EN G IN E R EM OVA L - 6 -C YL
1988 J e ep C hero ke e
1988 ENGINES
Jeep - Engine Removal - 6-Cylinder
Cherokee, Comanche, Wagoneer, Wrangler
6-CYLINDER ENGINES
4.0L
1) Scribe hinge locations, remove engine compartment light
(if equipped) and remove hood. Disconnect battery cables and remove
battery. Drain cooling system.
2) Disconnect wire connectors from alternator, ignition coil
and distributor. Disconnect oil pressure sender wire, starter wires
and fuel injector wiring harness (if equipped). Detach 2 fuel pipe
quick connect couplings at left inner fender panel. Disconnect engine
ground strap and remove air cleaner.
3) Disconnect the vacuum purge hose at fuel vapor canister
tee. Disconnect wire from idle speed actuator and oxygen sensor.
Detach throttle cable from bracket and disconnect throttle valve rod
at bellcrank. Remove upper and lower radiator hoses.
4) On automatic transmission models, disconnect the
transmission fluid cooler tubing. On all models, remove fan shroud and
radiator. Remove fan and spacer or Tempatrol fan assembly. Hold fan
pulley to water pump flange using 5/16" x 1/2" SAE capscrew while
crankshaft is rotated.
5) Disconnect cruise control cable (if equipped). Disconnect\
wires from starter motor solenoid and disconnect CEC system harness.
Remove power brake vacuum check valve from booster (if equipped).
6) Disconnect power steering hoses from steering gear (if
equipped). Drain power steering pump reservoir and plug end of hoses.
Cap all fittings on steering gear and hoses. Raise and support
vehicle. Remove starter. Remove flywheel housing access cover.
7) Remove upper and loosen lower bellhousing-to-engine bolts.
Attach lifting equipment to engine. Raise engine off front mounts.
Place support under bellhousing. Remove remaining bellhousing-to-
engine bolts. Lift engine out of engine compartment.
4.2L
1) Remove battery and drain cooling system. Remove air
cleaner and engine compartment light from hood. Scribe hinge location
and remove hood. Disconnect and plug front fuel line at pump and fuel
return line at frame.
2) Disconnect heater hoses at heater. Label and disconnect
all wiring, lines, linkage and hoses at engine. Remove vacuum switch
assembly bracket from cylinder head cover. Remove both radiator hoses
and automatic transmission oil lines (if equipped) at radiator. Remove\
radiator and shroud.
3) Remove fan and spacer. Use 5/16" x 1/2" SAE bolt to hold
fan pulley to water pump flange. Remove starter and disconnect engine
ground strap. Remove engine mount-to-bracket nuts. Disconnect exhaust
pipe at manifold.
4) Discharge A/C system (if equipped). Disconnect and plug
hose or port openings at compressor. Disconnect hoses at power
steering gear and drain reservoir. Remove power brake vacuum check
valve. Remove bracket bolt for automatic transmission filler tube (if
equipped).
5) Lift and support vehicle. On models with automatic
Page 652 of 1378
transmission, remove converter housing cover. Index mark converter and
driven plate for reassembly. Remove driven plate-to-converter bolts,
rotating crankshaft to access each bolt. Remove oil pan bolts holding
automatic transmission oil lines. On Wrangler models, remove exhaust
pipe support brace at converter housing.
6) On manual transmission models, remove flywheel housing
cover. Remove inner support bolts for clutch release arm. Disconnect
springs and remove clutch release arm. Remove outer bracket retainer
for release lever rod. On all models, remove upper and loosen lower
bellhousing bolts.
7) Lower vehicle. Support transmission. If A/C equipped,
remove idler pulley and mounting bracket. Attach lifting equipment to
engine. Raise engine off front mounts and support transmission. Remove
lower bellhousing bolts. Lift engine from compartment while pulling
forward.
