Removal and InstallationApproach Lamp
Headlamp Assembly
Headlamp Leveling Front Sensor
Headlamp Leveling Rear Sensor
High Mounted Stoplamp
Rear Fog Lamp
Rear Lamp Assembly
Side Turn Signal Lamp417-02: Interior Lighting
Description and OperationComponent Location
Overview
System Operation and Component DescriptionDiagnosis and TestingInterior Lighting417-04: Daytime Running Lamps (DRL)
Description and OperationOverview
System Operation and Component Description418: Electrical Distribution
418-00: Module Communications Network
Description and OperationOverview
System Operation and Component DescriptionDiagnosis and TestingCommunications NetworkRemoval and InstallationAuxiliary Junction Box (AJB)
Central Junction Box (CJB)418-02: Wiring Harnesses
Description and OperationWiring HarnessGeneral ProceduresWiring Harness RepairRemoval and InstallationLuggage Compartment Lid Wiring Harness419: Electronic Feature Group
419-01A: Anti-Theft - Active
Description and OperationComponent Location
Overview
Page 119 of 3039
DTC Description Possible Causes Action U3000-01
Control module -
General
Electrical Failure
General electrical
failure
Check integrity of electrical connectors and pins to module.
Check damper negative circuits for short to Ground. Refer to
the new module installation note at the top of the DTC Index.
Install a new Adaptive Damping Control Module U3000-04
Control Module -
System Internal
Failure
Module Internal
failure
Refer to the electrical wiring diagrams and check all damper
solenoid circuits for short to power. If no harness faults are
found suspect adaptive damping control module. Install a new
module, refer to new module installation note at top of DTC
Index U3000-43
Control Module -
Special memory
failure
Module Internal
failure
Suspect Adaptive Damping Control Module internal failure.
Install a new module, refer to the new module/component
installation note at the top of the DTC Index U3000-45
Control Module -
Program memory
failure
Module Internal
failure
Refer to the electrical circuit diagrams and check power and
ground circuit for fault. Clear DTC turn off ignition, wait 1
minute. Turn on ignition, check for DTCs. If DTC returns
suspect Adaptive Damping Control Module internal failure.
Install a new module, refer to the new module/component
installation note at the top of the DTC Index U3000-47
Control Module -
Watchdog /
safety Micro
controller failure
Module Internal
Failure
If this DTC is logged contact your local in-market support U3000-52
Control Module -
Not activated
Adaptive Damping
Control Module has
been replaced and not
programmed
Install the latest software / Carry out the new-module
(software) install procedure U3000-54
Control Module -
Missing
calibration
Adaptive damping
control module has
been replaced and no
software is installed
Install the latest software / Carry out the new-module
(software) install procedure U3003-1C Battery voltage
- Circuit voltage
out of range
Circuit voltage out of
range (Supply Voltage
at adaptive damping
control module <
10.5v or Supply
Voltage at adaptive
damping control
module > 18v for 30s)
Check the battery is in good condition and fully charged, refer
to the battery care manual. Refer to the starting and charging
section of the workshop manual and check the performance of
the charging system. Refer to the electrical circuit diagrams
and check power and ground circuit to adaptive damping
control module for faults, including intermittent high
resistance U3003-62 Battery Voltage
- Signal compare
failure
High Resistance
Connections
Adaptive Damping
Control module
Internal Failure
Check the battery is in good condition and fully charged, refer
to the battery care manual. Refer to the starting and charging
section of the workshop manual and check the performance of
the charging system. Refer to the electrical circuit diagrams
and check power and ground circuit to adaptive damping
control module for faults, including intermittent high
resistance
Page 158 of 3039
Published: 17-Apr-2014
General Information - Diagnostic Trouble Code (DTC) Index DTC: Electric
Parking Brake (PBM)
Description and Operation
Electric Parking Brake (PBM)
CAUTION: Diagnosis by substitution from a donor vehicle is NOT acceptable. Substitution of control modules does not
guarantee confirmation of a fault, and may also cause additional faults in the vehicle being tested and/or the donor vehicle
NOTES:
If the control module or a component is suspect and the vehicle remains under manufacturer warranty, refer to the
warranty policy and procedures manual, or determine if any prior approval programme is in operation, prior to the installation
of a new module/component
Generic scan tools may not read the codes listed, or may read only 5-digit codes. Match the 5 digits from the scan tool to
the first 5 digits of the 7-digit code listed to identify the fault (the last 2 digits give extra information read by the
manufacturer-approved diagnostic system)
When performing voltage or resistance tests, always use a digital multimeter accurate to three decimal places and with a
current calibration certificate. When testing resistance, always take the resistance of the digital multimeter leads into account
Check and rectify basic faults before beginning diagnostic routines involving pinpoint tests
Inspect connectors for signs of water ingress, and pins for damage and/or corrosion
If diagnostic trouble codes are recorded and, after performing the pinpoint tests, a fault is not present, an intermittent
concern may be the cause. Always check for loose connections and corroded terminals
Where an 'on demand self-test' is referred to, this can be accessed via the 'diagnostic trouble code monitor' tab on the
manufacturers approved diagnostic system
Check DDW for open campaigns. Refer to the corresponding bulletins and SSM's which may be valid for the specific
customer complaint and carry out the recommendations as needed.
