INFINITI QX60 2018 Quick Reference Guide

8
2nd Row Seats
Forward and backward adjustment:
Pull the center of the bar
1 up and hold it while you slide the seat
forward or backward to the desired position until it latches.
Seat angle adjustment:
Pull up on the lever
2 and lean back until the seat latches. To bring
the seatback forward, pull the lever up and lean your body forward until
it latches.
MULTI-MODE/CHILD SEAT ACCESS FUNCTION
On the passenger’s side of the vehicle, the 3
rd row can be accessed
without removing a child seat installed in the 2nd row.
• Lift up on the seatback release lever 3 and slide the entire
seat forward.
• To return the seat to a locked position, push the upper seatback
rearward until the seatback and track are locked.
Please see your Owner’s Manual for important safety information, system limitations, and
additional operating and feature information.

1
2
3
Wiper and Washer Switch
Move the lever 1 up or down to one of the following positions to
operate the windshield wipers:
MIST
One sweep operation
OFF Wipers ar e off
AUTO Speed-sensing and r ain-sensing (if so equipped)
automatic wipe
LO
Continuous wipe, slow
HI Continuous wipe, fast
To adjust the wiper sensitivity for the AUTO setting, twist the
control ring 2. The rain-sensing function (if so equipped) can be
disabled in the vehicle information display under “Vehicle Settings”.
Pull the lever 1 toward you operate the windshield washer.
REAR WIPER AND WASHER
Turn the rear wiper switch
3 to one of the following positions to
operate the rear wiper:
OFF
Wiper is OFF
INT Intermittent wiping
ON
Continuous wipe, slow
Push the lever 1 forward to operate the rear windshield washer.Please see your Owner’s Manual for important safety information, system limitations, and
additional operating and feature information.

1
2 3

9
Dynamic Driver Assistance Switch
(if so equipped)
The Dynamic Driver Assistance switch 1 can be used to temporarily turn
on and off the following systems:
• Lane Departur e Prevention (LDP): The LDP system helps warns the
driver with a warning light and chime and helps assist the driver to
return the vehicle to the center of the traveling lane.
• Distance Control Assist (DCA): The DCA system helps assist the driver
to maintain a following distance from a vehicle ahead by activating the
brakes and moving the accelerator pedal upward to decelerate smoothly.
• Blind Spo t Intervention® (BSI): The BSI system helps alert the driver of
other vehicles in adjacent lanes when changing lanes with a warning
light and chime. It also helps assist the driver to return to the center
of the current traveling lane when another vehicle is present in the
adjacent lane.
Please see your Owner’s Manual for important safety information, system limitations, and
additional operating and feature information.
1
The USB ports 1 are located in the center console under
the armrest.
• When a c ompatible USB memory device or iPod® is plugged
into one of the USB ports, compatible audio files stored on
the device can be played through the vehicle’s audio system.
• These ports will also char ge compatible devices.
USB/iPOD® CHARGING PORTS
• There is a USB port located in the 2nd row on the back of the
center console
2 and two ports in the 3rd row
located above the cup holders
3. These ports will charge
compatible devices.Please see your Owner’s Manual for important safety information, system limitations,
and additional operating and feature information.
USB Connection Ports

1
3
2

10
Remote Start* (if so equipped)
To start your vehicle remotely, press the
button 1 on the Infiniti Intelligent Key, and
within 5 seconds, press and hold the remote
engine start
button 2 for at least
2 seconds.
• Automatic climate control will begin
heating or cooling the vehicle based
on the temperature inside and outside
the vehicle.
• The engine will run f or 10 minutes and
then turn off. To extend the time for
an additional 10-minute period, repeat
the procedure.
• To start driving, depress the brake pedal
and press the ignition switch START/STOP button.
Remote start can be enabled or disabled through the vehicle
information display.
HEATED STEERING WHEEL (if so equipped)
The heated steering wheel may be activated during remote
engine start when outside and cabin temperatures are low.
During remote start, the heated steering wheel switch will be
inoperable until the ignition switch is turned on.
* State laws may apply; review local laws before using.Please see your Owner’s Manual for important safety information, system limitations,
and additional operating and feature information.
1
2
Two positions for the driver’s seat,
steering column and outside mirrors
can be stored in the automatic
drive positioner memory. To set a
memory position:
1. Place the ignition switch in the
ON or ACC position. (The vehicle
should be stopped while setting
the memory.)
2. Adjust the driver’s seat, steering column and outside mirrors to the
desired positions using the adjusting switches for each feature.
3. Push the SET switch 1, and within 5 seconds, push the memory
switch (1 or 2) 2. The indicator light for the memory switch you select
will illuminate for approximately 5 seconds and a chime will sound
when the memory is stored.
4. Press the unlock button on the key fob to link the memorized position
to your Infiniti Intelligent Key.
The driver’s seat and steering column will automatically move when the
shift lever is in the P (PARK) position to allow the driver to get in and out
of the driver’s seat more easily. “Exit Seat Slide” and “Exit Steering UP” can
be disabled in the vehicle information display under “Vehicle Settings”.
Please see your Owner’s Manual for important safety information, system limitations, and
additional operating and feature information.
Automatic Drive Positioner
(if so equipped)
2 1

