REMOTE KEYLESS ENTRY SYSTEMBL-61
C
DE
F
G H
J
K L
M A
B
BL
Revision: November 2009 2006 QX56
Hazard reminder does not activate properly when
pressing lock or unlock button of keyfob.
(Horn reminder OK)1. Check hazard reminder mode with CONSULT-II
NOTE:
Hazard reminder mode can be changed.
First check the hazard reminder mode setting.
BL-57
2. Check hazard function with hazard switch
—
3. Replace BCM. BCS-20
Horn reminder does not activate properly when
pressing lock or unlock button of keyfob.
(Hazard reminder OK)1. Check horn reminder mode with CONSULT-II
NOTE:
Horn reminder mode can be changed.
First check the horn reminder mode setting.
BL-57
2. Check horn function with horn switch
—
3. IPDM E/R operation check BL-68
4. Replace BCM.BCS-20
Back door open/close operation is not carried out
with keyfob operation.
(The automatic back door system is normal.)1. Keyfob battery and function check (use Remote Keyless Entry
Tester J-43241)
NOTE:
If the result of keyfob function check is OK, keyfob is not malfunc-
tioning.
BL-65
2. Key switch (insert) check
BL-62
3. Check that glass hatch is closed —
4. Remote keyless entry receiver system BL-66
5. Replace BCM.BCS-20
Room lamp, ignition keyhole illumination and step
lamp operation do not activate properly.1. Room lamp operation check
BL-70
2. Ignition keyhole illumination operation checkBL-70
3.Step lamp operation checkLT- 1 3 5
4. Door switch check BL-63
5. Replace BCM.BCS-20
Panic alarm (horn and headlamp) does not activate
when panic alarm button is continuously pressed.1. Keyfob battery and function check (use Remote Keyless Entry
Tester J-43241)
NOTE:
If the result of keyfob function check is OK, keyfob is not malfunc-
tioning. BL-65
2. Key switch and key lock solenoid (insert) check
BL-62
3. Replace BCM.BCS-20
Auto door lock operation does not activate properly.
(All other remote keyless entry functions OK.)1. Check auto door lock operation mode with CONSULT-II
NOTE:
Auto door lock operation mode can be changed.
First check the auto door lock operation mode setting.
BL-57
2. Replace BCM.
BCS-20
Keyless power window down (open) operation does
not activate properly.
(All other remote keyless entry functions OK.)1. Check power window down operation mode with CONSULT-II
NOTE:
Power window down operation mode can be changed.
First check the power window down operation mode setting.
BL-57
2. Check power window function with switch
—
3. Replace BCM. BCS-20
SymptomDiagnoses/service procedureReference
page

BL-76
VEHICLE SECURITY (THEFT WARNING) SYSTEM
Revision: November 20092006 QX56
System DescriptionEIS0060F
DESCRIPTION
Operation Flow

Setting the vehicle security system
Initial condition

Ignition switch is in OFF position.
Disarmed phase

When the vehicle is being driven or when doors or glass hatch is open, the vehicle security system is set
in the disarmed phase on the assumption that the owner is inside or near the vehicle.
Pre-armed phase and armed phase

The vehicle security system turns into the "pre-armed" phase when hood, glass hatch and all doors are
closed and locked by keyfob. The security indicator lamp illuminates for 30 seconds, then the system
automatically shifts into the "armed" phase.
Canceling the set vehicle security system
When one of the following operations is performed, the armed phase is canceled.
1. Unlock the doors with the key or the keyfob.
2. Open the power back door with the keyfob. When the power back door is closed after opening the power back door with the keyfob, the system returns to the armed phase.
Activating the alarm operation of the vehicle security system
Make sure the system is in the armed phase.
When one of the following operations is performed, the system sounds the horns and flashes the headlamps
for about 50 seconds.
1. Engine hood, glass hatch or any door is opened before unlocking door with key or keyfob.
7. BCM M18, M19, M20
(view with instrument panel LH
removed) 8. Horn E3
(view with grille removed) 9. Front door lock assembly LH (key
cylinder switch) D14
10. Main power window and door lock/ unlock switch D7, D8
Power window and door lock/unlock
switch RH D105 11. Front door switch
LH B8
RH B108 12. Rear door switch
LH B18
RH B116
13. Back door latch (door ajar switch) D503 Glass hatch ajar switch D707 14. Combination meter M24
15. Hood switch E8
16. RH headlamp
PIIA1367E

