WARNING!
Stand clear of vehicles when pulling with tow
hooks. Tow straps and chains may break, causing
serious injury.
TOWING A DISABLED VEHICLE
2WD Models Only
Provided the transmission is operable, tow only in N
(Neutral) at speeds not exceeding 30 mph (48 km/h), for
distances of not more than 15 miles (24 km). Towing at
more than 30 mph (48 km/h) or for more than 15 miles
(24 km) can cause severe transmission damage. If the
transmission is not operable, or the vehicle must be
towed faster than 30 mph (48 km/h) or farther than 15
miles (24 km), remove the driveshaft or tow with all four
wheelsOFFthe ground. Acceptable methods are to towthe vehicle on a flatbed or with one end of the vehicle
raised and the other end on a towing dolly.
4WD Models Only
The manufacturer recommends towing with all four
wheelsOFFthe ground. Acceptable methods are to tow
the vehicle on a flatbed or with one end of the vehicle
raised and the other end on a towing dolly.
WHAT TO DO IN EMERGENCIES 341
6

ONBOARD DIAGNOSTIC SYSTEM — OBD II
Your vehicle is equipped with a sophisticated onboard
diagnostic system called OBD II. This system monitors
the performance of the emissions, engine, and automatic
transmission control systems. When these systems are
operating properly, your vehicle will provide excellent
performance and fuel economy, as well as engine emis-
sions well within current government regulations.
If any of these systems require service, the OBD II system
will turn on the “Malfunction Indicator Light.” It will
also store diagnostic codes and other information to
assist your service technician in making repairs. Al-
though your vehicle will usually be drivable and not
need towing, see your dealer for service as soon as
possible.CAUTION!
•Prolonged driving with the “Malfunction Indica-
tor Light” on could cause further damage to the
emission control system. It could also affect fuel
economy and driveability. The vehicle must be
serviced before any emissions tests can be per-
formed.
•If the “Malfunction Indicator Light” is flashing
while the engine is running, severe catalytic con-
verter damage and power loss will soon occur.
Immediate service is required.
Loose Fuel Filler Cap Message
After fuel is added, the vehicle diagnostic system can
determine if the fuel filler cap is loose, improperly
installed, or damaged. A loose fuel filler cap message will
be displayed in the instrument cluster. Tighten the gas
348 MAINTAINING YOUR VEHICLE

•More than 50% of your driving is at sustained high
speeds during hot weather, above 90°F (32°C)
•Trailer towing
•Taxi, Police, or delivery service (Commercial Service)
•Off road or desert operation
•If equipped for and operating with E-85 (ethanol) fuel
IfANYof these apply to you, then change your engine oil
every 3,000 miles (5 000 km) or 3 months, whichever
comes first, and follow the maintenance recommenda-
tions in “Maintenance Schedule B.”
If none of these apply to you, then change your engine oil
every 6,000 miles (10 000 km) or 6 months, whichever
comes first.
NOTE:Under no circumstances should oil change in-
tervals exceed 6,000 miles (10 000 km) or 6 months
whichever comes first.
Engine Oil Selection
For best performance and maximum protection for all
engines under all types of operating conditions, the
manufacturer recommends engine oils that are API Cer-
tified and meet the requirements of DaimlerChrysler
Material Standard MS-6395. Use Moparor an equiva-
lent oil meeting the specification MS-6395.
Oil Filler Caps
MAINTAINING YOUR VEHICLE 353
7

To minimize the possibility of catalytic converter damage:
•Do not shut off the engine or interrupt the ignition
when the transmission is in gear and the vehicle is in
motion.
•Do not try to start the engine by pushing or towing the
vehicle.
•Do not idle the engine with any spark plug wires
disconnected or removed, such as when diagnostic
testing.
•Do not idle the engine for prolonged periods during
very rough idle or malfunctioning operating condi-
tions.
•Do not allow vehicle to run out of fuel.
NOTE:Intentional tampering with emissions control
systems can result in civil penalties being assessed
against you.
Crankcase Emission Control System
Proper operation of this system depends on freedom
from sticking or plugging due to deposits. As vehicle
mileage builds up, the PCV valve and passages may
accumulate deposits. If a valve is not working properly,
replace it with a new valve. DO NOT ATTEMPT TO
CLEAN THE OLD PCV VALVE!
Check ventilation hose for indication of damage or
plugging deposits. Replace if necessary.
Air Cleaner Filter
Under normal driving conditions, replace the air filter at
the intervals shown on “Maintenance Schedule A.” If,
however, you drive the vehicle frequently under dusty or
severe conditions, the filter element should be inspected
periodically and replaced if necessary at the intervals
shown on “Maintenance Schedule B.”
358 MAINTAINING YOUR VEHICLE

