Fig. 4: Drive Shaft Phase Alignment
Align drive shaft and slip joint trunnions in same plane.
FLANGE ALIGNMENT & RUNOUT
1) All flanges must be perpendicular in both vertical and
horizontal planes to engine crankshaft. Only exception is "broken
back" type driveline, which has flanges that are not perpendicular in
vertical plane. See Fig. 5.
Fig. 5: Typical "Broken Back" Type Drive Shaft Alignment
Angle "A" equals angle "B".
2) With nonparallel or "broken back" type installation,
working angles of universal joints of given drive shaft are equal.
Angle "A" = angle "B".
3) This is calculated as follows: angle of output shaft
centerline is subtracted from angle of drive shaft. Difference should
equal angle of drive shaft subtracted from pinion shaft angle.
4) Parallel type joints maintain constant velocity between
output shaft and pinion shaft. Vibration is minimized and component
life maximized when universal joints are parallel.
Page 432 of 1378
Fig. 6: Aligning One-Piece Drive Shaft
Yokes must be parallel.
5) Using dial indicator, measure runout of transmission
flange, center bearing flange and pinion flange. If runout exceeds .
003-.005" (.08-.13 mm), replace flange.
6) If dial indicator cannot be used, push rod with snug fit
through flange bearing bore. See if it aligns with opposite flange
bore. If not, replace flange.
7) Rotate transmission flange until it is vertical, measuring
from side. Check center bearing and pinion flanges. They cannot be
more than one degree off vertical. See DRIVE SHAFT PHASING in this
article.
Fig. 7: Vertical Alignment of Drive Shaft
Flanges in pairs should be parallel.
8) Rotate transmission flange until it is vertical, measured
from side. Measure angle from end and record it. Check all other
flanges for same angle. They must be within 1/2 degree of each other.
Adjust as required.
Page 433 of 1378
9) If difficulty is encountered when making these
adjustments, horizontal alignment should be checked. Even though
vertical alignment is correct, horizontal alignment can be badly out
of adjustment. This is often found after major component replacement
or repair of serious accident damage. See Fig. 8.
Fig. 8: Horizontal Alignment of Drive Shaft
Plane of trunnions should be parallel.
10) To make horizontal alignment checks, set straightedges
up. See Fig. 9. Set transmission output flange horizontal and clamp
straightedge to flange in a horizontal plane. Repeat procedure with
drive pinion flange. Ensure that flanges are horizontal by checking
angle of straightedge with spirit level.
Fig. 9: Checking Horizontal Alignment
Measure at 6 points shown using straightedges and framing squares.
11) Using straightedge that is 12" longer than width of rear
wheel track at 90 degrees, clamp to frame side rails. Use large
Page 434 of 1378
framing squares to align straightedge with side rails.
12) Measure distance "X" at each side. If both measurements
are not within 1/16" (1.6 mm) of each other, transmission flange is
horizontally misaligned.
13) Measure distance "Y" (edge of straightedge to axle shaft
centerline) at each side. If 2 dimensions are not within 1/8" (3.2 mm)\
of each other, axle housing is misaligned.
14) Measure distance "W" at each side. If both measurements
are not within 1/16" (1.6 mm) of each other, pinion flange is
horizontally misaligned.