VEHICLE SECURITY (THEFT WARNING) SYSTEMBL-77
C
DE
F
G H
J
K L
M A
B
BL
Revision: November 2009 2006 QX56
2. Door is unlocked without using key or keyfob.
3. Power back door is opened without using the keyfob.
POWER SUPPLY AND GROUND CIRCUIT
Power is supplied at all times

through 10A fuse [No.19, located in the fuse block (J/B)]

to combination meter (security indicator lamp) terminal 8 and

through 50A fusible link (letter f , located in the fuse and fusible link box)

to BCM terminal 70

through 15A fuse [No. 22, located in the fuse block (J/B)]

to BCM terminal 57

through 15A fuse (No. 25, located in the fuse and fusible link box)

to horn relay terminal 2

through 20A fuse (No. 52, located in the IPDM E/R) and

through 20A fuse (No. 53, located in the IPDM E/R),

to IPDM E/R internal CPU.
With the ignition switch in the ACC or ON position, power is supplied

through 10A fuse [No. 4, located in the fuse block (J/B)]

to BCM terminal 11.
Ground is supplied

to BCM terminal 67

through body grounds M57, M61 and M79 and

to IPDM E/R terminals 38 and 59

through body ground E9, E15 and E24.
INITIAL CONDITION TO ACTIVATE THE SYSTEM
The operation of the vehicle security system is controlled by the doors, hood and glass hatch.
To activate the vehicle security system, BCM must receive signals indicating the doors, hood and glass hatch
are closed and the doors are locked.
When a door is open, BCM terminal 12, 13, 42, 47 or 48 receives a ground signal from each door switch.
When front door LH is unlocked, BCM terminal 22 receives a signal from terminal 14 of main power window
and door lock/unlock switch.
When front door RH is unlocked, BCM terminal 22 receives a signal from terminal 16 of power window and
door lock/unlock switch RH or the rear power window switch LH or RH.
When the back door is open, BCM terminal 43 receives a ground signal

from terminal 7 of the back door latch (door ajar switch)

through body grounds B7 and B19.
When the glass hatch is open, BCM terminal 42 receives a ground signal

from terminal + of the glass hatch ajar switch

through glass hatch ajar switch case ground.
VEHICLE SECURITY SYSTEM ALARM OPERATION
The vehicle security system is triggered by

opening a door

opening the hood

opening the glass hatch

unlocking door without using the key or keyfob.
The vehicle security system will be triggered once the system is in armed phase,

when BCM receives a ground signal at terminals 12, 13, 47, 48 (door switch), terminal 42 (glass hatch ajar
switch) or terminal 43 [back door latch (door ajar switch)], or IPDM E/R terminal 41 (hood switch) receives
a ground signal.
Power is supplied at all times

to horn relay terminal 2

BL-78
VEHICLE SECURITY (THEFT WARNING) SYSTEM
Revision: November 20092006 QX56

through 15A fuse (No. 25, located in fuse and fusible link box).
When the vehicle security system is triggered, ground is supplied intermittently

from IPDM E/R terminal 45

to headlamp high relay and

to horn relay terminal 1.
The headlamps flash and the horn sounds intermittently.
The alarm automatically turns off after 50 seconds, but will reactivate if the vehicle is tampered with again.
VEHICLE SECURITY SYSTEM DEACTIVATION
To deactivate the vehicle security system, a door must be unlocked with the key or keyfob.
When the key is used to unlock the front door LH, BCM terminal 22 receives signal

