fog light INFINITI QX80 2023 Owners Manual

JVC1126X
1. Hood (P.3-21)
2. Windshield wiper and washer— Switch operation (P.2-40)
— Rain-sensing auto wiper system
(P.2-41)
— Wiper blade replacement (P.8-15) — Window washer fluid (P.8-10)
3. Moonroof (P.2-76)
4. Power windows (P.2-73)
5. Roof rack (P.2-72)
6. Towing hook (P.6-18)
7. Front view camera (P.4-4) 8. Sonar sensors
— Camera aiding sonar function
(P.4-17)
9. Headlight washers (if so equipped) (P.2-50)
10. Fog light (P.2-52)
11. Headlight (P.2-44) — Adaptive Front lighting System
(AFS) (if so equipped) (P.2-50)
12. Front parking light/daytime running light/front turn signal light (P.2-44)
13. Tires — Wheel and tires (P.8-27, P.10-9)
— Flat tire (P.6-3)
— Tire Pressure Monitoring System
(TPMS) (P.2-16, P.5-5)
14. Outside mirrors (P.3-37) — Side view camera (P.4-4)
— Welcome light (P.2-78)
15. Side turn signal lights (P.8-23)
16. Doors — Keys (P.3-2)
— Door locks (P.3-4)
— Intelligent Key system (P.3-7)
— Remote keyless entry system
(P.3-15)
— Remote engine start (if so equipped)
(P.3-19)
Illustrated table of contents0-3
EXTERIOR FRONT

0-8Illustrated table of contents
WAA0354X
1. Power liftgate switch (if so equipped)(P.3-22)
2. Heated steering wheel switch (P.2-53)
3. Instrument brightness control switch (P.2-51) 4. TRIP/RESET switch for twin trip od-
ometer (P.2-7)
5. Headlight, fog light and turn signal switch
— Headlight (P.2-44)
— Turn signal (P.2-52) — Fog light (P.2-52)
6. Steering-wheel-mounted controls (left side)
— Audio control steering switch (See
INFINITI InTouch
®Owner’s Manual.)
— Vehicle information display control
(P. 2-21)
— Trip computer switch (P.2-35)
7. Wiper and washer switch (P.2-40)
8. Steering-wheel-mounted controls (right side)
— Cruise control system (if so
equipped) (P.5-62)
— Intelligent Cruise Control (ICC) sys-
tem (if so equipped) (P.5-64)
— Lane Departure Prevention (LDP)
system (if so equipped) (P.5-27)
— Distance Control Assist (DCA) sys-
tem (if so equipped) (P.5-85)
— Blind Spot Intervention
®(BSI) sys-
tem (if so equipped) (P.5-42)
— Hands-Free Phone System switch
(See INFINITI InTouch
®Owner’s Man-
ual.)
9. Shift lever (P.5-17)
10. Four-Wheel Drive (4WD) shift switch (if so equipped) (P.5-116)/SNOW
mode switch (P.2-57)/TOW mode
switch (P.2-58)/Vehicle Dynamic Con-
COCKPIT

Red lightNamePage
Automatic Transmission (AT)
oil temperature warning light 2-12
Automatic Transmission (AT)
park warning light2-12
Brake warning light
2-12
Charge warning light 2-13
Engine oil pressure warning
light2-13
Master warning light 2-14
Seat belt warning light 2-14
Security indicator light 2-14
Supplemental air bag warn-
ing light2-14Yellow
light Name
Page
Adaptive Front lighting Sys-
tem (AFS) indicator light (if so
equipped) 2-15
Anti-lock Braking System
(ABS) warning light
2-15
Automatic Transmission (AT)
check warning light2-15
Check suspension indicator
light2-15
Four-Wheel Drive (4WD)
warning light (4WD models)
2-15
Forward Emergency Braking
(FEB) system warning light2-16
Low tire pressure warning
light
2-16
Malfunction Indicator Light
(MIL) 2-17
Master warning light 2-18
Vehicle Dynamic Control
(VDC) off indicator light2-18
Vehicle Dynamic Control
(VDC) warning light
2-18Other
light Name Page
Exterior light indicator
2-19
Front fog light indicator light2-19
High beam assist indicator
light2-19
High beam indicator light
2-19
TOW mode indicator light 2-19
Turn signal/hazard indicator
lights2-19
Illustrated table of contents0-13
WARNING AND INDICATOR LIGHTS

