headlights JEEP COMMANDER 2007 1.G User Guide

Sound Horn With Lock?
When this feature is selected a short horn sound will
occur when the remote keyless entry “Lock” button is
pressed. This feature may be selected with or without the
flash lights on lock/unlock feature. Pressing the STEP
button when in this display will select “Yes” or “No.”
Flash Lights With Lock?
When this feature is selected, the front and rear turn
signals will flash when the doors are locked or unlocked
using the remote keyless entry transmitter. This feature
may be selected with or without the sound horn on lock
feature selected. Pressing the STEP button when in this
display will select “Yes” or “No.”
Headlamp Delay
When this feature is selected the driver can choose, when
exiting the vehicle, to have the headlamps remain on for
30, 60, or 90 seconds, or not remain on. Pressing the STEP
button when in this display will select 30, 60, 90, or OFF.
Illuminated Approach?
When this feature is selected the driver can choose, when
entering the vehicle, to have the headlamps come on for 30,
60, or 90 seconds, or not come on at all. Pressing the STEP
button when in this display will select 30, 60, 90, or OFF.
Auto Headlamp Low/High Beams? (Available with
SmartBeam Only)
When this feature is selected and the headlight switch
has been moved to the A (Auto) position, the headlights
will automatically switch from high to low beams when
approaching a vehicle. Pressing the STEP button when in
this display will select “Low Beam” or “Low/High
Beam.” Refer to “Lights — SmartBeams” in Section 3 of
this manual.
NOTE:System will activate at or above 20 mph (32
km/h).
UNDERSTANDING YOUR INSTRUMENT PANEL 189
4

Headlamps On With Wipers? (Available with Auto
Headlights Only)
When this feature is selected and the headlight switch
has at least once been moved to the A (Auto) position, the
headlights will turn on when the wipers are turned on.
The headlights will also turn off when the wipers are
turned off if they were turned on in this way. Pressing the
STEP button when in this display will select “Yes” or
“No.”
NOTE:Turning the headlights on during the daytime
causes the instrument panel lights to dim. To increase the
brightness, refer to “Lights” in Section 3 of this manual.
Front Wipers Rain Sense? (Available with Rain
Sensing Wipers Only)
Pressing the STEP button when in this display will select
“Manual” or “Rain Sense.”
Service Interval
When this feature is selected a service interval between
2,000 (3 200 km) and 6,000 miles (10 000 km) in 500 mile
(800 km) increments may be selected. Pressing the STEP
button when in this display will select distances between
2,000 (3 200 km) and 6,000 miles (10 000 km) in 500 mile
(800 km) increments.
Reset Service Distance (Displays Only if Service
Interval was Changed)
When this feature is selected the current accumulated
service distance can be reset to the newly selected service
interval. Pressing the STEP button when in this display
will select “Yes” or “No.”
190 UNDERSTANDING YOUR INSTRUMENT PANEL

Leather Seat Care & Cleaning
MoparTotal Clean is specifically recommended for
leather upholstery.
Your leather upholstery can be best preserved by regular
cleaning with a damp soft cloth. Small particles of dirt
can act as an abrasive and damage the leather upholstery
and should be removed promptly with a damp cloth.
Stubborn soils can be removed easily with a soft cloth
and MoparTotal Clean. Care should be taken to avoid
soaking your leather upholstery with any liquid. Please
do not use polishes, oils, cleaning fluids, solvents, deter-
gents, or ammonia based cleaners to clean your leather
upholstery. Application of a leather conditioner is not
required to maintain the original condition.WARNING!
Do not use volatile solvents for cleaning purposes.
Many are potentially flammable, and if used in
closed areas they may cause respiratory harm.
Cleaning Headlights
Your vehicle has plastic headlights that are lighter and
less susceptible to stone breakage than glass headlights.
Plastic is not as scratch resistant as glass and therefore
different lens cleaning procedures must be followed.
To minimize the possibility of scratching the lenses and
reducing light output, avoid wiping with a dry cloth. To
remove road dirt, wash with a mild soap solution fol-
lowed by rinsing.
Do not use abrasive cleaning components, solvents, steel
wool or other aggressive material to clean the lenses.
MAINTAINING YOUR VEHICLE 391
7

