C1109 POWER AND GROUND SYSTEMBRC-35
< COMPONENT DIAGNOSIS > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
4. Turn ignition switch OFF.
5. Check continuity between ABS actuator and electric unit (control unit) connector E125 terminals 16, 47 and ground.
Is the inspection result normal?
YES >> Check battery for terminal looseness, low voltage, etc. If any malfunction is found, repair malfunc-
tioning parts.
NO >> Repair or replace malfunctioning components.
Special Repair RequirementINFOID:0000000005194904
1.ADJUSTMENT OF STEERING AN GLE SENSOR NEUTRAL POSITION
Always perform neutral position adjustment for the st eering angle sensor when replacing the ABS actuator
and electric unit (control unit). Refer to BRC-8, "
ADJUSTMENT OF STEERING ANGLE SENSOR NEUTRAL
POSITION : Description".
>> GO TO 2
2.CALIBRATION OF DECEL G SENSOR
Always perform calibration of decel G sensor when replacing the ABS actuator and electric unit (control unit).
Refer to BRC-9, "
CALIBRATION OF DECEL G SENSOR : Description".
>> END
ABS actuator and electric unit (control unit) —Con tin uit y
Connector Terminal
E125 16, 47 Ground Yes
AWFIA0016ZZ
Revision: April 20092010 QX56

BRC-36
< COMPONENT DIAGNOSIS >[VDC/TCS/ABS]
C1110, C1170 ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
C1110, C1170 ABS ACTUATOR AND EL
ECTRIC UNIT (CONTROL UNIT)
DTC LogicINFOID:0000000005147977
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAGNOSIS RESULTS
Check the self-diagnosis results.
Is above displayed on the self-diagnosis display?
YES >> Proceed to diagnosis procedure. Refer to BRC-36, "Diagnosis Procedure".
NO >> Inspection End
Diagnosis ProcedureINFOID:0000000005147978
1.REPLACE ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
>> Replace ABS actuator and electric unit (control unit). Refer to BRC-116, "
Removal and Installa-
tion".
Special Repair RequirementINFOID:0000000005194905
1.ADJUSTMENT OF STEERING ANGLE SENSOR NEUTRAL POSITION
Always perform neutral position adjustment for the st eering angle sensor when replacing the ABS actuator
and electric unit (control unit). Refer to BRC-8, "
ADJUSTMENT OF STEERING ANGLE SENSOR NEUTRAL
POSITION : Description".
>> GO TO 2
2.CALIBRATION OF DECEL G SENSOR
Always perform calibration of decel G sensor when replac ing the ABS actuator and electric unit (control unit).
Refer to BRC-9, "
CALIBRATION OF DECEL G SENSOR : Description".
>> END
DTC Display item Malfunction detected condition Possible cause
C1110 CONTROLLER FAILURE When there is an internal malfunction in the ABS actuator
and electric unit (control unit).
• ABS actuator and electric unit
(control unit)
C1170 VARIANT CODING In a case where VARIANT CODING is different.
Self-diagnosis results
CONTROLLER FAILURE VARIANT CODING
Revision: April 20092010 QX56

BRC-38
< COMPONENT DIAGNOSIS >[VDC/TCS/ABS]
C1111 ABS MOTOR, MOTOR RELAY SYSTEM
1. Turn ignition switch OFF.
2. Disconnect ABS actuator and elec
tric unit (control unit) connec-
tor.
3. Check voltage between the ABS actuator and electric unit (con- trol unit) connector E125 terminal 1 and ground.
Is the inspection result normal?
YES >> GO TO 3
NO >> Repair or replace malfunctioning components.
3.CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) GROUND CIRCUIT
Check continuity between ABS actuator and electric unit (control
unit) connector E125 terminals 16, 47 and ground.
Is the inspection result normal?
YES >> Replace ABS actuator and electric unit (control unit). Refer to BRC-116, "
Removal and Installation".
NO >> Repair or replace malfunctioning components.
Component InspectionINFOID:0000000005147983
1.CHECK ACTIVE TEST
1. On “ACTIVE TEST”, select “ABS MOTOR”.
2. Touch “On” and “Off” on screen. Make sure motor re lay and actuator relay operates as shown in table
below.
Is the inspection result normal?
YES >> Inspection End
NO >> Go to diagnosis procedure. Refer to BRC-37, "
Diagnosis Procedure".
Special Repair RequirementINFOID:0000000005194906
1.ADJUSTMENT OF STEERING ANGLE SENSOR NEUTRAL POSITION
Always perform neutral position adjustment for the st eering angle sensor when replacing the ABS actuator
and electric unit (control unit). Refer to BRC-8, "
ADJUSTMENT OF STEERING ANGLE SENSOR NEUTRAL
POSITION : Description".
>> GO TO 2
2.CALIBRATION OF DECEL G SENSOR
Always perform calibration of decel G sensor when replac ing the ABS actuator and electric unit (control unit).
Refer to BRC-9, "
CALIBRATION OF DECEL G SENSOR : Description".
>> END
ABS actuator and electric unit (control unit) —Volt a g e
Connector Terminal
E125 1Ground Battery voltage
AWFIA0017ZZ
ABS actuator and electric unit (control unit)
—Continuity
Connector Terminal
E125 16, 47GroundYes
AWFIA0016ZZ
Operation OnOff
MOTOR RELAY OnOff
ACTUATOR RLY OnOn
Revision: April 20092010 QX56

