Snow JEEP COMMANDER 2006 1.G Owners Manual

Fog Lights — If Equipped
The fog light switch is located in the multi-
function control lever. To activate the fog lights,
turn on the park/turn lights, low beam headlights,
or “Auto” headlights and pull out the end of the multi-
function control lever. A light in the instrument cluster
shows when the fog lights are on.
NOTE:Turning on the high beam headlights turns off
the fog lights.
A front fog light is a lighting device providing illumina-
tion forward of the vehicle under conditions of fog, rain,
snow, or dust. Principally, the front fog light supplements
the lower beam of a standard headlight system.
NOTE:Proper aim and adjustments of the front fog
lights should be made to prevent excessive glare for other
drivers.
Turn Signals
Move the multi-function control lever up or down and
the arrows on each side of the instrument cluster will
flash to show proper operation of the front and rear turn
signal lights. You can signal a lane change by moving the
lever partially up or down.
High Beam Switch
Pull the multi-function control lever towards you to
switch the headlights to “High” beam. The “High Beam
Indicator Light” on the instrument cluster will illumi-
nate. Pull the multi-function control lever a second time
to switch the headlights to “Low” beam.
Passing Light
You can signal another vehicle with your headlights by
lightly pulling the multi-function control lever toward
the steering wheel. This will cause the headlights to turn
on at high beam and remain on until the lever is released.
126 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Headlight Time Delay
There is also a feature that delays turning off the vehicle
lights for 30, 60, or 90 seconds after the ignition switch is
turned OFF. To activate the headlight delay, the multi-
function control lever must be rotated to the “Off”
position after the ignition switch is turned OFF. Only the
headlights will illuminate during this time. Refer to
“EVIC- Customer Programmable Features” in Section 4
to turn this feature “On/Off” or set the time interval.
WINDSHIELD WIPERS AND WASHERS
The front and rear wipers and washers are operated by a
switch in the right side control lever. Turn the end of the
control lever to select “Lo,” “Hi,” or one of the five speed
sensitive intermittent windshield wiper speeds. Refer to
“Speed Sensitive Intermittent Wiper System” in this
section. For information on the rear wiper and washer
refer to “Rear Window Features” in this section.NOTE:Always remove any build-up of snow that
prevents the windshield wiper blades from returning to
the OFF position. If the windshield wiper switch is
turned off and the blades cannot return to the OFF
position, damage to the wiper motor may occur.
Windshield Wiper/Washer Switch
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 127
3

High Range (4WD Models) or 2WD Models
On
This is the normal operating mode for ESP in 4WD high
range and in 2WD vehicles. Whenever the vehicle is
started or the transfer case (if equipped) is shifted from
4WD low range or neutral back to 4WD high range, the
ESP system will be in this mode. This mode should be
used for most all driving situations. ESP should only be
turned to “Partial Off” or “Full Off” for specific reasons
as noted below.
Partial Off
This mode is entered by momentarily depressing the
ESP Control Switch. When inPartial Offmode, the
TCS portion of ESP, except for the “limited slip” feature
described in the TCS section, has been disabled and the
ESP/TCS Indicator Lightwill be illuminated. All other
stability features of ESP function normally. This mode is
intended to be used if the vehicle is in deep snow, sand,or gravel conditions and more wheel spin than ESP
would normally allow is required to gain traction. To
turn ESP on again, momentarily depress theESP Control
Switch. This will restore the normal “ESP On” mode of
operation.
ESP Control Switch
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 137
3

NOTE:To improve the vehicle’s traction when driving
with snow chains, or starting off in deep snow, sand, or
gravel, it may be desirable to switch to the “Partial Off”
mode by pressing the ESP switch. Once the situation
requiring ESP to be switched to the “Partial Off” mode is
overcome, turn ESP back on by momentarily depressing
the “ESP Control Switch”. This may be done while the
vehicle is in motion.
Full Off
This mode is intended for off-highway or off-road use
when ESP stability features could inhibit vehicle maneu-
verability due to trail conditions. This mode is entered by
depressing and holding the “ESP Control Switch” for 5
seconds when the vehicle is stopped and the engine is
running. In this mode, all ESP and TCS stability features
are turned off except for the “limited slip” feature de-
scribed in the TCS section. After 5 seconds, a chime will
sound, theESP/TCS Indicator Lightwill illuminate,
and theESP OFFmessage will appear in the ElectronicVehicle Information Center (EVIC). Refer to “Electronic
Vehicle Information Center (EVIC)” in Section 4 of this
manual. (See page 186 for more information.) To turn ESP
on again, momentarily depress theESP Control Switch.
This will restore the normal “ESP On” mode of operation.
NOTE:The “ESP OFF” message will display and the
audible chime will sound when the gear selector is
placed into the “P” (Park) position from any position
other than “P” (Park), and then moved out of the “P”
(Park) position. This will occur even if the message was
previously cleared.
138 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