The table below lists all diagnostic trouble codes (DTCs) that could be logged in the electric parking brake module, for
additional diagnosis and testing information refer to the relevant diagnosis and testing section.
For additional information, refer to: Parking Brake (206-05 Parking Brake and Actuation, Diagnosis and Testing).
DTC Description Possible Causes Action P1536-62
Parking Brake Switch
Circuit - Signal compare
failure
Wiring harness fault
Switch internal fault
All signals from the switch are active at the same
time. Refer to the electrical circuit diagrams and
check all the switch apply, release and return
circuits for short circuit or open circuit. Repair
wiring harness as required
If no fault with wiring harness suspect switch has
an internal fault. Refer to the Warranty Policy and
Procedures manual if a module/component is
suspect P1536-66
Parking Brake Switch
Circuit - Signal has too
many transitions /
events
System abuse
Wiring harness fault
Switch internal fault
NOTE: The Electric Parking Brake system will be
locked out if the module receives more then 30
apply/release requests within 1 minute.
Cycle the ignition to clear the fault mode. Clear
the DTC and test the system
Refer to the electrical circuit diagrams and check
all the switch apply, release and return circuits for
intermittent short circuit or open circuit. Repair
wiring harness as required
If there are no wiring faults and the DTC resets
Page 168 of 3039
DTC Description Possible Causes Action Intake valve solenoid 1 stuck
advanced a new module/component P0027-72
Exhaust Valve Control
Solenoid Circuit
Range/Performance (Bank 1)
- Actuator stuck open
NOTE: - Circuit VFS_EX_A -
Exhaust valve solenoid 1 angle
less than target
Exhaust valve solenoid 1 slow or
not operating
Check operation of exhaust valve
solenoid 1. Check and install a new
exhaust valve solenoid 1 as
required. Refer to the warranty policy
and procedures manual, or determine
if any prior approval programme is in
operation, prior to the installation of
a new module/component P0027-77
Exhaust Valve Control
Solenoid Circuit
Range/Performance (Bank 1)
- Commanded position not
reachable
NOTE: - Circuit VFS_EX_A -
Exhaust valve solenoid 1 angle
greater than target
Exhaust valve solenoid 1 not
returning to target in time
Exhaust valve solenoid 1 stuck
advanced
Check operation of exhaust valve
solenoid 1. Check and install a new
exhaust valve solenoid 1 as
required. Refer to the warranty policy
and procedures manual, or determine
if any prior approval programme is in
operation, prior to the installation of
a new module/component P0028-72
Intake Valve Control
Solenoid Circuit
Range/Performance (Bank 2)
- Actuator stuck open
NOTE: - Circuit VFS_IN_B -
Intake valve solenoid 2 angle less
than target
Intake valve solenoid 2 slow or not
operating
Check operation of intake valve
solenoid 2. Check and install a new
intake valve solenoid 2 as required.