from terminal 14 of the main power window and door lock/unlock switch.
When the BCM receives this signal or unlock signal from keyfob, the vehicle security system is deactivated.
(Disarmed phase)
PANIC ALARM OPERATION
Remote keyless entry system may or may not operate vehicle security system (horn and headlamps) as
required.
When the remote keyless entry system is triggered, ground is supplied intermittently

from IPDM E/R terminal 45

to headlamp high relay and

to horn relay terminal 1.
The headlamp flashes and the horn sounds intermittently.
The alarm automatically turns off after 25 seconds or when BCM receives any signal from keyfob.
CAN Communication System DescriptionEIS0060G
Refer to LAN-26, "CAN COMMUNICATION" .

VEHICLE SECURITY (THEFT WARNING) SYSTEMBL-85
C
DE
F
G H
J
K L
M A
B
BL
Revision: November 2009 2006 QX56
Terminals and Reference Value for BCMEIS0060J
Terminal Wire
Color Item
Condition Voltage (V)
(Approx.)
11 O Ignition switch (ACC or ON) Ignition switch (ACC or ON position) Battery voltage
12 R/L Front door switch RH Door open (ON) → Door close (OFF) 0 → Battery voltage
13 GR Rear door switch RH Door open (ON) → Door close (OFF) 0 → Battery voltage
22 W/V Bus When ignition switch is ON or power
window timer operates
23 G/O Combination meter (security
indicator lamp) Goes off
→ Illuminates (Every 2.4
seconds) Battery voltage
→ 0
39 L CAN-H ——
40 P CAN-L ——
42 GR Glass hatch ajar switch Glass hatch open (ON) →
Glass
hatch close (OFF) Battery voltage
→ 0
43 R/B Back door latch (door ajar
switch) Door open (ON)
→ Door close (OFF) 0 → Battery voltage
47 SB Front door switch LH Door open (ON) → Door close (OFF) 0 → Battery voltage
48 R/Y Rear door switch LH Door open (ON) → Door close (OFF) 0 → Battery voltage
57 Y/R Battery power supply —Battery voltage
67 B Ground —0
70 W/B Battery power supply —Battery voltage
PIIA2344E

VEHICLE SECURITY (THEFT WARNING) SYSTEMBL-91
C
DE
F
G H
J
K L
M A
B
BL
Revision: November 2009 2006 QX56
Symptom ChartEIS0060O
*1: Make sure the system is in the armed phase.SYMPTOM PROCEDURE Diagnostic procedure
1 Vehicle security
system cannot be
set by
···· Door switch Refer to
BL-92, "
Door Switch Check" .
Lock/unlock switch Refer to BL-98, "
Door Lock/Unlock Switch Check" .
Door outside key Refer to BL-96, "
Front Door Lock Assembly LH (Key Cylinder Switch)
Check" .
BCM If the above systems are “OK ”, replace BCM. Refer to BCS-20, "
BCM" .
2 Security indicator
does not turn
“
ON ”. Combination meter Refer to BL-95, "
Combination Meter (Security Indicator Lamp) Check" .
BCM If the above systems are “OK ”, replace BCM. Refer to BCS-20, "
BCM" .
3 *1 Vehicle secu-
rity system does
not alarm when
···· Any door, hood or glass hatch
is opened. Refer to BL-92, "
Door Switch Check" .
Refer to BL-94, "
Hood Switch Check" .
If the above systems are “ OK”, replace BCM. Refer to BCS-20, "
BCM" .
4 Vehicle security
alarm does not
activate. Horn alarm
Refer to BL-98, "
Vehicle Security Horn Alarm Check" .
If the above systems are “ OK”, check horn system.
Refer to WW-55, "
HORN" .
Headlamp alarm Refer to BL-98, "
Vehicle Security Headlamp Alarm Check" .
If the above systems are “ OK”, replace BCM. Refer to BCS-20, "
BCM" .
5 Vehicle security
system cannot be
canceled by
····Door outside key
Refer to BL-96, "
Front Door Lock Assembly LH (Key Cylinder Switch)
Check" .
If the above systems are “ OK”, check main power window and door lock/
unlock switch.
Keyfob Check remote keyless entry function. Refer to
BL-65, "
Keyfob Battery and
Function Check" .
If the above systems are “ OK”, replace BCM. Refer to BCS-20, "
BCM" .

