prevailing road conditions. The “ESP/TCS Indicator
Light” will flash any time the ESP or TCS is active and
helping to improve vehicle stability. If the “ESP/TCS
Indicator Light” is on solid, the ESP system has been
turned off by the driver or a temporary condition exists
that will not allow full ESP function. (See page 131 for
more information.)
12. Tire Pressure Monitoring Telltale Light
Each tire, including the spare (if provided),
should be checked monthly when cold and
inflated to the inflation pressure recommended
by the vehicle manufacturer on the vehicle
placard or tire inflation pressure label. (If your vehicle
has tires of a different size than the size indicated on the
vehicle placard or tire inflation pressure label, you should
determine the proper tire inflation pressure for those
tires.)As an added safety feature, your vehicle has been
equipped with a tire pressure monitoring system (TPMS)
that illuminates a low tire pressure telltale when one or
more of your tires is significantly under-inflated. Accord-
ingly, when the low tire pressure telltale illuminates, you
should stop and check your tires as soon as possible, and
inflate them to the proper pressure. Driving on a signifi-
cantly under-inflated tire causes the tire to overheat and
can lead to tire failure. Under-inflation also reduces fuel
efficiency and tire tread life, and may affect the vehicle’s
handling and stopping ability.
Please note that the TPMS is not a substitute for proper
tire maintenance, and it is the driver ’s responsibility to
maintain correct tire pressure, even if under-inflation has
not reached the level to trigger illumination of the TPMS
low tire pressure telltale. (See page 297 for more infor-
mation.)
UNDERSTANDING YOUR INSTRUMENT PANEL 181
4

Tire Pressure Monitor System (TPMS)........297
▫Base System.........................297
▫Premium System......................299
▫General Information...................303

Tire Chains...........................303

Tire Rotation Recommendations............304

Fuel Requirements......................305
▫3.7/4.7L Engines (If Equipped)............305
▫5.7L Engines (If Equipped)...............305
▫Reformulated Gasoline.................306
▫Gasoline/Oxygenate Blends..............306
▫MMT In Gasoline.....................307
▫Materials Added To Fuel................307▫Fuel System Cautions..................307
▫Carbon Monoxide Warnings..............308

Fuel Tank Filler Cap (Gas Cap).............309
▫Loose Fuel Filler Cap Message............311

TrailerTowing .........................312
▫Common Towing Definitions.............312
▫Trailer Hitch Classification...............314
▫Trailer Towing Weights
(Maximum Trailer Weight Ratings).........315
▫Trailer And Tongue Weight..............316
▫Towing Requirements..................317
▫TowingTips .........................321

Recreational Towing (Behind Motorhome, Etc.) . . 323
STARTING AND OPERATING 251
5

Improper alignment will not cause vehicle vibration.
Vibration may be a result of tire and wheel out-of-
balance. Proper balancing will reduce vibration and
avoid tire cupping and spotty wear.
TIRE PRESSURE MONITOR SYSTEM (TPMS)
Base System
The Tire Pressure Monitor System (TPMS) uses wireless
technology with wheel rim mounted electronic sensors to
monitor tire pressure levels. Sensors, mounted to each
wheel as part of the valve stem, transmit tire pressure
readings to the Receiver Module.
NOTE:It is particularly important, for you to check the
tire pressure in all of your tires regularly and to maintain
the proper pressure.
The “Tire Pressure Monitoring Telltale Light” will
illuminate in the instrument cluster, and an au-
dible chime will be activated when one or moretire pressures is low. The “Tire Pressure Monitoring
Telltale Light” will flash on and off for 10 to 60 seconds
when a system fault is detected. The flash cycle will
repeat every ten minutes or until the fault condition is
removed and reset.
The Tire Pressure Monitor System (TPMS) consists of the
following components:•Receiver Module
•5 Wheel Sensors (including Full Size Spare Tire)
•Tire Pressure Monitoring Telltale Light
The system will consist of tire pressure monitoring
sensors attached to each wheel through the valve stem
mounting hole, a central receiver module and a “Tire
Pressure Monitoring Telltale Light.” A sensor is located in
the spare wheel if the vehicle is equipped with a match-
ing full size spare wheel and tire assembly.
STARTING AND OPERATING 297
5

