CavityCartridge
FuseMini
FuseDescription
9 20 Amp
YellowPwr Outlet (B+)
10 10 Amp
RedFinal Drive Control
Module (FDCM),
Heater Ventilation,
Air Conditioning
(HVAC), Switch
Bank, Transfer Case
Switch, O/H, Heater
Ventilation, Air Con-
ditioning (HVAC)
Relay, Rear Park As-
sist
11 Spare
(B+)CavityCartridge
FuseMini
FuseDescription
12 10 Amp
RedDoor Mods, Mem.
Sw, O/H Lamps, IP
Courtesy Lamps,
Glove Box Lamp (B+)
13 10 Amp
RedAutowipe (R/A)
14 20 Amp
YellowCigar Ltr (R/A)
15 10 Amp
RedTire Pressure Trans-
ducers (R/O)
16 10 Amp
RedSteering Control
Module (SCM), Diag.
Connector, Cluster
(B+)
17 15 Amp
BlueFlipper Glass (B+)
394 MAINTAINING YOUR VEHICLE

CavityCartridge
FuseMini
FuseDescription
19 Spare
(R/S)
20 10 Amp
RedSentry Key Remote
Entry Module
(SKREEM), Cluster
(R/S)
21 Spare
(Acc De-
lay)
22 15 Amp
BlueRear Wiper (B+)CavityCartridge
FuseMini
FuseDescription
24 10 Amp
RedPower Distribution
Center (PDC) Relays,
Final Drive Control
Module (FDCM),
Front Control Module
(FCM) (R/S), A580
(R/S)
25 10 Amp
RedShifter Assy (BTSI),
Trans. Case Switch,
ESP/ABS, Brake
Supp Rly Coil (R/S)
MAINTAINING YOUR VEHICLE 395
