DOOR MIRROR REMOTE CONTROL SWITCH
CHANGEOVER SWITCH
CHANGEOVER SWITCH : DescriptionINFOID:0000000001735491
Changeover switch is integrated into door mirror remote control switch.
Changeover switch has three positions (L, N and R).
It changes door mirror motor operation by transmitting control signal to automatic drive positioner control unit.
CHANGEOVER SWITCH : Comp onent Function CheckINFOID:0000000001735492
1. CHECK CHANGEOVER SWITCH FUNCTION
Check the operation on “MIR CHNG SW-R” or “MIR CHNG SW-L” in “DATA MONITOR” mode with CON-
SULT-III.
Refer to ADP-26, "
CONSULT-III Function".
Is the inspection result normal?
YES >> Changeover switch function is OK.
NO >> Refer to ADP-61, "
CHANGEOVER SWITCH : Diagnosis Procedure".
CHANGEOVER SWITCH : Diagnosis ProcedureINFOID:0000000001735493
1. CHECK CHANGEOVER SWITCH SIGNAL
1. Turn ignition switch ON.
2. Check voltage between automatic drive positioner control unit
connector and ground.
Is the inspection result normal?
YES >> GO TO 6
NO >> GO TO 2
2. CHECK HARNESS CONTINUITY
1. Turn ignition switch OFF.
2. Disconnect automatic drive positioner control unit and door mir- ror remote control switch.
3. Check continuity between automat ic drive positioner control unit
connector and door mirror remote control switch connector.
4. Check continuity between automatic driv e positioner control unit connector and ground.
Te r m i n a l s
Change over switch condition Voltage (V)
(Approx.)
(+)
(-)
Automatic drive
positioner control unit connector Terminal
M33 2
Ground RIGHT
0
Other than above 5
18 LEFT
0
Other than above 5
PIIA4767E
Automatic drive
positioner control unit connector Te r m i n a lDoor mirror re-
mote control
switch connector Terminal Continuity
M33 (A) 2
D10 (B) 11
Ye s
18 10
ALJIA0201ZZ
Revision: March 2010 2008 QX56

ADP-62
< COMPONENT DIAGNOSIS >
DOOR MIRROR REMOTE CONTROL SWITCH
Is the inspection result normal?
YES >> GO TO 3
NO >> Repair or replace harness.
3. CHECK DOOR MIRROR REMOTE CONTROL SWITCH GROUND CIRCUIT
Check continuity between door mirro r remote control switch connec-
tor and ground.
Is the inspection result normal?
YES >> GO TO 4
NO >> Repair or replace harness.
4. CHECK AUTOMATIC DRIVE POSITIONER CONTROL UNIT OUTPUT SIGNAL
1. Connect automatic drive positioner control unit.
2. Turn ignition switch ON.
3. Check voltage between automatic drive positioner control unit connector and ground.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Replace automatic drive positioner control unit.
5. CHECK CHANGEOVER SWITCH
Check changeover switch.
Refer to ADP-62, "
CHANGEOVER SWITCH : Component Inspection".
Is the inspection result normal?
YES >> Refer to GI-38, "Intermittent Incident".
NO >> Replace door mirror remote control switch.
6. CHECK INTERMITTENT INCIDENT
Check intermittent incident.
Refer to GI-38, "
Intermittent Incident".
Is the inspection result normal?
YES >> Replace automatic drive positioner control unit.
NO >> Repair or replace the malfunctioning parts.
CHANGEOVER SWITCH : Component InspectionINFOID:0000000001735494
1. CHECK CHANGEOVER SWITCH
Automatic drive positioner control
unit connector Te r m i n a l
GroundContinuity
M33 (A) 2
No
18
Door mirror remote control switch
connector Terminal
GroundContinuity
D10 7 Yes
ALJIA0189ZZ
Te r m i n a l s
Voltage (V)(Approx.)
(+)
(-)
Automatic drive positioner
control unit connector Te r m i n a l
M33 2
Ground 5
18
PIIA4767E
Revision: March 2010 2008 QX56

