Inspect Shocks for Leakage
\b\
\
\
\
\
\
\
Inspect Tire Wear Pattern
\b\
\
\
\
\
\
\
Rotate Tires and Adjust Air Pressure (Including Spare)
\
\
\
\
\
\
\
Replace
\
\
\
\
\
\
\
Engine Oil
\b\
\
\
\
\
\
\
Oil Filter
\b\
\
\
\
\
\
\
Spark Plugs
\b\
\
\
\
\
\
\
Ignition Cables
\b\
\
\
\
\
\
\
Distributor Cap and Rotor
\b\
\
\
\
\
\
\
Air Filter Element
\b\
\
\
\
\
\
\
Fuel Filter
\b\
\
\
\
\
\
\
PCV Valve (
1)
\b\
\
\
\
\
\
\
PCV Filter
\b\
\
\
\
\
\
\
EGR Valve & Tube (1987-92)
\b\
\
\
\
\
\
\
Vacuum Operated Emission Components (1987-92)
\b\
\
\
\
\
\
\
PCV Valve (
1)
\b\
\
\
\
\
\
\
Drive Belt (V-Type) (
2)
\b\
\
\
\
\
\
\
Flush and Fill Engine Coolant, if not done in last 24 months
\b\
\
\
\
\
\
\
Automatic Transmission Fluid, Filter and Adjust Bands
\
\
\
\
\
\
\
(
1) - Replacement is recommended by Chrysler at this time, but it
is not required to maintain the warranty on the PCV valve.
(
2) - Check and replace as needed.
\
\
\
\
\
\
\
Lubrication Specifications
\
\
\
\
\
\
\
Application Specification
Automatic Transmission .......................... Dexron-IIE ATF
Brake Master Cylinder .......... DOT 3 (SAE J-1703F) Brake Fluid
Engine Coolant ........... Alugard 340-2 & Water (50/50 Mixture)
Engine Oil (
1)
Gasoline Engine
Temperature Range
Above 30
F (-1
C) ........ SAE 20W-40 Or 20W-50 API SH/CD
Above 0
F (-18
C) ......... SAE 10W-30 Or 10W-40 API SH/CD
Less Than 60
F (16
C) ............... SAE 5W-30 API SH/CD
Drive Axles ................................ SAE 75W-90 API GL-5
Drive Axles (Trac-Lok) (
2) ................ SAE 80W-140 API GL-5
Drive Axles (Trailer Towing) .............. SAE 80W-140 API GL-5
Hydraulic Clutch ............... DOT 3 (SAE J-1703F) Brake Fluid
Manual Transmission ........................ SAE 75W-90 API GL-5
Parking Brake Cable Guides ................. NLGI Grade 2, GC-LB
Page 1002 of 1378
Door & Hood Hinges ............................ Light Engine Oil
Manual Steering Box ............... Multi-Purpose NLGI Grade 2EP
Power Steering Pump ....................... Power Steering Fluid
Transfer Case ................................... Dexron-IIE ATF
Brake Caliper Bushings ........ GE 661 or DOW 111 Silicone Grease
Caliper Slide Pins ........... GE 661 or DOW 111 Silicone Grease
Wheel Bearings .................. Multi-Purpose NLGI Grade GC-LB
Drive Shaft U-Joints .............. Multi-Purpose NLGI Grade 2EP
Steering Linkage (
4)( 5) .................... NLGI Grade 2, GC-LB
Ball Joints (
4)( 6) ......................... NLGI Grade 2, GC-LB
Weatherstrip .......................... Silicone Spray Lubricant
Wheel Lug Nut Torque ...................... 95 ft. lbs. (129 N.m)
(
1) - SAE 10W-30 SH/CD is preferred.
(
2) - Add 4 ozs. (118 ml) of Limited-Slip differential lubricant
additive when changing fluid.
(
3) - For vehicles operating under heavy-duty towing conditions,
use SAE 75W-140 Synthetic lube.
NOTE: Before using SAE 75W-140 Synthetic the old fluid must
be DRAINED and FLUSHED with clean mineral based axle
lubricant. Then refill with new synthetic lube.
(
4) - Use low pressure grease gun to prevent seal damage.
(
5) - Fill until lubricant squeezes out from the base of seals.
(
6) - Fill ball joint until seal starts to swell.
