8W-60 POWER WINDOWS
Component Page
Body Control Module............... 8W-60-2, 3
Diagnostic Junction Port............. 8W-60-2, 3
Driver Door Module............ 8W-60-2, 3, 4, 5
Driver Front Power Window Motor..... 8W-60-2, 3
Driver Rear Power Window Motor....... 8W-60-5
Driver Rear Power Window Switch....... 8W-60-5
Fuse 12.......................... 8W-60-2, 3
G300........................ 8W-60-2, 4, 5, 6Component Page
G301........................ 8W-60-3, 4, 5, 6
Junction Block.................. 8W-60-2, 3, 4
Passenger Door Module.......... 8W-60-2, 3, 4, 6
Passenger Front Power
Window Motor................... 8W-60-2, 3
Passenger Rear Power Window Motor.... 8W-60-6
Passenger Rear Power Window Switch.... 8W-60-6
Power Distribution Center........... 8W-60-2, 3
WJ8W-60 POWER WINDOWS 8W - 60 - 1

ASH RECEIVER LAMP - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 Z300 20BK GROUND
2 E2 20OR PANEL LAMPS DRIVER
AUTOMATIC DAY/NIGHT MIRROR - BLACK 7 WAY
CAV CIRCUIT FUNCTION
1 G5 20BK/LG FUSED IGNITION SWITCH OUTPUT (RUN-START)
2 Z150 20BK GROUND
3 L1 20BK/VT BACK-UP LAMP FEED
4 P112 20BK/WT AUTO DAY/NIGHT MIRROR (+)
5 P114 20BK/YL AUTO DAY/NIGHT MIRROR (-)
6- -
7- -
AUTOMATIC HEADLAMP LIGHT SENSOR/VTSS LED - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 L109 20WT ULTRALIGHT SENSOR SIGNAL
2 L110 20BK/YL ULTRALIGHT SENSOR RETURN
3 G69 20BK/OR VTSS INDICATOR DRIVER
4 M1 20PK FUSED B(+)
AUTOMATIC ZONE CONTROL MODULE C1 (AZC) - WHITE 16 WAY
CAV CIRCUIT FUNCTION
1 C102 20TN/BK MODE DOOR DRIVER (B)
2- -
3 C32 20GY/DB RECIRCULATION DOOR DRIVER (A)
4 C100 20YL/DB RECIRCULATION DOOR DRIVER (B)
5- -
6 C79 20BK/WT FUSED REAR WINDOW DEFOGGER RELAY OUTPUT
7- -
8 Z118 20BK GROUND
9 C35 20DG/YL MODE DOOR DRIVER (A)
10 C33 20DB/RD DRIVER BLEND DOOR DRIVER (A)
11 - -
12 - -
13 - -
14 C81 20LB/WT REAR WINDOW DEFOGGER SWITCH SENSE
15 - -
16 - -
WJ8W-80 CONNECTOR PIN-OUT 8W - 80 - 9

DRIVER DOOR LOCK MOTOR/AJAR SWITCH - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 G75 18TN/RD DRIVER DOOR AJAR SWITCH SENSE
2 Z243 12BK (RHD) GROUND
2 Z28 12BK (LHD) GROUND
3 P34 18PK/BK DRIVER DOOR UNLOCK DRIVER
4 P35 18OR/BK DRIVER DOOR LOCK DRIVER
DRIVER DOOR MODULE C1 - WHITE 15 WAY
CAV CIRCUIT FUNCTION
