U1310 AV CONTROL UNIT
DescriptionINFOID:0000000005146299
Replace the AV control unit if this DTC is displayed. Refer to AV-169, "Removal and Installation".
DTC LogicINFOID:0000000005146300
Part name Description
AV CONTROL UNIT • Integrates HDD (hard disk
drive) allowing map data and music data to be
stored.
• It is the master unit of the MULTI AV system, and it is connected to each control unit by means of communication. It operates each system according to com-
munication signals from the AV control unit.
• The AV control unit includes the audio, hands-free phone, voice control, navi- gation, and vehicle information functions.
• It is connected to ECM and combination meter via CAN communication to ob-
tain necessary information for the vehicle information function.
• It inputs the automatic brightness ON/OFF signals that are required for the dis- play dimming control.
• It inputs the signals for driving status recognition (vehicle speed, reverse and
parking brake).
DTC Display contents of
CONSULT-III DTC Detection Condition
Action to take
U1310 CONTROL UNIT (AV)
[U1310] An initial diagnosis error is detected in AV communication
circuit. Replace AV control unit. Refer to
AV-
169, "Removal and Installation".
Revision: April 20092010 QX56

AV-76
< COMPONENT DIAGNOSIS >[AUDIO SYSTEM]
POWER SUPPLY AND GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect the video monitor connector R202 and the DVD
player connector M205.
3. Check continuity between the video monitor harness connector R202 (A) and the DVD player connector M205 (B).
4. Check continuity between video monitor harness connector R202 (A) and ground.
Are continuity test results as specified?
YES >> Check DVD player power and ground supply. Refer to AV-68, "AV CONTROL UNIT : Diagnosis
Procedure".
NO >> Repair harness or connector.
3.CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect video monitor connector.
3. Check continuity between video monitor harness connector
R202 and ground.
Does continuity exist?
YES >> Inspection end.
NO >> Repair harness or connector.
MICROPHONE
MICROPHONE : Diagnosis ProcedureINFOID:0000000005146310
Regarding Wiring Diagram information, refer to AV-116, "Wiring Diagram".
1.CHECK POWER SUPPLY CIRCUIT
Check voltage between microphone harness connector R109 termi-
nal 4 and ground.
Is approximately 5V present?
YES >> GO TO 3.
NO >> GO TO 2.
AB Continuity
Connector Terminal Connector Terminal
R202 11
M205 9
Ye s
12 25
A -Contin u it y
Connector Terminal
R202 11
Ground No
12
AWLIA1600ZZ
Connector Terminal Ignition switch position Continuity
R202 1
OFF Yes
2
ALNIA0329GB
Signal name Connector Terminal Ignition switch
position Value (Approx.)
MIC power R109 4ON 5V
WKIA5796E
Revision: April 20092010 QX56

AV
POWER SUPPLY AND GROUND CIRCUITAV-77
< COMPONENT DIAGNOSIS > [AUDIO SYSTEM]
C
D
E
F
G H
I
J
K L
M B A
O P
2.CHECK POWER SUPPLY CIRCUIT (CONTINUITY)
1. Turn ignition switch OFF.
2. Disconnect microphone and AV control unit harness connectors.
3. Check continuity between microphone harness connector R109 (A) terminal 4 and AV control unit harness connector M45 (B)
terminal 70.
4. Check continuity between microphone harness connector R109 (A) terminal 4 and ground.
Are the continuity test results as specified?
YES >> Replace the AV control unit. Refer to AV-169, "Removal and Installation".
NO >> Repair harness or connector.
3.CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect microphone harness connector R109 and AV control unit harness connector M45.
3. Check continuity between microphone harness connector R109 (A) terminal 2 and AV control unit harness connector M45 (B)
terminal 71.
Does continuity exist?
YES >> Inspection End.
NO >> Repair harness or connector.
AB Continuity
Connector Terminal Connector Terminal
R109 4 M45 70 Yes
A —Con tin uit y
Connector Terminal
R109 4Ground No
ALNIA0441GB
AB
Continuity
Connector Terminal Connector Terminal
R109 2 M45 71 Yes
AWLIA1601ZZ
Revision: April 20092010 QX56