\
\
\
\
\
\
\
Fluid Capacities
\
\
\
\
\
\
\
Application ( 1) Quantity
Automatic Transmission
1984-86 (904 HD)
Fluid Change ............................... 4.0 Qts. (3.8L)
Overhaul (Dry Fill) ........................ 8.0 Qts. (7.6L) \
1987-88
Fluid Change ............................... 4.0 Qts. (3.8L)
Overhaul (Dry Fill) ........................ 8.5 Qts. (8.0L) \
Cooling System (
2)
4-Cylinder .................................. 10.0 Qts. (9.5L)
6-Cylinder ................................. 12.0 Qts. (11.4L)
Engine Oil
4-Cylinder ................................... 4.0 Qts. (3.8L)
6-Cylinder ................................... 6.0 Qts. (5.7L)
Fuel Tank
Standard .................................. 13.5 Gals. (51.1L)
Optional .................................... 20 Gals. (75.7L)
Manual Transmission (
3)
AX4 (AISIN) .................................. 7.4 Pts. (3.5L) \
T4 (Borg-Warner) ............................. 3.9 Pts. (1.8L) \
AX5 (AISIN) .................................. 7.0 Pts. (3.3L) \
T5 (Borg-Warner) ............................. 4.5 Pts. (2.1L) \
Transfer Case
1985-86
Selec-Trac (229 Full-Time) ................. 6.0 Pts. (2.8L) \
Command-Trac (Part-Time 207) ............... 4.5 Pts. (2.1L) \
1987
Selec-Trac ................................. 2.5 Pts. (1.2L)
Command-Trac ............................... 2.2 Pts. (1.0L)
1988
Selec-Trac ................................. 3.0 Pts. (1.4L)
Command-Trac ............................... 2.2 Pts. (1.0L)
Drive Axles (
3)
Front ........................................ 2.5 Pts. (1.2L)
Front (Disconnect Housing) .................. 5.0 Ozs. (0.15L) \
Page 1003 of 1378
Rear ......................................... 2.5 Pts. (1.2L)
Rear (Trac-Lok) (
4) .......................... 2.5 Pts. (1.2L)
(
1) - Capacities are recommended or calculated levels. Always use
dipstick (if available) to measure level.
(
2) - Includes 2.3 qts. for coolant recovery bottle.
(
3) - Fill to bottom of filler plug hole.
(
4) - Add 4 ozs. (118 ml) of Limited-Slip differential lubricant
additive first, then add new fluid.
\
\
\
\
\
\
\
Service Labor Times
\
\
\
\
\
\
\
Application Hours
2.5L
Automatic Transmission ................................... 3.5
Manual Transmission ...................................... 3.5
2.8L
Automatic Transmission ................................... 3.7
Manual Transmission ...................................... 3.7
4.0L
Automatic Transmission ................................... 3.6
Manual Transmission ...................................... 3.6
\
\
\
\
\
\
\
\f
LUBRICATION SPECIFICATIONS
LUBRICATION SPECIFICATIONS TABLE\
\
\
\
\
\
\
Application Fluid Specifications
Automatic Transmission ......................... Dexron-IIE ATF
Brake Master Cylinder ......... DOT 3 (SAE J-1703F) Brake Fluid
Engine Coolant .......... Alugard 340-2 & Water (50/50 Mixture)
Engine Oil ( 1)
Gasoline Engine
Temperature Range
Above 30
F (-1
C) ....... SAE 20W-40 Or 20W-50 API SH/CD
Above 0
F (-18
C) ........ SAE 10W-30 Or 10W-40 API SH/CD
Less Than 60
F (16
C) .............. SAE 5W-30 API SH/CD
Drive Axles ............................... SAE 75W-90 API GL-5
Drive Axles (Trac-Lok) ( 2) ............... SAE 80W-140 API GL-5
Drive Axles (Trailer Towing) ............. SAE 80W-140 API GL-5
Hydraulic Clutch .............. DOT 3 (SAE J-1703F) Brake Fluid
Manual Transmission ....................... SAE 75W-90 API GL-5
Manual Steering Box .............. Multi-Purpose NLGI Grade 2EP
Power Steering Pump ...................... Power Steering Fluid
Transfer Case .................................. Dexron-IIE ATF
Brake Caliper Bushings ....... GE 661 or DOW 111 Silicone Grease
Caliper Slide Pins .......... GE 661 or DOW 111 Silicone Grease
Wheel Bearings ........... Mopar Multi-Purpose NLGI Grade GC-LB
Drive Shaft U-Joints ....... Mopar Multi-Purpose NLGI Grade 2EP
Steering Linkage ( 4)( 5) ...... Mopar Multi-mileage or equivalent
Ball Joints ( 4)( 6) ........... Mopar Multi-mileage or equivalent
Weatherstrip ......................... Silicone Spray Lubricant
( 1) - SAE 10W-30 SH/CD is preferred.
( 2) - Add 4 ozs. (118 ml) of Limited-Slip differential lubricant
additive when changing fluid.
( 3) - For vehicles operating under heavy-duty towing conditions,
use SAE 75W-140 Synthetic lube.
NOTE: Before using SAE 75W-140 Synthetic the old fluid must be
Page 1004 of 1378
DRAINED and FLUSHED with clean mineral based (non-synthetic)
axle lubricant. Then refill with new synthetic lube.