DOOR MIRROR REMOTE CONTROL SWITCHADP-63
< COMPONENT DIAGNOSIS >
C
DE
F
G H
I
K L
M A
B
ADP
N
O P
Check door mirror remote control switch.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace door mirror remote control switch.
MIRROR SWITCH
MIRROR SWITCH : DescriptionINFOID:0000000001735495
It operates angle of the door mirror face.
It transmits mirror face adjust operation to automatic drive positioner control unit.
MIRROR SWITCH : Component Function CheckINFOID:0000000001735496
1. CHECK MIRROR SWITCH FUNCTION
Check the operation on “MIR CON SW–UP/DN” and “M IR CON SW–RH/LH” in “DATA MONITOR” mode
with CONSULT-III.
Refer to ADP-26, "
CONSULT-III Function".
Is the inspection result normal?
YES >> Mirror switch function is OK.
NO >> Refer to ADP-63, "
MIRROR SWITCH : Diagnosis Procedure".
MIRROR SWITCH : Diagnosis ProcedureINFOID:0000000001735497
1. CHECK MIRROR SWITCH FUNCTION
1. Turn ignition switch ON.
2. Check voltage between automatic drive positioner control unit
connector and ground.
Is the inspection result normal?
YES >> GO TO 6
NO >> GO TO 2
2. CHECK HARNESS CONTINUITY
Te r m i n a l Change over switch
condition Continuity
Door mirror remote control switch
10 7LEFT
Yes
Other than above No
11 RIGHT
Yes
Other than above No
ALJIA0272ZZ
Te r m i n a l s
Mirror switchCondition Voltage (V)
(Approx.)
(+)
(–)
Automatic drive
positioner control unit connector Te r m i n a l
M33 3
Ground UP
0
Other than above 5
4 LEFT
0
Other than above 5
19 DOWN
0
Other than above 5
20 RIGHT
0
Other than above 5
PIIA4771E
Revision: March 2010 2008 QX56

ADP-64
< COMPONENT DIAGNOSIS >
DOOR MIRROR REMOTE CONTROL SWITCH
1. Turn ignition switch OFF.
2. Disconnect automatic drive posit ioner control unit and door mir-
ror remote control switch.
3. Check continuity between automat ic drive positioner control unit
connector and door mirror remote control switch connector.
4. Check continuity between automatic driv e positioner control unit connector and ground.
Is the inspection result normal?
YES >> GO TO 3
NO >> Repair or replace harness.
3. CHECK DOOR MIRROR REMOTE CONTROL SWITCH GROUND CIRCUIT
Check continuity between door mirro r remote control switch connec-
tor and ground.
Is the inspection result normal?
YES >> GO TO 4
NO >> Repair or replace harness.
4. CHECK AUTOMATIC DRIVE POSITIONER CONTROL UNIT OUTPUT SIGNAL
1. Connect automatic drive positioner control unit.
2. Turn ignition switch ON.
3. Check voltage between automatic drive positioner control unit and ground.
Is the inspection result normal?
Automatic drive
positioner control unit connector Te r m i n a lDoor mirror remote
control switch con- nector Terminal Continuity
M33 (A) 3
D10 (B) 15
Ye s
41
3
19 12
20 4
Automatic drive positioner control unit connector Te r m i n a l
GroundContinuity
M33 (A) 3
No
4
19
20
ALJIA0191ZZ
Door mirror remote control switch connector Te r m i n a l
Ground Continuity
D10 7 Yes
ALJIA0189ZZ
Te r m i n a l s
Voltage (V)(Approx.)
(+)
(-)
Automatic drive positioner
control unit connector Te r m i n a l
M33 3
Ground 5
4
19
20
PIIA4771E
Revision: March 2010 2008 QX56

DOOR MIRROR REMOTE CONTROL SWITCHADP-65
< COMPONENT DIAGNOSIS >
C
DE
F
G H
I
K L
M A
B
ADP
N
O P
YES >> GO TO 5
NO >> Replace automatic drive positioner control unit.
5. CHECK MIRROR SWITCH
Check mirror switch.
Refer to ADP-65, "
MIRROR SWITCH : Component Inspection".
Is the inspection result normal?
YES >> Refer to GI-38, "Intermittent Incident".
NO >> Replace door mirror remote control switch.
6. CHECK INTERMITTENT INCIDENT
Check intermittent incident.
Refer to GI-38, "
Intermittent Incident".
Is the inspection result normal?
YES >> Replace automatic driv e positioner control unit.
NO >> Repair or replace the malfunctioning parts.
MIRROR SWITCH : Component InspectionINFOID:0000000001735498
1.CHECK MIRROR SWITCH
Check door mirror remote control switch.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace door mirror remote control switch.
Te r m i n a l Mirror switch condition Continuity
Door mirror remote
control switch
4
7RIGHT Yes
Other than above
No
13 LEFT
Yes
Other than above No
15 UP
Yes
Other than above No
12 DOWN
Yes
Other than above No
AWJIA0239ZZ
Revision: March 2010 2008 QX56

