Page 172 of 408
vehicle placard or tire inflation pressure label, you should
determine the proper tire inflation pressure for those
tires.)
As an added safety feature, your vehicle has been
equipped with a tire pressure monitoring system (TPMS)
that illuminates a low tire pressure telltale when one or
more of your tires are significantly under-inflated. Ac-
cordingly, when the low tire pressure telltale illuminates,
you should stop and check your tires as soon as possible,
and inflate them to the proper pressure. Driving on a
significantly under-inflated tire causes the tire to over-
heat and can lead to tire failure. Under-inflation also
reduces fuel efficiency and tire tread life, and may affect
the vehicle’s handling and stopping ability.Please note that the TPMS is not a substitute for proper
tire maintenance, and it is the driver ’s responsibility to
maintain correct tire pressure, even if under-inflation has
not reached the level to trigger illumination of the TPMS
low tire pressure telltale.
The Tire Pressure Monitoring Telltale Lamp will illumi-
nate in the instrument cluster, and an audible chime will
be activated when one or more tire pressures is low. The
Tire Pressure Monitoring Telltale Lamp will flash on and
off for 60 seconds when a system fault is detected. The
flash cycle will repeat every ten minutes or until the fault
condition is removed and reset.
If this indicator comes on, the entire, PRNDL/ odometer,
display will brighten to FULL DAYTIME INTENSITY
and will not be dimmable.
172 UNDERSTANDING YOUR INSTRUMENT PANEL
Page 173 of 408
CAUTION!
The TPMS has been optimized for the original
equipment tires and wheels. TPMS pressures and
warning have been established for the tire size
equipped on your vehicle. Undesirable system op-
eration or sensor damage may result when using
replacement equipment that is not of the same size,
type, and/or style. Aftermarket wheels can cause
sensor damage. Do not use tire sealant from a can, or
balance beads if your vehicle is equipped with a
TPMS, as damage to the sensors may result.
23. Four-Wheel-Drive
This light indicates the vehicle is in 4WD.
24. Odometer/Trip Odometer
A vacuum fluorescent display indicates the total distance
the vehicle has been driven. Also, the cluster will display,replacing the odometer/trip odometer, vehicle warning
messages such as: door/gate ajar and loose gas cap.
Loose gas cap will be displayed from the Odometer/Trip
Odometer on all models.
NOTE:If vehicle is equipped with the optional Elec-
tronic Vehicle Information Center (EVIC) in the instru-
ment cluster, all warnings including “door”, and “gATE”
will only be displayed in the EVIC display. For additional
information, refer to “Electronic Vehicle Information Cen-
ter — If Equipped” in Section 3.
U.S. federal regulations require that upon transfer of
vehicle ownership, the seller certify to the purchaser the
correct mileage that the vehicle has been driven. There-
fore, if the odometer reading is changed during repair or
replacement, be sure to keep a record of the reading
before and after the service so that the correct mileage can
be determined.
UNDERSTANDING YOUR INSTRUMENT PANEL 173
4
Page 180 of 408
Elapsed Time
Shows the total elapsed time of travel since the last reset
when the ignition switch is in the ACC position. Elapsed
time will increment when the ignition switch is in the ON
or START position.
Tire Pressure Monitor (TPM)
Refer to Section 5, “Tire Pressure Monitoring System
(TPMS) for system operation.
Personal Settings (Customer Programmable
Features)
This allows the driver to set and recall features when the
transmission is in PARK (automatic transmission) or the
vehicle is stopped (manual transmissions).
Press and release the EVIC button until Personal Settings
is displayed in the EVIC.
Use the EVIC button to display one of the following
choices:
Language
When in this display you may select different languages
for all display nomenclature, including the trip functions.
Pressing the EVIC button while in this display selects
English, Espanol, Deutsch, Italiano, or Francais depend-
ing on availability. As you continue the displayed infor-
mation will be shown in the selected language.
NOTE:UConnect™ language will not change using the
EVIC. Please refer to “Language Selection” in the
HANDS–FREE COMMUNICATION (UConnect™) — IF
EQUIPPED section of this manual for details.
Lock Doors Automatically at 15 MPH (24 Km/h)
When ON is selected all doors lock automatically when
the speed of the vehicle reaches 15 mph (24 km/h). Press
and hold the EVIC button when in this display until
“ON” or “OFF” appears to make your selection.