2 Instruments and controls
Cockpit ........................................................................\
......... 2-3
Instrument panel ............................................................... 2-5
Meters and gauges .......................................................... 2-6Speedometer and odometer ..................................... 2-7
Tachometer ................................................................... 2-8
Engine coolant temperature gauge ....................... 2-8
Fuel gauge ..................................................................... 2-9
Engine oil pressure gauge ......................................... 2-9
Voltmeter ..................................................................... 2-10
Warning lights, indicator lights and
audible reminders ............................................................ 2-11 Checking lights ........................................................... 2-12
Warning/indicator lights (red) ............................... 2-12
Warning/indicator lights (yellow) ......................... 2-15
Warning/indicator lights (other) ........................... 2-19
Audible reminders ..................................................... 2-19
Vehicle information display .......................................... 2-20 How to use the vehicle information display ...... 2-21
Startup display ........................................................... 2-21
Settings ........................................................................\
2-21
Operational indicators ............................................. 2-28
Trip computer ............................................................. 2-35
Clock and outside air temperature ....................... 2-37
Security systems ............................................................. 2-37 Vehicle Security System .......................................... 2-38 INFINITI Vehicle Immobilizer System ................ 2-39
Wiper and washer switch ........................................... 2-40 Washer operation ................................................... 2-41
Rain-sensing auto wiper system ........................ 2-41
Rear window wiper and washer operation ..... 2-42
Rear window and outside mirror
defroster switch ............................................................. 2-43 Rear window and outside mirror defroster ..... 2-43
Headlight and turn signal switch .............................. 2-44 Headlight switch .................................................... 2-44
Headlight washer (if so equipped) .................... 2-50
Instrument brightness control ............................. 2-51
Turn signal switch ................................................... 2-52
Fog light switch ....................................................... 2-52
Heated steering wheel ................................................. 2-53
Horn ........................................................................\
........... 2-53
Heated seats ................................................................... 2-54 Front ........................................................................\
... 2-54
Rear (if so equipped) .............................................. 2-55
Climate controlled seats (if so equipped) ................ 2-56
Warning systems switch .............................................. 2-57
SNOW mode switch ..................................................... 2-57
TOW mode switch ......................................................... 2-58
Vehicle Dynamic Control (VDC) OFF switch ......... 2-58
Rear door alert ................................................................ 2-59

WAA0354X
1. Power liftgate switch (if so equipped)
2. Heated steering wheel switch
3. Instrument brightness control switch
4. TRIP/RESET switch for twin trip od-ometer
5. Headlight, fog light and turn signal switch
— Headlight
— Turn signal
— Fog light
6. Steering-wheel-mounted controls (left side) — Audio control steering switch
— Vehicle information display control
— Trip computer switch
7. Wiper and washer switch
8. Steering-wheel-mounted controls (right side)
— Cruise control system (if so
equipped)
— Intelligent Cruise Control (ICC) sys-
tem (if so equipped)
— Lane Departure Prevention (LDP)
system (if so equipped)
— Distance Control Assist (DCA) sys-
tem (if so equipped)
— Blind Spot Intervention
®(BSI) sys-
tem (if so equipped)
— Hands-Free Phone System switch
9. Shift lever
10. Four-Wheel Drive (4WD) shift switch (if so equipped)/SNOW mode switch/
TOW mode switch/Vehicle Dynamic
Control (VDC) OFF switch
11. INFINITI controller
12. Headlight aiming control (if so equipped)
13. Power liftgate main switch
14. Remote tip-up 2nd row seat switch (if so equipped)
Instruments and controls2-3
COCKPIT

Warning indicator light (red)Warning indicator light (yellow)Vehicle Dynamic Control (VDC) off in-
dicator light
Automatic Transmission (AT) oil tem-
perature warning lightAdaptive Front lighting System (AFS)
indicator light (if so equipped)Vehicle Dynamic Control (VDC) warning
light
Automatic Transmission (AT) park
warning lightAnti-lock Braking System (ABS) warning
lightWarning indicator light (other)
Exterior light indicator
Brake warning lightAutomatic transmission check warning
lightFront fog light indicator light
Charge warning lightCheck suspension indicator lightHigh beam assist indicator light
Engine oil pressure warning lightFour-Wheel Drive (4WD) warning light
(4WD models)High beam indicator light
Master warning lightForward Emergency Braking (FEB) sys-
tem warning lightTOW mode indicator light
Seat belt warning light and chimeLow tire pressure warning lightTurn signal/hazard indicator lights
Security indicator lightMalfunction Indicator Light (MIL)
Supplemental air bag warning lightMaster warning light
Instruments and controls2-11
WARNING LIGHTS, INDICATOR
LIGHTS AND AUDIBLE REMINDERS

