audio INFINITI QX60 2019 Quick Reference Guide

Additional information about your vehicle is also available in your Owner’s Manual, INFINITI InTouch™ Owner’s Manual at www.InfinitiUSA.com.
Table of Contents
• A cellular telephone should not be used for any purpose while
driving so full attention may be
given to vehicle operation.
•
Alw

ays wear your seat belt.
•

Supplemen
tal air bags do not
replace proper seat belt usage. • Childr
en 12 and under

should always ride in the
rear seat properly secured
in child restraints or seat
belts according to their age
and weight.
• Do not drink and drive. For more information, refer to the “Safety — Seats,
seat belts and supplemental restraint system (section
1)”
, the “Monitor, climate, audio, phone and voice
recognition systems (section 4)” and the “Starting
and driving (section 5)” of your Owner’s Manual.
PLEASE SEE YOUR OWNER’S MANUAL FOR IMPORTANT SAFETY INFORMATION AND SYSTEM OPERATION LIMITATIONS.
Cockpit Overview ........................................................................\
......... 1
Instrumen t Panel ........................................................................\
.......... 3
Meters and Gauges
........................................................................\
..... 5
Opening the Liftgate
........................................................................\
... 7
Motion-Activated Liftgate (if so equipped)
..................................7
Outside Mirrors
........................................................................\
............ 8
Dynamic Driver Assistance Switch (if so equipped)
....................8
Wiper and Washer Switch
................................................................. 9
2
nd Row Seats ........................................................................\
................ 9
USB C onnection Ports ........................................................................\
10
Remote Engine Start (if so equipped)
.............................................11Automatic Drive Positioner (if so equipped)
.................................
11
Heater and Air Conditioner (automatic) .........................................
12
Connecting your Cellular Phone or Device via Bluetooth
® ........ 13
Blue
tooth® Streaming Audio ............................................................. 13
V
oice Recognition........................................................................\
......... 14
Clock Set/Adjustment
........................................................................\
14
Center Display


........................................................................\
............... 15
Navigation System (if so equipped)
................................................. 16
INFINITI InTouch™ Services (if so equipped)
.................................17
Infiniti Mobile Entertainment System (MES) (if so equipped)
..18
3499324_19b_QX60_US_QRG_062118.indd 46/21/18 9:46 AM

4
Instrument Panel
Multi-function control touch-screen/RearView Monitor display/ Around View
® Monitor display (if so equipped)
Climate control panel
•

H
eater and air conditioning (automatic)
•


F
ront and rear window defroster
Infiniti multi-function controller
Audio system
Shift lever
Lower instrument panel switches

•
V
ehicle Dynamic Control (VDC) OFF switch


•
P
ower liftgate switch


•
H
eated steering wheel switch (if so equipped)


•
W
arning systems switch
•


P
ower inverter switch (if so equipped)
3499324_19b_QX60_US_QRG_062118.indd 46/21/18 9:46 AM

10
USB Connection Ports
The USB ports are located in the center console under the armrest and below the climate
controls
(if so equipped).
•


When a c
ompatible USB memory device or iPod® is plugged into one of the USB ports,
compatible audio files stored on the device can be played through the vehicle’s audio system.
•


These ports will also char

ge compatible devices.
USB/iPOD
® CHARGING PORTS
•


Ther

e is a USB port located in the 2nd row on the back of the center console and a port in the
3rd row located above the cup holders . These ports will charge compatible devices.
Please see your Owner’s Manual for important safety information, system limitations, and additional operating and
feature information.
3499324_19b_QX60_US_QRG_062118.indd 106/21/18 9:47 AM

13
Connecting your Cellular Phone
or Device via Bluetooth
®*
Using Bluetooth® technology, you can
connect (pair) your cellular phone with the
in-vehicle system for hands-free use of your
cellular phone.
1.



Pr

ess the SETTING button on the
control panel.
2.



Select the

“Phone/Mail” key.
3

.

Select

“Connect Device”.
4.



Select

“Add New (X/5 Free)”.
5.