REPLACEMENT BULBS
Interior Lights Bulb Type
Glove Box Light......................... 194
Grab Handle Light................L002825W5W
Overhead Console Reading Lights..........VT4976
Rear Cargo Light.......................214–2
Visor Vanity Light.....................V26377
Underpanel Courtesy Lights................. 906
Instrument Cluster (General Illumination)....... 103
Telltale/Hazard Light...................... 74
* Available only from authorized dealers.Exterior Lights Bulb Type
Backup Lights.........................3057K
Front Fog Lights........................9145
Front Park/Turn Light...................3157K
Front Side Marker.......................2825
Headlights (Low Beam)...................9006
Headlights (High Beam)...................9005
Rear License Plate Light.................... 168
Rear Stop/Tail Lights....................3057K
Rear Turn/Tail Lights (2)..................3057
NOTE:Numbers refer to commercial bulb types that
can be purchased from your authorized dealer.
If a bulb needs to be replaced, visit your authorized
dealer or refer to the applicable Service Manual.
MAINTAINING YOUR VEHICLE 401
7

ABS (Anti-Lock Brake System)............177,275
Adding Fuel........................... 314
Adding Washer Fluid..................... 167
Adjustable Pedals....................... 130
Air Cleaner, Engine (Engine Air Cleaner Filter) . . . 366
Air Conditioner Maintenance............... 371
Air Conditioning........................ 235
Air Conditioning, Operating Tips............ 244
Air Conditioning, Rear Zone................ 242
Air Conditioning Refrigerant............... 372
Air Conditioning System.................. 235
Air Filter.............................. 366
Air Pressure, Tires....................... 289
Airbag................................ 46
Airbag Deployment....................... 53
Airbag Light.......................55,69,177
Airbag Maintenance....................... 54
Alarm (Security Alarm).................18,178
Alarm System (Security Alarm)............... 18Alignment and Balance................... 294
Alterations/Modifications, Vehicle............. 9
Antenna, Satellite Radio................... 230
Antifreeze (Engine Coolant)................ 402
Disposal............................ 379
Anti-Lock Brake System (ABS)............135,275
Anti-Lock Warning Light.................. 177
Anti-Theft System.....................18,178
Appearance Care........................ 388
Auto Down Power Windows................ 30
Automatic Dimming Mirror................. 77
Automatic Door Locks..................... 27
Automatic Headlights.................... 120
Automatic Temperature Control (ATC)......... 236
Automatic Transmission................256,385
Adding Fluid......................... 386
Fluid and Filter Changes................. 385
Fluid Level Check...................... 385
Fluid Type........................... 385
438 INDEX

System Hoses......................... 381
Tank Capacity........................ 402
Fuel, Flexible.............See Flexible Fuel Vehicles
Fuel System Caution................310,315,316
Fuses................................ 393
Garage Door Opener (HomeLink) ........... 151
Gas Cap (Fuel Filler Cap)............314,316,359
Gasoline (Fuel)......................... 307
Gasoline, Reformulated................... 308
Gasoline/Oxygenate Blends................ 308
Gauges
Coolant Temperature.................... 180
Fuel................................ 182
Speedometer......................... 176
Tachometer.......................... 178
Gear Ranges........................... 257
General Information....................23,306
Glass Cleaning.......................... 392Gross Axle Weight Rating.................. 320
Gross Vehicle Weight Rating................ 319
GVWR............................... 317
Hands-Free Phone (UConnect™).............. 80
Hazard Warning Flasher................... 340
Head Restraints......................... 106
Head Rests............................ 106
Headlights............................ 120
Cleaning............................ 391
On With Wipers....................... 121
Heated Mirrors.......................... 79
Heated Seats........................... 106
Heater, Engine Block..................... 255
High Beam Indicator..................... 176
High Beam/Low Beam Select (Dimmer) Switch . . 124
Hitches
Trailer Towing........................ 323
Holder, Cup........................... 163
444 INDEX

LATCH
(Lower Anchors and Tether for CHildren).....61,63
Lead Free Gasoline...................... 307
Leaks, Fluid............................ 70
Life of Tires............................ 293
Liftgate................................ 32
Liftgate Flipper Glass...................... 33
Liftgate Window Wiper/Washer............. 166
Lights..............................70,119
Airbag............................55,177
Alarm............................... 69
Anti-Lock........................... 177
Automatic Headlights................... 120
Battery Saver......................... 120
Brake Assist Warning.................143,181
Brake Warning........................ 176
Courtesy/Reading..................... 125
Cruise.............................. 182
Daytime Running...................... 123Dimmer Switch, Headlight............. 119,124
Electronic Stability Program (ESP)
Indicator........................143,178,181
Electronic Throttle Control Warning......... 182
Fog .............................123,183
Four-Wheel Drive Indicator............... 181
Fuses............................... 393
Hazard Warning Flasher................. 340
Headlight Switch...................... 120
Headlights On With Wipers............... 121
High Beam Indicator.................... 176
Illuminated Entry....................... 19
Instrument Cluster..................120,122
Interior..........................122,125
Lights On Reminder.................... 123
Low Fuel............................ 183
LowTire ............................ 179
Malfunction Indicator (Check Engine)........ 176
Oil Pressure.......................... 178
446 INDEX
