service INFINITI QX56 2007 Factory Service Manual

-1
QUICK REFERENCE INDEX
AGENERAL INFORMATIONGIGeneral Information
BENGINEEMEngine Mechanical
LUEngine Lubrication System
COEngine Cooling System
ECEngine Control System
FLFuel System
EXExhaust System
ACCAccelerator Control System
CTRANSMISSION/
TRANSAXLEATAutomatic Transmission
DDRIVELINE/AXLETFTransfer
PRPropeller Shaft
FFDFront Final Drive
RFDRear Final Drive
FAXFront Axle
RAXRear Axle
ESUSPENSIONFSUFront Suspension
RSURear Suspension
WTRoad Wheels & Tires
FBRAKESBRBrake System
PBParking Brake System
BRCBrake Control System
GSTEERINGPSPower Steering System
HRESTRAINTSSBSeat Belts
SRSSupplemental Restraint System (SRS)
IBODYBLBody, Lock & Security System
GWGlasses, Window System & Mirrors
RFRoof
EIExterior & Interior
IPInstrument Panel
SESeat
APAdjustable Pedal
JAIR CONDITIONERATCAutomatic Air Conditioner
KELECTRICALSCStarting & Charging System
LTLighting System
DIDriver Information System
WWWiper, Washer & Horn
BCSBody Control System
LANLAN System
AVAudio Visual, Navigation & Telephone System
ACSAuto Cruise Control System
PGPower Supply, Ground & Circuit Elements
LMAINTENANCEMAMaintenance
Edition: August 2006
Revision: December 2007
Publication No. SM7E-1J60U1
B
D
© 2007 NISSAN NORTH AMERICA, INC.
All rights reserved. No part of this Service Manual may be reproduced or stored in a retrieval system, or transmitted in any
form, or by any means, electronic, mechanical, photo-copying, recording or otherwise, without the prior written permission
of Nissan North America, Inc.
A
C
E
F
G
H
I
J
K
L
M

-2
This manual contains maintenance and repair procedures for the
2007 INFINITI QX56.
In order to assure your safety and the efficient functioning of the vehicle,
this manual should be read thoroughly. It is especially important that the
PRECAUTIONS in the GI section be completely understood before starting
any repair task.
All information in this manual is based on the latest product information
at the time of publication. The right is reserved to make changes in specifi-
cations and methods at any time without notice.
IMPORTANT SAFETY NOTICE
The proper performance of service is essential for both the safety of
the technician and the efficient functioning of the vehicle.
The service methods in this Service Manual are described in such a
manner that the service may be performed safely and accurately.
Service varies with the procedures used, the skills of the technician
and the tools and parts available. Accordingly, anyone using service
procedures, tools or parts which are not specifically recommended
by NISSAN must first be completely satisfied that neither personal
safety nor the vehicle’s safety will be jeopardized by the service
method selected.

PLEASEHELPMAKETHISSERVICEMANUALBETTER!
YourcommentsareimportanttoINFINITIandwillhelpustoimproveourServiceManuals.
UsethisformtoreportanyissuesorcommentsyoumayhaveregardingourServiceManuals.
Pleaseprintthisformandtypeorwriteyourcommentsbelow.Mailorfaxto:
NissanNorthAmerica,Inc.
TechnicalServiceInformation
39001SunriseDrive,P.O.Box9200
FarmingtonHills,MIUSA48331
FAX:(248)488-3910
SERVICEMANUAL:Model:Year:
PUBLICATIONNO.(Refer to Quick Reference Index ):
Pleasedescribeany Service Manualissuesorproblemsindetail:
Pagenumber(s)Note:Pleaseincludeacopyofeachpage,markedwithyourcomments.
Arethetroublediagnosisprocedureslogicalandeasytouse?(circleyouranswer)YESNO
Ifno,whatpagenumber(s)?Note:Pleaseincludeacopyofeachpage,markedwithyourcomments.
Pleasedescribetheissueorproblemindetail:
Istheorganizationofthemanualclearandeasytofollow?(circleyouranswer)YESNO
Pleasecomment:
WhatinformationshouldbeincludedinINFINITIServiceManualstobettersupportyouinservicingor
repairingcustomervehicles?
DATE:YOURNAME:POSITION:
DEALER:DEALERNO.:ADDRESS:
CITY:STATE/PROV./COUNTRY:ZIP/POSTALCODE:
RINFINITI

