Refer to the front of this book for detailed information and illustrations regarding the location and identification of harnesses, relays, fuses, grounds,
control modules and control module pins.
NOTE: The values listed are approximately those that can be expected at the control module connector pins with all circuit conn
ections made and all
components connected and fitted. The following abbreviations are used to represent values for Control Module Pin-Out data
I Input
O Output
B+ Battery Voltage PG Power Ground
SS Sensor / Signal Supply V
SG Sensor / Signal GroundC CAN Network
S SCP Network
D2 D2B Network D Serial and Encoded Data
V Voltage (DC)
PWM Pulse Width Modulated
CAUTION: The information on this data page is furnished to ai d the user in understanding circuit operation. THIS INFORMATION SH OULD BE USED FOR
REFERENCE ONLY.DATE OF ISSUE: May 2004
Fig. 07.1
FOR CONTROL MODULE PIN-OUT INFORMATION, UNFOLD PAGE TO LEFT. COMPONENTS
Component Connector(s) Connector Description LocationAUXILIARY LIGHTING SWITCH FC11 10-WAY / YELLOW FASCIA, ADJACENT TO STEERING COLUMN
ENGINE COOLANT LEVEL SENSOR CP3 2-WAY / BLACK ENGINE COMPARTMENT, COOLANT EXPANSION TANK
FRONT ELECTRONIC MODULE CA24 26-WAY / NATURAL LH ‘A’ POST
CA31 20-WAY / BLACK
FH9 22-WAY / BLACK
FH59 12-WAY / BLACK
FH60 17-WAY / BLACK
FUEL LEVEL SENSOR – LH SIDE (DIESEL) FP14 2-WAY / BLACK FUEL TANK, LH SIDE
FUEL LEVEL SENSOR – LH SIDE (GASOLINE) FP3 4-WAY / BLACK FUEL TANK, LH SIDE
FUEL LEVEL SENSOR – RH SIDE (DIESEL) FP13 6-WAY / GREY FUEL TANK, RH SIDE
FUEL LEVEL SENSOR – RH SIDE (GASOLINE) FP4 4-WAY / BLACK FUEL TANK, RH SIDE
FUEL LEVEL SENSOR – RH SIDE (NAS N/A ONLY) FP8 4-WAY / BLACK FUEL TANK, RH SIDE
FUEL LEVEL SENSOR – RH SIDE (NAS SC ONLY) FP9 4-WAY / BLACK FUEL TANK, RH SIDE
FUEL LOW LEVEL SWITCH (DIESEL) FP13 6-WAY / GREY FUEL TANK, RH SIDE
IGNITION SWITCH FC18 7-WAY / BLACK STEERING COLUMN COWLING
INSTRUMENT CLUSTER FC8 32-WAY / BLACK INSTRUMENT PANEL FC9 32-WAY / BLACK
MAIN LIGHTING SWITCH (COLUMN SWITCHGEAR) FC116 6-WAY / BLACK STEERING COLUMN COWLING
OIL PRESSURE SWITCH (DIESEL) C29 1-WAY / BLACK ADJACENT TO OIL FILTER
OIL PRESSURE SWITCH (GASOLINE) PI46 1-WAY / BLACK ADJACENT TO OIL FILTER
REAR ELECTRONIC MODULE CA63 17-WAY / BLACK LUGGAGE COMPARTMENT, RH REAR CA100 12-WAY / BLACK
CA101 20-WAY / BLACK
CA102 22-WAY / BLACK