TORQUE SPECIFICATIONS
TORQUE SPECIFICATIONS TABLE \
\
\
\
\
\
Application Ft. Lbs. (N.m)
Automatic Transmission-to-Block .................. 28 (38)
Clutch Housing-to-Block
Top ............................................ 27 (37)
Bottom ......................................... 43 (58)
Drive Plate-to-Converter ......................... 22 (30)
Drive Plate/Flywheel-to-Crankshaft ............. 105 (143)
Front Support Bracket-to-Block ................... 35 (47)
Front Support Cushion-to-Bracket ................. 33 (45)
Front Support Cushion-to-Crossmember ............. 37 (50)
Rear Support Bracket-to-Transmission ............. 33 (45)
Rear Support Cushion-to-Bracket .................. 30 (41)
Starter Motor-to-Converter Housing ............... 18 (24)
\
\
\
\
\
\
Page 653 of 1378
\003
* E N G IN E S YSTE M S U NIF O RM IN SPEC TIO N G UID ELIN ES *
1 988 J e ep C hero ke e
GENERAL INFORMATION
Engine Performance and Maintenance Motorist Assurance Program
Standards For Automotive Repair
All Makes and Models
INTRODUCTION TO MOTORIST ASSURANCE PROGRAM (MAP)
CONTENTS
Motorist Assurance Program (MAP)
OVERVIEW OF MOTORIST ASSURANCE PROGRAM
OVERVIEW OF SERVICE REQUIREMENTS AND SUGGESTIONS
Engine Assemblies
CYLINDER HEAD ASSEMBLIES
LONG BLOCK ASSEMBLIES
SHORT BLOCK ASSEMBLIES
Engine Components
ACCELERATOR PEDAL POSITION SENSORS
ACCESSORY BELTS
ACCESSORY PULLEYS
ACTUATORS
AIR CONDITIONING CYCLING SWITCHES
AIR CONDITIONING PRESSURE SENSORS
AIR DUCTS AND TUBES
AIR FILTER ELEMENTS
AIR FILTER GASKETS
AIR FILTER HOUSINGS AND GASKETS
AIR FUEL RATIO SENSORS
AIR INJECTION CONTROL SOLENOIDS
AIR PLENUMS
AIR PUMP BELTS
AIR PUMPS (ELECTRIC-DRIVEN)
AIR TUBES
ASPIRATOR, CHECK AND DECEL VALVES
BAFFLES
BALLAST PRIMARY SUPPLY RESISTOR WIRES
BALLAST RESISTORS AND PRIMARY SUPPLY RESISTOR WIRES
BAROMETRIC PRESSURE SENSORS
BATTERIES
BATTERY CABLES, WIRES AND CONNECTORS
BATTERY CONNECTORS
BATTERY TRAYS AND HOLD DOWN HARDWARE
BATTERY WIRES
BELT-DRIVEN AIR PUMPS
BELT IDLER ASSEMBLIES (ACCESSORY AND CAM BELTS)
BELT TENSIONERS (ACCESSORY AND CAM BELTS)
BOOST CONTROL MECHANISMS
CAMSHAFT POSITION SENSORS
CARBURETORS AND CHOKES
CASTING CORE PLUGS AND EXPANSION PLUGS
CHARGE AIR COOLERS "INTERCOOLERS" (CAC)
CHECK VALVES
CHOKES
Page 654 of 1378
CLUTCH PEDAL POSITION SWITCHES
COLD START INJECTORS
CONNECTORS
COOLANT
COOLANT RECOVERY TANKS
COOLING FAN MOTOR MODULES
COOLING FAN MOTOR RELAYS AND MODULES
COOLING FAN MOTOR RESISTORS
COOLING FAN MOTOR SENSORS AND SWITCHES
COOLING FAN MOTOR SWITCHES
COOLING FAN MOTORS
CRANKSHAFT POSITION SENSORS
DECEL VALVES
DEFLECTORS
DIP STICKS AND TUBES
DIP STICK TUBES
DISTRIBUTOR ADVANCES AND RETARDERS (MECHANICAL AND VACUUM)
DISTRIBUTOR BOOTS AND SHIELDS
DISTRIBUTOR CAPS
DISTRIBUTOR RETARDERS (MECHANICAL AND VACUUM)
DISTRIBUTOR ROTORS
DISTRIBUTOR SHIELDS
DISTRIBUTORS
EARLY FUEL EVAPORATION VALVES (HEAT RISER ASSEMBLIES)
EGR COOLERS
EGR EXHAUST MANIFOLD PASSAGES
EGR INTAKE AND EXHAUST MANIFOLD PASSAGES
EGR PLATES AND COOLERS
ELECTRONIC SPARK CONTROL MODULES
ELECTRONIC TRANSMISSION CONTROL DEVICES
ELECTRONIC TRANSMISSION FEEDBACK DEVICES
ENGINE COOLANT TEMPERATURE SENSORS
ENGINE COOLING SYSTEMS
ENGINE COVERS (OIL PAN, VALVE COVER, TIMING COVER)
