light INFINITI QX80 2014 Quick Reference Guide

*See your Owner ’s Manual for information.
01 INSTRUMENT BRIGHTNESS CONTROL SWITCH*
02 TRIP COMPUTER SWITCHES
03 HEADLIGHT AND TURN SIGNAL SWITCH
04 WINDSHIELD WIPER AND WASHER SWITCH
05 STEERING WHEEL SWITCHES FOR AUDIO* /
BLUETOOTH® / NAVIGATION
06 CRUISE CONTROL
07 WARNING SYSTEMS SWITCH*
08 POWER LIFTGATE SWITCH
09 TILT / TELESCOPIC STEERING WHEEL SWITCH*
10 DYNAMIC DRIVER ASSISTANCE SWITCH*
11 POWER LIFTGATE MAIN SWITCH*
12 HOOD RELEASE*
13 CONTROL PANEL DISPLAY SCREEN*
14 AUDIO SYSTEM
15 CLIMATE CONTROL SYSTEM
16 CLIMATE CONTROLLED SEAT KNOBS*
17 TIP-UP 2ND ROW SEAT SWITCHES
18 HEATED STEERING WHEEL SWITCH*
19 POWER OUTLET*
20 FRONT PASSENGER AIR BAG STATUS LIGHT*
21 FOUR-WHEEL DRIVE (4WD) SHIFT SWITCH*
0102
0304
050607
11
08
12
13
14
15
16
17
20
17
18
16
19
21
0910Behind
steering wheel on column
Behind
shift lever
1591592_14b_Infiniti_QX80_QRG_093013.indd 49/30/13 9:35 AM

table of contents
new system features
Infiniti Connection System™ (if so equipped)............................2
Theater Package (if so equipped)
.....................................
3
Around View® Monitor with Moving Object Detection (MOD)...............4
Blind Spot Warning (BSW) and Blind Spot Intervention™ (BSI) (if so equipped)..4
Lane Departure Prevention (LDP) System (if so equipped).................4
essential information
Tire Pressure Monitoring System (TPMS) with Tire Inflation Indicator........5
Loose Fuel Cap..................................................6
Fuel-filler Door

..................................................
6
Adaptive Front Lighting System (AFS) (if so equipped)

....................
6
Clock Set/Adjustment

............................................
7
first drive features
INFINITI Intelligent Key System....................................8
Power Liftgate...................................................9
Front Seat Adjustments..........................................10


Automatic Drive Positioner

.......................................
10


2
nd Row Seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . 11

3rd Row Power Folding Seats ......................................12
Outside Mirror Control Switch.....................................13
Starting/Stopping the Engine

.....................................
13
Headlight Control...............................................14
Windshield Wiper and Washer Switch

..............................
15


Automatic Climate Controls.......................................16



Rear Climate Controls

...........................................
17
FM/AM/SiriusXM Satellite Radio with CD/DVD Player..................18



Conventional (Fixed Speed) Cruise Control

..........................
19


Intelligent Cruise Control (ICC) System (if so equipped) ...............19
system guide
Trip Computer..................................................21
Bluetooth® Hands-free Phone System ..............................21

Navigation System..............................................24


HomeLink
® Universal Transceiver..................................25
To view detailed
instructional videos, go to
www.infinitiownersinfo.mobi/2014/qx80 or snap this barcode with an
appropriate barcode reader.
Please see your Owner’s Manual for important safety information
and system operation limitations.
•

A cellular telephone should not be used for any purpose while


driving so full attention may be given to vehicle operation.
• Always wear your seat belt.
• Supplemental air bags do not replace proper seat belt usage.
•

Children 12 and under should always ride in the rear seat


properly secured in child restraints or seat belts according to
their age and weight.
• Do not drink and drive.
For more information, refer to the “Safety –– Seats, seat belts and
supplemental restraint system (section 1)”, “Monitor, climate,
audio, phone and voice recognition systems (section 4)” and
“Starting and driving (section 5)” of your Owner’s Manual.
Additional information about your vehicle is also available in your Owner’s Manual, Navigation System Owner’s Manual and
at www.InfinitiUSA.com.
1591592_14b_Infiniti_QX80_QRG_093013.indd 59/30/13 9:35 AM

2*Infiniti Connection™ is only available on vehicles equipped with optional Infiniti Connectio\
n™ subscription service.
INFINITI Connection™ System* (if so equipped)
Infiniti Connection™ combines personalized convenience
and concierge settings and personal security features
to compliment the Total Ownership Experience.
For more details on Infiniti Connection
™, or to enroll
your vehicle, please visit www.Infiniticonnection.com
or call 855-444-7244.
Available services include:
Infiniti Personal Assistant – To access Infiniti Personal

Assistant, select “Connect to Voice Menu” from the Infiniti Connection menu or touch the

key on the map screen. At the voice prompt, say “Infiniti Personal As\
sistant” to be connected.
•


Your Infiniti Personal Assistant can send destination information direct\
ly to your vehicle.