Refer to the warranty policy and
procedures manual, or determine if
any prior approval programme is in
operation, prior to the installation of
a new module/component P0028-77
Intake Valve Control
Solenoid Circuit
Range/Performance (Bank 2)
- Commanded position not
reachable
NOTE: - Circuit VFS_IN_B -
Intake valve solenoid 2 angle
greater than target
Intake valve solenoid 2 not
returning to target in time
Intake valve solenoid 2 stuck
advanced
Check operation of intake valve
solenoid 2. Check and install a new
intake valve solenoid 2 as required.
Refer to the warranty policy and
procedures manual, or determine if
any prior approval programme is in
operation, prior to the installation of
a new module/component P0029-72
Exhaust Valve Control
Solenoid Circuit
Range/Performance (Bank 2)
- Actuator stuck open
NOTE: - Circuit VFS_EX_B -
Exhaust valve solenoid 2 angle
less than target
Exhaust valve solenoid 2 slow or
not operating
Check operation of exhaust valve
solenoid 2. Check and install a new
exhaust valve solenoid 2 as
required. Refer to the warranty policy
and procedures manual, or determine
if any prior approval programme is in
operation, prior to the installation of
a new module/component P0029-77
Exhaust Valve Control
Solenoid Circuit
Range/Performance (Bank 2)
- Commanded position not
reachable
NOTE: - Circuit VFS_EX_B -
Exhaust valve solenoid 2 angle
greater than target
Exhaust valve solenoid 2 not
returning to target in time
Exhaust valve solenoid 2 stuck
advanced
Check operation of exhaust valve
solenoid 2. Check and install a new
exhaust valve solenoid 2 as
required. Refer to the warranty policy
and procedures manual, or determine
if any prior approval programme is in
operation, prior to the installation of
a new module/component P0031-11
HO2S Heater Control Circuit
Low (Bank 1, Sensor 1) -
Circuit short to ground NOTES:
- Circuit HTR_CTRL_A_UPSTREAM -
LR - Circuit UHEGO HEATER A -
Pre catalyst oxygen sensor-odd
heater control circuit (Bank 1,
Sensor 1) circuit short circuit to
ground
Using the manufacturer approved
diagnostic system check datalogger
signal, Oxygen Sensor (O2S) Heater
Duty Cycle Bank 1 Sensor 1 (0x03A1)
Refer to the electrical circuit
diagrams and check pre catalyst
oxygen sensor-odd heater control
circuit (Bank 1, Sensor 1) circuit for
short circuit to ground
Page 194 of 3039
DTC Description Possible Causes Action B1C33-14
Steering Column Tilt
Feedback Signal - Circuit
short to ground or open
Steering column tilt
feedback signal circuit -
short to ground, open circuit
Carry out any pinpoint tests associated with this
DTC using the manufacturer approved diagnostic
system. Refer to the electrical circuit diagrams
and check steering column tilt feedback signal
circuit for short to ground, open circuit B1C34-77
Steering Column Telescope Solenoid -
Commanded position
not reachable
REACH axis fails to move
minimum distance within
allotted time period. Motion
may have been prohibited
due to motor jamming,
stalling or solenoid pin not
engaging
Check for restricted/jammed steering column
motor mechanism. Refer to the electrical circuit
diagrams and check steering column motor
UP/IN, DOWN/OUT circuit for short, open circuit B1C34-94
Steering Column Telescope Solenoid -
Unexpected operation
REACH axis moves when it
has not been commanded
to. Motion may have
occurred due to solenoid pin
not disengaging or
mechanism has been
jammed on, whilst TILT axis
has been commanded to
move
Check for stuck/jammed solenoid/switch. Refer
to the electrical circuit diagrams and check
steering column motor UP/IN, DOWN/OUT circuit
for short, open circuit B1C35-12
Steering Column Telescope Feedback
Signal - Circuit short to
battery
Steering column TELE
feedback signal circuit -
short to power
Refer to the electrical circuit diagrams and check
steering column TELE feedback signal circuit for
short to power B1C35-14
Steering Column Telescope Feedback
Signal - Circuit short to
ground or open
Steering column TELE
feedback signal circuit -
short to ground, open circuit
Carry out any pinpoint tests associated with this
DTC using the manufacturer approved diagnostic
system. Refer to the electrical circuit diagrams
and check steering column TELE feedback signal
circuit for short to ground, open circuit B1C36-11
Steering Column Tilt/Telescope Switch -
Circuit short to ground
Steering column adjust
switch circuit - short to
ground