(4) - Use low pressure grease gun to prevent seal damage.
( 5) - Fill until lubricant squeezes out from the base of seals.
( 6) - Fill ball joint until seal starts to swell.
\
\
\
\
\
\
\
FLUID CAPACITIES
FLUID CAPACITIES TABLE\
\
\
\
\
\
\
Application Quantity ( 1)
A/C System R-12 Refrigerant Capacity ............... 36-40 Ozs.
Automatic Transmission
1984-86 (904 HD)
Fluid Change .............................. 4.0 Qts. (3.8L)
Overhaul (Dry Fill) ....................... 8.0 Qts. (7.6L)
1987-88
Fluid Change .............................. 4.0 Qts. (3.8L)
Overhaul (Dry Fill) ....................... 8.5 Qts. (8.0L)
Cooling System ( 2)
4-Cylinder ................................. 10.0 Qts. (9.5L)
6-Cylinder ................................ 12.0 Qts. (11.4L)
Engine Oil
4-Cylinder .................................. 4.0 Qts. (3.8L)
6-Cylinder .................................. 6.0 Qts. (5.7L)
Fuel Tank
Standard ................................. 13.5 Gals. (51.1L)
Optional ................................... 20 Gals. (75.7L)
Manual Transmission ( 3)
AX4 (AISIN) ................................. 7.4 Pts. (3.5L)
T4 (Borg-Warner) ............................ 3.9 Pts. (1.8L)
AX5 (AISIN) ................................. 7.0 Pts. (3.3L)
T5 (Borg-Warner) ............................ 4.5 Pts. (2.1L)
Transfer Case
1985-86
Selec-Trac (229 Full-Time) ................ 6.0 Pts. (2.8L)
Command-Trac (Part-Time 207) .............. 4.5 Pts. (2.1L)
1987
Selec-Trac ................................ 2.5 Pts. (1.2L)
Command-Trac .............................. 2.2 Pts. (1.0L)
1988
Selec-Trac ................................ 3.0 Pts. (1.4L)
Command-Trac .............................. 2.2 Pts. (1.0L)
Drive Axles ( 3)
Front ....................................... 2.5 Pts. (1.2L)
Front (Disconnect Housing) ................. 5.0 Ozs. (0.15L)
Rear ........................................ 2.5 Pts. (1.2L)
Rear (Trac-Lok) ( 4) ......................... 2.5 Pts. (1.2L)
( 1) - Capacities are recommended or calculated levels. Always use
dipstick (if available) to measure level.
( 2) - Includes 2.3 qts. for coolant recovery bottle.
( 3) - Fill to bottom of filler plug hole.
( 4) - Add 4 ozs. (118 ml) of Limited-Slip differential lubricant
additive first, then add new fluid.
\
\
\
\
\
\
\
Page 1005 of 1378
\003
SEA TS - P O W ER
1988 J e ep C hero ke e
1988 Power Seats
JEEP
Cherokee, Wagoneer,
Grand Wagoneer
DESCRIPTION
A 3 armature permanent magnet reversible motor is coupled
through cables to rack and pinion assemblies, located in the tracks.
This system provides 6 different movement directions. Circuit is
protected by a 30-amp circuit breaker on the fuse block.
TESTING
PRELIMINARY CHECKS
Ensure battery is fully charged and all electrical
connections are clean and tight. Turn on dome light. Apply switch to
the inoperative position. If dome light dims, seat motion is
attempting to function, indicating mechanical failure. Check and
repair as necessary. If dome light does not dim, proceed with the
following tests.
HARNESS VOLTAGE
Disconnect switch harness connector, located under seat.
Connect ground lead of test light to terminal No. 2. Touch other lead
of test light to terminal No. 1. See Fig. 1. If test light comes on,
circuit is good. If test light does not come on, check circuit breaker
and harness. If harness and circuit breaker checks good, perform drive
motors check.
Fig. 1: Seat Switch Terminal Identification
Courtesy of Chrysler Motors.
DRIVE MOTORS
Page 1006 of 1378
Rear Motor
Disconnect switch harness connector. Connect a covered jumper
wire between terminal No. 1 and 5. See Fig. 1. Connect a second
covered jumper wire between terminal No. 2 and 6. If motor does not
operate, reverse jumper wire at terminal No. 5 and 6. If motor still
does not operate, either harness or complete 3 motor assembly is
defective.
Center Motor
Disconnect switch harness connector. Connect a covered jumper
wire between terminal No. 1 and 3. See Fig. 1. Connect a second
covered jumper wire between terminal No. 2 and 4. If motor does not
operate, reverse jumper wire at terminal No. 3 and 4. If motor still
does not operate, either harness or complete 3 motor assembly is
defective.