Automatic Collision Notification – In case of air bag deployment, a s\
ignal is sent containing

the vehicle location and customer information to a Response Specialist w\
ho notifies the
proper authorities.
Emergency Call – This service provides emergency

assistance by connecting subscriber to an Infiniti
Connection
™ Specialist.
•


In case of an emergency, press the in-vehicle

telematics SOS

button
01.
•


A Response Specialist will provide assistance based

on the situation described by the vehicle’s occupant.
Enhanced Roadside Assistance – Roadside Assistance can be accessed by\
touching the Infiniti

Connection™ key on the Info menu, the key on the map screen or by pressing the SOS button. •
This service allows subscribers to receive assistance for a non-emergenc\
y incident such

as towing or a third party response.
•


If warranted, Roadside Assistance may also be used in conjunction with t\
he Emergency


Assistance service by pressing the SOS button.
My Schedule – Access your personal online Google Calendar™, hear details read via

text-to-speech** and select locations as a destination via the navigatio\
n system.
Report Stolen Vehicle – A Response Specialist will attempt to obtain \
location information

from a reported stolen vehicle and provide that information to local law\
enforcement
agencies to assist in the recovery of your stolen vehicle.
Remote Door Lock/Unlock – Remotely access your vehicle via Infiniti C\
onnection Response

Specialist or designated website to remotely lock or unlock your vehicle\
.
Alarm Notification – This system will notify you when the factory-ins\
talled vehicle alarm

system has been activated.
Scheduled Maintenance Notification – Receive scheduled maintenance no\
tifications based

on mileage data provided by your vehicle.
Maintenance Alert – Receive notification of a vehicle system malfunct\
ion that triggers

instrument panel warning lights.
Destination Assistance – Receive point-of-interest assistance via gui\
ded IVR (Interactive

Voice Response), or Response Specialist by pressing the
key on the map screen, or
Infiniti Connection™ web portal.
01
new system features
1591592_14b_Infiniti_QX80_QRG_093013.indd 29/30/13 9:35 AM

4
Around View® Monitor with Moving Object Detection (MOD)
Moving Object Detection (MOD) operates only with
the Around View® Monitor activated.



•


To temporarily turn the system on or off select

the “MOD” key on the bottom of the control
panel display.
When the CAMERA button is pressed and the vehicle
speed is less than 6 MPH (10 km/h) or the shift lever
is moved to the R (REVERSE) position, the Information
Display Screen will automatically change to view the area surrounding th\
e vehicle.
With the Around View® Monitor displayed, the corner sonar system can detect objects
near the vehicle and warn the driver by sounding a tone and showing an i\
ndicator in
the display screen.
For more information, refer to the “Monitor, climate, audio, phone and voice recognition systems (section 4\
)” of your
Owner’s Manual.
new system features
Lane Departure Prevention (LDP) System
(if so equipped)
This system will help you return the vehicle to the
center direction of the traveling lane by applying
brake control to the left or right wheels individually
(for a short period of time).
For more information, refer to the “Starting and driving (section 5)” of your
Owner’s Manual.
Blind Spot Warning (BSW) and Blind Spot Intervention™ (BSI)
(if so equipped)
The Blind Spot Warning (BSW) system alerts the
driver when another vehicle moves into the vehicle’s
blind spot area.
An indicator light near the outside mirror will
illuminate if the radar sensors detect a vehicle in the
detection zone.
The Blind Spot Intervention™ (BSI) system can assist
the driver in returning the vehicle to the center of the
traveling lane by applying individual brake pressure
to the left or right wheels for a short period of time.
The indicator light will first illuminate in orange and
then turn green before turning off. This indicates
that the Blind Spot Warning (BSW) and Blind Spot
Intervention (BSI) systems are operational.
For more information, refer to the “Starting and driving (section 5)” of your Owner’s Manual.
1591592_14b_Infiniti_QX80_QRG_093013.indd 49/30/13 9:35 AM

5
Tire Pressure Monitoring System (TPMS) with Tire Inflation Indicator
A CHECK TIRE PRESSURE warning message will appear
in the vehicle information display
01 and the low tire
pressure warning light 02 will illuminate when one or
more tires are low on pressure and air is needed.



•


The tire pressures should be

checked when the tires are cold.
The tires are considered cold after
the vehicle has been parked for 3
hours or more or driven less than 1
mi (1.6 km) at moderate speeds.
When adding air to an under-inflated tire, the TPMS
with Tire Inflation Indicator provides visual and
audible signals to help you inflate the tires to the
recommended COLD tire pressure.
To use the Tire Inflation Indicator:



1.