CA103 26-WAY / NATURAL
WASHER FLUID LEVEL SWITCH FH37 2-WAY / BLACK WASHER FLUID CONTAINERHARNESS IN-LINE CONNECTORS
Connector Connector Description / Location LocationCP1 10-WAY / BLACK / INTERCOOLER PUMP LINK LEAD ENGINE COMPARTMENT, RH FRONT, ADJACENT TO RADIATOR
CP7 4-WAY / BLACK / FRONT END HARNESS ENGINE COMPARTMENT, RH FRONT, ADJACENT TO RADIATOR
FC4 14-WAY / GREEN / FASCIA HARNESS IN-LINE CONNECTOR BEHIND INSTRUMENT PANEL, LH SIDE
FC26 16-WAY / BLUE / CABIN HARNESS TO FASCIA HARNESS BEHIND INSTRUMENT PANEL, DRIVER SIDE
FP2 8-WAY / BLACK / CABIN HARNESS TO FUEL PUMP HARNESS TOP OF FUEL TANK, RH SIDE
FP6 2-WAY / BLACK / CABIN HARNESS TO FUEL PUMP HARNESS TOP OF FUEL TANK, RH SIDE
PI41 42-WAY / BLACK / ENGINE HARNESS TO VEHICLE HARNESSES ENGINE COMPARTMENT, BULKHEAD, PASSENGER SIDEGROUNDS
Ground LocationCA156 LUGGAGE COMPARTMENT, RH SIDE
FC38 UNDER CENTER OF INSTRUMENT PANEL, ON TRANSMISSION TUNNEL
FH42 ENGINE COMPARTMENT, BEHIND RH HEADLAMP
FH77 LH LOWER ‘A’ POST, ADJACENT TO THE FRONT ELECTRONIC MODULE (FORWARD OF CA30)
NOTE: Refer to the Appendix at the rear of this book for Network Messages. Front Electronic Module Pin Description and CharacteristicI FH9–15 WASHER FLUID LEVEL SWITCH (NORMALLY OPEN): OPEN CIRCUIT / GROUND
S FH59–1 SCP –
B+ FH59–6 BATTERY POWER SUPPLY (LOGIC): B+
S FH59–7 SCP +
I FH59–9 ENGINE OIL PRESSURE SWITCH (NORMALLY OPEN): OPEN CIRCUIT / GROUND
PG FH59–12 POWER GROUND: GROUND
PG FH60–11 POWER GROUND: GROUND
PG FH60–13 POWER GROUND: GROUND
PG FH60–14 POWER GROUND: GROUND
PG FH60–15 POWER GROUND: GROUNDInstrument ClusterPin Description and CharacteristicPG FC8–2 POWER GROUND: GROUND
I FC8–3 SEAT BELT AUDIBLE WARNING REQUEST: AUDIBLE WARNING REQUEST ACTIVE = GROUND
B+ FC8–4 IGNITION SWITCHED POWER SUPPLY (I): B+
I FC8–5 KEY-IN AUDIBLE WARNING: B+ WHEN KEY IN
I FC8–6 KEY-IN AUDIBLE WARNING (J-GATE): GROUND WHEN NOT-IN-PARK
B+ FC8–14 IGNITION SWITCHED POWER SUPPLY (II): B+
B+ FC8–15 BATTERY POWER SUPPLY (LOGIC): B+
SG FC8–18 AUXILIARY LIGHTING SWITCH SIGNAL GROUND: GROUND
I FC8–19 LOW ENGINE COOLANT LEVEL WARNING: GROUND WHEN COOLANT LEVEL LOW
I FC8–23 AIR BAG WARNING: HARD-WIRED TO AIR BAG INDICATOR
B+ FC8–24 IGNITION SWITCHED POWER SUPPLY (II) (AIRBAG WARNING): B+
SG FC8–32 SIGNAL GROUND: GROUND
I FC9–1 TRIP COMPUTER – MESSAGE CENTER SIGNALS: VARIABLE RESISTANCE