ACC-1
ENGINE
C
D
E
F
G
H
I
J
K
L
M
SECTION ACC
A
ACC
N
O
P
CONTENTS
ACCELERATOR CONTROL SYSTEM
SERVICE INFORMATION ............................2
PRECAUTIONS ...................................................2
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ...................................................................
2
ACCELERATOR CONTROL SYSTEM ..............3
Removal and Installation ..........................................3
SERVICE DATA AND SPECIFICATIONS
(SDS) ..................................................................
5
Accelerator Control ...................................................5

ACC-2
< SERVICE INFORMATION >
PRECAUTIONS
SERVICE INFORMATION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000003532213
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WARNING:
• To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
• Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal
injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag
Module, see the SRS section.
• Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or har-
ness connectors.

ACCELERATOR CONTROL SYSTEM
ACC-3
< SERVICE INFORMATION >
C
D
E
F
G
H
I
J
K
L
MA
ACC
N
P O
ACCELERATOR CONTROL SYSTEM
Removal and InstallationINFOID:0000000003532214
Adjustable Accelerator Pedal
CAUTION:
• Do not disassemble the accelerator pedal adjusting mechanism.
• Before removal and installation the accelerator and brake pedals must be in the frontmost position.
This is to align the base position of the accelerator and brake pedals.
• Do not disassemble the accelerator pedal assembly.
• Do not remove the accelerator pedal position sensor from the accelerator pedal bracket.
• Avoid damage from dropping the accelerator pedal assembly during handling.
• Keep the accelerator pedal assembly away from water.
REMOVAL
1. Move the accelerator and brake pedals to the frontmost position.
2. Turn the ignition switch OFF and disconnect the negative battery terminal.
3. Disconnect the adjustable brake pedal cable from the adjustable brake pedal.
• Unlock, then pull the adjustable brake pedal cable to disconnect it from the adjustable brake pedal.
LBIA0379E
1. Adjustable accelerator pedal assem-
bly2. A/T control cable mounting bracket (part
of the accelerator pedal assembly)3. Adjustable pedal electric motor (part
of the accelerator pedal assembly)
4. Adjustable brake pedal cable (part of
the accelerator pedal assembly)

ACC-4
< SERVICE INFORMATION >
ACCELERATOR CONTROL SYSTEM
4. Disconnect the adjustable pedal electric motor electrical connec-
tor.
5. Disconnect the adjustable pedal electric motor memory electri-
cal connector, if equipped.
6. Disconnect the accelerator position sensor electrical connector.
7. Remove the two upper and one lower accelerator pedal nuts.
8. Remove the adjustable accelerator pedal assembly.
CAUTION:
• Do not disassemble the accelerator pedal assembly.
• Do not remove the accelerator pedal position sensor from
the accelerator pedal bracket.
• Do not disassemble the accelerator pedal adjusting mechanism.
• Avoid damage from dropping the accelerator pedal assembly during handling.
• Keep the accelerator pedal assembly away from water.
INSTALLATION
Installation is in the reverse order of removal.
INSPECTION AFTER INSTALLATION
• Check that the accelerator pedal moves smoothly within the specified ranges.
• Depress and release the accelerator pedal to check that it returns smoothly to the original released position.
• Perform an electrical inspection of the accelerator pedal position sensor. Refer to EC-581
.
CAUTION:
When the harness connector of the accelerator pedal position sensor is disconnected, perform
“Accelerator Pedal Released Position Learning”. Refer to EC-77, "
Accelerator Pedal Released Posi-
tion Learning".
LBIA0380E
Adjustable accelerator pedal – total pedal applied stroke : 48.3 mm (1.90 in)
Adjustable accelerator pedal – total pedal adjustment travel : 73.2 mm (2.88 in)