C1113, C1145, C1146 YAW RATE/SIDE/DECEL G SENSOR
BRC-39
< COMPONENT DIAGNOSIS > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
C1113, C1145, C1146 YAW RATE/SIDE/DECEL G SENSOR
DescriptionINFOID:0000000005147985
The yaw rate/side/decel G sensor detects the yaw rate /side/decel G affecting the vehicle, and transmits the
data to the ABS actuator and electric uni t (control unit) as an analog voltage signal.
DTC LogicINFOID:0000000005147986
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAGNOSIS RESULTS
Check the self-diagnosis results.
Is above displayed on the self-diagnosis display?
YES >> Proceed to diagnosis procedure. Refer to BRC-39, "Diagnosis Procedure".
NO >> Inspection End
Diagnosis ProcedureINFOID:0000000005147987
Regarding Wiring Diagram information, refer to BRC-92, "Wiring Diagram - BRAKE CONTROL SYSTEM -".
CAUTION:
• Sudden turns (such as spin turns, acceleration turns), drifting, etc. when VDC function is OFF may
cause the yaw rate/side/decel G sensor system to indi cate a malfunction. This is not a malfunction if
normal operation can be resumed after restarting the engine.
• If vehicle is on turn table at entrance to parking garage, or on other moving surface, VDC OFF indica- tor lamp may illuminate and CONSULT-III self-dia gnosis may indicate yaw rate sensor system mal-
function. However, in this case there is no malfunc tion in yaw rate sensor system. Take vehicle off of
turn table or other moving surface, and st art engine. Results will return to normal.
1.CONNECTOR INSPECTION
1. Disconnect the ABS actuator and electric unit (control unit) connector and yaw rate/side/decel G sensor connector.
2. Check the terminals for deformation, disconnection, looseness or damage.
Is the inspection result normal?
YES >> GO TO 2
NO >> Repair or replace as necessary.
2.YAW RATE/SIDE/DECEL G SENSOR HARNESS INSPECTION
DTC Display item Malfunction detected condition Possible cause
C1113 G-SENSOR Longitudinal G-sensor is malfunctioning, or signal line of
longitudinal G-sensor is open or shorted.
• Harness or connector
• ABS actuator and electric unit
(control unit)
• Yaw rate/side/decel G sensor
C1145 YAW RATE SENSOR
Yaw rate sensor is malfunctioning, or the yaw rate sensor
signal line is open or shorted.
C1146 SIDE G-SEN CIRCUIT Side G sensor is malfunctioning, or circuit of side G sen-
sor is open or shorted.
Self-diagnosis results
G-SENSOR
YAW RATE SENSOR
SIDE G-SEN CIRCUIT
Revision: April 20092010 QX56