SG FC9–10 MAIN LIGHTING SWITCH SIGNAL GROUND: GROUND
C FC9–12 CAN +
C FC9–13 CAN –
I FC9–17 TRIP CYCLE SWITCH – MESSAGE CENTER SIGNAL: VARIABLE RESISTANCE
S FC9–25 SCP +
S FC9–26 SCP –
C FC9–28 CAN +
C FC9–29 CAN –Rear Electronic ModulePin Description and CharacteristicB+ CA101–3 BATTERY POWER SUPPLY: B+
I CA101–15 GASOLINE, RH FUEL LEVEL SENSOR SIGNAL: VARIABLE RESISTANCE
I CA101–16 GASOLINE, LH FUEL LEVEL SENSOR SIGNAL: VARIABLE RESISTANCE
S CA102–1 SCP +
S CA102–2 SCP –
PG CA102–12 POWER GROUND: GROUND
I CA102–17 LOW LEVEL SWITCH
I CA102–20 LOW LEVEL SWITCH
PG CA103–11 POWER GROUND: GROUND
PG CA103–12 POWER GROUND: GROUND
I CA103–17 DIESEL, RH FUEL LEVEL SENSOR SIGNAL: VARIABLE RESISTANCE
I CA103–18 DIESEL, LH FUEL LEVEL SENSOR SIGNAL: VARIABLE RESISTANCE
SG CA103–23 FUEL LEVEL SENSORS SIGNAL GROUND: GROUND
PG CA103–25 POWER GROUND: GROUND
PG CA103–26 POWER GROUND: GROUND
Page 93 of 200
Instrument Cluster; Audible Warnings
Jaguar S-TYPE 2005
Instrument Cluster; Audible Warnings
Fig. 07.1
13 4114
46 80
76 77 92
ll
15 45ll ll SS
81 118EE
Fig .01.1
Fig .01 .2 F
ig .01.3
Fig .01 .4
Fig . 01.5 F
ig . 01.6 F
ig .01 .7
Input
OutputI
O
B
P+Battery VoltagePower Ground Sensor/Signal Supply V
Sensor/Signal Ground Serial and Encoded Data
CAN
+
SCPC
S DD
–
D2B Network2
f07_1_200045
SS
FC9-26 FC9-25
U Y
20.220.2
G Y
20.120.1
FC9-12
FC9-13G Y
20.120.1
FC9-28
FC9-29
FC26-12
O
CP1-7
(*CP7-4) (*CP7-3)
FH42
B
CP1-6 FC4-13
CP3-1 CP3-2
NGWG
FC8-15
FC8-14
FC8-2
B
FC38
FC8-3
WB
I
8535II
P
B
FC18-5
FC18-4
NR
W
FC8-4
WG
FC8-24
BB
2I39II
FC8-23
BG
I
FC8-32
B
CCCC
CAN
7
FC8-5
WU
IB
FC9-1
GR
I
FC26-11
WB BG
17.117.1
FC8-18
GO
FC11-7FC11-2
9.1K
3.9K
1.1K
360R
SCP
U Y
FH59-7
FH59-1
NG
FH59-6
FH60-15
B
86
P
B
20.220.2
SS
U Y
CA102-1
CA102-2
N
CA101-3
87
B
20.220.2
SS
FH60-14
B
P
FH60-13
B
P
FH59-12
B
P
FH60-11
B
P
FH77
CA103-26
B
P
CA103-25
B
P
CA103-12
B
P
CA103-11
B
P
CA102-12
B
P
CA156
FC8-19
O
I
FC8-6
Y
I
04.1
O
B
FH59-9
BG
I
P
PI41-16
BG
WU
FH9-15
B
I
FH42
CA101-15
WR
I
CA103-23
NR
CA101-16
WU
I
FP6-1
FP2-5
FP6-2
F
E
160R
20R
NRFPS1
NR
F
E
160R
20R
NR
WU WR
470R330R
I
FC9-17
OG
FC116-5
FC9-10
UY
FC116-6
CA103-17
WR
III
CA103-23
NR
CA103 -18
WU
I
FP2-2
FP2-5
FP2-3
NRFPS1
NRNR
WU WR
CA102-17
O
FP2-6
O
CA102-20
Y
FP2-4
Y
YW
KO
KO
YW
FP3-3
FP3-1
MAIN LIGHTING SWITCH
(COLUMN SWITCHGEAR)
REFER TO APPENDIX
CAN / IC MESSAGES.