180 UNDERSTANDING YOUR INSTRUMENT PANEL
Page 230 of 408
Four Wheel Drive System — If Equipped......243
Parking Brake.........................244
Brake System..........................246
▫Anti-Lock Brake System (ABS) —
If Equipped.........................247
Power Steering........................250
Tire Safety Information...................251
▫Tire Markings........................251
▫Tire Identification Number (TIN)..........254
▫Tire Loading And Tire Pressure...........255
Tires — General Information...............259
▫Tire Pressure.........................259
▫Tire Inflation Pressures.................260
▫Radial-Ply Tires......................263▫Compact Spare Tire — If Equipped.........263
▫Limited Use Spare — If Equipped.........264
▫Tire Spinning........................265
▫Tread Wear Indicators..................266
▫LifeOfTire .........................266
▫Replacement Tires.....................267
▫Alignment And Balance.................268
Tire Pressure Monitoring System (TPMS) — If
Equipped............................269
▫Base Tire Pressure Monitoring System (TPMS)
Operation – If Equipped................269
▫Premium System – If Equipped...........270
▫General Information...................275
Tire Chains...........................275
230 STARTING AND OPERATING
Page 269 of 408
Improper alignment will not cause vehicle vibration.
Vibration may be a result of tire and wheel out-of-
balance. Proper balancing will reduce vibration and
avoid tire cupping and spotty wear.
TIRE PRESSURE MONITORING SYSTEM (TPMS)
— IF EQUIPPED
Base Tire Pressure Monitoring System (TPMS)
Operation – If Equipped
This is the Tire Pressure Monitoring System warn-
ing indicator located in the instrument cluster.
•The Tire Pressure Monitoring System (TPMS) will
warn the driver of a low tire pressure based on the
vehicle recommended cold placard pressure.
•The tire pressure will vary with temperature by about
1 psi (6.9 kPa) for every 12 °F (6.5 °C). This means that
when the outside temperature decreases, the tire pres-
sure will decrease. Tire pressure should always be setbased on cold inflation tire pressure. This is defined as
the tire pressure after a vehicle has not been driven for
more than 3 hours - and in outside ambient tempera-
ture. Refer to the “Tires – General Information” in this
section for information on how to properly inflate the
vehicle’s tires. The tire pressure will also increase as
the vehicle is driven - this is normal and there should
be no adjustment for this increased pressure.
•The TPM System will warn the driver of a low tire
pressure if the tire pressure falls below the low pres-
sure warning threshold for any reason, including low
temperature effects.
•The TPM System will continue to warn the driver of
low tire pressure as long as the condition exists, and
will not turn off until the tire pressure is at or above
recommended cold placard pressure. Once the low tire
pressure warning has been illuminated, the tire pres-
sure must be increased to the recommended cold
STARTING AND OPERATING 269
5
Page 270 of 408
placard pressure in order for the TPM warning lamp to
be turned off. The system will automatically update
and the TPM warning lamp will extinguish once the
updated tire pressures have been received. The vehicle
may need to be driven for up to 10 minutes above 15
mph (25 km/h) to receive this information.
For example, your vehicle may have a recommended
cold (parked for more than 3 hours) placard of 35 °F (241
kPa). If the ambient temperature is 68 °F (20 °C) and the
measured tire pressure is 30 psi (207 kPa), a temperature
drop to 20 °F (-7 °C) will decrease the tire pressure to
approximately 26 psi (179 kPa). This tire pressure is
sufficiently low enough to turn ON the “Tire Pressure
Monitoring Light”. Driving the vehicle may cause the tire
pressure to rise to approximately 30 psi (207 kPa), but the
“Tire Pressure Monitoring Light” will still be ON. In this
situation, the “Tire Pressure Monitoring Light” will turn
OFF only after the tires have been inflated to the vehicle’s
recommended cold placard pressure value.Premium System – If Equipped
The Tire Pressure Monitor System (TPMS) uses wireless
technology with wheel rim mounted electronic sensors to
monitor tire pressure levels. Sensors, mounted to each
wheel as part of the valve stem, transmit tire pressure
readings to the Receiver Module.
NOTE:It is particularly important, for you to check the
tire pressure in all of your tires regularly and to maintain
the proper pressure.
The TPMS consists of the following components:
•Receiver Module
•4 Tire Pressure Monitoring Sensors
•3 Trigger Modules (mounted in three of the four wheel
wells)
270 STARTING AND OPERATING
Page 273 of 408
If the ignition key is cycled, this sequence will repeat,
providing the system fault still exists. If the system fault
no longer exists, the Tire Pressure Monitoring Telltale
Light will no longer flash, and theCHECK TPM SYS-
TEMtext message will no longer display.
NOTE:Your system can be set to display pressure units
in PSI, kPa, or BAR.