1 A146 12OR/WT FUSED B(+)
2 Q23 16RD/WT DRIVER REAR WINDOW DRIVER (DOWN)
3 Q13 16DB DRIVER REAR WINDOW DRIVER (UP)
4 Z28 12BK (LHD) GROUND
4 Z234 12BK (RHD) GROUND
5 P35 18OR/BK DRIVER DOOR LOCK DRIVER
6- -
7 P34 18PK/BK DRIVER DOOR UNLOCK DRIVER
8 D30 20VT/YL (JAPAN) DIAGNOSTIC OUT
9 D25 20YL/VT PCI BUS
10 G73 20LG/OR DRIVER CYLINDER LOCK SWITCH SENSE
11 G75 18TN/RD DRIVER DOOR AJAR SWITCH SENSE
12 E21 20OR/RD DRIVER REAR DOOR SWITCH ILLUMINATION
13 Q11 16LB DRIVER WINDOW DRIVER (UP)
14 - -
15 Q21 16WT DRIVER WINDOW DRIVER (DOWN)
DRIVER DOOR MODULE C2 - BLACK 12 WAY
CAV CIRCUIT FUNCTION
1 P95 20OR MIRROR HORIZONTAL DRIVER
2 C118 20BK/WT MIRROR HEATER GROUND
3 P64 20VT MIRROR VERTICAL POSITION SIGNAL
4 P69 20GY MIRROR SENSOR GROUND
5 P65 20DG MIRROR HORIZONTAL POSITION SIGNAL
6 C117 20BK MIRROR HEATER 12 VOLT SUPPLY
7 P91 20WT MIRROR COMMON DRIVER
8 P93 20RD MIRROR VERTICAL DRIVER
9 M21 20PK/DG COURTESY LAMP DRIVER
10 P110 20YL (BUILT-UP-EXPORT) FOLDING MIRROR RETURN
11 P99 20DB (BUILT-UP-EXPORT) FOLDING MIRROR FEED
12 L121 20BK/RD COURTESY LAMP GROUND
8W - 80 - 68 8W-80 CONNECTOR PIN-OUTWJ

DRIVER POWER SEAT SWITCH (MIDLINE/PREMIUM) - GREEN 10 WAY
CAV CIRCUIT FUNCTION
1 Z1 16BK GROUND
2 P43 16GY/LB (MIDLINE/PREMIUM I) DRIVER SEAT RECLINER UP DRIVER
2 P43 20GY/LB (PREMIUM II/III) RECLINER UP SWITCH SENSE
3 P17 16RD/YL (MIDLINE/PREMIUM I) DRIVER SEAT HORIZONTAL REARWARD DRIVER
3 P17 20RD/YL (PREMIUM II/III) DRIVER SEAT HORIZONTAL REARWARD SWITCH
SENSE
4 P41 16GY/WT (MIDLINE/PREMIUM I) DRIVER SEAT RECLINER DOWN DRIVER
4 P41 20GY/WT (PREMIUM II/III) RECLINER DOWN SWITCH SENSE
5 F35 16RD (MIDLINE/PREMIUM I) FUSED B(+)
5 P9 20RD/LB (PREMIUM II/III) SEAT SWITCH B(+) SUPPLY
6 P15 16YL/LB (MIDLINE/PREMIUM I) DRIVER SEAT HORIZONTAL FORWARD DRIVER
6 P15 20YL/LB (PREMIUM II/III) DRIVER SEAT HORIZONTAL FORWARD SWITCH
SENSE
7 P19 16YL/LG (MIDLINE/PREMIUM I) SEAT FRONT UP SWITCH SENSE
7 P21 20RD/LG (RHD PREMIUM II/III) SEAT FRONT DOWN SWITCH SENSE
7 P19 20YL/LG (PREMIUM II/III) SEAT FRONT UP SWITCH SENSE
8 P13 20RD/WT (RHD PREMIUM II/III) DRIVER SEAT REAR DOWN DRIVER
8 P11 20YL/WT (PREMIUM II/III) SEAT REAR UP SWITCH SENSE
8 P11 16YL/WT (MIDLINE/PREMIUM I) DRIVER SEAT REAR UP DRIVER