RESTRAINTS CONTROL MODULE: AIRBAG INDICATOR DRIVE(CIRCUIT CONTINUED)
RESTRAINTS CONTROL MODULE:
SEAT BELT AUDIBLE WARNING DRIVE (CIRCUIT CONTINUED)
J GATE: NOT-IN-PARK
(CIRCUIT CONTINUED)
KEY-IN
IGNITION SWITCH
TRIP COMPUTER SWITCHES
AUXILIARY LIGHTING SWITCH
TRIP CYCLESWITCH
INSTRUMENT CLUSTER
LOW ENGINE COOLANT LEVEL
WARNINGMESSAGE CENTER MESSAGE CENTER
KEY-IN
AUDIBLE WARNING KEY-IN
AUDIBLE WARNING
SEAT BELT
AUDIBLE WARNING AIR BAG
WARNING INDICATOR AIR BAG
WARNINGS LOGIC
LOGIC
LOGIC REFER TO APPENDIX
SCP/ICMESSAGES
FRONT ELECTRONIC MODULE
REAR ELECTRONIC MODULE
PI46-1
(*C29-1)
OIL PRESSURE SWITCH
FH37-2 FH37-1
WASHER FLUIDLEVEL SWITCH
RH SIDE FUEL LEVELSENSOR
LH SIDE FUEL LEVEL SENSOR
FUEL TANK (GASOLINE)
FP4-3 FP4-1
†FP8-3
†FP8-4
†FP8-2 (N/A)
†FP9-4 (SC)
†FP9-3 (SC)†FP8-5 (N/A)
RESET
TRIP A / B MLS / KM
Note:
*Diesel only
ENGINE
COOLANT LEVEL SENSOR
F
E
160R
20R
F
E
160R
20R
YW
KO
KO
YW
FP14-1
FP14-2
RH SIDE FUEL LEVEL
SENSOR
LH SIDE FUEL LEVEL SENSOR
FUEL TANK (DIESEL)
FP13-1
FP13-2FP13-5
FP13-6
100RLOW LEVEL SWITCH
330R
Note: †
NAS only
VARIANT: All Vehicles
VIN RANGE: All
DATE OF ISSUE: May 2004
Page 132 of 200
Refer to the front of this book for detailed information and illustrations regarding the location and identification of harnesses, relays, fuses, grounds,
control modules and control module pins.
NOTE: The values listed are approximately those that can be expected at the control module connector pins with all circuit conn
ections made and all
components connected and fitted. The following abbreviations are used to represent values for Control Module Pin-Out data
I Input
O Output
B+ Battery Voltage PG Power Ground
SS Sensor / Signal Supply V
SG Sensor / Signal GroundC CAN Network
S SCP Network
D2 D2B Network D Serial and Encoded Data
V Voltage (DC)
PWM Pulse Width Modulated
CAUTION: The information on this data page is furnished to ai d the user in understanding circuit operation. THIS INFORMATION SH OULD BE USED FOR
REFERENCE ONLY.DATE OF ISSUE: May 2004
Fig. 13.1
FOR CONTROL MODULE PIN-OUT INFORMATION, UNFOLD PAGE TO LEFT. COMPONENTS
Component Connector(s) Connector Description LocationFRONT ELECTRONIC MODULE CA24 26-WAY / NATURAL LH ‘A’ POST
CA31 20-WAY / BLACK
FH9 22-WAY / BLACK
FH59 12-WAY / BLACK
FH60 17-WAY / BLACK
FRONT POWER DISTRIBUTION FUSE BOX — — ENGINE COMPARTMENT, RH SIDE
POWER WASH PUMP FH38 2-WAY / BLACK ENGINE COMPARTMENT, WASHER FLUID TANK
POWER WASH RELAY — — FRONT POWER DISTRIBUTION FUSE BOX – R18
RAIN SENSING MODULE CA248 12-WAY / BLACK LUGGAGE COMPARTMENT, UNDER PARCEL SHELF
RAIN SENSING UNIT RF14 3-WAY / BLACK REAR VIEW MIRROR
WASHER FLUID LEVEL SWITCH FH37 2-WAY / BLACK WASHER FLUID CONTAINER
WINDSHIELD WASHER PUMP FH36 5-WAY / GREEN ENGINE COMPARTMENT, ADJACENT TO WASHER FLUID CONTAINER
WIPE / WASH SWITCH FC118 6-WAY / BLACK STEERING COLUMN STALK
WIPER HIGH / LOW RELAY — — FRONT POWER DISTRIBUTION FUSE BOX – R15
WIPER MOTOR ASSEMBLY FH17 6-WAY / BLACK ENGINE COMPARTMENT, BULKHEAD
WIPER PARK RELAY — — FRONT POWER DISTRIBUTION FUSE BOX – R16HARNESS IN-LINE CONNECTORS