Refer to the electrical circuit diagrams and check
steering column adjust switch circuit for short to
ground B1C48-11
Flash to Pass Switch -
Circuit short to ground
Main beam flash switch
circuit - short to ground
Refer to the electrical circuit diagrams and check
main beam flash switch circuit for short to
ground B1C48-15
Flash to Pass Switch -
Circuit short to battery
or open
Main beam flash switch
circuit - short to power,
open circuit
Carry out any pinpoint tests associated with this
DTC using the manufacturer approved diagnostic
system. Refer to the electrical circuit diagrams
and check main beam flash switch circuit for
short to power, open circuit B1C53-11
Front Wiper Intermittent
Data - Circuit short to
ground
Intermittent wipe switch
circuit - short to ground
Refer to the electrical circuit diagrams and check
intermittent wipe switch circuit for short to
ground B1C53-15
Front Wiper Intermittent
Data - Circuit short to
battery or open
Intermittent wipe switch
circuit - short to power,
open circuit
Carry out any pinpoint tests associated with this
DTC using the manufacturer approved diagnostic
system. Refer to the electrical circuit diagrams
and check intermittent wipe switch circuit for
short to power, open circuit B1D36-11 Turn Indicator Switch -
Circuit short to ground
Direction indicator switch
circuit - short to ground
Refer to the electrical circuit diagrams and check
direction indicator switch circuit for short to
ground B1D36-15 Turn Indicator Switch -
Circuit short to battery
or open
Direction indicator switch
circuit - short to power,
open circuit
Carry out any pinpoint tests associated with this
DTC using the manufacturer approved diagnostic
system. Refer to the electrical circuit diagrams
and check direction indicator switch circuit for
short to power, open circuit
Page 223 of 3039
DTC Description Possible Causes Action or short to power short to power B1124-11
Lamp Fade Control -
Circuit short to ground
Interior lamp fade
control circuit - short to
ground
Refer to the electrical circuit diagrams and check
interior lamp fade control circuit for short to ground B1124-12
Lamp Fade Control -
Circuit short to battery
Interior lamp fade
control circuit - short to
power
Refer to the electrical circuit diagrams and check
interior lamp fade control circuit for short to power B113C-12
Hazard Switch
Illumination - Circuit
short to battery
Hazard switch
illumination control
circuit - short to power
Refer to the electrical circuit diagrams and check
hazard switch illumination control circuit for short to
power B113C-14
Hazard Switch
Illumination - Circuit
short to ground or open
Hazard switch
illumination control
circuit - short to ground,
open circuit
Refer to the electrical circuit diagrams and check
hazard switch illumination control circuit for short to
ground, open circuit B113E-12
External Boot/Trunk
Release Switch - Circuit
short to battery
External luggage
compartment lid release
switch digital input
circuit - short to power
Refer to the electrical circuit diagrams and check
external luggage compartment lid release switch
digital input circuit for short to power B113E-23
External Boot/Trunk
Release Switch - Signal
stuck low
External luggage
compartment lid release
switch digital input
circuit - signal stuck low
Carry out any pinpoint test associated with this DTC
using the manufacturer approved diagnostic system.
Refer to the electrical circuit diagrams and check
external luggage compartment lid release switch
digital input circuit for short to ground B11D9-49
Vehicle Battery -
Internal electronic
failure
Vehicle battery
damaged/worn out
Check battery is in fully charged and serviceable
condition using the Midtronics battery tester and
the battery care manual B11DB-49
Battery Monitoring
Module - Internal
electronic failure
Internal electronic
failure
Suspect the battery monitoring module. Check and
install a new module as required, refer to the new
module/component installation note at the top of
the DTC Index B11DB-87
Battery Monitoring
Module - Missing
message
Battery monitoring
module connector
dis-connected/poor
connection
Battery monitoring
module to RJB LIN
circuit - open circuit
Battery monitoring
module to battery
positive monitor circuit -
open circuit
Battery monitoring
module/RJB failure
Carry out any pinpoint test associated with this DTC
using the manufacturer approved diagnostic system.