WARNING!
•Drivers must be careful when backing up even when
using the Rear Park Assist System. Always check
carefully behind your vehicle, look behind you, and
be sure to check for pedestrians, animals, other
vehicles, obstructions, and blind spots before back-
ing up. You are responsible for safety and must
continue to pay attention to your surroundings. Fail-
ure to do so can result in serious injury or death.
•Before using the Rear Park Assist System, it is
strongly recommended that the ball mount and hitch
ball assembly is disconnected from the vehicle when
the vehicle is not used for towing. Failure to do so
can result in injury or damage to vehicles or ob-
stacles because the hitch ball will be much closer to
the obstacle than the rear fascia when the warning
display turns the red LEDs ON. Also, the sensors
could detect the ball mount and hitch ball assembly,
depending on its size and shape, giving a false
indication that an obstacle is behind the vehicle.
NOTE:Clean all four Rear Park Assist Sensors regularly,
taking care not to scratch or damage them. The sensors
must not be covered with ice, snow, slush, mud, dirt or
debris. Failure to do so can result in the system not
working properly. The system might not detect an ob-
stacle behind the fascia or it could provide a false
indication that an obstacle is behind the fascia.
Assure objects are not within 11.8 inches (30 cm) from the
rear fascia while driving the vehicle. Failure to do so can
result in the system misinterpreting a close object as a
sensor problem, causing theSERVICE PARK ASSIST
SYSTEMmessage to be displayed in the instrument
cluster.
Ultrasonic noise from airbrakes of nearby trucks, air
powered jackhammers and air powered shop tools, to
name a few, will cause the Rear Park Assist System to be
disabled until the ultrasonic noise is no longer present.
146 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

WARNING!
Leaving the Speed Control ON when not in use is
dangerous. You could accidentally set the system or
cause it to go faster than you want. You could lose
control and have an accident. Always leave the
system OFF when you aren’t using it.
Driving Up or Down Hills
When going up or down hills, it is possible for your
vehicle to lose or gain speed, even though the Speed
Control is engaged. The automatic transmission may also
downshift to a lower gear, to maintain speed going up or
down hills. If going down a hill steep enough to cause the
vehicle to gain speed, press the brake pedal, which will
disengage the Speed Control and help slow your vehicle.
WARNING!
To help keep your vehicle under control, do not use
Speed Control under these conditions:
•When it is not possible to keep your vehicle at a set
speed.
•On slippery roads, such as on snow or ice.
•In heavy or varying traffic volume, in traffic that varies
in speed, or on winding roads.
•Be sure to turn the Speed Control switch to the OFF
position when not in use to avoid accidental engage-
ment.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 151
3

Window Fogging
Interior fogging on the windshield can be quickly re-
moved by turning the mode selector to Defrost, and
turning on the high blower. The Defrost/Floor mode can
be used to maintain a clear windshield and provide
sufficient heating. If side window fogging becomes a
problem increase blower speed. Vehicle windows tend to
fog on the inside in mild but rainy or humid weather.
NOTE:Recirculate without A/C should not be used for
long periods as fogging may occur.
Outside Air Intake
Make sure the air intake, located directly in front of the
windshield, is free of obstructions such as leaves. Leaves
collected in the air intake may reduce airflow and if they
enter the plenum they could plug the water drains. In
winter months make sure the air intake is clear of ice,
slush and snow.
UNDERSTANDING YOUR INSTRUMENT PANEL 247
4

Anti-Lock Brake System..................271

Power Steering........................274

On-Road Driving Tips...................275

Off-Road Driving Tips...................276
▫When To Use 4WD Low Range —
If Equipped.........................276
▫Driving Through Water.................276
▫Driving In Snow, Mud And Sand..........277
▫HillClimbing ........................278
▫Traction Downhill.....................279
▫After Driving Off-Road.................279

Multi Displacement System (MDS) - 5.7L Engine
Only ................................280

Tire Safety Information...................281▫Tire Markings........................281
▫Tire Identification Number (TIN)..........284
▫Tire Loading And Tire Pressure...........285

Tires — General Information...............289
▫Tire Pressure.........................289
▫Tire Inflation Pressures.................290
▫Tire Pressures For High Speed Operation....292
▫Radial-Ply Tires......................293
▫Tire Spinning........................293
▫Tread Wear Indicators..................294
▫LifeOfTire .........................294
▫Replacement Tires.....................295
▫Alignment And Balance.................296
250 STARTING AND OPERATING

▫Towing – 2WD Models.................323
▫Towing — Quadra-Trac I
(Single-Speed Transfer Case) 4WD Models....323▫Towing — Quadra–Trac II /Quadra–Drive II
4WD Models........................324

Snow Plow...........................328
252 STARTING AND OPERATING

cause damage to the transmission. The torque converter
will refill within five seconds of shifting from Park into
any other gear position.
Rocking the Vehicle
If the vehicle becomes stuck in snow, sand, or mud, it can
often be moved by a rocking motion. Move the gear
selector rhythmically between D (Drive) and R (Reverse),
while applying slight pressure to the accelerator.
NOTE:The Electronic Stability Program (ESP) and
Traction Control (if equipped) should be turned OFF
before attempting to rock the vehicle. Refer to Section 3 of
this manual. (See page 131 for more information.)
The least amount of accelerator pedal pressure to main-
tain the rocking motion without spinning the wheels or
racing the engine is most effective. Racing the engine or
spinning the wheels, due to the frustration of not freeing
the vehicle, may lead to transmission overheating and
failure. Allow the engine to idle with the transmissionselector in N (Neutral) for at least one minute after every
five rocking-motion cycles. This will minimize overheat-
ing and reduce the risk of transmission failure during
prolonged efforts to free a stuck vehicle.
CAUTION!
When “rocking” a stuck vehicle by moving between
“First” and R (Reverse), do not spin the wheels faster
than 15 mph (24 km/h), or drivetrain damage may
result.
STARTING AND OPERATING 263
5