Connector Connector Description / Location LocationFC19 16-WAY / GREEN / CABIN HARNESS TO FASCIA HARNESS BEHIND INSTRUMENT PANEL, LH SIDE
FH1 20-WAY / BLACK / CABIN HARNESS TO FRONT HARNESS RH ‘A’ POST, LOWER
RF34 16-WAY / GREEN / CABIN HARNESS TO DOOR HARNESS ‘D’ POST, UNDER PARCEL SHELFGROUNDS
Ground LocationCA116 BEHIND REAR SEAT BACK, RH SIDE
FH22 ENGINE COMPARTMENT, BEHIND LH HEADLAMP
FH42 ENGINE COMPARTMENT, BEHIND RH HEADLAMP
FH77 LH LOWER ‘A’ POST, ADJACENT TO THE FRONT ELECTRONIC MODULE (FORWARD OF CA30)
NOTE: Refer to the Appendix at the rear of this book for Network Messages. Front Electronic Module Pin Description and CharacteristicI CA31–2 WIPER MODE SELECT: VARIABLE RESISTANCE
I CA31–13 WIPER DELAY / WASH: VARIABLE RESISTANCE
SG CA31–14 WIPE / WASH SWITCH SIGNAL GROUND: GROUND
O FH9–1 WIPER PARK RELAY ACTIVATE: TO ACTIVATE, FEM SWITCHES CIRCUIT TO GROUND
O FH9–3 WIPER HIGH / LOW RELAY ACTIVATE: TO ACTIVATE, FEM SWITCHES CIRCUIT TO GROUND
I FH9–13 WIPER PARK: PARK = GROUND
O FH9–14 WINDSHIELD WASHER PUMP DRIVE: TO ACTIVATE, FEM SWITCHES CIRCUIT TO B+
I FH9–15 WASHER FLUID LEVEL SWITCH (NORMALLY OPEN): OPEN CIRCUIT / GROUND
S FH59–1 SCP –
O FH59–4 POWER WASH RELAY ACTIVATE: TO ACTIVATE, FEM SWITCHES CIRCUIT TO GROUND
S FH59–7 SCP +
B+ FH60–1 SWITCHED SYSTEM POWER SUPPLY: B+
PG FH60–11 POWER GROUND: GROUND
Page 133 of 200
Wash / Wipe System
Jaguar S-TYPE 2005
Wash / Wipe System
Fig. 13.1
13 4114
46 80
76 77 92
ll
15 45ll ll SS
81 118EE
Fig .01.1
Fig .01 .2 F
ig .01.3
Fig .01 .4
Fig . 01.5 F
ig . 01.6 F
ig .01 .7
Input
OutputI
O
B
P+Battery VoltagePower Ground Sensor/Signal Supply V
Sensor/Signal Ground Serial and Encoded Data
CAN
+
SCPC
S DD
–
D2B Network2
f13_1_200045
FH60-11
B
P
FH77
WR
Y
GW
CA248-6 CA248-3
W
CA248-1
FC118-4
FHS16
CA31-2
BWWU
YU
FH36-2
FH36-1
FH17-3
FH17-1
NR
FH22
(FH42)
FH42
FC118-6
FC118-5
WRY
GW
CA31-14
CA31-13
CAS9
CAS10
CAS11
FC19-16 FC19-15 FC19-14
WR
Y
GW
II
CA248-12
Y
GW
WR
O
FH9-14
NW
YG
555354
NG
NR
R
RG
BG
O
FH59-4
O
FH9-1
O
FH9-3
B
FH38-2
FH38-1
FH9-15
FH37-1
FH37-2
B
I
FH59-1
U
FH59-7
Y
20.220.2
SS
BG
I
BG
FH9-13
FH17-2
FH17-5
FH17-4
B
NR
Y
YU
51
52
WB
CA248-11
NR
FH60-1
S60
B
NR NR
NR
261R261R261R1K3562R332R200R121R100R
100R261R261R
261R
261R
RF14-2 RF14-1
YB WB
RF14-3
YB
RF34-12
RF34-13
RF34-14
CA248-8
BG
BCA248-7
YB
CA248-10
YB
CA248-9
PB
24IICA116
1I
32
51
R18
4
32
51
R15
4
32
51
R16
4
56
FH1-17
BG
WIPER
MODE SELECT
WIPER
DELAY/WASH
RAIN SENSING MODULE *
RAIN SENSING UNIT *
* NOTE:
Rain sensing system – rain sensing vehicles only.
WIPE / WASH SWITCH
FLUID LEVEL WARNING;
VEHICLE SPEED
FRONT ELECTRONIC MODULE WIPER HIGH / LOW RELAY
WIPER PARK RELAY
POWER WASH RELAY
FRONT POWER DISTRIBUTION FUSE BOX WASHER FLUID LEVEL SWITCH
WINDSHIELD WASHER PUMPPOWER WASH PUMP
WIPER MOTOR ASSEMBLY
PARK
RUN
LOW SPEED
HIGH SPEED
F21 5A
FH32-18
FH32-27
VARIANT:
All Vehicles
VIN RANGE: All
DATE OF ISSUE: May 2004
Page 180 of 200
viDATE OF ISSUE: May 2004
SCP Message Matrix
AppendixJaguar S-TYPE 2005
Low Fuel Level Status: No (False)IC X
Low Fuel Level Status: Yes (True) IC X
Low Washer Fluid Tell Tale Command: OFF FEM X