If additional DTCs B108783, B108786, B108787 are
logged, suspect the RJB. Check and install a new
RJB as required, refer to the new module/component
installation note at the top of the DTC Index. If
additional DTCs B108783, B108786, B108787 are
NOT logged, check for good/clean contact at battery
monitoring module connector, refer to electrical
circuit diagrams and check battery monitoring
module to RJB LIN circuit and battery monitoring
module to battery positive monitor circuit for open
circuit. Clear DTC and repeat automated diagnostic
procedure using manufacturer approved diagnostic
system. If DTC remains suspect the battery
monitoring module, check and install a new battery
monitoring module as required, refer to the new
module/component installation note at the top of
the DTC Index B123A-11 Left Front Turn Indicator
- Circuit short to ground
Left front turn signal
lamp control circuit -
short to ground
Refer to the electrical circuit diagrams and check left
front turn signal lamp control circuit for short to
ground B123A-12 Left Front Turn Indicator
- Circuit short to battery
Left front turn signal
lamp control circuit -
short to power
Refer to the electrical circuit diagrams and check left
front turn signal lamp control circuit for short to
power
Page 224 of 3039
DTC Description Possible Causes Action B123A-13 Left Front Turn Indicator
- Circuit open
Left front turn signal
lamp control circuit -
open circuit
Refer to the electrical circuit diagrams and check left
front turn signal lamp control circuit for open circuit B123A-15 Left Front Turn Indicator
- Circuit short to battery
or open
Left front turn signal
lamp control circuit -
short circuit to power,
open circuit, high
resistance
Refer to electrical circuit diagrams and check left
front turn signal lamp control circuit for short circuit
to power, open circuit, high resistance. Repair wiring
harness as required. Clear DTC and retest B123B-11
Right Front Turn
Indicator - Circuit short
to ground
Right front turn signal
lamp control circuit -
short to ground
Refer to the electrical circuit diagrams and check
right front turn signal lamp control circuit for short
to ground B123B-12
Right Front Turn
Indicator - Circuit short
to battery
Right front turn signal
lamp control circuit -
short to power
Refer to the electrical circuit diagrams and check
right front turn signal lamp control circuit for short
to power B123B-13
Right Front Turn
Indicator - Circuit open
Right front turn signal
lamp control circuit -
open circuit
Refer to the electrical circuit diagrams and check
right front turn signal lamp control circuit for open
circuit B123B-15
Right Front Turn
Indicator - Circuit short
to battery or open
Right front turn signal
lamp control circuit -
short circuit to power,
open circuit, high
resistance
Refer to electrical circuit diagrams and check right
front turn signal lamp control circuit for short circuit
to power, open circuit, high resistance. Repair wiring
harness as required. Clear DTC and retest B1247-11 Left Rear Turn Indicator
- Circuit short to ground
Left rear turn signal
lamp control circuit -
short to ground
Refer to the electrical circuit diagrams and check left
rear turn signal lamp control circuit for short to
ground B1247-12 Left Rear Turn Indicator
- Circuit short to battery
Left rear turn signal
lamp control circuit -
short to power
Refer to the electrical circuit diagrams and check left
rear turn signal lamp control circuit for short to
power B1247-13 Left Rear Turn Indicator
- Circuit open
Left rear turn signal
lamp control circuit -
short to power, open
circuit
Refer to the electrical circuit diagrams and check left
rear turn signal lamp control circuit for open circuit B1247-15 Left Rear Turn Indicator
- Circuit short to battery
or open
Left rear turn signal
lamp control circuit -
short circuit to power,
open circuit, high
resistance
Refer to electrical circuit diagrams and check left
rear turn signal lamp control circuit for short circuit
to power, open circuit, high resistance. Repair wiring
harness as required. Clear DTC and retest B1248-11
Right Rear Turn
Indicator - Circuit short
to ground
Right rear turn signal
lamp control circuit -
short to ground
Refer to the electrical circuit diagrams and check
right rear turn signal lamp control circuit for short to
ground B1248-12
Right Rear Turn
Indicator - Circuit short
to battery
Right rear turn signal
lamp control circuit -
short to power
Refer to the electrical circuit diagrams and check