9 P13 20RD/WT (PREMIUM II/III) SEAT REAR DOWN SWITCH SENSE
9 P13 16RD/WT (MIDLINE/PREMIUM I) DRIVER SEAT REAR DOWN DRIVER
9 P11 20YL/WT (RHD PREMIUM II/III) DRIVER SEAT REAR UP DRIVER
10 P21 16RD/LG (MIDLINE/PREMIUM I) SEAT FRONT DOWN SWITCH SENSE
10 P21 20RD/LG (PREMIUM II/III) SEAT FRONT DOWN SWITCH SENSE
10 P19 20YL/LG (RHD PREMIUM II/III) SEAT FRONT UP SWITCH SENSE
DRIVER REAR POWER WINDOW MOTOR - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 Q124 16DG/WT WINDOW DRIVER (DOWN)
2 Q114 16GY/WT WINDOW DRIVER (UP)
DRIVER REAR POWER WINDOW SWITCH - BLUE 6 WAY
CAV CIRCUIT FUNCTION
1 Q14 16GY DRIVER REAR WINDOW DRIVER (UP)
2 Q114 16GY/WT WINDOW DRIVER (UP)
3 E21 20OR/RD DRIVER REAR DOOR SWITCH ILLUMINATION
4 Q24 16DG DRIVER REAR WINDOW DRIVER (DOWN)
5 Q124 16DG/WT WINDOW DRIVER (DOWN)
6 Z1 16BK GROUND
WJ8W-80 CONNECTOR PIN-OUT 8W - 80 - 73

INTAKE PORT SWIRL ACTUATOR (DIESEL) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 Z18 18BK GROUND
2 F15 18RD/DG FUSED AUTO SHUT DOWN RELAY OUTPUT
3 K900 18GY INTAKE PORT SWIRL ACTUATOR SIGNAL
INTRUSION TRANSCEIVER MODULE (BUILT-UP-EXPORT) - BLACK 6 WAY
CAV CIRCUIT FUNCTION
1 Z155 20BK GROUND
2- -
3 X75 20GY/LG SIREN SIGNAL CONTROL
4- -
5 D25 20YL/VT PCI BUS
6 F70 20PK FUSED B(+)
JUNCTION BLOCK BODY CONTROL MODULE - BLACK 26 WAY
CAV CIRCUIT FUNCTION
1 L308 PARK LAMP RELAY CONTROL
2 L26 FOG LAMP RELAY CONTROL
3 Q29 ACCESSORY DELAY RELAY CONTROL
4 L307 LOW BEAM RELAY CONTROL
5 G5 FUSED IGNITION SWITCH OUTPUT (RUN-START)
6 X4 HORN RELAY CONTROL
7 V16 WIPER HIGH/LOW RELAY CONTROL
8 G80 LIFTGATE FLIP-UP AJAR SWITCH SENSE
9 L11 HIGH BEAM RELAY CONTROL
10 L91 HAZARD SWITCH SENSE
11 C80 REAR WINDOW DEFOGGER RELAY CONTROL
12 Z2 GROUND
13 L96 (BUILT-UP-EXPORT) REAR FOG LAMP RELAY CONTROL
14 L7 PARK LAMP RELAY OUTPUT
15 Z1 GROUND
16 M2 COURTESY LAMP DRIVER
17 - -
18 - -
19 M20 COURTESY LAMP LOAD SHED
20 V55 WIPER PARK SWITCH SENSE
21 G78 LIFTGATE AJAR SWITCH SENSE
22 G10 SEAT BELT SWITCH SENSE
23 G77 LEFT REAR DOOR AJAR SWITCH SENSE
24 G73 LIFTGATE COURTESY DISABLE
25 V23 FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
26 M1 FUSED B(+)
8W - 80 - 86 8W-80 CONNECTOR PIN-OUTWJ

JUNCTION BLOCK C1 - BLACK 52 WAY
CAV CIRCUIT FUNCTION
1 Q30 16TN ACCESSORY DELAY RELAY OUTPUT