Low Washer Fluid Tell Tale Command: ON FEM X
Memory Feature Menu Status DDM X X
Memory Feature Menu Status IC X X X
Memory Features 1 Command: Recall DDM X X X
Memory Features 1 Command: Set / Save DDM X X X
Memory Features 2 Command: Recall DDM X X X
Memory Features 2 Command: Set / Save DDM X X X
Memory Features Recall Cancel Command: Yes (True) DDM X X X
Memory Features Recall Cancel Command: Yes (True) DSCM X X X
Memory Features Recall Cancel Command: Yes (True) IC X X X
Network Bus Wake-up Command: Yes (True) DDM
Network Bus Wake-up Command: Yes (True) DSCM
Network Bus Wake-up Command: Yes (True) FEM
Network Bus Wake-up Command: Yes (True) IC
Network Bus Wake-up Command: Yes (True) REM
Odometer Rolling Count Status IC X
Passenger’s Front Door Ajar Switch Status: Active FEM X X X X
Passenger’s Front Door Ajar Switch Status: Inactive FEM X X X X
Passenger’s Front Door Lock Switch Status: Active REM X
Passenger’s Front Door Unlock Switch Status: Active REM X
Passenger’s Mirror Down Motion Command: Enable(d) DDM X
Passenger’s Mirror Left Motion Command: Disable(d) DDM X
Passenger’s Mirror Left Motion Command: Enable(d) DDM X
Passenger’s Mirror Right Motion Command: Enable(d) DDM X
Passenger’s Mirror Up Motion Command: Enable(d) DDM X
Passenger’s Rear Door Ajar Switch Status: Active REM X X X X
Passenger’s Rear Door Ajar Switch Status: Inactive REM X X X X
Pedal Adjustment Status: Disabled FEM X
Message Name
SourceReceivers
FEM
REM IC
DSCM
ADCM SCLM
AUDIO NCM DDM
Page 183 of 200
DATE OF ISSUE: May 2004ix
AppendixJaguar S-TYPE 2005
SCP Message Matrix
Request Left Front Turn Lamp OK StatusIC X
Request Left Rear Brake Lamp OK Status IC X
Request Left Rear Tail Lamp OK Status IC X
Request Left Rear Turn Lamp OK Status IC X
Request Left Side Mid Vehicle Turn Lamp OK Status IC X
Request Low Fuel Level Status NCM X
Request Low Washer Fluid Telltale Command IC X
Request Memory Feature Menu Status DSCM X
Request Memory Feature Menu Status FEM X
Request Parking Brake Switch Status AUDIO
Request Passenger’s Front Door Ajar Switch Status AUDIO X
Request Passenger’s Front Door Ajar Switch Status DDM X
Request Passenger’s Front Door Ajar Switch Status IC X
Request Passenger’s Front Door Ajar Switch Status REM X
Request Passenger’s Rear D oor Ajar Switch Status AUDIO X
Request Passenger’s Rear D oor Ajar Switch Status DDM X
Request Passenger’s Rear D oor Ajar Switch Status FEM X
Request Passenger’s Rear D oor Ajar Switch Status IC X
Request Rear Windshield Electric Defrost Switch Status REM
Request Right Front Turn Lamp OK Status IC X
Request Right Rear Brake Lamp OK Status IC X
Request Right Rear Tail Lamp OK Status IC X
Request Right Rear Turn Lamp OK Status IC X
Request Right Side Mid Vehicle Turn Lamp OK Status IC X
Request Steering Column Lock System Status IC X
Request Vehicle Speed Control Active Status FEM X
Right Front Turn Lamp OK Status: No (False) FEM X
Right Front Turn Lamp OK Status: Yes (True) FEM X
Right Rear Brake Lamp OK Status: No (False) REM X
Right Rear Brake Lamp OK Status: Yes (True) REM X
Right Rear Tail Lamp OK Status: No (False) REM X