Front Motor
Disconnect switch harness connector. Connect a covered jumper
wire between terminal No. 1 and 7. See Fig. 1. Connect a second
covered jumper wire between terminal No. 2 and 8. If motor does not
operate, reverse jumper wire at terminal No. 7 and 8. If motor still
does not operate, either harness or complete 3 motor assembly is
defective.
NOTE: No further testing information is available from
manufacturer.
REMOVAL & INSTALLATION
MOTOR
CAUTION: Use care to avoid bending drive cables during removal.
NOTE: Whenever maintenance of motor, cable and housing assemblies
or transmissions is necessary, they must be synchronized to
ensure easy and proper operation. Refer to manufacturer for
proper procedure.
Removal & Installation
Remove seat assembly. Lay seat assembly on its back. Remove
motor mounting screws. Disconnect housings and cables from motor
assembly and remove motor. To install, reverse removal procedure.
Page 1007 of 1378
SER VIC E IN DIC ATO R & W AR NIN G L IG HTS
1988 J e ep C hero ke e
1984-92 MAINTENANCE
AMC/Jeep/Eagle Service Indicator & Warning Lights
Jeep; Cherokee, Wagoneer
SERVICE INDICATOR & WARNING LIGHTS
BRAKE WARNING LIGHT
If the light stays on when the parking brake is off, it
indicates a possible brake system fluid leak or low pressure level.
LOCK INDICATOR LIGHT (1984-87)
Indicates that Selec-Trac transfer case is in part time 4WD
(high or low range).
FULL TIME 4WD INDICATOR LIGHT
Indicates that Selec-Trac transfer case is in full-time 4WD
(4x4 FULL TIME).
PART TIME 4WD INDICATOR LIGHT
Indicates that Selec-Trac transfer case is in part time 4WD
(4x4 PART TIME or 4 LO) or that Command-Trac transfer case is in 4WD
(4H or 4L).
WATER IN FUEL LIGHT (TURBO DIESEL)
Indicates water has collected in the fuel filter and should
be drained immediately.
DIESEL WAIT LIGHT (TURBO DIESEL)
Illuminates during glow plugs warm-up cycle.
LOW FUEL WARNING LIGHT
Glows when approximately 2 gals. (7.6L) remain in fuel tank.
EMISSION MAINTENANCE INDICATOR LIGHT
Illuminates at approximately 82,500 miles to indicate
scheduled maintenance (or recommended maintenance on California
vehicles). Light will remain on until system is serviced and light is
reset.
CHECK ENGINE LIGHT
If this light illuminates and remains on while driving, it
indicates a potential engine control problem that needs service.
CHECK ANTI-LOCK LIGHT
Illuminates to indicate a self-check is in process at vehicle
start up. If light remains on after start-up or comes on and stays on
Page 1008 of 1378
at road speeds, it may indicate that the ABS system has detected a
malfunction or has become inoperative. The system reverts to standard
non-anit-lock brakes. If both Red BRAKE light and Amber CHECK ANTI-
LOCK light are on, have vehicle serviced immediately.
Fig. 1: Instrument Panel Interior Controls
Courtesy of Chrysler Motors.
Fig. 2: Dash Gauges & Warning Lights (Gasoline Engines)
Courtesy of Chrysler Motors.
Page 1009 of 1378
Fig. 3: Dash Gauges & Warning Lights (Turbo-Diesel Engines)
Courtesy of Chrysler Motors.
Page 1010 of 1378
\003
97I0 02000: S H IF T IN TE R LO CK
1988 J e ep C hero ke e
NHTSA RECALL BULLETIN
Model(s): 1984-95 Jeep Cherokee
1993-95 Jeep Grand Cherokee
Campaign No: 97I002000
Number of Affected Vehicles: 2200000
Beginning Date of Manufacture: 1983 AUG
Ending Date of Manufacture: 1995 JUL
VEHICLE DESCRIPTION:
Multipurpose passenger vehicles equipped with automatic transmissions.
DESCRIPTION OF DEFECT:
This is not a safety recall in accordance with Federal Regulation 573.
However, it is deemed a safety improvement campaign by the agency.
Drivers can mistakenly step on the accelerator pedal when they intend
to step on the brake pedal.
CONSEQUENCE OF DEFECT:
Pedal misapplication by a driver can cause unintended acceleration.
CORRECTIVE ACTION
Dealers will install a shift interlock on the automatic transmission
of these vehicles.
Chrysler has decided to conduct a safety improvement campaign to
install a shift interlock on these vehicles. Owners can contact
Chrysler at 1-800-853-1403.
ADDITIONAL INFORMATION:
The National Highway Traffic Safety Administration operates Monday
through Friday from 8:00 AM to 4:00 PM, Eastern Time. For more
information call (800) 424-9393 or (202) 366-0123. For the hearing
impaired, call (800) 424-9153.