Move the shift lever to the
P (PARK) position and
apply the parking brake.



2.

Place the ignition switch in the
ON position. Do not start the engine.



3.

Add air to the under-inflated tire and within a few seconds, the hazard \
warning lights

will start flashing.



4.

When the designated tire pressure is reached, the horn will beep once an\
d the hazard

warning flashers will stop.



5.

Repeat this procedure for any additional under-inflated tires.
After tire pressures are adjusted, drive the vehicle at s peeds above 16 MPH (25 km/h). The
CHECK TIRE PRESSURE warning message and low tire pressure warning light will disappear.
When the low tire pressure warning light flashes for approximately 1 min\
ute and then remains
on, the TPMS is not functioning properly. Have the system checked by an \
INFINITI retailer.
Tire pressure rises and falls depending on the heat caused by the vehicl\
e’s operation and
the outside temperature. Low outside temperature can lower the temperature of the ai\
r inside
the tire, which can cause a lower tire inflation pressure. This may caus\
e the low tire pressure
warning light to illuminate. If the warning light illuminates, check the\
tire pressure in your tires.
•

Check the tire pressure (including the spare tire) often and always pr\
ior to long distance trips.
The Tire and Loading Information label contains valuable information. Pl\
ease refer to section 9,
“Technical and consumer information” in your Owner’s Manual for\
the location of the
Tire and Loading Information label.
For more information, refer to the “Instruments and controls (section 2)” , “Starting and driving (section 5)” and the “Maintenance and
do-it-yourself (section 8)” of your Owner’s Manual.
02
01
essential information
1591592_14b_Infiniti_QX80_QRG_093013.indd 59/30/13 9:35 AM

6
Loose Fuel Cap
A LOOSE FUEL CAP warning message will appear
in the vehicle information display
01 when the

fuel-filler cap is not tightened correctly.
To tighten, turn the cap clockwise until a single
click is heard.
The warning message will disappear when the
vehicle detects the fuel-filler cap is properly tightened and the reset \
button
02 is pressed.
If the cap is not properly tightened, the Malfunction Indicator Light may illuminate.
For more information, refer to the “Instruments and controls (section 2)” and the “Pre-driving checks and adjustments
(section 3)” of your Owner’s Manual.
01
Adaptive Front Lighting System (AFS) (if so equipped)
As your vehicle turns left or right, or drives along winding roads, the \
AFS system
moves your low beams left or right, according to your vehicle’s steer\
ing pattern.
For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.
essential information
02
Fuel-filler Door
The fuel-filler door is located on the left, rear side of
the vehicle.
When the doors of the vehicle are locked or
unlocked, the fuel-filler door is automatically
locked or unlocked at the same time.
To open the door, once unlocked, push the right side of the door.
For more information, refer to the “Pre-driving checks and adjustments (section 3)” of your Owner’s Manual.
1591592_14b_Infiniti_QX80_QRG_093013.indd 69/30/13 9:35 AM

7
Clock Set/Adjustment
DIGITAL CLOCK ADJUSTMENT
To adjust the time and the appearance of the clock
on the display:
1. Press the SETTING button on the control panel.
2. Touch the Others key.
3. Touch the Clock key.
The following settings can be adjusted:
•


On-screen Clock:
The clock in the upper right corner of the display can be turned
ON or OFF.
•


Clock Format (24h):
The clock can be set to 12 hours or 24 hours.
•


Offset (hour):
The time can be adjusted by increasing or decreasing per hour.
•


Offset (min):
The time can be adjusted by increasing or decreasing per minute.
•


Daylight Savings Time:
The application of daylight savings time can be turned ON or OFF.
•


Time Zone:
Adjust the time zone from the following:
•

Pacific

•

Atlantic

•

Mountain

•

Newfoundland

•

Central

•

Hawaii
•


Eastern

•

Alaska
Press the BACK button to return to the previous screen.
ANALOG CLOCK ADJUSTMENT
To set the clock backward, push the button 01.
To set the clock forward, push the button 02.
To move forward or backward faster, push and hold
the button for more than 5 seconds.
For more information, refer to the “Instruments and controls (section 2)”
or the “Monitor, climate, audio, phone and voice recognition systems
(section 4)” of your Owner’s Manual.0102
1591592_14b_Infiniti_QX80_QRG_093013.indd 79/30/13 9:35 AM

8
first drive features
INFINITI Intelligent Key System
The INFINITI Intelligent Key system allows you to lock
or unlock your vehicle, open your liftgate and start the
engine. It is important to make sure the Intelligent Key
is with you (that is, in your pocket or purse).
REMOTE ENGINE START*
The remote engine start system must be enabled in
the vehicle settings within the vehicle information display.
The remote engine start operating range is approximately
200 ft (60 m) from the vehicle. The effective operating range
may be shorter due to environmental conditions or obstacles
between you and the vehicle.
For the remote engine start to function, the vehicle must be
in the P (PARK) position with the ignition off, and all the doors
closed and locked.
To start your vehicle remotely:



1.