Message Name
SourceReceivers
FEM
REM IC
DSCM
ADCM SCLM
AUDIO NCM DDM
Page 198 of 200
6DATE OF ISSUE: May 2004
Component IndexJaguar S-TYPE 2005
STEERING WHEEL LIGHTING . . . . . . . . . . . . . . . . . . . . . . . Fig. 09.2
STEERING WHEEL SPEED CONTROL SWITCHES . . . . . . Fig. 03.2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 03.4
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 03.6
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 03.8
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 05.3
SUBWOOFERS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 15.2
SUN SHADE MOTOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 19.1
SUN VISOR LAMPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 09.1
SWITCHED SYSTEM POWER RELAYS . . . . . . . . . . . . . . . . Fig. 01.6
T
TAIL LAMP UNITS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 08.3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 08.4
TELEMATICS DISPLAY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 09.2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 16.1
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 16.2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 16.3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 16.4
TELEPHONE ANTENNA . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 16.1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 16.2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 16.3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 16.4
THROTTLE MOTOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 03.1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 03.3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 03.5
THROTTLE MOTOR RELAY . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 03.1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 03.3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 03.5
TIRE PRESSURE MONITORING SYSTEM MODULE . . . . . . Fig. 05.5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 20.1
TIRE PRESSURE RECEIVER MODULE . . . . . . . . . . . . . . . . Fig. 05.5
TIRE PRESSURE SENSORS. . . . . . . . . . . . . . . . . . . . . . . . . Fig. 05.5
TP SENSOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 03.1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 03.3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 03.5
TPMS INITIATORS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 05.5
TRAILER TOWING CONNECTORS . . . . . . . . . . . . . . . . . . . . Fig. 08.4
TRAILER TOWING CONTROL MODULE . . . . . . . . . . . . . . . Fig. 08.4
TRAILER TOWING JUNCTION BOX . . . . . . . . . . . . . . . . . . . Fig. 08.4
TRAILER TOWING RELAY. . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 08.4
TRANSIT ISOLATION RELAY . . . . . . . . . . . . . . . . . . . . . . . . Fig. 01.1
TRANSMISSION CAPACITORS. . . . . . . . . . . . . . . . . . . . . . . Fig. 04.1
TRANSMISSION CONTROL MODULE . . . . . . . . . . . . . . . . . Fig. 02.1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 02.2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 02.3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 04.1
