CAUTION!
Failure to follow these cautions can cause damage to
the heating elements:
•Use care when washing the inside of the rear
window. Do not use abrasive window cleaners on
the interior surface of the window. Use a soft cloth
and a mild washing solution, wiping parallel to the
heating elements. Labels can be peeled off after
soaking with warm water.
• Do not use scrapers, sharp instruments, or abrasive
window cleaners on the interior surface of the
window.
• Keep all objects a safe distance from the window.
ROOF LUGGAGE RACK — IF EQUIPPED
The crossbars and siderails are designed to carry the
cargo on vehicles equipped with a luggage rack. The load
must not exceed 150 lbs (68 kg), and should be uniformly
distributed over the luggage rack crossbars.
NOTE: If not equipped with crossbars, your authorized
dealer can order and install MOPAR crossbars built
specifically for this roof rack system.
Distribute cargo weight evenly on the luggage rack
crossbars. The luggage rack does not increase the total
load carrying capacity of the vehicle. Be sure the total
load of cargo inside the vehicle plus that on the external
rack does not exceed the maximum vehicle load capacity.
The crossbars must also be secured in one of the seven
detent positions marked with an arrow on the siderails to
prevent movement. To move the crossbars, loosen the
thumb screws located at the upper edge of each crossbar
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 209

approximately eight turns, then move the crossbar to the
desired position, keeping the crossbars perpendicular to
the luggage rack side rails. Once the crossbar is in one of
the seven detent positions, retighten the thumb screws to
lock the crossbar into position.
NOTE:
•To help control wind noise when the crossbars are not
in use, place the front crossbar in the first detent from
the front of the vehicle and the rear crossbar in the
second detent from the rear of the vehicle.
• If the rear crossbar (or any metallic object) is placed
over the satellite radio antenna (if equipped), you may
experience interruption of satellite radio reception. For
improved satellite radio reception, place the rear cross-
bar in the second detent from the rear of the vehicle
when not in use.CAUTION!
• To prevent damage to the roof of your vehicle, DO
NOT carry any loads on the luggage rack without
crossbars installed. The load should be secured and
placed on top of the crossbars, not directly on the
roof. If it is necessary to place the load on the roof,
place a blanket or some other protection between
the load and the roof surface.
• To avoid damage to the luggage rack and vehicle,
do not exceed the maximum luggage rack load
capacity of 150 lb (68 kg). Always distribute heavy
loads as evenly as possible and secure the load
appropriately.
• Long loads which extend over the windshield, such
as wood panels or surfboards, or loads with large
frontal area should be secured to both the front and
rear of the vehicle.
(Continued)
210 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

CAUTION!(Continued)
•Travel at reduced speeds and turn corners carefully
when carrying large or heavy loads on the roof
rack. Wind forces, due to natural causes or nearby
truck traffic, can add sudden upward lift to a load.
This is especially true on large flat loads and may
result in damage to the cargo or your vehicle.
WARNING!
Cargo must be securely tied before driving your
vehicle. Improperly secured loads can fly off the
vehicle, particularly at high speeds, resulting in per-
sonal injury or property damage. Follow the roof rack
cautions when carrying cargo on your roof rack.
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 211

UNDERSTANDING YOUR INSTRUMENT PANEL
CONTENTS
INSTRUMENT PANEL FEATURES ..........217
 INSTRUMENT CLUSTER .................218
 WARNING AND INDICATOR LIGHTS .......223
▫ Red Telltale Indicator Lights ..............224
▫ Yellow Telltale Indicator Lights ............233
▫ Green Telltale Indicator Lights ............244
▫ Blue Telltale Indicator Light ..............246
▫ White Telltale Indicator Light .............246
 MINI-TRIP COMPUTER — IF EQUIPPED .....247
▫ Control Buttons ...................... .248
ELECTRONIC VEHICLE INFORMATION CENTER
(EVIC) — IF EQUIPPED ..................249
▫ Engine Oil Change Indicator System — If
Equipped .......................... .252
▫ EVIC Functions ...................... .253
▫ Compass/Temperature/Audio ............253
▫ Average Fuel Economy ..................254
▫ Distance To Empty (DTE) ................254
▫ Tire Pressure Monitor (TPM) ..............254
▫ Elapsed Time ....................... .2544

