ACS-30
[ICC]
TROUBLE DIAGNOSIS — GENERAL DESCRIPTION
Revision: November 20092006 QX56
ACTIVE TEST
CAUTION:
Do not perform the active test while driving. Active test cannot be started while ICC system warning
indicator is illuminated.
Active Test
1. Touch “ACTIVE TEST” on "SELECT DIAG MODE" screen.
2. Touch any of “ICC BUZZER 1”, “METER LAMP ”, “STOP LAMP”
and “BOOSTER SOL/V 3 ” on "SELECT TEST ITEM" screen.
3. Touch “START”.
4. Active test screen will be shown.
ICC BUZZER 1

To u c h “ON” and “OFF” to check that ICC warning chime oper-
ates as in the following chart.
BCIA0031E
SKIA6195E
ICC BUZZER 1 ONOFF
Buzzer sound BeepNot activated
SKIA1228E

TROUBLE DIAGNOSIS — GENERAL DESCRIPTIONACS-31
[ICC]
C
DE
F
G H
I
J
L
M A
B
ACS
Revision: November 2009 2006 QX56
METER LAMP

Start engine.

Touch “ON” and “OFF” to check that ICC system displays operate as required.

The following ICC lamps will illuminate at the same time,
CRUISE (orange), CRUISE (green), SET and ICC digital dis-
play.
STOP LAMP

Touch “ON” and “OFF” to check that the stop lamps operate as
in the following chart.
BOOSTER SOL/V 3

Touch any of “MODE 1”, “MODE 2”, “MODE 3” to check that fol-
lowing operation condition is caused by operating monitor and
brake pedal.

“START ” is displayed 10 seconds after operation start. (Active
test is completed.)
Self-Diagnostic FunctionEKS00BLY
WITH CONSULT-II
1. Go to operation check after asking the customer for symptom information. Refer to ACS-9, "ACTION
TEST" .
2. Stop vehicle, turn ignition switch OFF, then connect CONSULT-II and CONSULT-II CONVERTER to data link connector.
METER LAMP ONOFF
All ICC system dis-
plays Full illumination
OFF
SKIA1231E
STOP LAMP ONOFF
Stop lamp Lamp ONLamp OFF
SKIA1232E
SKIA1233E
PKIA0363J

ACS-32
[ICC]
TROUBLE DIAGNOSIS — GENERAL DESCRIPTION
Revision: November 20092006 QX56
3. With engine started, touch “START”, “ICC ”, “SELF-DIAG RESULTS ” on CONSULT-II screen in this order.
CAUTION:
If “ICC” cannot be shown after several attempts, the ICC unit may be malfunctioning and should
be replaced. Refer to ACS-59, "
ICC Unit" .
4. Self-diagnostic result appears on screen. If “NO DTC ···” is shown, check ICC warning lamp. If any mal-
function is indicated, GO TO step 5.
5. Refer to ACS-36, "
Diagnostic Trouble Code (DTC) Chart" , perform appropriate check, and repair or
replace malfunctioning part as necessary.
6. Turn ignition switch OFF.
7. Start engine and touch “START ”, “ICC ”, “SELF-DIAG RESULTS ”, and “ERASE ” on CONSULT-II.
CAUTION:
DTC of an existing malfunction will not erase. If the memory does not erase, GO TO step 5.
8. Perform ICC system running test (drive vehicle with ICC system ON), and make sure that ICC warning lamp does not illuminate.
WITHOUT CONSULT-II
1. Go to operation check after asking the customer for symptom information. Refer to ACS-9, "ACTION
TEST" .
2. Stop the vehicle to start the self-diagnosis.
3. Turn ignition switch OFF.
4. Turn ignition switch ON, and wait 5 seconds. Press ACCEL/RES switch 5 times, and then press COAST/SET switch 5 times all
within 5 seconds to start self-diagnosis.
CAUTION:

Do not start the engine.

Do not press the ICC ON/OFF switch ON.