do not use polishes, oils, cleaning fluids, solvents, deter-
gents, or ammonia based cleaners to clean your leather
upholstery. Application of a leather conditioner is not
required to maintain the original condition.
WARNING!
Do not use volatile solvents for cleaning purposes.
Many are potentially flammable, and if used in
closed areas they may cause respiratory harm.
Glass Surfaces
All glass surfaces should be cleaned on a regular basis
with MoparGlass Cleaner or any commercial
household-type glass cleaner. Never use an abrasive type
cleaner. Use caution when cleaning inside rear windows
equipped with electric defrosters. Do not use scrapers or
other sharp instruments which may scratch the elements.When cleaning the rear view mirror, spray cleaner on the
towel or rag that you are using. Do not spray cleaner
directly on the mirror.
Cleaning Plastic Instrument Cluster Lenses
The lenses in front of the instruments in this vehicle are
molded in clear plastic. When cleaning the lenses, care
must be taken to avoid scratching the plastic.
1. Clean with a wet soft rag. A mild soap solution may be
used, but do not use high alcohol content or abrasive
cleaners. If soap is used, wipe clean with a clean damp
rag.
2. Dry with a soft tissue.
380 MAINTAINING YOUR VEHICLE

Cavity Fuse/Color Description
1 30 Amp Pink Audio Amp (B+)
2 15 Amp Blue Sunroof (B+)
3 10 Amp Red Htd Mirror (EBL)
4 20 Amp Yellow Rr Pwr Out (B+)
5 10 Amp Red Rr HVAC (R/O)
6 10 Amp Red OCM (B+)
7 20 Amp Yellow Door Locks (B+)
8 15 Amp Blue Steer Col Lock (B+)
9 20 Amp Yellow Pwr Outlet (B+)
10 10 Amp Red Ign Run Only Out (R/O)
11 Spare
12 10 Amp Red Mem. Sw, Courtesy Lamp
(B+)
13 Spare
14 20 Amp Yellow Cigar Ltr (R/A)
15 10 Amp Red Tire Press Mon (R/O)Cavity Fuse/Color Description
16 10 Amp Red SCM, Cluster OBD (B+)
17 15 Amp Blue Flipper Glass (B+)
19 10 Amp Red OCM (R/S)
20 10 Amp Red WCM, Cluster (R/S)
21 15 Amp Blue Autowipe (Accy Delay)
22 15 Amp Blue Rear Wiper (B+)
24 10 Amp Red PDC, FCM, A580 (R/S)
25 10 Amp Red ABS, Trans. Case Switch
(R/S)
CB1 20 Amp Cycle -Wipers (B+)
CB2 20 Amp Non - Cycle Seats (B+)
CB3 20 Amp Non - Cycle Windows (De-
lay)
382 MAINTAINING YOUR VEHICLE

Underhood Fuses (Power Distribution Center)
Cavity Fuse/Color Description
1 40 Amp Green HVAC Blower
2 30 Amp Pink Power Outlets
3 30 Amp Pink Rr Wiper/Ign R/O
Cavity Fuse/Color Description
4 30 Amp Pink ABS Pump
5 50 Amp Red Cabin Htr 1 (Diesel Only)
6 50 Amp Red ASD
7 30 Amp Pink Rr HVAC (XK)
8 40 Amp Green Acc Delay/Seats
9 Spare
10 40 Amp Green Starter/JB Power
11 30 Amp Pink Cig Ltr/T-Tow
12 40 Amp Green EBL/Htd Mirror
13 40 Amp Green JB Power
14 50 Amp Red Cabin Htr 2 (Diesel Only)
15 50 Amp Red Cabin Htr 3 (Diesel Only)
16 25 Amp Natural IPM/Coils
17 Spare
18 20 Amp Yellow TCM/AC Clutch
19 20 Amp Yellow Ign Sw
Power Distribution Center
MAINTAINING YOUR VEHICLE 383
7

