INFINITI QX56 2010 Factory Service Manual

PWC-116
< PRECAUTION >
PRECAUTIONS
5. When the repair work is completed, return the ignition switch to the ″LOCK ″ position before connecting
the battery cables. (At this time, the steering lock mechanism will engage.)
6. Perform a self-diagnosis check of a ll control units using CONSULT-III.
Revision: April 20092010 QX56

POWER WINDOW MAIN SWITCHPWC-117
< ON-VEHICLE REPAIR >
C
DE
F
G H
I
J
L
M A
B
PWC
N
O P
ON-VEHICLE REPAIR
POWER WINDOW MAIN SWITCH
Removal and InstallationINFOID:0000000005147265
REMOVAL
1. Remove the power window main switch finisher (2) from the door finisher LH. Refer to INT-11, "
Removal and Installation".
2. Using a suitable tool (A), remove the screws from the power win- dow main switch (1), then release from the finisher (2).
INSTALLATION
Installation is in the reverse order of removal.
ALKIA0856ZZ
Revision: April 20092010 QX56

PWC-118
< ON-VEHICLE REPAIR >
FRONT POWER WINDOW SWITCH
FRONT POWER WINDOW SWITCH
Removal and InstallationINFOID:0000000005147266
REMOVAL
1. Remove the front power window switch finisher (2) from the frontdoor finisher RH. Refer to INT-11, "
Removal and Installation".
: Pawl
2. Using a suitable tool (A), release the tabs and remove the front power window switch (1).
INSTALLATION
Installation is in the reverse order of removal.
ALKIA0857ZZ
Revision: April 20092010 QX56

REAR POWER WINDOW SWITCHPWC-119
< ON-VEHICLE REPAIR >
C
DE
F
G H
I
J
L
M A
B
PWC
N
O P
REAR POWER WINDOW SWITCH
Removal and InstallationINFOID:0000000005147267
REMOVAL
1. Remove the rear power window switch finisher (1) from the rear door finisher. Refer to INT-11, "
Removal and Installation".
2. Using a suitable tool (A), release the tabs and remove the rear power window switch (2).
INSTALLATION
Installation is in the reverse order of removal.
ALKIA0860ZZ
Revision: April 20092010 QX56

PWC-120
< ON-VEHICLE REPAIR >
REAR POWER VENT WINDOW SWITCH
REAR POWER VENT WINDOW SWITCH
Removal and InstallationINFOID:0000000005268493
REMOVAL
1. Remove the instrument lower panel LH, refer to IP-14, "Removal and Installation".
2. Using a suitable tool, release the upper and lower tabs , then remove the rear power vent window switch.
INSTALLATION
Installation is in the reverse order of removal.
1. Rear power vent window switch 2. Instrument lower panel LH Tab
ALKIA1619ZZ
Revision: April 20092010 QX56

PWO
PWO-1
ELECTRICAL & POWER CONTROL
C
DE
F
G H
I
J
K L
B
SECTION PWO
A
O P
N
CONTENTS
POWER OUTLET
PRECAUTION .......
........................................2
PRECAUTIONS .............................................. .....2
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ............................................................. ......
2
Precaution Necessary for Steering Wheel Rota-
tion After Battery Disconnect ............................... ......
2
COMPONENT DIAGNOSIS ..........................4
POWER SOCKET ..............................................4
Wiring Diagram .................................................... .....4
ON-VEHICLE REPAIR ..................................7
POWER SOCKET ..............................................7
Removal and Installation ..................................... .....7
Revision: April 20092010 QX56

PWO-2
< PRECAUTION >
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000005212333
The Supplemental Restraint System such as “A IR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and w hether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SR and SB section of this Service Man-
ual.
WARNING:
• To avoid rendering the SRS inopera tive, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
• Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintent ional activation of the system. For re moval of Spiral Cable and Air Bag
Module, see the SR section.
• Do not use electrical test equipmen t on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harn esses can be identified by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
• When working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Igni-
tion ON or engine running, DO NOT use air or electri c power tools or strike near the sensor(s) with a
hammer. Heavy vibration could activate the sensor( s) and deploy the air bag(s), possibly causing
serious injury.
• When using air or electric power tools or hammers , always switch the Ignition OFF, disconnect the
battery, and wait at least 3 minu tes before performing any service.
Precaution Necessary for Steering W heel Rotation After Battery Disconnect
INFOID:0000000005212334
NOTE:
• This Procedure is applied only to models with Intelligent Key system and NATS (NISSAN ANTI-THEFT SYS-
TEM).
• Remove and install all control units after disconnecting both battery cables with the ignition knob in the
″LOCK ″ position.
• Always use CONSULT-III to perform self-diagnosis as a part of each function inspection after finishing work.
If DTC is detected, perform trouble diagnosis according to self-diagnostic results.
For models equipped with the Intelligent Key system and NATS, an electrically controlled steering lock mech-
anism is adopted on the key cylinder.
For this reason, if the battery is disconnected or if the battery is discharged, the steering wheel will lock and
steering wheel rotation will become impossible.
If steering wheel rotation is required when battery pow er is interrupted, follow the procedure below before
starting the repair operation.
OPERATION PROCEDURE
1. Connect both battery cables. NOTE:
Supply power using jumper cables if battery is discharged.
2. Use the Intelligent Key or mechanical key to turn the ignition switch to the ″ACC ″ position. At this time, the
steering lock will be released.
3. Disconnect both battery cables. The steering lock will remain released and the steering wheel can be rotated.
4. Perform the necessary repair operation.
Revision: April 20092010 QX56

PWO
PRECAUTIONSPWO-3
< PRECAUTION >
C
DE
F
G H
I
J
K L
B A
O P
N
5. When the repair work is completed, return the ignition switch to the
″LOCK ″ position before connecting
the battery cables. (At this time, the steering lock mechanism will engage.)
6. Perform a self-diagnosis check of al l control units using CONSULT-III.
Revision: April 20092010 QX56

PWO-4
< COMPONENT DIAGNOSIS >
POWER SOCKET
COMPONENT DIAGNOSIS
POWER SOCKET
Wiring DiagramINFOID:0000000005146377
ABMWA0422GB
Revision: April 20092010 QX56

PWO
POWER SOCKETPWO-5
< COMPONENT DIAGNOSIS >
C
DE
F
G H
I
J
K L
B A
O P
N
ABMIA1172GB
Revision: April 20092010 QX56