NOTE:For vehicles with optional wheel/tire sizes and
significantly different tire placard pressures, the placard
pressure value and the low-pressure threshold value is
re-programmable at your authorized dealer to accommo-
date the customer selected wheel/tire combinations rec-
ommended by DaimlerChrysler Corporation.CAUTION!
The TPMS has been optimized for the original
equipment tires and wheels. TPMS pressures have
been established for the tire size equipped on your
vehicle. Undesirable system operation or sensor
damage may result when using replacement equip-
ment that is not of the same size, type, and/or style.
After-market wheels can cause sensor damage. Do
not use tire sealant from a can, or balance beads if
your vehicle is equipped with a TPMS, as damage to
the sensors may result.
298 STARTING AND OPERATING

CAUTION!
After inspecting or adjusting the tire pressure al-
ways reinstall the valve stem cap. This will prevent
moisture and dirt from entering the valve stem,
which could damage the wheel rim sensor.
NOTE:
•The TPMS can inform the driver of a low tire pressure
condition.
•The TPMS is not intended to replace normal tire care
and maintenance, nor to provide warning of a tire
failure or condition.
•The TPMS should not be used as a tire pressure gauge
while adjusting your tire pressure.
Premium System
The Tire Pressure Monitor System (TPMS) uses wireless
technology with wheel rim mounted electronic sensors to
monitor tire pressure levels. Sensors mounted to each
wheel as part of the valve stem transmit tire pressure
readings to the Receiver Module. The wheel sensors
monitor tire pressure, and status for all four active road
tires and the spare tire. The spare tire pressure is moni-
tored, but not displayed.
NOTE:It is particularly important, for you to check the
tire pressure in all of your tires regularly and to maintain
the proper pressure.
The “Tire Pressure Monitoring Telltale Light” will
illuminate in the instrument cluster, and an au-
dible chime will be activated when one or more
tire pressures is low. The “Tire Pressure Monitoring
Telltale Light” will flash on and off for 10 to 60 seconds
STARTING AND OPERATING 299
5

when a system fault is detected. The flash cycle will
repeat every ten minutes or until the fault condition is
removed and reset.
The Tire Pressure Monitor System (TPMS) consists of the
following components:
•Receiver Module
•5 Wheel Sensors (including Full Size Spare Tire)
•4 Wheel Sensor Trigger Modules
•Tire Pressure Monitoring System Display Messages in
the EVIC
•Tire Pressure Monitoring Telltale Light
The system consists of tire pressure monitoring sensors
attached to each wheel through the valve stem mounting
hole, a central receiver module, Wheel Sensor Trigger
Modules mounted in three of the four wheel wells,various Tire Pressure Monitoring System Display Mes-
sages in the EVIC, and a “Tire Pressure Monitoring
Telltale Light.” A sensor shall be installed in the spare
wheel if the vehicle is equipped with a matching full size
spare wheel and tire assembly.
NOTE:For vehicles with optional wheel/tire sizes and
significantly different tire placard pressures, the placard
pressure value and the low-pressure threshold value is
re-programmable at your authorized dealer to accommo-
date the customer selected wheel/tire combinations rec-
ommended by DaimlerChrysler Corporation.
The followingwarningswill cause a text message to be
displayed, an audible chime to sound and the “Tire
Pressure Monitoring Telltale Light” to illuminate. The
audible chime will occur once every ignition cycle for
eachwarningdetected. The “Tire Pressure Monitoring
300 STARTING AND OPERATING