right rear turn signal lamp control circuit for short to
power B1248-13
Right Rear Turn
Indicator - Circuit open
Right rear turn signal
lamp control circuit -
open circuit
Refer to the electrical circuit diagrams and check
right rear turn signal lamp control circuit for open
circuit B1248-15
Right Rear Turn
Indicator - Circuit short
to battery or open
Right rear turn signal
lamp control circuit -
short circuit to power,
open circuit, high
resistance
Refer to electrical circuit diagrams and check right
rear turn signal lamp control circuit for short circuit
to power, open circuit, high resistance. Repair wiring
harness as required. Clear DTC and retest
Page 256 of 3039
DTC Description Possible Causes Action P0657-1C
Actuator Supply Voltage
A Circuit / Open - Circuit
voltage out of range
Actuator supply (pressure
control valves etc)
voltage plausibility fault
Refer to electrical Circuit diagrams and check
Transmission Control Module connector for signs of
water ingress or damage, check pin 7 for Short to
Power or Ground (should NOT be connected and
harness terminal should have a bung installed). If
no fault identified, suspect the Transmission
Control Module. Check and install a new
Transmission Control Module as required, refer to
the warranty policy and procedures manual if a
module/component is suspect. P0658-11
Actuator Supply Voltage
A Circuit Low - Circuit
Short to Ground
Actuator supply (pressure
control valves etc)
voltage Short to Ground
Suspect the Transmission Control Module. Install a
new Transmission Control Module as required,
refer to the warranty policy and procedures manual
if a module/component is suspect. P0659-12
Actuator Supply Voltage
A Circuit High - Circuit
Short to Battery
Actuator supply (pressure
control valves etc)
voltage Short to Power
Suspect the Transmission Control Module. Install a
new Transmission Control Module as required,
refer to the warranty policy and procedures manual
if a module/component is suspect. P0667-01
PCM / ECM / TCM Internal Temperature Sensor A
Range/Performance -
General Electrical Failure
General electrical failure
Suspect the Transmission Control Module. Install a
new Transmission Control Module as required,
refer to the warranty policy and procedures manual
if a module/component is suspect. P0667-04
PCM / ECM / TCM Internal Temperature Sensor A
Range/Performance -
System Internal Failures
Internal Electronic Failure
Suspect the Transmission Control Module. Install a
new Transmission Control Module as required,
refer to the warranty policy and procedures manual
if a module/component is suspect. P0667-49
PCM / ECM / TCM Internal Temperature Sensor A
Range/Performance -
Internal electronic failure
Internal electronic failure
Suspect the Transmission Control Module. Install a
new Transmission Control Module as required,
refer to the warranty policy and procedures manual
if a module/component is suspect. P0700-02 Transmission Control
System (MIL Request) -
General signal failure
General Signal failure
Clear DTC, Road test and re-test, Read DTCs and
Investigate as required P0700-22 Transmission Control
System (MIL Request) -
Signal amplitude >
maximum
Double fault from
monitoring of internal
power supply and
pressure
regulator/solenoid control
software
If any of the following DTCs are also present;
P074013, P096712, P273912, P273012, P272112,
P096312, P276312, P097112, suspect the
Transmission Control Module, check and install a
new Transmission Control Module as required,
refer to the warranty policy and procedures manual
if a module/component is suspect. P0700-75 Transmission Control
System (MIL Request) -
Emergency Position Not
Reachable
Emergency Position Not
Reachable
Clear DTC, Road test and re-test, Read DTCs and
investigate as required P0710-13 Transmission Fluid Temperature Sensor A
Circuit - Circuit Open
Transmission fluid
temperature sensor
Circuit Open Circuit
Clear DTC and test. If code re-detects suspect the
Transmission Control Module. Install a new
Transmission Control Module as required, refer to
the warranty policy and procedures manual if a
module/component is suspect. P0711-01 Transmission Fluid Temperature Sensor A
Circuit
Range/Performance -
General Electrical Failure
General electrical failure
Clear DTC and test. If code re-detects suspect the
Transmission Control Module. Install a new
Transmission Control Module as required, refer to
the warranty policy and procedures manual if a
module/component is suspect. P0711-22 Transmission Fluid Temperature Sensor A
Circuit
Range/Performance -