I

f a PIN appears on the screen, operate
the Bluetooth
® device to enter/
confirm the PIN.
For any Bluetooth
® connectivity issues, reboot your cellular
phone or device.
* Some jurisdictions prohibit the use of cellular telephones while driving.
Please see your INFINITI InTouch™ Owner’s Manual for important safety information, system
limitations, and additional operating and feature information.
If you have a compatible Bluetooth® device with streaming audio
(A2DP and AVRCP profiles), you can set up a wireless connection
between your Bluetooth
® device and the in-vehicle audio system,
enabling you to listen to the audio from your device through the
vehicle’s audio system.
To switch to Bluetooth
® Streaming Audio after connecting your
Bluetooth® device:
1.

Press the MEDIA button on the control panel.
2.

Touch the “Source” key
.
3

. Then, touch the “Bluetooth Audio” key
.
For any Bluetooth
® connectivity issues, reboot your cellular
phone or device.
Please see your INFINITI InTouch™ Owner’s Manual for important safety information,
system limitations, and additional operating and feature information.
Bluetooth® Streaming Audio
3499324_19b_QX60_US_QRG_062118.indd 136/21/18 9:47 AM

15
Center Display
INFINITI InTouch™ controls the audio, RearView/Around View®
Monitor (if so equipped), Navigation System (if so equipped),
InTouch Apps, Bluetooth
® hands-free phone, and various settings
using the touch-screen display, center dial, menu button and
steering wheel switches.
CENTER DIAL AND MENU BUTTONS
ENTER – Select the highlighted item.
Center dial – Turn or slide to select an item or navigate
through options.
BACK – Return to the previous screen.
CAMERA – Press to view the Around View® Monitor
(if so equipped). Press and hold to control the brightness.
STEERING WHEEL SWITCHES
– Return to the previous screen.
ENTER – Press to select the highlighted item.
– Tilt the ENTER button up or down to
navigate through options.
Please see your INFINITI InTouch™ Owner’s Manual for important
safety information, system limitations, and additional operating and
feature information.
TOUCH-SCREEN DISPLAY
– Return to the previous screen.
< or > – Touch the arrow keys to navigate between screens.
Touch any key to select that item.
3499324_19b_QX60_US_QRG_062118.indd 156/21/18 9:48 AM

18
Infiniti Mobile Entertainment System (MES) (if so equipped)
With this entertainment system, you can play video
files on both the front and rear display screens.
Watching a DVD:
•



Insert a D
VD into the DVD slot
and the DVD
will play automatically. The front display will only
work when the vehicle is in park and the parking
brake is engaged.
•





Pr

ess the DISC button
on the control panel to
bring up the DVD menu and display settings. Use
the touch-screen and the center dial to select
the menu items.
•


T

o access standard DVD controls on the front
display while playing a DVD on the rear display,
press the MEDIA button
on the control panel
while the vehicle is in the P (PARK) position and
the parking brake is applied.
Watching videos from a USB or HDMI device:
•





C

onnect your compatible device to the USB
or HDMI port located at the rear of the center
console box.
•





The sour

ce can be changed on the rear displays
using the remote by pressing the HOME
button
on the remote controller.
To watch or control videos on the front display, the
vehicle must be in the P (PARK) position with the
parking break applied.
To listen to the audio wirelessly and independently,
use the headphones provided, or connect your
own wired headphones to one of the headphone
jacks
, located on the back of the center console.
REAR DISPLAYS
The rear displays can be activated or deactivated
individually by the remote controller or the front
display control panel.
To turn the rear displays on and off from the
remote controller:
1.



Select the pr
eferred side (L or R)
and press the
power button
on the remote controller.
To turn the rear displays on and off from the
front seats:
1.



Pr

ess the AUDIO button
on the control panel.
2.



Select the

“Rear Display” key
on the display.
3

.
Then select either

the “L Display Power” or “R
Display Power” key
to turn the left or right
screen ON or OFF.
Please see your INFINITI InTouch™ Owner’s Manual for important
safety information, system limitations, and additional operating and
feature information.