11
Heater and Air Conditioner (automatic)
• Press the AUTO button 1 to turn the system on and automatically control the
inside temperature.
• Press the CLIMATE button 2 to adjust the automatic climate controls using
the climate settings on the control panel display screen.
• Use the driver’s side 3 or passenger’s side 4 control buttons (warmer air)
or
(cooler air) to control the desired side’s temperature.
• Press the air flow control button 5 to manually cycle through the available air
flow modes.
• Press the DUAL button 6 to turn the system on and off.
• Press the fan speed control buttons 7 to increase or decrease the fan speed.
• Press the front defroster button 8 to turn the front defroster system on and
off, and use the temperature control buttons 3 to change the temperature.
• To defrost the rear window and outside mirrors, push the rear defroster
switch 9 to turn the system on and off.
• Press the intake air control button 10 to recirculate the air inside the vehicle.
• Press the OFF button 11 to turn the climate control system off.
4
3
5 6
12
REAR CONTROLS
• Press the REAR ON-OFF button 12 to turn the rear
air conditioner on and off.
• Press the OFF button 13 to turn the system off.
• Adjust the fan speed up or down using the control
buttons
14.
• Press the AUTO button 15 to turn on the
automatic mode.
• Adjust the temperature up or down using the TEMP
buttons
16.
Please see your Owner’s Manual for important safety information, system
limitations, and additional operating and feature information.
10
13 14
15
16
1 2 8 9 11 7

12
Connecting your Cellular Phone
or Device via Bluetooth
®*
Using Bluetooth® technology, you can connect (pair)
your cellular phone with the in-vehicle system for
hands-free use of your cellular phone.
1. Press the SETTING button on the
control panel.
2. Select the “Phone/Mail” key.
3. Select “Connect Device”.
4. Select “Add New (X/5
Free)”.
5. If a PIN appears on the screen, operate the
Bluetooth® device to enter/confirm the PIN.
For any Bluetooth® connectivity issues, reboot your cellular phone or device.* Some jurisdictions prohibit the use of cellular telephones while driving.
Please see your Owner’s Manual for important safety information, system limitations, and additional
operating and feature information.
If you have a compatible Bluetooth® device with streaming audio (A2DP
and AVRCP profiles), you can set up a wireless connection between your
Bluetooth
® device and the in-vehicle audio system, enabling you to listen to
the audio from your device through the vehicle’s audio system.
After connecting your Bluetooth
® device, press the MEDIA button on the
control panel to switch to Bluetooth® Streaming Audio.
For any Bluetooth® connectivity issues, reboot your cellular phone or device.Please see your Owner’s Manual for important safety information, system limitations, and additional
operating and feature information.
Bluetooth® Streaming Audio Voice Recognition
SYSTEM OPERATING TIPS
•
The interior of the vehicle should be as quiet as possible.
• Speak naturally. Speaking too fast, too slow, too soft, or
too loud makes voice recognition more difficult.
• Confirm that the correct voice commands are being used.
Glance at the screen to see the currently
available commands.
USING THE VOICE RECOGNITION SYSTEM
• Press the or button 1 on the steering wheel, and a
list of commands will appear on the screen.
• After the tone sounds, speak the command.
• To skip the voice prompt and give the command
immediately, press the
or button 1 on the steering
wheel to interrupt the system. Speak the next command
after the tone sounds.
• To cancel the command, press and hold the or
button 1 on the steering wheel.
Please see your Owner’s Manual for important safety information, system
limitations, and additional operating and feature information.

1

13
Center Display
Infiniti InTouch® controls the audio, RearView/Around View® Monitor
(if so equipped), Navigation System (if so equipped), InTouch Apps,
Bluetooth
® hands-free phone, and various settings using the
touch-screen display, Infiniti controller, menu button and steering
wheel switches.
INFINITI CONTROLLER AND MENU BUTTONS
4 ENTER – Select the highlighted item.
5 Center dial – Turn or slide to select an item or navigate
through options.
6 BACK – Return to the previous screen.
7 CAMERA – Press to view the Around View® Monitor
(if so equipped). Press and hold to control the brightness.
STEERING WHEEL SWITCHES
8 – Return to the previous screen.
9 ENTER – Press to select the highlighted item.
10 – Tilt the ENTER button up or down to
navigate through options.
Please see your Owner’s Manual for important safety information,
system limitations, and additional operating and feature information.
9
8
10
TOUCH-SCREEN DISPLAY
1 – Return to the previous screen.
2 < or > – Touch the arrow keys to navigate between screens.
3 Touch any key to select that item.
3
1
2 2
5 4 6 7