BRC-40
< COMPONENT DIAGNOSIS >[VDC/TCS/ABS]
C1113, C1145, C1146 YAW
RATE/SIDE/DECEL G SENSOR
Check continuity between the ABS actuator and electric unit (control
unit) connector E125 (A) and the yaw rate/side/decel G sensor con-
nector M108 (B).
Is the inspection result normal?
YES >> GO TO 3
NO >> Repair or replace as necessary.
3.YAW RATE/SIDE/DECEL G SENSOR INSPECTION
1. Connect the yaw rate/side/decel G sensor connector and ABS actuator and electric unit (control unit) con- nector.
2. Perform the yaw rate/side/decel G sensor component inspection. Refer to BRC-40, "
Component Inspec-
tion".
Is the inspection result normal?
YES >> Replace the ABS actuator and electric unit (control unit). Refer to BRC-116, "Removal and Instal-
lation".
NO >> Replace the yaw rate/side/decel G sensor. Refer to BRC-119, "
Removal and Installation".
Component InspectionINFOID:0000000005147988
1.CHECK DATA MONITOR
Select “YAW RATE SEN”, “SIDE G-SENSOR”, “DECEL G-SEN” in “DATA MONITOR” and check yaw rate/
side/decel G sensor signal.
Is the inspection result normal?
YES >> Inspection End
NO >> Go to diagnosis procedure. Refer to BRC-39, "
Diagnosis Procedure".
Special Repair RequirementINFOID:0000000005194907
1.ADJUSTMENT OF STEERING ANGLE SENSOR NEUTRAL POSITION
Always perform neutral position adjustment for the st eering angle sensor when replacing the ABS actuator
and electric unit (control unit). Refer to BRC-8, "
ADJUSTMENT OF STEERING ANGLE SENSOR NEUTRAL
POSITION : Description".
>> GO TO 2
2.CALIBRATION OF DECEL G SENSOR
Always perform calibration of decel G sensor when replac ing the ABS actuator and electric unit (control unit).
Refer to BRC-9, "
CALIBRATION OF DECEL G SENSOR : Description".
ABS actuator and electric unit
(control unit) Yaw rate/side/decel G sensor
Continuity
Connector Terminal Connector Terminal
E125 (A) 6
M108 (B) 3
Ye s
24
5
25 1
29 2
AWFIA0024ZZ
Vehicle conditionYAW RATE SEN
(DATA MONITOR) SIDE G-SENSOR
(DATA MONITOR) DECEL G-SEN
(DATA MONITOR)
Stopped -4 to +4 deg/s -1.1 to +1.1 m/s-0.11 G to +0.11 G
Turning right Negative value Negative value -
Turning left Positive value Positive value -
Speed up --Negative value
Speed down --Positive value
Revision: April 20092010 QX56

C1113, C1145, C1146 YAW RATE/SIDE/DECEL G SENSOR
BRC-41
< COMPONENT DIAGNOSIS > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
>> END
Revision: April 20092010 QX56

BRC-42
< COMPONENT DIAGNOSIS >[VDC/TCS/ABS]
C1115 WHEEL SENSOR
C1115 WHEEL SENSOR
DescriptionINFOID:0000000005147990
When the sensor rotor rotates, the magnetic field changes. It converts the magnetic field changes to current
signals (rectangular wave) and transmits them to t
he ABS actuator and electric unit (control unit).
DTC LogicINFOID:0000000005147991
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAGNOSIS RESULTS
Check the self-diagnosis results.
Is above displayed on the self-diagnosis display?
YES >> Proceed to diagnosis procedure. Refer to BRC-42, "Diagnosis Procedure".
NO >> Inspection End
Diagnosis ProcedureINFOID:0000000005194908
Regarding Wiring Diagram information, refer to BRC-92, "Wiring Diagram - BRAKE CONTROL SYSTEM -".
CAUTION:
Do not check between wheel sensor terminals.
1.CONNECTOR INSPECTION
1. Disconnect the ABS actuator and electric unit (contro l unit) connector and wheel sensor of malfunctioning
code.
2. Check the terminals for deformati on, disconnection, looseness or damage.
Is the inspection result normal?
YES >> GO TO 2
NO >> Repair or replace as necessary.
2.CHECK WHEEL SENSOR OUTPUT SIGNAL
1. Connect ABS active wheel sensor tester (J-45741) to wheel sensor using appropriate adapter.
2. Turn on the ABS active wheel sensor tester power switch. NOTE:
The green POWER indicator should illuminate. If the POWER indicator does not illuminate, replace the
battery in the ABS active wheel sensor tester before proceeding.
3. Spin the wheel of the vehicle by hand and observe the red SENSOR indicator on the ABS active wheel
sensor tester. The red SENSOR indicator should flash on and off to indicate an output signal.
NOTE:
If the red SENSOR indicator illuminates but does not flash, reverse the polarity of the tester leads and
retest.
Does the ABS active wheel sensor tester detect a signal?
YES >> GO TO 3
NO >> Replace the wheel sensor. Refer to BRC-114, "
Removal and Installation".
DTC Display item Malfunction detected condition Possible cause
C 111 5 ABS SENSOR
[ABNORMAL SIGNAL] When wheel sensor input signal is malfunctioning. • Harness or connector
• Wheel sensor
• ABS actuator and electric unit
(control unit)
Self-diagnosis results
ABS SENSOR [ABNORMAL SIGNAL]
Revision: April 20092010 QX56