AV-106
< COMPONENT DIAGNOSIS >[AUDIO SYSTEM]
STEERING SWITCH
STEERING SWITCH
DescriptionINFOID:0000000005146341
When one of the steering wheel audio control switches
is pushed, the resistance in the steering wheel audio
control switch circuit changes depending on which button is pushed.
Diagnosis ProcedureINFOID:0000000005146342
Regarding Wiring Diagram information, refer to AV-116, "Wiring Diagram".
1.CHECK STEERING WHEEL AUDIO CONTROL SWITCH RESISTANCE
1. Turn ignition switch OFF.
2. Disconnect steering wheel audio control switch connector M102.
3. Check resistance between steering switch connector terminals.
Do the steering wheel audio control switches check OK?
YES >> GO TO 2.
NO >> Replace steering wheel audio control switch. Refer to AV-179, "
Removal and Installation".
2.CHECK HARNESS
1. Turn ignition switch OFF.
2. Disconnect AV control unit connector M42 and spiral cable con- nector M30.
3. Check continuity between AV control unit harness connector M42 (A) and spiral cable harness connector M30 (B).
4. Check continuity between AV c ontrol unit connector M42 (A) and ground.
Terminal Signal name ConditionResistance
(Ω)
(Approx.)
16 17 Seek (down)
Depress switch. 165
Volume (down) Depress VOL down switch. 487
Phone/Send Depress switch. 0
20 17 Seek (up)
Depress switch. 165
Volume (up) Depress VOL up switch. 487
Mode/End Depress switch. 0
WKIA4457E
AB

Continuity
Connector Terminal Connector Terminal
M42 6
M30 24
Ye s
15 31
16 32
A —Continuity
Connector Terminal
M42 6
Ground No
15
16
ALNIA0332GB
Revision: April 20092010 QX56

AV-108
< COMPONENT DIAGNOSIS >[AUDIO SYSTEM]
MICROPHONE SIGNAL CIRCUIT
MICROPHONE SIGNAL CIRCUIT
DescriptionINFOID:0000000005146343
Voice signals are transmitted from the microphone to the
AV control unit using the microphone signal circuits.
Diagnosis ProcedureINFOID:0000000005146344
Regarding Wiring Diagram information, refer to AV-116, "Wiring Diagram".
1.CHECK HARNESS BETWEEN AV CONTROL UNIT AND MICROPHONE
1. Turn ignition switch OFF.
2. Disconnect AV control unit connector and microphone connec- tor.
3. Check continuity between AV control unit harness connector M45 (A) and microphone harness connector R109 (B).
4. Check continuity between AV control unit harness connector M45 (A) and ground.
Are the continuity test results as specified?
YES >> GO TO 2.
NO >> Repair harness or connector.
2.CHECK MICROPHONE POWER SUPPLY
1. Connect AV control unit connector and microphone connector.
2. Turn ignition switch ON.
3. Check voltage between microphone harness connector R109 terminal 4 and ground.
Is voltage reading approx. 5 volts?
YES >> GO TO 3.
NO >> Replace AV control unit. Refer to AV-169, "
Removal and
Installation".
3.CHECK MICROPHONE SIGNAL
AB
Continuity
Connector Terminal Connector Terminal
M45 72
R109 1
Ye s
71 2
70 4
A —Con tin uit y
Connector Terminal
M45 70
GroundNo
71
72
AWLIA1603ZZ
4 - Ground : Approx. 5V
WKIA5796E
Revision: April 20092010 QX56

AV
MICROPHONE SIGNAL CIRCUITAV-109
< COMPONENT DIAGNOSIS > [AUDIO SYSTEM]
C
D
E
F
G H
I
J
K L
M B A
O P
Check signal between AV control unit harness connector M45 termi-
nals 71 and 72.
Are voltage readings as specified?
YES >> Replace AV control unit. Refer to AV-169, "Removal and Installation".
NO >> Replace microphone. Refer to AV-187, "
Removal and Installation".
Connector(+) (-)
Reference signal
Terminal Terminal
M45 71 72While speaking into MIC
ALNIA0423GB
PKIB5037J
Revision: April 20092010 QX56

AV-114
< ECU DIAGNOSIS >[AUDIO SYSTEM]
AV CONTROL UNIT
47
(W) 48
(R) AUX jack audio signal LH Input Ignition
switch ON When AUX mode
is select-
ed
58
(O/L) 42
(W) Headphone LH audio sig-
nal
OutputIgnition
switch ON When DVD player is oper-
ating
59
(W/L) 43
(O) Headphone RH audio sig-
nal
OutputIgnition
switch ON When DVD player is oper-
ating
60 — Shield — —— —
62
(B) Ground A/C and AV switch assem-
bly ground —Ignition
switch ON —0
V
63
(B) 48
(R) AUX jack audio signal RH Input Ignition
switch ON When AUX mode
is select-
ed
65
(B) Ground Ground
—Ignition
switch ON —0
V
66
(Y) Ground Battery power supply Input Ignition
switch OFF —
Battery voltage
67
(B) Ground Ground
—Ignition
switch
ON —0
V
68
(Y) Ground Battery power supply Input Ignition
switch OFF —
Battery voltage
69
(V) Ground ACC power supply
InputIgnition
switch
ACC —
Battery voltage
70
(W) Ground MIC power
OutputIgnition
switch ON —5
V
Terminal
(Wire color) Description
ConditionR
e

ference value
(Approx.)
+ – Signal nameInput/
Output
SKIB3609E
SKIB3609E
SKIB3609E
SKIB3609E
Revision: April 20092010 QX56