NOTE:If your vehicle is equipped with a compact spare
wheel and tire assembly that does not have a tire pressure
monitoring sensor. Therefore, it will not be monitored by
the Tire Pressure Monitor System (TPMS). In the event
that the compact spare tire is swapped with a low
pressure road tire, the next ignition key cycle will still
show the “Tire Pressure Monitoring Lamp” to be ON, a
chime to sound, and the Electronic Vehicle Information
Center (EVIC) will still show the low tire pressure value
flashing on the graphic display. However, driving the
vehicle for up to 10 minutes above 15 mph (25 km/h) willdisplay a “CHECK TPM SYSTEM” text message on the
EVIC. This text message will then be followed by a
graphic, with “- -“ in place of the flashing low pressure
value. For every subsequent key cycle, the “Tire Pressure
Monitoring Lamp” will be ON, a chime will sound, a
“CHECK TPM SYSTEM” text message will be display in
the EVIC, and the graphic display will have “- -“ in place
of the pressure value of the spare tire location. Once the
original road tire has been properly repaired, and put
back onto the vehicle in place of the compact spare tire.
The TPMS will update the graphic display on the EVIC
with a new tire pressure value instead of “- -“, and the
“Tire Pressure Monitoring Lamp” will be OFF as long as
none of the road tire(s) are below the low pressure
warning threshold. The vehicle may need to be driven for
up to 10 minutes above 15 mph (25 km/h) to receive this
information.
STARTING AND OPERATING 273
5
Page 274 of 408
CAUTION!
The TPMS has been optimized for the original
equipment tires and wheels. TPMS pressures have
been established for the tire size equipped on your
vehicle. Undesirable system operation or sensor
damage may result when using replacement equip-
ment that is not of the same size, type, and/or style.
Aftermarket wheels can cause sensor damage. Do
not use tire sealant from a can, or balance beads if
your vehicle is equipped with a TPMS, as damage to
the sensors may result.
CAUTION!
After inspecting or adjusting the tire pressure, al-
ways reinstall the valve stem cap. This will prevent
moisture and dirt from entering the valve stem,
which could damage the wheel rim sensor.
NOTE:
•The TPMS is not intended to replace normal tire care
and maintenance, or to provide warning of a tire
failure or condition.
•The TPMS should not be used as a tire pressure gauge
while adjusting your tire pressure.
•Driving on a significantly under-inflated tire causes
the tire to overheat and can lead to tire failure.
Under-inflation also reduces fuel efficiency and tire
tread life, and may affect the vehicle’s handling and
stopping ability.
274 STARTING AND OPERATING
Page 275 of 408
•The TPMS is not a substitute for proper tire mainte-
nance, and it is the driver ’s responsibility to maintain
correct tire pressure, even if under-inflation has not
reached the level to trigger illumination of the Tire
Pressure Monitoring Telltale lamp.
•Seasonal temperature changes will affect tire pressure,
and the TPM system will monitor the actual tire
pressure in the tire.
General Information
This device complies with part 15 of the FCC rules and
RSS 210 of Industry Canada. Operation is subject to the
following conditions:
•This device may not cause harmful interference.
•This device must accept any interference received,
including interference that may cause undesired op-
eration.The tire pressure sensors are covered under one of the
following licenses:
United States.....................KR5S120123
Canada........................2671-S120123
TIRE CHAINS
Due to limited clearance, tire chains are not recom-
mended.
CAUTION!
Damage to the vehicle may result if tire chains are
used.
STARTING AND OPERATING 275
5
Page 406 of 408
Jacking............................. 301
LifeofTires .......................... 266
Load Capacity.....................255,256
Pressure Monitor System (TPMS)........... 269
Quality Grading....................... 389
Radial.............................. 263
Replacement......................... 267
Rotation............................. 276
Safety...........................251,259
Sizes ............................... 252
Snow Tires........................... 276
Spare Tire........................... 302
Spinning ............................ 265
Tread Wear Indicators................... 266
Tongue Weight/Trailer Weight.............. 289
Towing ............................... 284
Disabled Vehicle....................... 310
Guide .............................. 288
Recreational.......................... 296Weight .............................. 288
Traction .............................. 308
TrailerTowing .......................... 284
Cooling System Tips.................... 295
Hitches............................. 287
Minimum Requirements................. 290
Trailer and Tongue Weight................ 289
Wiring .............................. 293
TrailerTowingGuide ..................... 288
TrailerWeight .......................... 288
Transaxle............................. 235
Automatic.................... 12,232,235,342
Autostick............................ 239
Manual........................ 13,233,241
Operation........................... 235
Overdrive........................... 238
Selection of Lubricant................... 342
Transmission
Range Indicator....................... 171
406 INDEX