ENGINE OIL
ENGINE OIL CANISTERS
ENGINE OIL COOLERS (EXTERNAL)
ENGINE OIL DRAIN PLUGS AND GASKETS
ENGINE OIL FILTERS AND CANISTERS
ENGINE OIL GASKETS
ENGINE OIL PRESSURE GAUGES (MECHANICAL)
EVAPORATIVE EMISSION (EVAP) CANISTER FILTERS
EVAPORATIVE EMISSION (EVAP) CANISTER PURGE DEVICES
EVAPORATIVE EMISSION (EVAP) CANISTERS
EVAPORATIVE EMISSION (EVAP) FEEDBACK DEVICES
EXHAUST GAS RECIRCULATION DEVICES
EXHAUST GAS RECIRCULATION FEEDBACK DEVICES
EXPANSION PLUGS
FAN CONTROL SENSORS
FUEL
FUEL ACCUMULATORS AND DAMPERS
FUEL AND COLD START INJECTORS
FUEL DAMPERS
FUEL DELIVERY CHECK VALVES
FUEL DISTRIBUTORS (BOSCH CIS)
FUEL FILLER NECKS AND RESTRICTORS
FUEL FILTERS
FUEL INJECTORS
FUEL LEVEL SENDERS7
FUEL PRESSURE REGULATORS
FUEL PUMPS (IN-TANK AND EXTERNAL, ELECTRICAL OR MECHANICAL)
FUEL RAILS
FUEL RESTRICTORS
Page 655 of 1378
FUEL TANKS
GAS CAPS
GASKETS
GROMMETS (VALVE COVER)
HARMONIC DAMPERS
HEATER CONTROL VALVES
HEATER CORES
HOSE AND TUBE COUPLERS, CONNECTORS AND CLAMPS
HOSE CLAMPS
HOSE CONNECTORS
HOSE COUPLERS
HOSES AND TUBES (FUEL LINES, RADIATOR, VACUUM, BY PASS,
HEATER, RECOVERY TANK AND OIL COOLERS)
HOUSINGS
IDLE AIR CONTROLS
IDLE SPEED CONTROL ACTUATORS
IGNITION BOOTS
IGNITION COIL TOWERS
IGNITION COILS
IGNITION CONTROL MODULES (ICM)
IGNITION SWITCHES
IGNITION TERMINALS
IGNITION WIRES, BOOTS, COIL TOWERS AND TERMINALS (SECONDARY)
IN-TANK FUEL STRAINERS
INERTIA FUEL SHUT-OFF SWITCHES
INTAKE AIR TEMPERATURE SENSORS
INTAKE MANIFOLDS
INTERCOOLERS
KNOCK SENSORS
LIQUID VAPOR SEPARATORS
MANIFOLD ABSOLUTE PRESSURE (MAP) SENSORS
MASS AIR FLOW (MAF) SENSORS
METAL AIR MANIFOLDS AND PIPES
METAL AIR PIPES
MIX CONTROL SOLENOIDS
MOTOR MOUNTS
O-RINGS, GASKETS, SEALS AND SPRING LOCKS
O2 SENSORS
OIL PRESSURE SENDING UNITS
OIL PUMP PICK-UP SCREENS
OIL PUMPS
PARK NEUTRAL POSITION SWITCHES
PCV BREATHER ELEMENTS
PCV ORIFICES
PCV VALVES
PICK-UP ASSEMBLIES (INCLUDES MAGNETIC, HALL EFFECT AND
OPTICAL)
POWER STEERING PRESSURE SENSORS
POWERTRAIN CONTROL MODULES (PCM) AND PROM
POWERTRAIN CONTROL PROM
PRESSURIZED EXPANSION TANK CAPS
RADIATOR CAPS AND PRESSURIZED EXPANSION TANK CAPS
RADIATOR FAN BLADES
RADIATOR FAN CLUTCHES
RADIATORS
ROLL OVER VALVES
SEALING COMPOUNDS
SEALS
SECONDARY AIR INJECTION SYSTEM MANAGEMENT DEVICES
SENSORS AND ACTUATORS
SHROUDS, BAFFLES AND DEFLECTORS
SPARK PLUGS
SPRING LOCKS
Page 656 of 1378
SUPER CHARGERS
SWITCHES
THERMAL VACUUM VALVES
THERMOSTATIC AIR DOOR ASSEMBLIES
THERMOSTATS AND HOUSINGS
THROTTLE BODIES
THROTTLE CABLES
THROTTLE LINKAGES AND CABLES
THROTTLE POSITION SENSORS
THROTTLE POSITION SWITCHES
TIMING BELT SPROCKETS
TIMING BELTS
TORQUE STRUTS
TRANSMISSION RANGE SWITCHES
TUBE CLAMPS
TUBE CONNECTORS
TUBE COUPLERS
TUBES
TURBO CHARGERS
VACUUM CONNECTIONS
VACUUM HOSES, TUBES AND CONNECTIONS (NON-METALLIC)
VACUUM REGULATOR SOLENOIDS
VACUUM TUBES
VEHICLE SPEED SENSORS
VOLUME AIR FLOW SENSORS
WASTE GATE CONTROL SOLENOIDS
WASTE GATES AND BOOST CONTROL MECHANISMS
WATER PUMPS (ELECTRIC)
WATER PUMPS (NON-ELECTRIC)
WIRING HARNESSES AND CONNECTORS
INTRODUCTION TO MOTORIST ASSURANCE PROGRAM (MAP)
OVERVIEW OF MOTORIST ASSURANCE PROGRAM
The Motorist Assurance Program is the consumer outreach
