit) connec- tor E125 and check terminals for deformation, disconnection, looseness, or damage. Repair or replace as
necessary.
2. Reconnect connectors and repeat ABS actuator and electric unit (control unit) self-diagnosis.
Is "ST ANG SEN CIRCUIT" or "ST ANG SEN COM CIR" displayed?
YES >> GO TO 3.
NO >> Inspection End.
3. CHECK STEERING ANGLE SENSOR HARNESS
1. Check CAN communication system. Refer to LAN-26, "
CAN COMMUNICATION" .
2. Turn ignition switch OFF and disconnect steering angle sensor connector M47 and ABS actuator and electric unit (control unit)
connector E125.
3. Check continuity between ABS actuator and electric unit (control unit) connector E125 and steering angle sensor connector M47.
OK or NG
OK >> GO TO 4.
NG >> Repair or replace harness.
Self-diagnosis results
CONTROLLER FAILURE VARIANT CODING
Self-diagnosis results
ST ANG SEN CIRCUIT
ST ANG SEN COM CIR
ABS actuator and electric unit (con- trol unit) harness connector E125 Steering angle
sensor
harness con- nector M47 Continuity
11 3Yes
15 4Yes
WFIA0224E

TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMSBRC-41
[VDC/TCS/ABS]
C
DE
G H
I
J
K L
M A
B
BRC
Revision: November 2009 2006 QX56
4. CHECK DATA MONITOR
1. Connect steering angle sensor and ABS actuator and electric unit (control unit) connectors.
2. Use “DATA MONITOR ” to check if the status of "STR ANGLE SIG" is normal.
OK or NG
OK >> Perform ABS actuator and electric unit (control unit) self-diagnosis again.
NG >> Replace spiral cable (steering angle sensor) and adjust neutral position of steering angle sensor. Refer to BRC-62, "
Adjustment of Steering Angle Sensor Neutral Position" .
Yaw Rate/Side/Decel G Sensor System InspectionEFS004XV
CAUTION:
Sudden turns (such as spin turns, acceleration turns), drifting, etc. when VDC function is OFF may
cause the yaw rate/side/decel G sensor system to indicate a problem. This is not a problem if normal
operation can be resumed after restarting the engine.
INSPECTION PROCEDURE
1. SELF-DIAGNOSIS RESULT CHECK
Check self-diagnosis results.
CAUTION:
If vehicle is on turn table at entrance to parking garage, or on other moving surface, VDC OFF indica-
tor lamp may illuminate and CONSULT-II self-diagnosis may indicate yaw rate sensor system malfunc-
tion. However, in this case there is no malfunction in yaw rate sensor system. Take vehicle off of turn
table or other moving surface, and start engine. Results will return to normal.
Is the above displayed in the self-diagnosis display items?
YES >> GO TO 2.
NO >> Inspection End.
2. CONNECTOR INSPECTION
Disconnect the ABS actuator and electric unit (control unit) connector E125 and yaw rate/side/decel G sensor
connector M108.
Check the terminals for deformation, disconnection, looseness or damage.
OK or NG
OK >> GO TO 3.
NG >> Repair or replace as necessary.
Steering condition Data monitor
Straight-ahead –3.5 deg to +3.5 deg
Turn wheel to the right by 90 ° Approx. - 90deg
Turn wheel to the left by 90 ° Approx. + 90deg
Self-diagnosis results
YAW RATE SENSOR G-SENSOR
SIDE G-SEN CIRCUIT

TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMSBRC-43
[VDC/TCS/ABS]
C
DE
G H
I
J
K L
M A
B
BRC
Revision: November 2009 2006 QX56
Solenoid and VDC Change-Over Valve System InspectionEFS004XW
INSPECTION PROCEDURE
1. SELF-DIAGNOSIS RESULT CHECK
Check self-diagnosis results.
Is the above displayed in the self-diagnosis display items?
YES >> GO TO 2.
NO >> Inspection End.
2. CONNECTOR INSPECTION
1. Disconnect ABS actuator and electric unit (control unit) connector E125.
2. Check the terminals for deformation, disconnection, looseness or damage.
OK or NG
OK >> GO TO 3.
NG >> Repair or replace as necessary.
Self-diagnosis results FR LH IN ABS SOL
FR LH OUT ABS SOL RR RH IN ABS SOL
RR RH OUT ABS SOL FR RH IN ABS SOL
FR RH OUT ABS SOL RR LH IN ABS SOL
RR LH OUT ABS SOL CV 1
CV 2SV 1
SV 2