Underhood Fuses (Integrated Power Module)
Cavity Fuse/Color Description
1 Micro Relay Wiper On/Off Rly
2 Micro Relay Wiper Hi/Lo Rly
3 Micro Relay Horn Rly
Cavity Fuse/Color Description
4 Micro Relay Rear Fog Rly (BUX Only)
5 Micro Relay Lt T-Tow Stop/Turn Rly
6 Micro Relay Rt T-Tow Stop/Turn Rly
7 Micro Relay Park Lamps Rly
8 10 Amp Red Lt Park Lamps
9 10 Amp Red T-Tow Park Lamps
10 10 Amp Red Rt Park Lamps
11 Mini Relay Rad Fan Hi Rly
12 20 Amp Yellow FCM Batt #4
13 20 Amp Yellow FCM Batt #2
14 20 Amp Yellow Adjustable Pedal
15 20 Amp Yellow Ft Fog Lamps
16 20 Amp Yellow Horn
17 20 Amp Yellow Rear Fogs
18 20 Amp Yellow FCM Batt #1
19 20 Amp Yellow Lt T-Tow Stop/Turn
Integrated Power Module
MAINTAINING YOUR VEHICLE 385
7

Cavity Fuse/Color Description
20 20 Amp Yellow FCM Batt #3
21 20 Amp Yellow Rt T-Tow Stop/Turn
22 30 Amp Pink FDCM Mod
23 50 Amp Red Rad Fan
24 Mini Relay Rad Fan Lo Rly
25 Micro Relay Ft Fog Lamps Rly
26 Micro Relay Adjustable Pedal Rly
27 15 Amp Blue IOD #1
28 20 Amp Yellow IOD #2 (Audio)
29 10 Amp Red ORC (Ign R/.S)
30 10 Amp Red ORC (Ign R/O)VEHICLE STORAGE
If you are leaving your vehicle dormant for more than 21
days you may want to take steps to protect your battery.
You may:
•Remove fuse #27 in the Intelligent Power Module
labeled Ignition-Off Draw (IOD#1).
•Or, disconnect the negative cable from the battery.
•Anytime you store your vehicle, or keep it out of
service (i.e. vacation) for two weeks or more, run the
air conditioning system at idle for about five minutes
in the fresh air and high blower setting. This will
insure adequate system lubrication to minimize the
possibility of compressor damage when the system is
started again.
386 MAINTAINING YOUR VEHICLE

EMISSION CONTROL SYSTEM MAINTENANCE
The “Scheduled” maintenance services, listed inbold
typemust be done at the times or mileages specified to
assure the continued proper functioning of the emission
control system. These, and all other maintenance services
included in this manual, should be done to provide best
vehicle performance and reliability. More frequent main-
tenance may be needed for vehicles in severe operating
conditions such as dusty areas and very short trip
driving.
Inspection and service also should be done any time a
malfunction is suspected.
NOTE:Maintenance, replacement, or repair of the emis-
sion control devices and systems on your vehicle may be
performed by any automotive repair establishment or
individual using any automotive part which has been
certified pursuant to U.S. EPA or, in the State of Califor-
nia, California Air Resources Board regulations.
MAINTENANCE SCHEDULES
There are two maintenance schedules that show the
requiredservice for your vehicle.
First is ScheduleB. It is for vehicles that are operated
under the conditions that are listed below and at the
beginning of the schedule.
•Day or night temperatures are below 32°F (0°C)
•Stop and go driving
•Excessive engine idling
•Driving in dusty conditions
•Short trips of less than 10 miles (16.2 km)
•More than 50% of your driving is at sustained high
speeds during hot weather, above 90°F (32°C)
•Trailer towing
•Heavy loading
392 MAINTENANCE SCHEDULES
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S