ADP-144
< ECU DIAGNOSIS >
BCM (BODY CONTROL MODULE)
Te r m i n a lWire
color Signal name Signal
input/
output Measuring condition
Reference value or waveform
(Approx.)
Ignition
switch Operation or condition
1BR/W Ignition keyhole illumi-
nation Output OFFDoor is locked (SW OFF)
Battery voltage
Door is unlocked (SW ON) 0V
2SB Combination switch
input 5 Input ON
Lighting, turn, wiper OFF
Wiper dial position 4
3G/Y Combination switch
input 4 Input ONLighting, turn, wiper OFF
Wiper dial position 4
4Y Combination switch
input 3 Input ON
Lighting, turn, wiper OFF
Wiper dial position 4
5G/B Combination switch
input 2
Input ONLighting, turn, wiper OFF
Wiper dial position 4
6V Combination switch
input 1
9GR/R Rear window defogger
switch
Input ONRear window defogger switch
ON
0V
Rear window defogger switch
OFF 5V
10 G Hazard lamp flash Input OFF ON (opening or closing)
0V
OFF (other than above) Battery voltage
11 O Ignition switch (ACC
or ON)
InputACC or
ON Ignition switch ACC or ON
Battery voltage
12 R/L Front door switch RH Input OFF ON (open)
0V
OFF (closed) Battery voltage
13 GR Rear door switch RH Input OFF ON (open)
0V
OFF (closed) Battery voltage
15 L/W Tire pressure warning
check connector
Input OFF
—5V
18 P Remote keyless entry
receiver and optical
sensor (ground)
Output OFF
—0V
SKIA5291E
SKIA5292E
SKIA5291E
SKIA5292E
Revision: March 2010 2008 QX56

BCM (BODY CONTROL MODULE)ADP-145
< ECU DIAGNOSIS >
C
DE
F
G H
I
K L
M A
B
ADP
N
O P
19 V/W Remote keyless entry
receiver (power sup-
ply) Output OFF Ignition switch OFF
20 G/W Remote keyless entry
receiver (signal) Input OFFStand-by (keyfob buttons re-
leased)
When remote keyless entry
receiver receives signal from
keyfob (keyfob buttons
pressed)
21 G NATS antenna amp. Input OFF
→
ON Ignition switch (OFF → ON) Just after turning ignition switch
ON: Pointer of tester should
move for approx. 1 second, then return to battery voltage.
22 W/V BUS — —Ignition switch ON or power
window timer operates
23 G/O Security indicator
lamp Output OFF
Goes OFF
→ illuminates (Ev-
ery 2.4 seconds) Battery voltage
→ 0V
25 BR NATS antenna amp. Input OFF
→
ON Ignition switch (OFF → ON) Just after turning ignition switch
ON: Pointer of tester should
move for approx. 1 second, then return to battery voltage.
26 Y/L Rear wiper auto stop
switch 2 Input ONRise up position (rear wiper
arm on stopper)
0V
A Position (full clockwise stop
position) 0V
Forward sweep (counterclock-
wise direction) Fluctuating
B Position (full counterclock-
wise stop position) Battery voltage
Reverse sweep (clockwise di-
rection) Fluctuating
27 W/R Compressor ON sig-
nal Input ONA/C switch OFF
5V
A/C switch ON 0V
Te r m i n a l
Wire
color Signal name Signal
input/
output Measuring condition
Reference value or waveform
(Approx.)
Ignition
switch Operation or condition
LIIA1893E
LIIA1894E
LIIA1895E
PIIA2344E
Revision: March 2010
2008 QX56

