INFINITI QX56 2009 Factory Service Manual

AUTOMATIC DRIVE POSITIONER CONTROL UNITADP-137
< ECU DIAGNOSIS >
C
DE
F
G H
I
K L
M A
B
ADP
N
O P
ABJIA0049GB
Revision: December 20092009 QX56

ADP-138
< ECU DIAGNOSIS >
AUTOMATIC DRIVE POSITIONER CONTROL UNIT
ABJIA0050GB
Revision: December 20092009 QX56

AUTOMATIC DRIVE POSITIONER CONTROL UNITADP-139
< ECU DIAGNOSIS >
C
DE
F
G H
I
K L
M A
B
ADP
N
O P
ABJIA0051GB
Revision: December 20092009 QX56

ADP-140
< ECU DIAGNOSIS >
AUTOMATIC DRIVE POSITIONER CONTROL UNIT
ABJIA0052GB
Revision: December 20092009 QX56

AUTOMATIC DRIVE POSITIONER CONTROL UNITADP-141
< ECU DIAGNOSIS >
C
DE
F
G H
I
K L
M A
B
ADP
N
O P
ABJIA0053GB
Revision: December 20092009 QX56

ADP-142
< ECU DIAGNOSIS >
AUTOMATIC DRIVE POSITIONER CONTROL UNIT
ABJIA0054GB
Revision: December 20092009 QX56

AUTOMATIC DRIVE POSITIONER CONTROL UNITADP-143
< ECU DIAGNOSIS >
C
DE
F
G H
I
K L
M A
B
ADP
N
O P
ABJIA0055GB
Revision: December 20092009 QX56

ADP-144
< ECU DIAGNOSIS >
AUTOMATIC DRIVE POSITIONER CONTROL UNIT
ABJIA0056GB
Revision: December 20092009 QX56

AUTOMATIC DRIVE POSITIONER CONTROL UNITADP-145
< ECU DIAGNOSIS >
C
DE
F
G H
I
K L
M A
B
ADP
N
O P
ABJIA0057GB
Revision: December 20092009 QX56

ADP-146
< ECU DIAGNOSIS >
BCM (BODY CONTROL MODULE)
BCM (BODY CONTROL MODULE)
Reference ValueINFOID:0000000004064157
VALUES ON THE DIAGNOSIS TOOL
Monitor Item Condition Value/Status
AIR COND SW A/C switch OFF OFF
A/C switch ON ON
AUT LIGHT SYS Outside of the room is dark OFF
Outside of the room is bright ON
AUTO LIGHT SW Lighting switch OFF OFF
Lighting switch AUTO ON
BACK DOOR SW Back door closed OFF
Back door opened ON
CDL LOCK SW Door lock/unlock switch does not operate OFF
Press door lock/unlock switch to the LOCK side ON
CDL UNLOCK SW Door lock/unlock switch does not operate OFF
Press door lock/unlock switch to the UNLOCK side ON
DOOR SW-AS Front door RH closed OFF
Front door RH opened ON
DOOR SW-DR Front door LH closed OFF
Front door LH opened ON
DOOR SW-RL Rear door LH closed OFF
Rear door LH opened ON
DOOR SW-RR Rear door RH closed OFF
Rear door RH opened ON
ENGINE RUN Engine stopped OFF
Engine running ON
FR FOG SW Front fog lamp switch OFF OFF
Front fog lamp switch ON ON
FR WASHER SW Front washer switch OFF OFF
Front washer switch ON ON
FR WIPER LOW Front wiper switch OFF OFF
Front wiper switch LO ON
FR WIPER HI Front wiper switch OFF OFF
Front wiper switch HI ON
FR WIPER INT Front wiper switch OFF OFF
Front wiper switch INT ON
FR WIPER STOP Any position other than front wiper stop position OFF
Front wiper stop position ON
HAZARD SW When hazard switch is not pressed OFF
When hazard switch is pressed ON
LIGHT SW 1ST Lighting switch OFF OFF
Lighting switch 1st ON
Revision: December 20092009 QX56