▫Display Units Of Measure In .............255
 Personal Settings (Customer-Programmable
Features) ............................ .255
▫ Language .......................... .255
▫ Auto Lock Doors ..................... .256
▫ Auto Unlock On Exit ...................256
▫ RKE Unlock ........................ .256
▫ Flash Lamps With Lock .................256
▫ Sound Horn With Lock .................257
▫ Headlamp Off Delay ...................257
▫ Headlamps with Wipers (Available with Auto
Headlights Only) ..................... .257
▫ Key Off Power Delay ...................257
▫ Illuminated Approach ..................258 ▫
Hill Start Assist (HSA) — If Equipped .......258
▫ Display Units In ..................... .258
▫ Automatic Compass Calibration ...........258
▫ Manual Compass Calibration .............259
▫ Compass Variance ....................259
 UCONNECT 230 – AM/FM STEREO RADIO AND
6–DISC CD/DVD CHANGER (MP3/WMA AUX
JACK) ............................. .261
▫ Operating Instructions — Radio Mode .......261
▫ Operation Instructions — DISC Mode For CD And
MP3/WMA Audio Play, DVD – Video .......270
▫ LIST Button — DISC Mode For MP3/WMA
Play .............................. .275
▫ INFO Button — DISC Mode For MP3/WMA
Play .............................. .275
214 UNDERSTANDING YOUR INSTRUMENT PANEL

▫Uconnect (Satellite Radio) — If Equipped . . . .277
 UCONNECT 430/430N CD/DVD/HDD/NAV — IF
EQUIPPED .......................... .282
▫ Operating Instructions (Voice Command System)
— If Equipped ...................... .282
▫ Operating Instructions (Uconnect Phone) — If
Equipped .......................... .282
 UCONNECT 130 ...................... .282
▫ Operating Instructions — Radio Mode ......282
▫ Operation Instructions — CD MODE For CD And
MP3 Audio Play ..................... .286
▫ Notes On Playing MP3 Files .............288
▫ Operation Instructions — Auxiliary Mode . . . .291
 UCONNECT 130 WITH SATELLITE RADIO . . .292 ▫
Operating Instructions — Radio Mode ......292
▫ Operation Instructions — CD MODE For CD And
MP3 Audio Play ..................... .298
▫ Notes On Playing MP3 Files .............300
▫ LIST Button — CD Mode For MP3 Play ......303
▫ INFO Button — CD Mode For MP3 Play .....303
▫ Uconnect (Satellite Radio) — If Equipped . . . .304
 iPod/USB/MP3 CONTROL — IF EQUIPPED . . .309
▫ Connecting The iPod Or External USB
Device ............................ .309
▫ Using This Feature .....................310
▫ Controlling The iPod Or External USB Device
Using Radio Buttons ...................310
▫ Play Mode ..........................311
4
UNDERSTANDING YOUR INSTRUMENT PANEL 215

▫List Or Browse Mode ...................312
▫ Bluetooth Streaming Audio (BTSA) .........314
 STEERING WHEEL AUDIO CONTROLS ......315
▫ Radio Operation ..................... .316
▫ CD Player .......................... .317
 CD/DVD DISC MAINTENANCE ...........317
RADIO OPERATION AND MOBILE DEVICES . .318
 CLIMATE CONTROLS ...................318
▫ Manual Heating And Air Conditioning ......318
▫ Automatic Temperature Control (ATC) — If
Equipped .......................... .323
▫ Operating Tips ...................... .329
216 UNDERSTANDING YOUR INSTRUMENT PANEL

INSTRUMENT PANEL FEATURES
1 — Air Outlet5 — Storage Bin9 — Heated Seat Switch – If Equipped
2 — Demisters 6 — Glove Compartment10 — Hazard Warning Flasher
3 — Instrument Cluster 7 — Climate Controls11 — ESC OFF Switch – If Equipped
4 — Radio 8 — Power Outlet12 — Heated Seat Switch – If Equipped
4
UNDERSTANDING YOUR INSTRUMENT PANEL 217

INSTRUMENT CLUSTER
