Page 481 of 1378

JEEP CHEROKEE 1988  Service Repair Manual valve.
         FORWARD DELAY VALVE
         Forward delay valve is located between EGR CTO switch and EGR
valve. It modifies initial vacuum signal applied to EGR valve by
delaying full vacuum force.

Page 482 of 1378

JEEP CHEROKEE 1988  Service Repair Manual          1) With the air cleaner temperature below 40�F (-4�C),
disconnect vacuum hoses from TVS and connect vacuum source to large
outlet.
         2) Apply vacuum to TVS. TVS should hold vacuum. If

Page 483 of 1378

JEEP CHEROKEE 1988  Service Repair Manual ELE C TR IC AL C O M PO NEN T L O CATO R

1988 J e ep C hero ke e
          1988 ELECTRICAL COMPONENT LOCATOR
          Jeep Electrical Component Locations
          Cherokee, Comanche & Wagoneer
CO

Page 484 of 1378

JEEP CHEROKEE 1988  Service Repair Manual A/C-Heater Blower Relays                Under right side of dash, on
                                        evaporator housing.
Automatic Load Leveling Relay           On load level compressor

Page 485 of 1378

JEEP CHEROKEE 1988  Service Repair Manual B+ Latch Relay                          On center of right front
                                        wheelwell.
Choke Relay                             On right front wheelwell.
Door Lock/Unlock R

Page 486 of 1378

JEEP CHEROKEE 1988  Service Repair Manual Fuel Pump Relay                         On right front wheelwell.
Horn Relay                              Taped to wiring harness, above
                                        fuse block.
Load Swap R

Page 487 of 1378

JEEP CHEROKEE 1988  Service Repair Manual Rear Window Defogger Relay              Under instrument panel, to
                                        right of steering column.
Rear Wiper Relay                        In tailgate, next to wiper

Page 488 of 1378

JEEP CHEROKEE 1988  Service Repair Manual Starter Relay (Graphic 2)               Behind right headlight, on
                                        wheelwell.
Timer Delay Relay                       Above starter relay, behind

Page 489 of 1378

JEEP CHEROKEE 1988  Service Repair Manual   Left Turn Signal Relay                Above left rear wheelwell.
  Right Turn Signal Relay                Above left rear wheelwell.���������\
���������\
���������\
���

Page 490 of 1378

JEEP CHEROKEE 1988  Service Repair Manual Fusible Links (Graphic 1)               At starter relay.
