start stop button INFINITI QX80 2023 User Guide

WAF0350X
Shift lever
To move the shift lever,
: Push the button while depressing the brake pedal,
: Push the button,
: Just move the shift lever.
Shifting
The shift lever position indicator light (next
to the shift lever) will be illuminated for
approximately 30 minutes after the ignition
switch is turned off. The indicator light may
also illuminate when the vehicle receives
radio waves. This is not a malfunction.
After starting the engine, fully depress the
brake pedal and shift the shift lever from P (Park) to R (Reverse), N (Neutral), D (Drive)
or Manual shift mode position.
Push the button to shift into P (Park) or R
(Reverse). All other positions can be selected
without pushing the button.
WARNING
Apply the parking brake if the shift lever
is in any position while the engine is not
running. Failure to do so could cause the
vehicle to move unexpectedly or roll
away and result in serious personal
injury or property damage.
CAUTION
Make sure the vehicle is completely
stopped and the transmission is in the
P (Park) position.
P (Park) position:
Use this position when the vehicle is parked
or when starting the engine. Make sure the
vehicle is completely stopped. The brake
pedal must be depressed and the shift lever
button pushed in to move the shift lever
from the N (Neutral) position or any drive position to the P (Park) position.
Apply the
parking brake. When parking on a hill, apply
the parking brake first, then move the shift
lever to the P (Park) position.
CAUTION
Use this position only when the vehicle is
completely stopped.
R (Reverse):
Use this position to back up. Always be sure
the vehicle is completely stopped before
selecting the R (Reverse) position. The brake
pedal must be depressed and the shift lever
button pushed in to move the shift lever
from the P (Park) position, the N (Neutral)
position or any drive position to the R
(Reverse) position.
N (Neutral):
Neither forward nor reverse gear is engaged.
The engine can be started in this position.
You may shift to the N (Neutral) position and
restart a stalled engine while the vehicle is
moving.
D (Drive):
Use this position for all normal forward
driving.
Starting and driving5-19

5-24Starting and driving
LDW SYSTEM OPERATION
The LDW system provides a lane departure
warning function when the vehicle is driven
at speeds of approximately 37 MPH (60
km/h) and above and the lane markings are
clear. When the vehicle approaches either
the left or the right side of the traveling lane,
the steering wheel will vibrate and the LDW
indicator on the vehicle information display
will blink to alert the driver.
The warning function will stop when the
vehicle returns inside of the lane markers.
WAF0731X
Steering-wheel-mounted controls (left
side)
Vehicle information display
Warning systems switch
Warning systems ON indicator light
HOW TO ENABLE/DISABLE THE
LDW SYSTEM
Perform the following steps to enable or
disable the LDW system.
1. Push the
button until “Settings”
appears in the vehicle information dis-

—When the vehicle is accelerated dur-
ing BSI system operation
— When steering quickly
— When the ICC, DCA, PFCW or FEB
warnings sound.
— When the hazard warning flashers
are operated.
— When driving on a curve at a high
speed.
— When the BSW system is turned off.
SYSTEM TEMPORARILY UNA-
VAILABLE
When any of the following messages appear
on the vehicle information display, a chime
will sound and the BSI system will be turned
off automatically.
. “Not Available: Poor Road Conditions”:
When the VDC system (except traction
control system function) or ABS oper-
ates.
. “Currently unavailable/Currently not
available”:
— When the VDC system is turned off.
— When the SNOW mode is selected.
— When the 4WD shift switch is in the 4H or 4L position. (4WD models)
. “Not Available: High Camera Temp”:
If the vehicle is parked in direct sunlight
under high temperature conditions (over approximately 104°F (40°C)).
. “Unavailable Side Radar Obstruction”:
When side radar blockage is detected.
Turn off the BSI system and turn it on again
when the above conditions no longer exist.
SYSTEM MALFUNCTION
When the BSI system malfunctions, it will be
turned off automatically, the BSI indicator
illuminates and a chime will sound, and the
“Malfunction” warning message will appear
in the vehicle information display.
Action to take:
Stop the vehicle in a safe location and push
the park button to engage the P (Park)
position. Turn the engine off and restart the
engine. If the warning message continues to
appear, It is recommended you visit an
INFINITI retailer for this service.
JVS1149X
SYSTEM MAINTENANCE
The two radar sensorsfor the BSI system
are located near the rear bumper. Always
keep the area near the radar sensors clean.
The radar sensors may be blocked by
temporary ambient conditions such as
splashing water, mist or fog.
The blocked condition may also be caused by
objects such as ice, frost or dirt obstructing
the radar sensors.
Check for and remove objects obstructing
the area around the radar sensors.
Do not attach stickers (including transparent
material), install accessories or apply addi-
tional paint near the radar sensors.
Starting and driving5-51