effort of the Automotive Maintenance and Repair Association, Inc.
(AMRA). Participation in the Motorist Assurance Program is drawn from
retailers, suppliers, independent repair facilities, vehicle
manufacturers and industry associations.
Our organization's mission is to strengthen the relationship
between the consumer and the auto repair industry. We produce
materials that give motorists the information and encouragement to
take greater responsibility for their vehicles-through proper,
manufacturer-recommended, maintenance. We encourage participating
service and repair shops (including franchisees and dealers) to adopt
(1) a Pledge of Assurance to their Customers and (2) the Motorist
Assurance Program Standards of Service. All participating service
providers have agreed to subscribe to this Pledge and to adhere to the
promulgated Standards of Service demonstrating to their customers that
they are serious about customer satisfaction.
These Standards of Service require that an inspection of the
vehicle's (problem) system be made and the results communicated to the\
customer according to industry standards. Given that the industry did
not have such standards, the Motorist Assurance Program successfully
promulgated industry inspection communication standards in 1994-95 for
the following systems: Exhaust, Brakes, ABS, Steering and Suspension,
Engine Maintenance and Performance, HVAC, and Electrical Systems.
Further, revisions to all of these inspection communication standards
are continually re-published. In addition to these, standards for
Drive Train and Transmissions have recently been promulgated.
Participating shops utilize these Uniform Inspection & Communication
Page 657 of 1378
Standards as part of the inspection process and for communicating
their findings to their customers.
The Motorist Assurance Program continues to work
cooperatively and proactively with government agencies and consumer
groups toward solutions that both benefit the customer and are
mutually acceptable to both regulators and industry. We maintain the
belief that industry must retain control over how we conduct our
business, and we must be viewed as part of the solution and not part
of the problem. Meetings with state and other government officials
(and their representatives), concerned with auto repair and/or
consumer protection, are conducted. Feedback from these sessions is
brought back to the association, and the program adjusted as needed.
To assure auto repair customers recourse if they were not
satisfied with a repair transaction, the Motorist Assurance Program
offers mediation and arbitration through MAP/BBB-CARE and other non-
profit organizations. MAP conducted pilot programs in twelve states
before announcing the program nationally in October, 1998. During the
pilots, participating repair shops demonstrated their adherence to the
Pledge and Standards and agreed to follow the UICS in communicating
the results of their inspection to their customers. To put some
"teeth" in the program, an accreditation requirement for shops was
initiated. The requirements are stringent, and a self-policing method
has been incorporated which includes the "mystery shopping" of
outlets.