When operation above is not completed within the 5 to 10
second window, DTC will not be displayed.

If self-diagnosis mode cannot be started after several
attempts, the ICC unit may be malfunctioning and should be
replaced. Refer to ACS-33, "
SELF-DIAGNOSIS BY ICC SYS-
TEM DISPLAY WILL NOT RUN" .
5. When self-diagnosis mode is started, DTCs are shown on set vehicle speed indicator.
CAUTION:

DTC will disappear after 5 minutes.
WKIA1921E
WKIA1922E

TROUBLE DIAGNOSIS — GENERAL DESCRIPTIONACS-33
[ICC]
C
DE
F
G H
I
J
L
M A
B
ACS
Revision: November 2009 2006 QX56

When multiple malfunctions are detected, a maximum of 3 code numbers can be stored; the lat-
est malfunction will be displayed first.
6. Check ACS-36, "
Diagnostic Trouble Code (DTC) Chart" , and repair or replace if necessary.
7. After repair, erase DTC stored in the ICC unit. Refer to ACS-33, "
Self-Diagnostic Erasing Method"
8. DTC 55 will be shown.
9. Turn ignition switch OFF to exit the diagnosis.
10. Perform ICC system running test (drive vehicle with ICC system ON), and make sure that ICC warning
lamp does not illuminate.
Self-Diagnostic Erasing Method
1. Stop the vehicle and turn the ignition switch OFF.
2. Turn ignition switch ON and start self-diagnosis.
3. During self-diagnosis mode, press CANCEL switch 5 times, and DISTANCE switch 5 times within a 10second time period.
CAUTION:

Switch inputs must be received within a 10 second time period.

When operation is not completed within 10 seconds start again from step 1.
4. DTC 55 will be shown. CAUTION:
DTC of an existing malfunction will not be erased.
5. Turn ignition switch OFF to exit the diagnosis.
6. Perform ICC system running test (drive vehicle with ICC system ON), and make sure that ICC system warning lamp (orange) does not illuminate.
SELF-DIAGNOSIS BY ICC SYSTEM DISPLAY WILL NOT RUN
Self Diagnosis Will Not Run
WKIA1985E
Component Possible Cause Specific causes
ICC unit power supply malfunction No voltage supply from ignition switchFuse blown
Harness open
Harness shorted
Ground cable not connected Harness open
Harness shorted
ICC steering switch malfunction No signal transmittedHarness open
Harness shorted
Spiral cable open
Spiral cable shorted
Switch or ECM malfunction
CAN communication system malfunction Signal not transmitted Harness open
Harness shorted
CAN communication outside the standard

AT-12
A/T FLUID
Revision: November 20092006 QX56
A/T FLUIDPFP:KLE40
Changing Automatic Transmission Fluid (ATF)ECS00EPX
1. Drive the vehicle to warm up the ATF to 80° C (176 ° F).
2. Stop the engine.
3. Remove the ATF level gauge bolt.
4. Drain the ATF from the drain plug hole and then install the drain plug with a new gasket. Refill the transmission with new ATF.
Always refill with the same volume as the drained ATF. Use the
ATF level gauge to check the ATF level as shown. Add ATF as
necessary.

To flush out the old ATF from the coolers, pour new ATF into the charging pipe with the engine idling
and at the same time drain the old ATF from the auxiliary transmission oil cooler hose return line.

When the color of the ATF coming out of the auxiliary transmission oil cooler hose return line is about
the same as the color of the new ATF, flushing out the old ATF is complete. The amount of new trans-
mission ATF used for flushing should be 30% to 50% of the specified capacity.
CAUTION:

Use only the specified ATF. Do not mix with other fluids.

Using an ATF other than the specified ATF will cause deterioration in driveability and automatic
transmission durability, and may damage the automatic transmission, which is not covered by
the warranty.

When filling the transmission with ATF, do not spill the ATF on any heat generating parts such
as the exhaust manifold.