BRC-44
[VDC/TCS/ABS]
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
Revision: November 20092006 QX56
3. CHECKING SOLENOID POWER AND GROUND
1. Check voltage between ABS actuator and electric unit (control unit) harness connector E125 and body ground.
2. Check resistance between ABS actuator and electric unit (con- trol unit) harness connector E125 and body ground.
OK or NG
OK >> Perform self-diagnosis again. If the same results appear, replace ABS actuator and electric unit (control
unit). Refer to BRC-66, "
Removal and Installation" .
NG >> Repair the circuit.
Actuator Motor, Motor Relay, and Circuit InspectionEFS004XX
INSPECTION PROCEDURE
1. CHECKING SELF-DIAGNOSIS RESULTS
Check self-diagnosis results.
Is the above displayed in the self-diagnosis display items?
YES >> GO TO 2.
NO >> Inspection End.
2. CONNECTOR INSPECTION
1. Disconnect ABS actuator and electric unit (control unit) connector E125.
2. Check the terminals for deformation, disconnection, looseness or damage.
OK or NG
OK >> GO TO 3.
NG >> Repair or replace as necessary. ABS actuator and electric
unit (control unit)connector E125 Body
ground Measured
value
(Approx.)
32 — 12V
WFIA0195E
ABS actuator and electric unit (control unit)connector E125 Body
ground Measured
value Ω
(Approx.)
16 —0Ω
47 —0Ω
WFIA0196E
Self-diagnosis results
PUMP MOTOR
ACTUATOR RLY

TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMSBRC-45
[VDC/TCS/ABS]
C
DE
G H
I
J
K L
M A
B
BRC
Revision: November 2009 2006 QX56
3. CHECKING ABS MOTOR AND MOTOR RELAY POWER SYSTEM
1. Check voltage between ABS actuator and electric unit (control unit) harness connector E125 and body ground.
2. Check resistance between ABS actuator and electric unit (con- trol unit) connector E125 and body ground.
OK or NG
OK >> Perform self-diagnosis again. If the same results appear, replace ABS actuator and electric unit (control
unit). Refer to BRC-66, "
Removal and Installation" .
NG >> Repair the circuit.
Stop Lamp Switch System InspectionEFS004XY
INSPECTION PROCEDURE
1. SELF-DIAGNOSIS RESULT CHECK
Check self-diagnosis results.
Is the above displayed in the self-diagnosis display items?
YES >> GO TO 2.
NO >> Inspection End.
2. CONNECTOR INSPECTION
1. Disconnect the ABS actuator and electric unit (control unit) connector E125 and stop lamp switch connec- tor E38.
2. Check the terminals for deformation, disconnection, looseness or damage.
OK or NG
OK >> GO TO 3.
NG >> Repair or replace as necessary. ABS actuator and electric
unit (control unit)connector E125 Body
ground Measured
value
(Approx.)
1—1 2V
WFIA0209E
ABS actuator and electric
unit (control unit)
harness connector E125 Body
ground Measured
value Ω
(Approx.)
16 —0Ω
47 —0Ω
WFIA0196E
Self-diagnosis results
STOP LAMP SW

BRC-46
[VDC/TCS/ABS]
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
Revision: November 20092006 QX56
3. STOP LAMP SWITCH INSPECTION
Check the voltage between the ABS actuator and electric unit (con-
trol unit) harness connector E125 terminal 41 and body ground.
OK or NG
OK >> Perform self-diagnosis again. If the same results appear, replace ABS actuator and electric unit (control
unit). Refer to BRC-66, "
Removal and Installation" .
NG >> GO TO 4.
4. STOP LAMP RELAY CIRCUIT INSPECTION
1. Disconnect the stop lamp relay harness connector E12.
2. Check the continuity between the ABS actuator and electric unit (control unit) harness connector E125 (B) terminal 41 and stop
lamp relay harness connector E12 (A) terminal 4.
OK or NG
OK >> Perform self-diagnosis again. If the same results appear, replace ABS actuator and electric unit (control
unit). Refer to BRC-66, "
Removal and Installation" .
NG >> Refer to LT- 1 0 6 , "
STOP LAMP" .
ABS/TCS/VDC Control Unit Power and Ground Systems InspectionEFS004XZ
INSPECTION PROCEDURE
1. SELF-DIAGNOSIS RESULT CHECK
Check self-diagnosis results.
Is the above displayed in the self-diagnosis display items?
YES >> GO TO 2.
NO >> Inspection End.
2. CONNECTOR INSPECTION
1. Disconnect the ABS actuator and electric unit (control unit) connector E125.
2. Check the terminals for deformation, disconnection, looseness or damage.
OK or NG
OK >> GO TO 3.
NG >> Repair or replace as necessary. Brake pedal depressed : Battery voltage
(approx. 12V)
Brake pedal not depressed : Approx. 0V
WFIA0198E
Continuity should exist
WFIA0431E
Self-diagnosis results
BATTERY VOLTAGE

TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMSBRC-47
[VDC/TCS/ABS]
C
DE
G H
I
J
K L
M A
B
BRC
Revision: November 2009 2006 QX56
3. ABS/TCS/VDC CONTROL UNIT POWER AND GROUND CIRCUIT INSPECTION
Measure the voltage and continuity between the ABS actuator and electric unit (control unit) harness connec-
tor E125 and body ground.
OK or NG
OK >> Check the battery for loose terminals, low voltage, etc. Repair as necessary.
NG >> Repair the circuit.
Brake Fluid Level Switch System InspectionEFS004Y0
INSPECTION PROCEDURE
1. SELF-DIAGNOSIS RESULT CHECK
1. Check the brake reservoir tank fluid level. If the level is low, add brake fluid.
2. Erase the self-diagnosis results and check the self-diagnosis results.
Is the above displayed in the self-diagnosis display items?
YES >> GO TO 2.
NO >> Inspection End.
2. CONNECTOR INSPECTION
1. Disconnect the ABS actuator and electric unit (control unit) connector E125 and brake fluid level switch connector E21.
2. Check the terminals for deformation, disconnection, looseness or damage.
OK or NG
OK >> GO TO 3.
NG >> Repair or replace as necessary.
3. CHECK THE HARNESS BETWEEN THE BRAKE FLUID LEVEL SWITCH AND THE ABS ACTUATOR
AND ELECTRIC UNIT (CONTROL UNIT)
Check the continuity between the brake fluid level switch harness connector E21 and the ABS actuator and
electric unit (control unit) harness connector E125.
OK or NG
OK >> GO TO 4.
NG >> Repair the circuit. Signal name
ABS actuator and electric unit
(control unit)
harness connector E125 Body
ground Measured value
Power supply 1
— Battery voltage (Approx. 12V)
32
Ground 16
—Continuity should exist.
47
Self-diagnosis results
BR FLUID LEVEL LOW
ABS actuator and electric unit
(control unit) harness connector E125 Brake fluid level switch harness
connector E21 Continuity
81Y es
8 Ground No
Ground 2Yes

BRC-48
[VDC/TCS/ABS]
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
Revision: November 20092006 QX56
4. CHECK BRAKE FLUID LEVEL SWITCH
Check continuity between brake fluid level switch terminals 1 and 2.
OK or NG
OK >> Perform self-diagnosis again. If the same results appear, replace ABS actuator and electric unit (control unit). Refer to BRC-66, "
Removal and Installation" .
NG >> Replace brake fluid level switch.
Active Booster System InspectionEFS004Y1
INSPECTION PROCEDURE
1. DISPLAY SELF DIAGNOSIS RESULTS
Check self-diagnosis results.
Is the above displayed in the self-diagnosis display items?
YES or NO
YES >> GO TO 2.
NO >> Inspection End.
2. CONNECTOR INSPECTION
1. Turn the ignition switch OFF.
2. Disconnect the active booster connector E49 and ABS actuator and electric unit (control unit) connector E125 and inspect the terminals for deformation, disconnection, looseness, or damage.
OK or NG
OK >> GO TO 3.
NG >> Repair connector. Continuity should not exist.
Self-diagnosis results
ABS ACTIVE BOOSTER SV NG
ABS ACTIVE BOOSTER RESPONSE NG ABS BRAKE RELEASE SW NG
ABS BRAKE BOOSTER DEFECT

TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMSBRC-49
[VDC/TCS/ABS]
C
DE
G H
I
J
K L
M A
B
BRC
Revision: November 2009 2006 QX56
3. ACTIVE BOOSTER CIRCUIT INSPECTION
1. Measure the continuity between the ABS actuator and electric unit (control unit) connector E125 and active booster connector E49.
2. Measure the continuity between the ABS actuator and electric unit (control unit) connector E125 and body ground.
OK or NG
OK >> GO TO 4.
NG >> Repair or replace harness or connector.
4. ACTIVE BOOSTER SENSOR INSPECTION
1. Reconnect the active booster and ABS actuator and electric unit (control unit) connectors.
2. Use "DATA MONITOR" to check if the status of "RELEASE SW NO" and "RELEASE SW NC" is normal.
OK or NG
OK >> Inspection End.
NG >> Replace active booster.
Delta Stroke Sensor System InspectionEFS004Y2
INSPECTION PROCEDURE
1. DISPLAY SELF DIAGNOSIS RESULTS
Check self-diagnosis result display item.
Is the above displayed in the self-diagnosis display items?
YES or NO
YES >> GO TO 2.
NO >> Inspection End. ABS actuator and electric unit
(control unit) connector E125 Active booster connector
E49 Continuity
17 3
Yes
27 1
28 5
30 2
31 4
ABS actuator and electric unit (control unit) connector E125 Body ground
Continuity
17
—No
27
28
30
31
Condition
Data monitor display
RELEASE SW NO RELEASE SW NC
When brake pedal is depressed ONOFF
When brake pedal is released OFFON
Self-diagnosis results
ABS DELTA S SEN NG