We welcome you to join us as we continue our outreach... with
your support, both the automotive repair industry and your customers
will reap the benefits. Please visit MAP at our Internet site www.
motorist.org or contact us at:
1444 I Street, NW Suite 700
Washington, DC 20005
Phone (202) 712-9042 Fax (202) 216-9646
January 1999
MAP UNIFORM INSPECTION GENERAL GUIDELINES
OVERVIEW OF SERVICE REQUIREMENTS AND SUGGESTIONS
It is MAP policy that all exhaust, brake, steering,
suspension, wheel alignment, drive-line, engine performance and
maintenance, and heating, ventilation and air conditioning, and
electrical services be offered and performed under the standards and
procedures specified in these sections.
Before any service is performed on a vehicle, an inspection
of the appropriate system must be performed. The results of this
inspection must be explained to the customer and documented on an
inspection form. The condition of the vehicle and its components will
indicate what services/part replacements may be "Required" or
"Suggested". In addition, suggestions may be made to satisfy the
requests expressed by the customer.
When a component is suggested or required to be repaired or
replaced, the decision to repair or replace must be made in the
customer's best interest, and at his or her choice given the options
available.
This section lists the various parts and conditions that
indicate a required or suggested service or part replacement.
Although this list is extensive, it is not fully inclusive. In
addition to this list, a technician may make a suggestion. However,
any suggestions must be based on substantial and informed experience,
or the vehicle manufacturer's recommended service interval and must be
documented.
Some conditions indicate that service or part replacement is
Page 658 of 1378
required because the part in question is no longer providing the
function for which it is intended, does not meet a vehicle
manufacturer's design specification or is missing.
Example:
An exhaust pipe has corroded severely and has a hole
in it through which exhaust gases are leaking. Replacement
of the exhaust pipe in this case is required due to
functional failure.
Example:
A brake rotor has been worn to the point where it
measures less than the vehicle manufacturer's discard
specifications. Replacement of the rotor is required
because it does not meet design specifications.
Some conditions indicate that a service or part replacement
is suggested because the part is close to the end of its useful life
or addresses a customer's need, convenience or request. If a
customer's vehicle has one of these conditions, the procedure may be
only to suggest service.
Example:
An exhaust pipe is rusted, corroded or weak, but no leaks are
present. In this case, the exhaust pipe has not failed.
However, there is evidence that the pipe may need replacement
in the near future. Replacement of the pipe may be suggested
for the customer's convenience in avoiding a future problem.
Example:
The customer desires improved ride and/or handling,
but the vehicle's shocks or struts have not failed. In this
case, replacement may be suggested to satisfy the customer's
wishes. In this case, replacement of the shocks or struts may
not be sold as a requirement.
A customer, of course, has the choice of whether or not a
shop will service his or her vehicle. He or she may decide not to
follow some of your suggestions. When a repair is required, a MAP shop
must refuse partial service on that system if, in the judgment of the
service provider, proceeding with the work could create or continue an
unsafe condition. When a procedure states that required or suggested
repair or replacement is recommended, the customer must be informed of
the generally acceptable repair/replacement options whether or not
performed by the shop.
When presenting suggested repairs to the customer, you must
present the facts, allowing the customer to draw their own conclusions
and make an informed decision about how to proceed.
The following reasons may be used for required and suggested
services. These codes are shown in the "Code" column of the MAP
Uniform Inspection & Communications Standards that follow:
Reasons to Require Repair or Replacement
A - Part no longer performs intended purpose
B - Part does not meet a design specification (regardless of
performance)
C - Part is missing
NOTE: When a repair is required, the shop must refuse partial
service to the system in question, if the repair creates
or continues an unsafe condition.
Page 659 of 1378
Reasons to Suggest Repair or Replacement
1 - Part is close to the end of its useful life (just above
discard specifications, or weak; failure likely to occur
soon, etc.)
2 - To address a customer need, convenience, or request (to
stiffen ride, enhance performance, eliminate noise,
etc.)