Do not reuse the drain plug gasket.
5. Install the ATF level gauge in the ATF charging pipe and tighten the level gauge bolt to specification.
6. Drive the vehicle to warm up the ATF to 80 ° C (176 ° F).
7. Check the ATF level and condition. Refer to AT- 1 2 , "
Checking Automatic Transmission Fluid (ATF)" . If the
ATF is still dirty, repeat steps 2 through 5.
Checking Automatic Transmission Fluid (ATF)ECS00EPY
1. Remove the ATF level gauge bolt.
2. Before driving, the ATF level can be checked at ATF tempera- tures of 30 ° to 50 °C (86 ° to 122 °F) using the “COLD” range on
the ATF level gauge as follows:
a. Park the vehicle on a level surface and set the parking brake.
b. Start the engine and move the selector lever through each gear position. Shift the selector lever into the “P” position.
c. Check the ATF level with the engine idling.
d. Remove the ATF level gauge and wipe it clean with a lint-free paper.
CAUTION:
When wiping the ATF from the ATF level gauge, always use
a lint-free paper, not a cloth.Drain plug : Refer to
AT- 2 5 0 , "
Components" .
WLIA0014E
ATF type and capacity : Refer to MA-11, "Fluids and Lubricants" .
Drain plug : Refer to AT- 2 5 0 , "
Components" .
Level gauge bolt : Refer to AT- 2 5 0 , "
Components" .
WLIA0014E

AT-30
A/T CONTROL SYSTEM
Revision: November 20092006 QX56
TCM FunctionECS00CDW
The function of the TCM is to:

Receive input signals sent from various switches and sensors.

Determine required line pressure, shifting point, lock-up operation, and engine brake operation.

Send required output signals to the respective solenoids.
CONTROL SYSTEM OUTLINE
The automatic transmission senses vehicle operating conditions through various sensors or signals. It always
controls the optimum shift position and reduces shifting and lock-up shocks.
CONTROL SYSTEM DIAGRAM
SENSORS (or SIGNALS)

TCM

ACTUATORS
PNP switch
Accelerator pedal position sensor
Closed throttle position signal
Wide open throttle position signal
Engine speed signal
A/T fluid temperature sensor
Revolution sensor
Vehicle speed signal
Stop lamp switch signal
Turbine revolution sensor
1st position switch signal
4th position switch signal
ATF pressure switch signal
Tow mode switch signal Shift control
Line pressure control
Lock-up control
Engine brake control
Timing control
Fail-safe control
Self-diagnosis
CONSULT-II communication line
Duet-EA control
CAN system
Input clutch solenoid valve
Direct clutch solenoid valve
Front brake solenoid valve
High and low reverse clutch
solenoid valve
Low coast brake solenoid valve
Torque converter clutch solenoid
valve
Line pressure solenoid valve
A/T CHECK indicator lamp
Starter relay
Back-up lamp relay
SCIA5624E

AT-42
TROUBLE DIAGNOSIS
Revision: November 20092006 QX56
TROUBLE DIAGNOSISPFP:00004
DTC Inspection Priority ChartECS00CE9
If some DTCs are displayed at the same time, perform inspections one by one based on the following priority
chart.
NOTE:
If DTC U1000 is displayed with other DTCs, first perform the trouble diagnosis for DTC U1000. Refer to
AT- 9 6
.
Fail-SafeECS00CEA
The TCM has an electrical fail-safe mode. This mode makes it possible to operate even if there is an error in a
main electronic control input/output signal circuit. In fail-safe mode the transmission is fixed in 2nd, 4th or 5th
(depending on the breakdown position), so the customer should feel “slipping” or “poor acceleration ”.
Even when the electronic circuits are normal, under special conditions (for example, when slamming on the
brake with the wheels spinning drastically and stopping the tire rotation), the transmission can go into fail-safe
mode. If this happens, switch “OFF ” the ignition switch for 10 seconds, then switch it “ON” again to return to
the normal shift pattern. Therefore, the customer's vehicle has returned to normal, so handle according to the
“diagnostics flow ” (Refer to AT- 4 5 , "
WORK FLOW" ).
FAIL-SAFE FUNCTION
If any malfunction occurs in a sensor or solenoid, this function controls the A/T to make driving possible.
Vehicle Speed Sensor

