key fob battery JEEP CHEROKEE 2014 KL / 5.G Owners Manual

Keyless Ignition Node (KIN)
This feature allows the driver to operate the ignition
switch with the press of a button, as long as the Remote
Keyless Entry (RKE) transmitter is in the passenger
compartment.
The Keyless Ignition Node (KIN) has four operating
positions, three of which are labeled and will illuminate
when in position. The three positions are OFF, ACC, and
ON/RUN. The fourth position is START, during start
RUN will illuminate.
NOTE:In case the ignition switch does not change with
the press of a button, the RKE transmitter (Key Fob) may
have a low or dead battery. In this situation a back up
method can be used to operate the ignition switch. Put
the nose side (side opposite of the emergency key) of the
Key Fob against the ENGINE START/STOP button and
press to operate the ignition switch.
Keyless Ignition Node (KIN)
1 — OFF
2 — ACC (ACCESSORY)
3 — ON/RUN
2
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 13

Key Fob — If Equipped
The Key Fob also contains the Remote Keyless Entry
(RKE) transmitter and an emergency key, which stores in
the rear of the Key Fob.
The emergency key allows for entry into the vehicle
should the battery in the vehicle or the Key Fob go dead.
You can keep the emergency key with you when valet
parking.
To remove the emergency key, slide the mechanical latch
on the face of the Key Fob sideways with your thumb and
then pull the key out with your other hand.
Emergency Key Removal (IGNM)
14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Proper towing or lifting equipment is required to prevent
damage to your vehicle. Use only tow bars and other
equipment designed for this purpose, following equip-
ment manufacturer ’s instructions. Use of safety chains is
mandatory. Attach a tow bar or other towing device to
main structural members of the vehicle, not to bumpers
or associated brackets. State and local laws regarding
vehicles under tow must be observed.
If you must use the accessories (wipers, defrosters, etc.)
while being towed, the ignition must be in the ON/RUN
position, not the ACC position.
If the key fob is unavailable, or the vehicle’s battery is
discharged, refer to “Shift Lever Override” in this section
for instructions on shifting the transmission out of PARK
so that the vehicle can be moved.CAUTION!
•Do not use sling type equipment when towing.
Vehicle damage may occur.
• When securing the vehicle to a flat bed truck, do
not attach to front or rear suspension components.
Damage to your vehicle may result from improper
towing.
Front-Wheel Drive (FWD) Models
The manufacturer recommends towing your vehicle with
all four wheels OFFthe ground using a flatbed.
If flatbed equipment is not available, this vehicle must
towed with the front wheels OFF the ground (using a
towing dolly, or wheel lift equipment with the front
wheels raised).6
WHAT TO DO IN EMERGENCIES 587

Jacking Instructions....................... .570
Jack Location ........................... .567
Jack Operation .......................... .566
Jump Starting ........................... .578
Key Fob Arm The Alarm .........................19
Panic Alarm ............................25
Programming Additional Key Fobs ...........18
Programming Additional Transmitters .........18
Key-In Reminder ..........................15
Keyless Enter-N-Go ........................38
Keyless Entry System .......................22
Key, Replacement ..........................18
Keys ...................................12
Key, Sentry (Immobilizer) ....................16
Lane Change and Turn Signals ................172
Lane Change Assist ....................... .172Lap/Shoulder Belts
.........................55
Latches ................................119
Hood ............................... .164
Latch Plate ...............................56
Lead Free Gasoline ....................... .519
Leaks, Fluid .............................119
Life of Tires ............................ .501
Liftgate .................................47
Liftgate Window Wiper/Washer ...............317
Light Bulbs ..............................119
Lights .................................119
Airbag ................................74
Anti-Lock ............................ .328
Automatic Headlights ....................167
Back-Up ............................. .646
Battery Saver ......................... .176
Brake Assist Warning ....................478
Brake Warning ........................ .327
Bulb Replacement ...................... .642
676 INDEX