WARNING/INDICATOR LIGHTS
(other)
See “Vehicle information display” (P.2-20).
Exterior light indicator
This indicator illuminates when the headlight
switch is turned to the AUTO,orposition and the front parking lights, instru-
ment panel lights, rear combination lights,
license plate lights or headlights are on. The
indicator turns off when these lights are
turned off.
Front fog light indicator light
The front fog light indicator light illuminates
when the front fog lights are on. (See “Fog
light switch” (P.2-52).)
High beam assist indicator
light
The high beam assist indicator light illumi-
nates when the high beam assist system is
turned on and it is operational. (See “High
beam assist” (P.2-47).)
High beam indicator light
This light comes on when the headlight high
beam is on and goes out when the low beam is selected.
TOW mode indicator light
This light will illuminate when the TOW
mode is selected while the engine is running.
(See “TOW mode” (P.5-125).)
Turn signal/hazard indicator
lights
The light flashes when the turn signal switch
lever or hazard switch is turned on.
AUDIBLE REMINDERS
Key reminder chime
A chime will sound if the driver side door is
opened while the ignition switch is pushed to
the ACC position. Make sure the ignition
switch is pushed to the OFF position, and
take the Intelligent Key with you when
leaving the vehicle.
Light reminder chime
A chime will sound when the driver side door
is opened with the headlight switch in the
orposition and the ignition switch in
the ACC, OFF or LOCK position.
Turn the headlight switch to the OFF (if so
equipped) or the AUTO position when you
leave the vehicle.
Parking brake reminder chime
The chime will sound if the vehicle is driven
at more than 4 MPH (7 km/h) with the
parking brake applied. Stop the vehicle and
release the parking brake.
Brake pad wear warning
The disc brake pads have audible wear
warnings. When a brake pad requires repla-
cement, it will make a high pitched scraping
sound when the vehicle is in motion. This
scraping sound will first occur only when the
brake pedal is depressed. After more wear of
the brake pad, the sound will always be
heard even if the brake pedal is not
depressed. Have the brakes checked as soon
as possible if the warning sound is heard.
Instruments and controls2-19

Intermittent (INT) — intermittent op-
eration (not adjustable)
Low (ON) — continuous low speed
operation
Push the switch forward
to operate the
washer. Then the wiper will also operate
several times.
WAC0617X
REAR WINDOW AND OUTSIDE
MIRROR DEFROSTER
To defog/defrost the rear window glass and
outside mirrors, start the engine and push
the switch
on. The indicator lightwill
come on. Push the switch again to turn the
defroster off.
It will automatically turn off in approxi-
mately 15 minutes.
CAUTION
When cleaning the inner side of the rear
window, be careful not to scratch or damage the rear window defroster.
Instruments and controls2-43
REAR WINDOW AND OUTSIDE
MIRROR DEFROSTER SWITCH

High beam assist
The high beam assist system will operate
when the vehicle is driven at speeds of
approximately 22 MPH (35 km/h) and
above. If an oncoming vehicle or leading
vehicle appears in front of your vehicle when
the headlight high beam is on, the headlight
will be switched to the low beam automa-
tically.
Precautions on high beam assist:
WARNING
.The high beam assist system is a
convenience but it is not a substitute
for safe driving operation. The driver
should remain alert at all times,
ensure safe driving practices and
switch the high beams and low beam
manually when necessary.
. The high beam or low beam may not
switch automatically under the fol-
lowing conditions. Switch the high
beam and low beam manually.
— During bad weather (rain, fog, snow, wind, etc.).
— When a light source similar to a headlight or tail light is in the
vicinity of the vehicle. — When the headlights of the on-
coming vehicle or the leading
vehicle are turned off, when the
color of the light is affected due to
foreign materials on the lights, or
when the light beam is out of
position.
— When there is a sudden, contin- uous change in brightness.
— When driving on a road that passes over rolling hills, or a road
that has level differences.
— When driving on a road with many curves.
— When a sign or mirror-like sur- face is reflecting intense light
towards the front of the vehicle.
— When the container, etc. being towed by a leading vehicle is
reflecting intense light.
— When a headlight on your vehicle is damaged or dirty.
— When the vehicle is leaning at an angle due to a punctured tire,
being towed, etc.
. The timing of switching the low beam
and high beam may change under the
following situations. — The brightness of the headlights
of the oncoming vehicle or leading
vehicle.
— The movement and direction of the oncoming vehicle and the
leading vehicle.
— When only one light on the on- coming vehicle or the leading
vehicle is illuminated.
— When the oncoming vehicle or the leading vehicle is a two-wheeled
vehicle.
— Road conditions (incline, curve, the road surface, etc.).
— The number of passengers and the amount of luggage.
Instruments and controls2-47

2-52Instruments and controls
SIC3271
Example
TURN SIGNAL SWITCH
Turn signal
Move the lever up or down to signal the
turning direction. When the turn is com-
pleted, the turn signals cancel automatically.
Lane change signal
.Move the lever up or down until the turn
signal begins to flash, but the lever does
not latch, to signal a lane change. Hold
the lever until the lane change is com-
pleted.
. Move the lever up or down until the turn
signal begins to flash, but the lever does not latch, and release the lever. The turn
signal will automatically flash three
times.
Choose the appropriate method to signal a
lane change based on road and traffic
conditions.
SIC3272
Example
FOG LIGHT SWITCH
To turn the fog lights on, turn the headlight
switch to theposition, then turn the
switch to theposition. To turn them off,
turn the switch to the OFF position.
The headlights must be on with the low
beams selected for the fog lights to operate.
The fog lights automatically turn off when
the high beam headlights are selected.
