headlight bulb JEEP CHEROKEE 2017 KL / 5.G User Guide

Turn Signals
Move the multifunction lever up or down and the arrows
on each side of the instrument cluster display will flash to
show proper operation of the front and rear turn signal
lights.
NOTE:
•If either light remains on and does not flash, or there is
a very fast flash rate, check for a defective outside light
bulb. If an indicator fails to light when the lever is
moved, it would suggest that the indicator bulb is
defective.
• A “Turn Signal On” message will appear in the instru-
ment cluster display and a continuous chime will sound
if the vehicle is driven more than 1 mile (1.6 km) with
either turn signal on.
• When the Daytime Running Lights are on and a turn
signal is activated, the Daytime Running Lamp will turn
off on the side of the vehicle in which the turn signal is
flashing. The Daytime Running Lamp will turn back on
when the turn signal is turned off.
Lane Change Assist — If Equipped
Tap the lever up or down once, without moving beyond
the detent, and the turn signal (right or left) will flash three
times then automatically turn off.
High/Low Beam Switch
Push the multifunction lever away from you to switch the
headlights to high beam. Pull the multifunction lever
toward you to switch the headlights back to low beam.
Flash-To-Pass
You can signal another vehicle with your headlights by
lightly pulling the multifunction lever toward you. This
will cause the headlights to turn on at high beam and
remain on until the lever is released.
Automatic High Beam Headlamp Control —
If Equipped
The Automatic High Beam Headlamp Control system
provides increased forward lighting at night by automat-
ing high beam control through the use of a digital camera
mounted on the inside rearview mirror. This camera de-
tects vehicle specific light and automatically switches from
high beams to low beams until the approaching vehicle is
out of view.
66 GETTING TO KNOW YOUR VEHICLE

Key FobArm The Alarm ..........................34
Disarm The Alarm ........................35
Programming Additional Key Fobs ..........25, 33
Key Fob Battery Service (Remote Keyless Entry) .....22
Key Fob Programming (Remote Keyless Entry) ......25
Key-In Reminder ............................28
Keyless Enter-N-Go ..........................38
Lock The Vehicle’s Doors ...................539
Passive Entry Programming .................539
Unlock Liftgate ......................... .539
Key, Replacement ........................ .25, 33
Keys ....................................20
Lane Change And Turn Signals .................66
Lane Change Assist ..........................66
LaneSense ............................... .355
Lap/Shoulder Belts ........................ .204
Latches ................................. .255
Hood ................................ .102
Leaks, Fluid ............................. .255
Life Of Tires ............................. .493
Liftgate ............................. .103, 104
Liftgate Window Wiper/Washer .................74
Light Bulbs .............................. .255Lights
.................................. .255
AirBag .........................143, 215, 253
Automatic Headlights ......................63
Battery Saver ............................67
Brake Assist Warning ..................... .176
Brake Warning ......................... .144
Cruise ............................... .162
Daytime Running .........................64
Dimmer Switch, Headlight ................65, 66
Engine Temperature Warning ................147
Exterior .............................. .255
Fog ...................................65
Hazard Warning Flasher ...................391
Headlights ..............................63
Headlights On Reminder ....................64
Headlights On With Wipers ..................64
Headlight Switch .........................63
High Beam ..............................66
High

Beam/Low Beam Select .................66
Hill Descent Control Indicator ...............179
Instrument Cluster ........................63
Intensity Control ..........................68
Interior ................................67
Lights On Reminder .......................64
Low Fuel ............................. .155
604 INDEX