Signal amplitude >
maximum
Signal amplitude >
maximum. Excessive
jump in temperature
Clear DTC. Carry out cold start road test, continue
driving vehicle until normal operating temperature
is achieved. Reads DTCs, if DTC returns, suspect
the Transmission Control Module. Install a new
Transmission Control Module as required, refer to
Page 257 of 3039
DTC Description Possible Causes Action the warranty policy and procedures manual if a
module/component is suspect. P0712-11 Transmission Fluid Temperature Sensor A
Circuit Low - Circuit Short
to Ground
Transmission fluid
temperature sensor
Circuit Short to Ground
Clear DTC and test. If code re-detects suspect the
Transmission Control Module. Install a new
Transmission Control Module as required, refer to
the warranty policy and procedures manual if a
module/component is suspect. P0713-01 Transmission Fluid Temperature Sensor A
Circuit High - General
Electrical Failure
General electrical failure
Clear DTC and test. If code re-detects suspect the
Transmission Control Module. Install a new
Transmission Control Module as required, refer to
the warranty policy and procedures manual if a
module/component is suspect. P0713-12 Transmission Fluid Temperature Sensor A
Circuit High - Circuit
Short to Battery
Transmission fluid
temperature sensor
Circuit Short to Power
Clear DTC and test. If code re-detects suspect the
Transmission Control Module. Install a new
Transmission Control Module as required, refer to
the warranty policy and procedures manual if a
module/component is suspect. P0716-14 Turbine/Input Shaft
Speed Sensor A Circuit
Range/Performance -
Circuit Short to Ground or
Open
Turbine/Input Shaft
Speed Sensor Circuit
Short to Ground or Open
Circuit
Clear DTC and test. If code re-detects suspect the
Transmission Control Module. Install a new
Transmission Control Module as required, refer to
the warranty policy and procedures manual if a
module/component is suspect. P0716-21 Turbine/Input Shaft
Speed Sensor A Circuit
Range/Performance -
Signal amplitude <
minimum
Turbine/Input Shaft
Speed Sensor signal too
small
Clear DTC and road test, if DTC returns suspect
the Transmission Control Module. Install a new
Transmission Control Module as required, refer to
the warranty policy and procedures manual if a
module/component is suspect. P0716-22 Turbine/Input Shaft
Speed Sensor A Circuit
Range/Performance -
Signal amplitude >
maximum
Turbine/Input Shaft
Speed Sensor signal
above maximum
Clear DTC and road test, if DTC returns suspect
the Transmission Control Module. Install a new
Transmission Control Module as required, refer to
the warranty policy and procedures manual if a
module/component is suspect. P0717-12 Turbine/Input Shaft
Speed Sensor A Circuit
No Signal - Circuit Short
to Battery
Turbine/input shaft speed
sensor A Circuit Short to
Power
Clear DTC and test. If code re-detects suspect the
Transmission Control Module. Install a new
Transmission Control Module as required, refer to
the warranty policy and procedures manual if a
module/component is suspect. P0720-12
Output Shaft Speed
Sensor Circuit - Circuit
Short to Battery
Transmission output
shaft speed sensor
Circuit Short to Power
Clear DTC and test. If code re-detects suspect the
Transmission Control Module. Install a new
Transmission Control Module as required, refer to
the warranty policy and procedures manual if a
module/component is suspect. P0720-14
Output Shaft Speed
Sensor Circuit - Circuit
Short to Ground or Open
Transmission output
shaft speed sensor
Circuit Short to Ground or
Open Circuit
Clear DTC and test. If code re-detects suspect the
Transmission Control Module. Install a new
Transmission Control Module as required, refer to
the warranty policy and procedures manual if a
module/component is suspect. P0721-22
Output Shaft Speed
Sensor Circuit
Range/Performance -
Signal amplitude >
maximum
Transmission output
shaft speed sensor signal
above maximum
Clear DTC and road test, if DTC returns suspect
the Transmission Control Module. Install a new
Transmission Control Module as required, refer to
the warranty policy and procedures manual if a
module/component is suspect. P0721-27
Output Shaft Speed
Sensor Circuit
Range/Performance -
Signal rate of change
above threshold
Output shaft speed
negative gradient too
high
Clear DTC and road test, if DTC returns suspect
the Transmission Control Module. Install a new
Transmission Control Module as required, refer to
the warranty policy and procedures manual if a
module/component is suspect.