Signals are input from two systems - from vehicle speed sensor A/T (revolution sensor) installed on the
transmission and from combination meter so normal driving is possible even if there is a malfunction in
one of the systems. And if vehicle speed sensor A/T (revolution sensor) has unusual cases, 5th gear is
prohibited.
Accelerator Pedal Position Sensor

If there is a malfunction in one of the systems, the accelerator opening angle is controlled by ECM accord-
ing to a pre-determined accelerator angle to make driving possible. And if there are malfunctions in tow
systems, the engine speed is fixed by ECM to a pre-determined engine speed to make driving possible.
Throttle Position Sensor

If there is a malfunction in one of the systems, the accelerator opening angle is controlled by ECM accord-
ing to a pre-determined accelerator angle to make driving possible. And if there are malfunctions in tow
systems, the accelerator opening angle is controlled by the idle signal sent from the ECM which is based
on input indicating either idle condition or off-idle condition (pre-determined accelerator opening) in order
to make driving possible.
PNP Switch

In the unlikely event that a malfunction signal enters the TCM, the position indicator is switched “OFF”, the
starter relay is switched “OFF ” (starter starting is disabled), the back-up lamp relay switched “OFF” (back-
up lamp is OFF) and the position is fixed to the “D” range to make driving possible.
Starter Relay

The starter relay is switched “OFF”. (Starter starting is disabled.)
Priority Detected items (DTC)
1 U1000 CAN communication line
2 Except above

TROUBLE DIAGNOSISAT-55
DE
F
G H
I
J
K L
M A
B
AT
Revision: November 2009 2006 QX56
Check Before Engine is StartedECS00CEF
1. CHECK AT CHECK INDICATOR LAMP
1. Park vehicle on level surface.
2. Move selector lever to “P” position.
3. Turn ignition switch to “OFF” position and wait at least 10 seconds.
4. Turn ignition switch to “ON” position. (Do not start engine.)
Does AT CHECK indicator lamp light up for about 2 seconds?
YES >> 1. Turn ignition switch to “OFF” position.
2. Carry out the self-diagnostics and record all NG items on the diagnostics worksheet. Refer to AT- 8 6
.
3. Go to AT- 5 5 , "
Check at Idle" .
NO >> Stop the road test and go to AT- 1 7 9 , "
A/T CHECK Indicator Lamp Does Not Come On" .
Check at Idle ECS00CEG
1. CHECK STARTING THE ENGINE
1. Park vehicle on level surface.
2. Move selector lever to “P” or “N” position.
3. Turn ignition switch to “OFF” position.
4. Turn ignition switch to “START” position.
Does the engine start?
YES >> GO TO 2.
NO >> Stop the road test and go to AT- 1 7 9 , "
Engine Cannot Be Started In “P” or “N” Position" .
2. CHECK STARTING THE ENGINE
1. Turn ignition switch to “ON” position.
2. Move selector lever in “D”,“4 ”, “3”, “2”, “1” or “R ” position.
3. Turn ignition switch to “START” position.
Does the engine start in either position?
YES >> Stop the road test and go to AT- 1 7 9 , "Engine Cannot Be Started In “P” or “N” Position" .
NO >> GO TO 3.
3. CHECK “P” POSITION FUNCTIONS
1. Move selector lever to “P” position.
2. Turn ignition switch to “OFF” position.
3. Release the parking brake.
4. Push the vehicle forward or backward.
5. Engage the parking brake.
When you push the vehicle with disengaging the parking brake, does it move?
YES >> Enter a check mark at “In “P” Position Vehicle Moves When Pushed ” on the diagnostics work-
sheet, then continue the road test.
NO >> GO TO 4.

