JEEP CHEROKEE TRAILHAWK 2019 Owners Manual

Bulb Number
Front Turn Signal Lamps LED (Serviced at an au- thorized dealer)
Front Fog Lamps LED (Serviced at an au- thorized dealer)
Rear Tail/Stop Lamps LED (Serviced at an au- thorized dealer)
Rear Turn Signal Lamps LED (Serviced at an au- thorized dealer)
Center High Mounted Stop Lamp (CHMSL) LED (Serviced at an au-
thorized dealer)
Back-Up Lamps W21W
License Plate Lamp LED (Serviced at an au- thorized dealer)
Replacing Exterior Bulbs
Back-up Lamp
1. Open the liftgate.
2. Use a fiber stick or flat blade screw driver at the top ofthe bulb access cover to pry the lower trim panel from
the liftgate. 3. Once the access panel is loose, pull it back exposing the
insulation.
4. Move insulation towards center of vehicle to expose the back of liftgate lamp.
5. Twist the socket counterclockwise and remove from lamp.
6. Pull the bulb to remove it from the socket.
7. Replace the bulb, reinstall the socket.
8. Move insulation back to original position.
9. Move insulation towards center of vehicle to expose the back of liftgate lamp.
10. Close the liftgate.
FUSES

WARNING!(Continued)
fuse with metal wires or any other material. Do not
place a fuse inside a circuit breaker cavity or vice
versa. Failure to use proper fuses may result in
serious personal injury, fire and/or property damage.
• Before replacing a fuse, make sure that the ignition is
off and that all the other services are switched off
and/or disengaged.
• If the replaced fuse blows again, contact an autho-
rized dealer.
• If a general protection fuse for safety systems (air
bag system, braking system), power unit systems
(engine system, transmission system) or steering
system blows, contact an authorized dealer.
General Information
The fuses protect electrical systems against excessive cur-
rent.
When a device does not work, you must check the fuse
element inside the blade fuse for a break/melt. Also, please be aware that when using power outlets for
extended periods of time with the engine off may result in
vehicle battery discharge.