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 05.3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 20.1
TRUNK AJAR SWITCH. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 09.1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 12.1
TRUNK LAMP – LH. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 09.1
TRUNK LID LAMP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 09.1
TRUNK LID LATCH ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . Fig. 12.2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 12.3
TRUNK RELEASE SOLENOID . . . . . . . . . . . . . . . . . . . . . . . . Fig. 12.1
TURN REPEATERS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 08.1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 08.2
TV ANTENNAS AND AMPLIFIERS . . . . . . . . . . . . . . . . . . . . Fig. 16.7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 16.8
V
VALET SWITCH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 12.1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 12.2 VARIABLE ASSIST STEERING ACTUATOR . . . . . . . . . . . . Fig. 05.2
VEHICLE INFORMATION ANTENNA . . . . . . . . . . . . . . . . . . Fig. 16.8
VEHICLE INFORMATION CONTROL MODULE . . . . . . . . . . Fig. 16.8
VEHICLE INFORMATION SENSOR . . . . . . . . . . . . . . . . . . . Fig. 16.8
VERTICAL ACCELEROMETERS . . . . . . . . . . . . . . . . . . . . . Fig. 05.4
VOICE ACTIVATION MODULE . . . . . . . . . . . . . . . . . . . . . . . Fig. 16.3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 16.4
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 16.5
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 20.3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 20.4
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 20.5
VOLUMETRIC CONTROL VALVE – FUEL PUMP
(DIESEL 2.7V6) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 03.8
VVT SOLENOID VALVES . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 03.1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 03.3
W
WASHER FLUID LEVEL SWITCH . . . . . . . . . . . . . . . . . . . . . Fig. 07.1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 13.1
WHEEL SPEED SENSORS. . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 05.1
WINDOW MOTOR ASSEMBLIES . . . . . . . . . . . . . . . . . . . . . Fig. 14.1
WINDOW SWITCHES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 09.2
WINDSHIELD WASHER PUMP . . . . . . . . . . . . . . . . . . . . . . Fig. 13.1
WIPE / WASH SWITCH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 13.1
WIPER HIGH / LOW RELAY . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 13.1
WIPER MOTOR ASSEMBLY. . . . . . . . . . . . . . . . . . . . . . . . . Fig. 13.1
WIPER PARK HEATER OR RH WINDSHIELD HEATER . . . Fig. 06.1
WIPER PARK HEATER / RH WINDSHIELD
HEATER RELAY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 06.1
WIPER PARK RELAY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 13.1
Y
YAW RATE AND LATERAL ACCELERATION
SENSORS CLUSTER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 05.1