Page 261 of 3039
DTC Description Possible Causes Action P0829-77
6-5 Shift - Commanded
Position Not Reachable
Gear Ratio Monitoring.
Mechanical Failures
Check and correct oil level. Clear DTC. If code
re-detects suspect Transmission (mechanical)
internal fault. Install a new Transmission as
required, refer to the warranty policy and
procedures manual if a module/component is
suspect. P084F-01
Park / Neutral Switch
Input Circuit - General
Electrical Failure
Wrong voltage level
detected on Park/No Park
signal
Check for correct output at Transmission Control
Module park signal pin (check in all positions) 12
volts in Park, 0 volts in all other positions. If fault
identified, suspect the Transmission Control
Module. Install a new Transmission Control Module
as required, refer to the warranty policy and
procedures manual if a module/component is
suspect. If no fault identified, check Park signal
circuit to Transmission Shift Module for short, open
circuit P0850-01
Park / Neutral Switch
Input Circuit - General
Electrical Failure
General electrical failure
Suspect the Transmission Control Module. Install a
new Transmission Control Module as required,
refer to the warranty policy and procedures manual
if a module/component is suspect. P0850-02
Park / Neutral Switch
Input Circuit - General
signal failure
General signal failure
Check Parklock mechanism, If Parklock operation
correct suspect the Transmission Control Module.
Install a new Transmission Control Module as
required, refer to the warranty policy and
procedures manual if a module/component is
suspect. P0850-29
Park / Neutral Switch
Input Circuit - Signal
invalid
Signal Invalid
Check Parklock mechanism, If Parklock operation
correct suspect the Transmission Control Module.
Install a new Transmission Control Module as
required, refer to the warranty policy and
procedures manual if a module/component is
suspect. P0850-1C
Park / Neutral Switch
Input Circuit - Circuit
voltage out of range
Circuit voltage out of
range
Suspect the Transmission Control Module. Install a
new Transmission Control Module as required,
refer to the warranty policy and procedures manual
if a module/component is suspect. P0919-93
Gear Shift Position
Control Error - No
operation
No shifting despite driver
request
Suspect the Transmission Control Module. Install a
new Transmission Control Module as required,
refer to the warranty policy and procedures manual
if a module/component is suspect. P0919-94
Gear Shift Position
Control Error -
Unexpected operation
Shifting without driver
request
Suspect the Transmission Control Module. Install a
new Transmission Control Module as required,
refer to the warranty policy and procedures manual
if a module/component is suspect. P0938-29
Hydraulic Oil Temperature
Sensor
Range/Performance -
Signal invalid
Transmission fluid
temperature compared
with module temperature
fault
Clear DTC. Carry out cold start road test, continue
driving vehicle until normal operating temperature
is achieved. Read DTCs, if DTC returns, suspect
the Transmission Control Module. Install a new
Transmission Control Module as required, refer to
the warranty policy and procedures manual if a
module/component is suspect. P0963-12
Pressure Control Solenoid
A Control Circuit High -
Circuit Short to Battery
Pressure control solenoid
1 Circuit Short to Power
Suspect the Transmission Control Module. Install a
new Transmission Control Module as required,
refer to the warranty policy and procedures manual
if a module/component is suspect. P0964-13
Pressure Control Solenoid
B Control Circuit / Open -
Circuit Open
Pressure Control Solenoid
B Control Circuit Open
Suspect the Transmission Control Module. Install a
new Transmission Control Module as required,
refer to the warranty policy and procedures manual