Telltale Light” will illuminate continuously (solid) and
shall remain illuminated until the warning condition is
removed/reset.
NOTE:The “Tire Pressure Monitoring Telltale Light”
will only illuminate for the four active road tires. A low
spare tire pressure will not cause the “Tire Pressure
Monitoring Telltale Light” to illuminate
When the appropriate conditions exist, the Electronic
Vehicle Information Center (EVIC) displays the following
messages.
LEFT FRONT, LEFT REAR, RIGHT FRONT,
RIGHT REAR, SPARE LOW PRESSURE
One or more of these messages will be displayed in the
EVIC if a low tire pressure condition exists in one or more
tires.Inspect all tires for proper inflation pressure, once the
proper tire pressure has been set, the TPMS will reset
automatically when the vehicle has been driven for at
least 2 minutes at or above 15 mph (24 km/h).
CHECK TPM SYSTEM
See your authorized dealer when this message appears in
the EVIC. This message indicates that a system fault
condition has been detected.
STARTING AND OPERATING 301
5

CAUTION!
The TPMS has been optimized for the original
equipment tires and wheels. TPMS pressures have
been established for the tire size equipped on your
vehicle. Undesirable system operation or sensor
damage may result when using replacement equip-
ment that is not of the same size, type, and/or style.
After-market wheels can cause sensor damage. Do
not use tire sealant from a can, or balance beads if
your vehicle is equipped with a TPMS, as damage to
the sensors may result.
CAUTION!
After inspecting or adjusting the tire pressure al-
ways reinstall the valve stem cap. This will prevent
moisture and dirt from entering the valve stem,
which could damage the wheel rim sensor.
NOTE:
•The TPMS can inform the driver of a low tire pressure
condition.
•The TPMS is not intended to replace normal tire care
and maintenance, nor to provide warning of a tire
failure or condition.
•The TPMS should not be used as a tire pressure gauge
while adjusting your tire pressure.
302 STARTING AND OPERATING

Dimmer Switch, Headlight.............122,126
Electronic Stability Program (ESP)
Indicator........................140,180,183
Electronic Throttle Control Warning......... 184
Fog .............................126,185
Four-Wheel Drive Indicator............... 183
Fuses............................... 381
Hazard Warning Flasher................. 330
Headlight Switch...................... 122
Headlights On With Wipers............... 123
High Beam Indicator.................... 178
Illuminated Entry....................... 18
Instrument Cluster..................122,125
Interior..........................120,125
Lights On Reminder.................... 125
Low Fuel............................ 185
LowTire ............................ 181
Malfunction Indicator (Check Engine)........ 178
Oil Pressure.......................... 180Passing............................. 126
Reading............................. 121
Seat Belt Reminder..................... 183
Security Alarm (Theft Alarm).............. 180
Service Engine Soon (Malfunction Indicator) . . . 178
SmartBeams.......................... 124
Tire Pressure Monitoring (TPMS)........... 181
Tow/Haul Indicator.................... 183
Traction Control....................140,180
Turn Signal........................122,126
VanityMirror .......................... 82
Voltage............................. 185
Load Floor, Cargo....................... 166
Loading Vehicle
Tires ............................... 285
Locks................................. 18
Automatic Door........................ 20
Child Protection........................ 19
Door................................ 18
428 INDEX

Inflation Pressures..................... 290
Jacking............................. 332
LifeofTires .......................... 294
Load Capacity.....................285,286
Pressure Monitor System (TPMS)........... 297
Pressure Warning Light.................. 181
Quality Grading....................... 417
Radial.............................. 293
Replacement......................... 295
Rotation............................. 304
Safety............................ 71,281
Sizes ............................... 282
Spare Tire........................... 333
Spinning ............................ 293
Tread Wear Indicators................... 294
Wheel Mounting....................... 337
Tongue Weight/Trailer Weight.............. 316
Torque Converter Clutch.................. 262
Tow Hooks, Emergency................... 340Tow/Haul Indicator Light................. 183
Towing ............................312,341
Disabled Vehicle....................... 341
Guide .............................. 315
Recreational.......................... 323
Weight .............................. 315
Traction Control......................... 133
Traction Control Light.................... 180
TrailerTowing .......................... 312
Cooling System Tips.................... 322
Hitches............................. 314
Minimum Requirements................. 317
Trailer and Tongue Weight................ 316
Wiring .............................. 320
TrailerTowingGuide ..................... 315
TrailerWeight .......................... 315
Transfer Case........................... 375
Maintenance.......................... 375
INDEX 435
10