14
Use the Infiniti controller 1 and ENTER button 2 to navigate through the center
display screens.
• Press the BACK button 3 to return to the previous screen.
• Press the MAP button 4 to display the map.
SETTING A ROUTE
To set a route, first ensure that the correct region is
selected on the touch-screen.
1. Press the NAVI button 5 on the control panel.
2. Select the “Destination Menu” key 6 on the display.
3. Select the pr eferred destination setting method.
4. Enter the address number, street name, and city as
prompted by the screen.
CANCELING A ROUTE
1. Press the NAVI button 5 on the control panel.
2. Select the “Cancel Route” key 7.Please see your Owner’s Manual for important safety information, system
limitations, and additional operating and feature information.
7
Navigation System (if so equipped)
6
To adjust the time and the appearance of the
clock on the display:
1 . Press the SETTING button 1 on the
Infiniti controller.
2. Locate and select the “Clock” key to adjust
“On-Screen Clock”, “Daylight Savings Time”,
“Clock Format (24h)”, and “Time Zone”.
3. The time c an be adjusted through “Offset
Adjustment” 2 by adjusting the minutes and/
or hours forward or backward. The current
clock time can be set up to a difference of
12 hours and 59 minutes.
Please see your Owner’s Manual for important safety
information, system limitations, and additional operating and
feature information.
Clock Set/Adjustment
2
1
2 1 3 4 5

15
Infiniti InTouch™ Services (if so equipped)
Available services include, but are not
limited to:
• Automatic Collision Notification
• Alarm Notification
• Maintenance Alert
• Scheduled Main tenance Notification
• Report Stolen Vehicle
• Emergency Call
• Remote Door Lock/Unlock
• Remote Engine Start/Stop
• Remote Horn/Lights
• My Schedule
• Destination Send-to-Vehicle
• Connected Search
• Drive Zone
• Maximum Speed Alert
• Mobile Information Service
• Valet Alert
The following services can also be accessed
by touching the
headset icon 4.
• Destination Assistance
• Enhanced Roadside Assistance
This service allows subscribers to receive
assistance for a non-emergency incident,
such as towing, or a third party response.

1
Infiniti InTouch ™ Services combine personalized
convenience settings and personal security features
to compliment the Total Ownership Experience®.
For more details on Infiniti InTouch Services or to
enroll your vehicle, please visit
usa.infinitiintouch.com or call 1-855-444-7244.
To access Infiniti InTouch Services:
1. Press the SETTING button 1 on the
Infiniti controller.
2. Select the “InTouch Services” key 2 on
the display .
• In case of an emergency, press and release the
in-vehicle telematics SOS button
3, located
above the rearview mirror. A Response
Specialist will provide assistance based on the
situation described by the vehicle’s occupant.
INFINITI INTOUCH SERVICES ENROLLMENT
1. Create an Infiniti Owner Portal account.
(https://owners.infinitiusa.com/iowners/)
2. From your Infiniti Owner Portal account, enroll
in Infiniti InTouch Services.
3. Download the Infiniti InTouch Services
companion app from the App store and
log in using your Infiniti Owner Portal ID
and Password.
Please see your Owner’s Manual for important safety information,
system limitations, and additional operating and feature information.

3
4 2

16
Infiniti Mobile Entertainment System (MES) (if so equipped)
With this entertainment system, you can play video files on
both the front and rear display screens.
Watching a DVD:
• Insert a DVD into the DVD slot 1 and the DVD will play
automatically. The front display will only work when the
vehicle is in park and the parking brake is engaged.
• Press the DISC button 2 on the control panel to bring
up the DVD menu and display settings. Use the
touch-screen and the Infiniti controller to select the
menu items.
Watching videos from a USB or HDMI device:
• Connect your compatible device to the USB or HDMI
port located at the rear of the center console box.
• The source can be changed on the rear displays using the
remote by pressing the HOME button 6.
Please see your Owner’s Manual for important safety information, system
limitations, and additional operating and feature information.

1
4 POWER – Turn display screen on
and off
5 DISPLAY SELECT – Change display
controls between right and left screen
6 HOME – Change video source
7 MENU – Change menu display
8 ENTER/Selection Buttons – Control
and select buttons
9 BACK – Previous menu button
10 SETUP – Bring up display menu
11 Video Controls – Play, stop, fast forward and rewind buttons
11 Volume – Control audio level

4
11
8
7 6
5
9
12
REAR DISPLAYS
To turn the rear displays on and off from
the front seats:
1. Press the AUDIO button 3 on the
control panel.
2. Select the “Rear Display” key on
the display.
3
2
10

M