Press the button
02
2. Within 5 seconds press and hold the remote engine start

button
06 for at least 2 seconds.

The engine will start and the parking lights will turn on.
Automatic climate control will begin heating or cooling the vehicle depe\
nding on the
last used mode.
The engine will run for 10 minutes and then turn off.
Repeat steps 1 and 2 to extend the time for an additional 10 minute peri\
od.
•


After two remote starts the ignition switch must be cycled before the re\
mote start can


be used again.
To start driving depress the brake pedal and push the ignition switch START/STOP button.
To lock the vehicle, push either door handle request switch 01 once or press the button
02 on the key fob.
To unlock the vehicle, perform one of the following procedures:



•

Push either door handle request switch 01 once; the corresponding door will unlock. Push
the door handle request switch
01 again within 1 minute; all other doors will unlock, or



•


Press the button 03 on the key fob to unlock the driver’s side door. Press the button
again; all other doors will unlock.
To open the liftgate, press the button 04 for more than 1 second.
The Intelligent Key can also be used to activate the panic alarm by pres\
sing and holding
the
button 05 for more than 1 second. Once activated, the panic alarm and headlights
will stay on for a period of time.
01
06
02
03
04
05
1591592_14b_Infiniti_QX80_QRG_093013.indd 89/30/13 9:35 AM

10
first drive features
Front Seat Adjustments
To slide the seat forward or backward, push the
control switch
01 forward or backward.
To recline the seatback, push the switch 02
forward or backward.
SEAT LIFTER
To raise or lower the front portion or height of
the seat, push the front or back end of the switch
01 up or down.
LUMBAR SUPPORT

To adjust the seat lumbar support, push the front or back end of the swi\
tch 03.
For more information, refer to the “Safety —— seats, seat belts and supplemental restraint system (section 1)”\
of your
Owner’s Manual.
010203
Automatic Drive Positioner
Two positions for the driver’s seat, steering column
and outside mirrors can be stored in the automatic
drive positioner memory.
Follow these procedures to set the memory positions:



•

Confirm the shift lever is in the
P (PARK) position.



•

Push the ignition switch to the
ON position.



•

Adjust the driver’s seat, steering column and outside mirrors to the \
desired positions
using the adjusting switches for each feature.



•
Push the SET switch and within 5 seconds, push the memory switch (1 or 2) for at
least 1 second.



•

The indicator light on the memory switch you select will illuminate for \
approximately
5 seconds.



•

The driver’s seat, steering column and outside mirror positions are n\
ow set to
your preference.
These memorized positions can also be linked to your INFINITI Intelligen\
t Key. To link a
memorized position to your INFINITI Intelligent Key, press the unlock bu\
tton on the key fob
after completing the previous step.
For more information, refer to the “Pre-driving checks and adjustments (section 3)” of your Owner’s Manual.
1591592_14b_Infiniti_QX80_QRG_093013.indd 109/30/13 9:35 AM

14
first drive features
Headlight Control
HEADLIGHT CONTROL
Turn the headlight control switch to the
position
01 to turn on the front parking, side marker,
tail, license plate and instrument panel lights.
Turn the switch to the
position 02 to turn on
the headlights.
AUTOLIGHT SYSTEM
The autolight system will automatically turn the headlights on when it i\
s dark and off when it
is light. The system will keep the headlights on for a period of time af\
ter you turn the ignition
off and all doors are closed.
To activate the autolight system, turn the headlight control switch to t\
he AUTO position 03
then push the ignition switch to ON. To deactivate the autolight system, turn the headlight
control switch to the OFF,
position 01 or position 02.
HIGH BEAM SELECT
Push the headlight control switch forward 04 to
select the high beam function. The blue indicator
light
illuminates in the instrument panel. Pull the
headlight switch back to the original position to select
the low beam. The blue indicator light extuiguishes.
Pull and release the headlight control switch 05 to
flash the headlight high beams on and off.
FOG LIGHT SWITCH
The headlights must be on and the low beams



selected for the fog lights to operate.
Turn the switch (inside collar) to the position 06
to turn the fog lights on.
Turn the switch (inside collar) to the OFF position to turn the fog lights off.
For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.
01
02
03
04
05
06
1591592_14b_Infiniti_QX80_QRG_093013.indd 149/30/13 9:36 AM
