headlight bulb JEEP COMPASS 2007 1.G Owners Manual

Move the Multi-Function Control Lever up or down and
the arrows on each side of the instrument cluster flash to
show proper operation of the front and rear turn signal
lights. You can signal a lane change by moving the lever
partially up or down without moving beyond the detent.
If either light remains on and does not flash, or there is a
very fast flash rate, check for a defective outside light
bulb. If an indicator fails to light when the lever is
moved, it would suggest that the fuse or indicator bulb is
defective.Highbeam/Lowbeam Select Switch
Push the Multi-Function Control Lever away from you to
switch the headlights to HIGH beam. Pull the Lever
toward you, to switch the headlights back to Low beam.
High Beam Control
122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

4. Oil Pressure Light
Shows low engine oil pressure. The light will come
on and remain on when the ignition switch is
turned from the OFF to the ON position, and the light
will turn off after the engine is started. If the bulb does
not come on during starting, have the system checked by
an authorized dealer.
If the light comes on and remains on while driving, stop
the vehicle and shut off the engine. DO NOT OPERATE
THE VEHICLE UNTIL THE CAUSE IS CORRECTED.
The light does not show the quantity of oil in the engine.
This can be determined using the procedure shown in
Section 7.
5. Low Fuel Light
When the fuel level drops to 2 gallons, the fuel
symbol will light and a single chime will sound.6. Speedometer
Indicates vehicle speed.
7. Airbag Light
The light comes on and remains on for 6 to 8
seconds as a bulb check when the ignition
switch is first turned ON. If the light does not
come on during starting, stays on, or comes on
while driving, have the system checked by an authorized
dealer.
8. Turn Signal Indicators
The arrows will flash in unison with the exterior
turn signal, when using the turn signal lever.
9. High Beam Indicator
This light shows that the headlights are on high
beam. Push the turn signal lever away from the
steering wheel to switch the headlights from high or low
beam.
UNDERSTANDING YOUR INSTRUMENT PANEL 167
4

VEHICLE STORAGE
If you will not be using your vehicle for more than 21
days you may want to take steps to preserve your battery.
You may:
•Disengage the mini fuse in the Power Distribution
Center labeled IOD (Ignition Off-Draw).
•Or, disconnect the negative cable from the battery.
REPLACEMENT BULBS
All the inside bulbs are brass or glass wedge base.
Aluminum base bulbs are not approved and should not
be used for replacement.LIGHT BULBS — Interior Bulb Number
Front Header Lamp......................T578
Center Dome Lamp......................T578
Rear Cargo/Flashlight.................8–A35LF
LIGHTS BULBS — Outside Bulb No.
Low Beam/High Beam Headlight............ H13
Front Park/Turn Signal/Side Marker Light. . . 3157AK
Front Fog Light.........................9145
Center High Mounted Stop Light
(CHMSL)...................... LEDAssembly
Rear Tail/Stop..........................3157
Rear Turn Signal......................3157AK
Backup Light..................... W16W(921)
License Light.......................... W5W
354 MAINTAINING YOUR VEHICLE

Key, Programming........................ 16
Key, Replacement........................ 15
Key, Sentry (Immobilizer)................... 14
Key-In Reminder......................... 14
Keyless Entry System (Sedan)................ 24
Keys................................. 12
Lane Change and Turn Signals...........167,358
Lap/Shoulder Belts....................... 37
Latches
Hood............................... 123
Lead Free Gasoline...................... 277
LifeofTires ............................ 266
Liftgate (Sedan).......................... 32
Liftgate Window Wiper/Washer............. 157
LightBulbs ............................ 354
Lights.............................. 74,118
Airbag.......................... 62,74,167
Back-Up............................. 358Brake Warning........................ 169
Bulb Replacement...................... 355
Cargo .............................. 152
Center Mounted Stop................... 361
Daytime Running...................... 120
Dimmer Switch, Headlight................ 119
Electronic Stability Program (ESP) Indicator . . . 142
Engine Temperature Warning.............. 168
Fog ..........................121,174,357
Headlight Switch...................... 119
Headlights........................... 119
High Beam Indicator.................... 167
Instrument Cluster..................... 119
License............................. 360
Lights On Reminder.................... 120
Low Fuel............................ 167
Malfunction Indicator (Check Engine)........ 174
Map Reading......................... 118
Oil Pressure.......................... 167
INDEX 399
10