BL-96
VEHICLE SECURITY (THEFT WARNING) SYSTEM
Revision: November 20092006 QX56
3. CHECK HARNESS CONTINUITY
1. Turn ignition switch OFF.
2. Disconnect BCM and combination meter (security indicator lamp).
3. Check continuity between BCM connector (A) M18 terminal 23 and combination meter (security indicator lamp) harness con-
nector (B) M24 terminal 28.
4. Check continuity between BCM connector (A) M18 terminal 23 and ground.
OK or NG
OK >> Check the following:

10A fuse [No. 19, located in fuse block (J/B)]

Harness for open or short between combination meter (security indicator lamp) and fuse
NG >> Repair or replace harness.
Front Door Lock Assembly LH (Key Cylinder Switch) CheckEIS0060S
1. CHECK FRONT DOOR LOCK ASSEMBLY LH (KEY CYLINDER SWITCH)
With CONSULT-II
Check front door lock assembly LH (key cylinder switch) ("KEY CYL LK-SW") and ("KEY CYL UN-SW) in
DATA MONITOR mode in CONSULT –II.Refer to BL-27, "
DATA MONITOR" .

When key inserted in front key cylinder is turned to LOCK:

When key inserted in front key cylinder is turned to UNLOCK:
Without CONSULT-II
Check voltage between main power window and door lock/unlock switch connector D7 terminals 4, 6 and
ground.
OK or NG
OK >> Front door lock assembly LH (key cylinder switch) signal is OK.
NG >> GO TO 2. 23 - 28
: Continuity should exist.
23 - ground : Continuity should not exist.
LIIA2253E
KEY CYL LK-SW : ON
KEY CYL UN-SW : ON
LIIA0188E
ConnectorTerminals
ConditionVoltage (V)
(Approx.)
(+) (– )
D7 4
Ground Neutral/Unlock
5
Lock 0
6 Neutral/Lock
5
Unlock 0
LIIA0566E

VEHICLE SECURITY (THEFT WARNING) SYSTEMBL-97
C
DE
F
G H
J
K L
M A
B
BL
Revision: November 2009 2006 QX56
2. CHECK DOOR KEY CYLINDER SWITCH LH GROUND HARNESS
Check continuity between front door lock assembly LH (key cylinder
switch) connector (A) D14 terminal 5 and body ground.
OK or NG
OK >> GO TO 3.
NG >> Repair or replace harness.
3. CHECK DOOR KEY CYLINDER SWITCH LH
Check continuity between front door lock assembly LH (key cylinder
switch) terminals.
OK or NG
OK >> GO TO 4.
NG >> Replace front door lock assembly LH (key cylinder switch). Refer to BL-131, "
Removal and Instal-
lation" .
4. CHECK DOOR KEY CYLINDER HARNESS
Check continuity between main power window and door lock/unlock
switch connector (A) D7 terminals 4, 6 and front door lock assembly
LH (key cylinder switch) connector (B) D14 terminals 1, 6 and body
ground.
OK or NG
OK >> Replace main power window and door lock/unlock switch.
NG >> Repair or replace harness.
Connector TerminalsContinuity
D14 5 – Ground Yes
WIIA0755E
Terminals Condition Continuity
1 – 5 Key is turned to UNLOCK or neutral.
No
Key is turned to LOCK. Yes
5 – 6 Key is turned to LOCK or neutral.
No
Key is turned to UNLOCK. Yes
LIIA1573E
Connector Terminals Connector Terminals Continuity
A: Main
power win- dow and
door lock/
unlock switch 4B: Front
door lock
assembly
LH (key
cylinder switch) 1Y
es
66Y es
4, 6 Ground No
WIIA0756E