3 - To comply with maintenance recommended by the vehicle's
Original Equipment Manufacturer (OEM)
4 - Technician's recommendation based on substantial and
informed experience
NOTE: Suggested services are always optional. When presenting
suggested repairs to the customer, you must present the
facts, allowing the customer to draw their own conclusions
and make an informed decision about how to proceed.
ENGINE ASSEMBLIES
SERVICE PROCEDURES REQUIRED AND SUGGESTED FOR PROPER VEHICLE
OPERATION
CYLINDER HEAD ASSEMBLIES
NOTE: A Cylinder Head Assembly is a cylinder head fitted with
valves, associated springs, retainers, and on overhead
camshaft cylinder heads (OHC), camshaft, camshaft
bearings, lash adjusters, tappets and rockers.
CYLINDER HEAD ASSEMBLY INSPECTION
\
\
\
\
\
\
\
Condition Code Procedure
Adjustable valve lash is
out of specification ... B ................. Require repair.
Internal component failure
(any component) ........ A ........... ( 1) Require repair or
replacement of cylinder
head assembly.
( 1) - It is Required that all other failure related components
be inspected for cause and condition. Additional components
or assemblies may be Suggested for repair or replacement,
such as a water pump on a short block (reason code 4,
technician's recommendation based on substantial and
informed experience).
Example:
If there is a failed head gasket with an external coolant
leak, in addition to Requiring replacement of the head
gasket, inspection of the following for cause and condition
is Required: Block, Cooling System, Cylinder Head. It may
be Suggested that additional inspections be performed, such
as the other head gasket on a V-type engine.
\
\
\
\
\
\
\
LONG BLOCK ASSEMBLIES
NOTE: A Long Block Assembly is a short block assembly together
with a cylinder head assembly and all those components
fitted within the rocker or cam cover, and timing cover
Page 660 of 1378
![JEEP CHEROKEE 1988 Service Repair Manual (the whole presented as an assembly). A rebuilt or new
oil pump, or kit shall be supplied or fitted as
appropriate.
LONG BLOCK ASSEMBLY INSPECTION
\](/img/16/57037/w960_57037-659.png "JEEP CHEROKEE 1988 Service Repair Manual (the whole presented as an assembly). A rebuilt or new
oil pump, or kit shall be supplied or fitted as
appropriate.
LONG BLOCK ASSEMBLY INSPECTION
\")
(the whole presented as an assembly). A rebuilt or new
oil pump, or kit shall be supplied or fitted as
appropriate.
LONG BLOCK ASSEMBLY INSPECTION
\
\
\
\
\
\
\
Condition Code Procedure
Internal component failure
(any component) ........ A ........... (1) Require repair or
replacement of the long
block assembly.
( 1) - It is Required that all other failure related components
be inspected for cause and condition. Additional components
or assemblies may be Suggested for repair or replacement
such as a water pump on a short block (reason code 4,
technician's recommendation based on substantial and
informed experience).
Example:
If there is a failed head gasket with an external coolant
leak, in addition to Requiring replacement of the head
gasket, inspection of the following for cause and
condition is Required: Block, Cooling System, Cylinder
Head. It may be Suggested that additional inspections be
performed, such as the other head gasket on a V-type
engine.
\
\
\
\
\
\
\
SHORT BLOCK ASSEMBLIES
NOTE: A Short Block Assembly is a cylinder block and all those
components contained within the limits of the block deck
or decks, the pan rail, the block rear face and the
timing cover (where fitted), including the crankshaft.
SHORT BLOCK ASSEMBLY INSPECTION
\
\
\
\
\
\
\
Condition Code Procedure
Any internal component
failure ................ A ........... ( 1) Require repair or
replacement of the short
block assembly.
( 1) - It is Required that all other failure related components
be inspected for cause and condition. Additional
components or assemblies may be Suggested for repair or
replacement, such as a water pump on a short block
(reason code 4, technician's recommendation based on
substantial and informed experience).
Example:
If there is a failed head gasket with an external coolant
leak, in addition to Requiring replacement of the head
gasket, inspection of the following for cause and condition
is Required: Block, Cooling System, Cylinder Head. It may
be Suggested that additional inspections be performed,
such as the other head gasket on a V-type engine.
\
\
\
\
\
\
\