C1115 WHEEL SENSORBRC-43
< COMPONENT DIAGNOSIS > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
3.CHECK TIRES
Check the inflation pressure, wear and size of each tire.
Is the inspection result normal?
YES >> GO TO 4
NO >> Adjust tire pressure or replace tire(s).
4.CHECK WHEEL BEARINGS
Check wheel bearing axial end play. Refer to FA X - 6 , "
On-Vehicle Inspection and Service" (front) or RAX-6,
"On-Vehicle Inspection and Service" (rear).
Is the inspection result normal?
YES >> GO TO 5
NO >> Repair or replace as necessary. Refer to FAX-7, "
Removal and Installation" (front) or RAX-8,
"Removal and Installation" (rear).
5.CHECK WIRING HARNESS FOR SHORT CIRCUIT
1. Disconnect ABS actuator and electric unit (control unit) connec- tor and wheel sensor connector of malfunction code.
2. Check continuity between wheel sensor connector terminals and ground.
Is the inspection result normal?
YES >> GO TO 6
NO >> Repair the circuit.
6.CHECK WIRING HARNESS FOR OPEN CIRCUIT
Check continuity between ABS actuator and electric unit (control unit) connector and the malfunctioning wheel
sensor connector.
Is the inspection result normal?
YES >> Replace the ABS actuator and elec tric unit (control unit). Refer to BRC-116, "Removal and Instal-
lation".
NO >> Repair the circuit.
Component InspectionINFOID:0000000005194909
1.CHECK DATA MONITOR
On “DATA MONITOR”, select “FR LH SENSOR”, “FR RH SENSOR”, “RR LH SENSOR”, and “RR RH SEN-
SOR”, and check the vehicle speed. Continuity should not exist.
AWFIA0188ZZ
Wheel sensor
ABS actuator and
electric unit (control unit) Wheel sensor
Continuity
Connector Terminal Connector Terminal
Front LH
E12545
E18 1
Ye s
46
2
Front RH 34
E117 1
33 2
Rear LH 37
C11 2
36 1
Rear RH 42
C10 2
43 1
Revision: April 20092010 QX56

BRC-44
< COMPONENT DIAGNOSIS >[VDC/TCS/ABS]
C1115 WHEEL SENSOR
Is the inspection result normal?
YES >> Inspection End
NO >> Go to diagnosis procedure. Refer to
BRC-42, "
Diagnosis Procedure".
Special Repair RequirementINFOID:0000000005194910
1.ADJUSTMENT OF STEERING ANGLE SENSOR NEUTRAL POSITION
Always perform neutral position adjustment for the st eering angle sensor when replacing the ABS actuator
and electric unit (control unit). Refer to BRC-8, "
ADJUSTMENT OF STEERING ANGLE SENSOR NEUTRAL
POSITION : Description".
>> GO TO 2
2.CALIBRATION OF DECEL G SENSOR
Always perform calibration of decel G sensor when replac ing the ABS actuator and electric unit (control unit).
Refer to BRC-9, "
CALIBRATION OF DECEL G SENSOR : Description".
>> END
Wheel sensor Vehicle speed (DATA MONITOR)
FR LH SENSOR
Nearly matches the speedometer dis-
play (±10% or less)
FR RH SENSOR
RR LH SENSOR
RR RH SENSOR
Revision: April 20092010 QX56

BRC-46
< COMPONENT DIAGNOSIS >[VDC/TCS/ABS]
C1116 STOP LAMP SWITCH
1. Disconnect the stop lamp relay harness connector E12.
2. Check the continuity between t
he ABS actuator and electric unit
(control unit) connector E125 (B) terminal 41 and stop lamp
relay connector E12 (A) terminal 4.
Is the inspection result normal?
YES >> Refer to EXL-4, "Work Flow".
NO >> Repair or replace malfunctioning components.
Special Repair RequirementINFOID:0000000005194913
1.ADJUSTMENT OF STEERING ANGLE SENSOR NEUTRAL POSITION
Always perform neutral position adjustment for the st eering angle sensor when replacing the ABS actuator
and electric unit (control unit). Refer to BRC-8, "
ADJUSTMENT OF STEERING ANGLE SENSOR NEUTRAL
POSITION : Description".
>> GO TO 2
2.CALIBRATION OF DECEL G SENSOR
Always perform calibration of decel G sensor when replac ing the ABS actuator and electric unit (control unit).
Refer to BRC-9, "
CALIBRATION OF DECEL G SENSOR : Description".
>> END
Continuity should exist.
AWFIA0020ZZ
Revision: April 20092010 QX56