AV-4
STEERING SWITCH ........................................174
Removal and Installation ..................................... ..174
REAR AUDIO REMOTE CONTROL UNIT ......175
Removal and Installation ..................................... ..175
DVD ENTERTAINMENT SYSTEM ..................176
Removal and Installation ..................................... ..176
BOSE SPEAKER AMP ....................................177
Removal and Installation ..................................... ..177
AUDIO ANTENNA ...........................................178
Location of Antennas ........................................... ..178
Window Antenna Repair ........................................178
SATELLITE RADIO ANTENNA .......................180
Removal and Installation .......................................180
GPS ANTENNA .............................................. ..181
Removal and Installation .......................................181
MICROPHONE ............................................... ..182
Removal and Installation .......................................182
REAR VIEW CAMERA .....................................183
Removal and Installation .......................................183
REAR VIEW CAMERA CONTROL UNIT ....... ..184
Removal and Installation .......................................184
Revision: March 2010 2008 QX56

AV-10
< FUNCTION DIAGNOSIS >[AUDIO SYSTEM]
AUDIO SYSTEM
The audio system consists of the following components
• AV control unit
• Display unit
• BOSE speaker amp.
• Window antenna
• Steering wheel audio control switches
• A/C and AV switch assembly
• Rear audio and remote control unit
• Front door speakers
• Front tweeters
• Center speaker
• Rear door speakers
• Rear door tweeters
• Back door speakers
• Subwoofer
When the audio system is on, radio signals are receiv
ed by the window antenna. The AV control unit then
sends audio signals to the BOSE speaker amp. The BO SE speaker amp. amplifies the audio signals before
sending them to the front door speakers, front tweeters, center speaker, rear door speakers, rear door tweet-
ers, back door speakers and the subwoofer.
Refer to Owner's Manual for audio system operating instructions.
SATELLITE RADIO SYSTEM
The satellite radio system consists of the following components
• Satellite antenna
• AV control unit
When the satellite radio system is on, radio signals are supplied to the AV contro l unit from the satellite
antenna. The AV control unit then sends audio signals to the BOSE speaker amp.
Refer to Owner's Manual for satellite radio system operating instructions.
SPEED SENSITIVE VOLUME SYSTEM
Volume level of this system goes up and down automatically in proportion to the vehicle speed. The control
level can be selected by the customer. Refer to Owner's Manual for operating instructions.
Revision: March 2010 2008 QX56

AV-12
< FUNCTION DIAGNOSIS >[AUDIO SYSTEM]
AUDIO SYSTEM
Component Description
INFOID:0000000001696021
10. Rear audio and remote control unit R204 11. Microphone R109 12. Front door speaker
LH D12
RH D112
13. Rear door tweeter LH D208
RH D308 14. Rear door speaker
LH D207
RH D307 15. Back door speaker
LH D518
RH D716
16. Subwoofer B72 (under driver’s seat) 17. BOSE speaker amp M112, M113 (view behind instrument panel above
accelerator pedal)18. Rear camera control unit B73 (locat-
ed behind luggage finisher LHl)
19. Rear view camera D504
Part name Description
AV control unit Controls audio system, NAVI functions and satellite radio system functions
Display unit • Touch screen controls all audio and A/C operations
• Displays all audio and climate control related information
BOSE speaker amp. Receives power (amp ON) and audio signals from AV control unit and out-
puts audio signals to each speaker.
Steering switches • Audio operation can be operated
• Steering switch signal is output to AV control unit
Front door speakers • Outputs audio signal from BOSE speaker amp.
• Outputs high, mid and low range sounds
Front tweeters • Outputs audio signal from BOSE speaker amp.
• Outputs high range sounds
Center speaker • Outputs audio signal from BOSE speaker amp.
• Outputs high range sounds
Rear door speakers • Outputs audio signal from BOSE speaker amp.
• Outputs high, mid and low range sounds
Rear door tweeters • Outputs audio signal from BOSE speaker amp.
• Outputs high range sounds
Back door speakers • Outputs audio signal from BOSE speaker amp.
• Outputs high, mid and low range sounds
Subwoofer • Outputs audio signal from BOSE speaker amp.
• Outputs low range sounds
Satellite antenna Audio signal (satellite radio) is received and output to AV control unit.
Revision: March 2010 2008 QX56