Condition B
Under the following conditions, making it
impossible to detect a vehicle ahead, the
PFCW system is automatically turned off.
The FEB system warning light (orange) will
illuminate and the “Forward Driving Aids
temporarily disabled Front Sensor blocked
See Owner’s Manual” warning message will
appear in the vehicle information display.
.When the sensor area of the front of the
vehicle is covered with dirt or is ob-
structed
Action to take:
If the warning light (orange) flashes, stop the
vehicle in a safe place, push the park button
to engage the P (Park) position and turn the
engine off. Clean the radar cover on the
front of the vehicle with a soft cloth, and
restart the engine. If the warning light
continues to illuminate, have the PFCW
system checked. It is recommended you visit
an INFINITI retailer for this service.
. When driving on roads with limited road
structures or buildings (for example, long
bridges, deserts, snow fields, driving next
to long walls)
Action to take:
When the above conditions no longer exist,
the PFCW system will resume automatically.
SYSTEM MALFUNCTION
If the PFCW system malfunctions, it will be
turned off automatically, a chime will sound,
the FEB system warning light (orange) will
illuminate and the "Malfunction" warning
message will appear in the vehicle informa-
tion display.
Action to take:
If the warning light (orange) illuminates, stop
the vehicle in a safe location. Turn the engine
off and restart the engine. If the warning
light continues to illuminate, have the PFCW
system checked. It is recommended you visit
an INFINITI retailer for this service.
JVS1154X
SYSTEM MAINTENANCE
The radar sensoris located on the front of
the vehicle.
To keep the system operating properly, be
sure to observe the following:
. Always keep the sensor area on the front
of the vehicle clean.
. Do not strike or damage the areas around
the sensor.
. Do not cover or attach stickers or similar
objects on the front bumper near the
sensor area. This could cause failure or
malfunction.
. Do not attach metallic objects near the
sensor area (brush guard, etc.). This
Starting and driving5-111

5-114Starting and driving
play. Use thebutton to select “Driver
Assistance.” Then push the OK button.
2. Select “Driver Attention Alert” and push the OK button to turn the system on or
off.
NOTE:
The setting will be retained even if the
engine is restarted.
DAA SYSTEM LIMITATIONS
WARNING
Listed below are the system limitations
for the DAA system. Failure to operate
the vehicle in accordance with these
system limitations could result in serious
injury or death.
. The DAA system may not operate
properly and may not provide an alert
in the following conditions:
— Poor road conditions such as an uneven road surface or pot holes.
— Strong side wind.
— If you have adopted a sporty driving style with higher cornering
speeds or higher rates of accel-
eration. — Frequent lane changes or changes
to vehicle speed.
. The DAA system will not provide an
alert in the following conditions:
— Vehicle speeds lower than 37 MPH (60 km/h).
— Short lapses of attention.
— Instantaneous distractions such as dropping an object.
SYSTEM MALFUNCTION
If the DAA system malfunctions, the “Driver
Attention Alert Malfunction” warning mes-
sage will appear in the vehicle information
display and the function will be stopped
automatically.
Action to take
Stop the vehicle in a safe location, place the
vehicle in P (Park) position, turn the engine
off and restart the engine. If the warning
message continues to appear, have the
system checked. It is recommended that
you visit an INFINITI retailer for this service.
CAUTION
During the first 1,200 miles (2,000 km),
follow these recommendations to obtain
maximum engine performance and en-
sure the future reliability and economy
of your new vehicle.
Failure to follow these recommendations
may result in shortened engine life and
reduced engine performance.
. Avoid driving for long periods at constant
speed, either fast or slow. Do not run the
engine over 4,000 rpm.
. Do not accelerate at full throttle in any
gear.
. Avoid quick starts.
. Avoid hard braking as much as possible.
. Do not tow a trailer for the first 500
miles (805 km).
BREAK-IN SCHEDULE