AV-156
< SYMPTOM DIAGNOSIS >[AUDIO SYSTEM]
MULTI AV SYSTEM
SYMPTOM DIAGNOSIS
MULTI AV SYSTEM
Symptom TableINFOID:0000000005146352
AUDIO SYSTEM
NAVIGATION SYSTEM
HANDS-FREE PHONE SYSTEM
REAR VIEW MONITOR
Symptom
Possible causeReference page
Inoperative • AV control unit power and ground circuit
•AV control unit •
AV- 6 8
•AV- 2 7
Steering switch does not operate • Steering switch
•AV control unit •
AV- 4 0•AV- 2 7
All speakers do not sound • AV control unit power and ground circuit
• BOSE speaker amp. ON signal
• BOSE speaker amp. power and ground circuit
• BOSE speaker amp.
•AV control unit •
AV- 6 8
•AV- 1 0 5
•AV- 7 0
•AV- 1 4 9
•AV- 11 0
One or several speakers do not sound • Front door speaker
• Front tweeter
• Center speaker
• Rear tweeter
• Rear door speaker
• Back door speaker
• Subwoofer •
AV- 8 5
•AV- 8 8
•AV- 9 1
•AV- 9 6
•AV- 9 3
•AV- 9 9
•AV- 1 0 2
Symptom Possible causeReference page
Inoperative • AV control unit power and ground circuit
•AV control unit •
AV- 6 8
•AV- 2 7
Steering switch does not operate • Steering switch
•AV control unit •
AV- 1 0 6•AV- 2 7
Voice activated control does not operate • Microphone
• Steering switch
•AV control unit •
AV- 1 0 8•AV- 1 0 6
•AV- 2 7
Symptom Possible causeReference page
Inoperative • AV control unit power and ground circuit
•AV control unit •
AV- 6 8
•AV- 2 7
Steering switch does not operate • Steering switch
•AV control unit •
AV- 1 0 6•AV- 2 7
Voice activated control does not operate • Microphone
• Steering switch
•AV control unit •
AV- 1 0 8•AV- 1 0 6
•AV- 2 7
Symptom Possible causeReference page
Inoperative • Rear view camera control unit power and ground circuit
• Reverse signal circuit
• Camera ON signal circuit
• Camera image signal circuit (rear view camera to rear
view camera control unit)
• Camera image signal circuit (rear view camera control unit to AV control unit)
• Rear view camera control unit •
AV- 7 2
•AV- 1 5 2
•AV- 1 5 2
•AV- 1 5 2
•AV- 1 5 2
•AV- 1 5 2
Revision: April 20092010 QX56

AV
MULTI AV SYSTEMAV-157
< SYMPTOM DIAGNOSIS > [AUDIO SYSTEM]
C
D
E
F
G H
I
J
K L
M B A
O P
DVD PLAYER
Symptom Possible causeReference page
DVD player inoperative • Power supply and ground circuits
• DVD player•
AV- 7 4
•AV- 1 5 4
No sound when playing a DVD • Audio signal circuits
•AV control unit
• DVD player•
AV- 8 5•AV- 6 8
•AV- 7 4
Video monitor is inoperative/does not display properly • Power supply and ground circuits
• Video out circuit
• DVD player
• Display monitor•
AV- 7 5•AV- 1 5 4
•AV- 7 4
•AV- 7 5
DVD remote control is inoperative/does not operate
properly • DVD player
• Rear audio remote control unit•
AV- 7 4
•AV- 11 0
Headphones inoperative • Headphone batteries
• Headphone audio signal circuits from AV control unit
•AV control unit
• Rear audio remote control unit•
AV- 1 5 4•AV- 11 0
•AV- 11 0
Revision: April 20092010 QX56

AV
MICROPHONEAV-187
< ON-VEHICLE REPAIR > [AUDIO SYSTEM]
C
D
E
F
G H
I
J
K L
M B A
O P
MICROPHONE
Removal and InstallationINFOID:0000000005146373
REMOVAL
1. Remove the front roof console finisher. Refer to INT-17,
"Removal and Installation".
2. Disconnect the Bluetooth microphone connector (A).
3. Detach the Bluetooth microphone (1) from the front roof console finisher and remove the Bluetooth microphone (1).
INSTALLATION
Installation is in the reverse order of removal.
ALNIA0275ZZALNIA0274ZZ
Revision: April 20092010 QX56