BL-112
AUTOMATIC BACK DOOR SYSTEM
Revision: November 20092006 QX56
Terminals and Reference Value for BCMEIS00611
21 W/V Power window serial link—
22 BR Half switch signal Back door half latch position
23 L/W Power liftgate switch ON
0
OFF 5
26 V Back door handle switch signal Handle operation
0
Other Battery voltage
Te r m i n a l
Wire
Color Item
Condition Voltage (V)
(Approx.)
PIIA2344E
PIIA2169E
Te r m i n a l Wire
Color Item
Condition Voltage (V)
(Approx.)
10 G Hazard lamp flash input Back door active
0
Other 5
22 W/V Bus —
42 GR Glass hatch ajar switch Open
0
Closed 5
43 R/B Back door latch (door ajar
switch) Open
0
Closed 5
67 B Ground —0
70 W/B Battery power supply —Battery voltage
PIIA2344E

BL-114
AUTOMATIC BACK DOOR SYSTEM
Revision: November 20092006 QX56
4. Using the inside emergency release lever, open the back door.
5. Have an assistant press and hold the back door handle switch.
6. While the assistant continues to hold the back door handle switch, turn ignition switch ON (DO NOT start
engine).
7. After approximately 5 seconds, the back door warning chime will sound for 0.5 seconds.
8. Release the back door handle switch.
9. Within 8 seconds of the back door warning chime sounding, press the power liftgate switch 5 times in rapid succession.
10. After approximately 5 seconds, the back door warning chime will sound for 1 second.
11. Release the power liftgate switch.
12. Immediately close the back door manually.
13. Press and release the power liftgate switch to activate operating check mode.
Self-diagnosis results are indicated by the back door warning chime.
Turn ignition switch OFF to end input signal check mode.
Diagnosis ChartEIS00614
Back door warning chime order Back door warning chime length
Start self-diagnosis 1.5 seconds
OK NG
1. Operating conditions diagnosis 0.5 seconds0.2 seconds
2. Back door encoder diagnosis 0.5 seconds0.2 seconds
3. Back door clutch diagnosis 0.5 seconds0.2 seconds
4. Back door motor diagnosis 0.5 seconds0.2 seconds
5. Cinch latch motor diagnosis 0.5 seconds0.2 seconds
Restart self-diagnosis 1.5 seconds
ItemNG ResultRefer to
1. Operating conditions diagnosis result One of the following operating conditions no
longer met: ignition switch ON, back door
close switch (CANCEL) ON, A/T selector lever
in P position—
2. Back door encoder diagnosis result Sensor diagnosis/short, pulse signal, pulse
signal directionBL-135
3. Back door clutch diagnosis result
Back door clutch does not operateBL-135
4. Back door motor diagnosis result Back door motor does not operate (no operat-
ing current)BL-135
5. Cinch latch motor diagnosis result Cinch latch motor does not operate (no oper-
ating current)
BL-135
Symptom
Suspect systemsRefer to
Automatic operations are not executed from the back door fully
closed or fully open position.
(Auto closure operates normally.) Power liftgate switch system inspection
BL-116
Park switch —
Power window serial link BL-112
Pinch strip system inspectionBL-121
Automatic operations are not carried out together with open/close
operations.
(Manual operations are normal.) Power liftgate switch system inspection
BL-116Back door close switch system inspectionBL-118
Auto back door power supply and ground cir-
cuit system inspection.BL-115
The auto closure function does not operate.
(Stops at the halfway position for auto closing operations.) Pinch strip system inspection
BL-121