SERVICE DATA AND SPECIFICATIONS (SDS)
ACC-5
< SERVICE INFORMATION >
C
D
E
F
G
H
I
J
K
L
MA
ACC
N
P O
SERVICE DATA AND SPECIFICATIONS (SDS)
Accelerator ControlINFOID:0000000003532215
ADJUSTABLE ACCELERATOR PEDAL
Total Pedal Travel and Stroke
Unit: mm (in)
Adjustable accelerator pedal - total pedal applied stroke 48.3 (1.90)
Adjustable accelerator pedal - total pedal adjustment travel 73.2 (2.88)

ACS-1
ELECTRICAL
C
D
E
F
G
H
I
J
L
M
SECTION ACS
A
B
ACS
N
O
P
CONTENTS
AUTO CRUISE CONTROL SYSTEM
ASCD
SERVICE INFORMATION ............................
3
AUTOMATIC SPEED CONTROL DEVICE
(ASCD) ................................................................
3
Description ................................................................3
ICC
SERVICE INFORMATION ............................
4
PRECAUTIONS ...................................................4
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ...................................................................
4
Precaution for ICC System Service ...........................4
PREPARATION ...................................................5
Special Service Tool .................................................5
DESCRIPTION ....................................................6
Outline .......................................................................6
Schematic .................................................................6
Component Description .............................................7
CAN Communication .................................................7
Switch Operation .......................................................7
ICC System Display ..................................................8
ACTION TEST .....................................................9
ICC System Running Test .........................................9
LASER BEAM AIMING ADJUSTMENT .............12
Outline of Laser Beam Aiming Adjustment Proce-
dure .........................................................................
12
Preparation ..............................................................12
Setting up the ICC Target Board .............................12
Sensor Adjustment ..................................................14
ELECTRICAL UNITS LOCATION ......................18
Component Parts and Harness Connector Loca-
tion ..........................................................................
18
WIRING DIAGRAM ...........................................19
Schematic ................................................................19
Wiring Diagram - ICC - ............................................20
TERMINALS AND REFERENCE VALUE .........24
Terminal and Reference Value for ICC Unit ............24
Terminal and Reference Value for ICC Sensor .......24
TROUBLE DIAGNOSIS — GENERAL DE-
SCRIPTION .......................................................
25
Work Flow ................................................................25
CONSULT-II Function (ICC) ....................................25
Self-Diagnostic Function ..........................................30
TROUBLE DIAGNOSIS FOR SELF-DIAG-
NOSTIC ITEMS .................................................
34
Diagnostic Trouble Code (DTC) Chart ....................34
DTC 11 CONTROL UNIT ........................................36
DTC 12 VDC CONTROL UNIT ................................36
DTC 20 CAN COMM CIRCUIT ................................37
DTC 31 POWER SUPPLY CIR1, DTC 34 POWER
SUPPLY CIR2 .........................................................
37
DTC 41 VHCL SPEED SE CIRC .............................38
DTC 43 VDC/TCS/ABS CIRC .................................38
DTC 45 BRAKE SW/STOP L SW ............................38
DTC 46 OPERATION SW CIRC .............................40
DTC 74 LASER BEAM OFF CNTR .........................41
DTC 90 STOP LAMP RLY FIX ................................41
DTC 92 ECM CIRCUIT ............................................45
DTC 96 NP RANGE ................................................45
DTC 97 AT CIRCUIT ...............................................46
DTC 98 GEAR POSITION .......................................46
DTC 102 LASER STAIN ..........................................47
DTC 103 LASER SENSOR FAIL .............................47
DTC 104 LASER AIMING INCMP ...........................48
DTC 107 LASER COMM FAIL ................................48
DTC 109 LASER HIGH TEMP ................................48
TROUBLE DIAGNOSIS FOR SYMPTOMS ......49
Symptom Chart ........................................................49

AUTOMATIC SPEED CONTROL DEVICE (ASCD)
ACS-3
< SERVICE INFORMATION >[ASCD]
C
D
E
F
G
H
I
J
L
MA
B
ACS
N
O
P
SERVICE INFORMATION
AUTOMATIC SPEED CONTROL DEVICE (ASCD)
DescriptionINFOID:0000000003533771
Regarding the information for ASCD system, refer to EC-30.