AT-58
TROUBLE DIAGNOSIS
Revision: November 20092006 QX56
6. CHECK LOCK-UP
When releasing accelerator pedal from D5, check lock-up from D5 to L/U.

Refer to AT- 6 0 , "Vehicle Speed When Shifting Gears" .
With CONSULT-II
Select “TCC SOLENOID 0.00A ” with the “MAIN SIGNAL ” mode for A/T.
Does it lock-up?
YES >> GO TO 7.
NO >> Enter a check mark at “A/T Does Not Perform Lock-up” on the diagnostics worksheet, then con-
tinue the road test.
7. CHECK LOCK-UP HOLD
Does it maintain lock-up status?
YES >> GO TO 8.
NO >> Enter a check mark at “A/T Does Not Hold Lock-up Condition ” on the diagnostics worksheet, then
continue the road test.
8. CHECK LOCK-UP RELEASE
Check lock-up cancellation by depressing brake pedal lightly to decelerate. With CONSULT-II
Select “TCC SOLENOID 0.00A ” with the “MAIN SIGNAL ” mode for A/T.
Does lock-up cancel?
YES >> GO TO 9.
NO >> Enter a check mark at “Lock-up Is Not Released” on the diagnostics worksheet, then continue the
road test.
9. CHECK SHIFT-DOWN D5 → D4
Decelerate by pressing lightly on the brake pedal. With CONSULT-II
Read the gear position and engine speed.
When the A/T shift-down D5
→ D4, does the engine speed drop smoothly back to idle?
YES >> 1. Stop the vehicle.
2. Go to Cruise test - Part 2 (Refer to AT- 5 8
).
NO >> Enter a check mark at “Engine Speed Does Not Return to Idle” on the diagnostics worksheet, then continue the road test. Go to Cruise test - Part 2 (Refer to AT- 5 8
).
Cruise Test - Part 2ECS00CEI
1. CHECK STARTING FROM D1
1. Move selector lever the “D ” position.
2. Accelerate at half throttle.
With CONSULT-II
Read the gear position.
Does it start from D1?
YES >> GO TO 2.
NO >> Enter a check mark at “Vehicle Cannot Be Started From D1 ” on the diagnostics worksheet, then
continue the road test.

AT-172
BRAKE SIGNAL CIRCUIT
Revision: November 20092006 QX56
BRAKE SIGNAL CIRCUITPFP:25320
CONSULT-II Reference ValueECS00CJX
Diagnostic ProcedureECS00CJY
1. CHECK CAN COMMUNICATION LINE
Perform the self-diagnosis. Refer to AT- 8 6 , "
SELF-DIAGNOSTIC RESULT MODE" .
Is a malfunction in the CAN communication indicated in the results?
YES >> Check CAN communication line. Refer to AT- 9 6 , "DTC U1000 CAN COMMUNICATION LINE" .
NO >> GO TO 2.
2. CHECK STOP LAMP SWITCH CIRCUIT
With CONSULT-II
1. Turn ignition switch “ ON”. (Do not start engine.)
2. Select “ECU INPUT SIGNALS ” in “DATA MONITOR” mode for
“A/T ” with CONSULT-II.
3. Read out ON/OFF switching action of the “BRAKE SW”.
OK or NG
OK >> INSPECTION END
NG >> GO TO 3.
3. CHECK STOP LAMP SWITCH
Check continuity between stop lamp switch harness connector termi-
nals 3 and 4.
Check stop lamp switch after adjusting brake pedal — refer to
BR-6, "
BRAKE PEDAL" .
OK or NG
OK >> INSPECTION END
NG >> Check the following items. If NG, repair or replace dam- aged parts.

Harness for short or open between battery and stop lamp switch.

Harness for short or open between stop lamp switch and combination meter.
Item name Condition Display value
BRAKE SW Depressed brake pedal.
ON
Released brake pedal. OFF
PCIA0070E
ConditionContinuity
When brake pedal is depressed Yes
When brake pedal is released No
WCIA0559E