2 L63 18DG/RD LEFT TURN SIGNAL
3- -
4- -
5 L95 18DG/YL (BUILT-UP-EXPORT) REAR FOG LAMP RELAY OUTPUT
6- -
7- -
8- -
9 G73 20LG/OR LIFTGATE COURTESY DISABLE
10 G77 20TN/OR LEFT REAR DOOR AJAR SWITCH SENSE
11 L7 18BK/YL PARK LAMP RELAY OUTPUT
12 - -
13 - -
14 - -
15 F37 16RD (LHD EXCEPT BASE) FUSED B(+)
15 F37 16RD/LB (RHD) FUSED B(+)
16 M2 18YL (RHD) COURTESY LAMP DRIVER
16 M2 20YL/DG (LHD) COURTESY LAMP DRIVER
17 - -
18 - -
19 - -
20 - -
21 - -
22 F22 20WT/PK (RHD) FUSED IGNITION SWITCH OUTPUT (RUN)
23 - -
24 G80 20VT/YL LIFTGATE FLIP-UP AJAR SWITCH SENSE
25 G78 20TN/BK LIFTGATE AJAR SWITCH SENSE
26 M20 18YL/BK (RHD) COURTESY LAMP LOAD SHED
26 M20 20YL/BK (LHD) COURTESY LAMP LOAD SHED
27 - -
28 - -
29 - -
30 G5 20DB/WT FUSED IGNITION SWITCH OUTPUT (RUN-START)
31 - -
32 M1 18PK/RD (RHD) FUSED B(+)
33 - -
34 - -
35 F9 14RD/BK FUSED B(+)
36 F70 18PK FUSED B(+)
37 - -
38 - -
39 - -
40 - -
41 F30 14RD/TN (LHD) CIGAR LIGHTER RELAY OUTPUT
41 F30 16RD/TN (RHD) CIGAR LIGHTER RELAY OUTPUT
42 - -
43 - -
44 - -
45 - -
46 - -
47 - -
48 - -
49 - -
50 C15 12BK/WT REAR WINDOW DEFOGGER RELAY OUTPUT
51 - -
52 - -
WJ8W-80 CONNECTOR PIN-OUT 8W - 80 - 87

JUNCTION BLOCK C3 - BLACK 52 WAY
CAV CIRCUIT FUNCTION
1 F22 20WT/PK FUSED IGNITION SWITCH OUTPUT (RUN)
2- -
3 L60 20TN RIGHT TURN SIGNAL
4 L302 20LB/YL RIGHT TURN SWITCH SENSE
5 L61 20TN/LG LEFT TURN SIGNAL
6 L91 20DB/PK HAZARD SWITCH SENSE
7- -
8 L305 20LB/WT LEFT TURN SWITCH SENSE
9- -
10 L309 20PK/LG HIGH BEAM RELAY CONTROL
11 F23 18DB/YL FUSED IGNITION SWITCH OUTPUT (RUN)
12 F22 20WT/PK FUSED IGNITION SWITCH OUTPUT (RUN)
13 - -
14 F85 16VT/WT FUSED B(+)
15 C79 20BK/WT FUSED REAR WINDOW DEFOGGER RELAY OUTPUT
16 - -
17 - -
18 - -
19 - -
20 - -
21 - -
22 - -
23 - -
24 A31 12RD/BK IGNITION SWITCH OUTPUT (RUN-ACC)
25 F60 16RD/WT FUSED B(+)
26 - -
27 A41 12YL IGNITION SWITCH OUTPUT (START)
28 F14 20LG/YL FUSED IGNITION SWITCH OUTPUT (RUN-START)
29 A22 12BK/OR IGNITION SWITCH OUTPUT (RUN)
30 F991 18OR/DB FUSED IGNITION SWITCH OUTPUT (RUN-START)
31 Z234 20BK GROUND
32 F33 20PK/RD FUSED B(+)
33 X12 16WT/RD FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
34 M1 20PK FUSED B(+)
35 M1 20PK (AZC) FUSED B(+)
36 A21 12DB IGNITION SWITCH OUTPUT (RUN-START)
37 - -
38 F70 20PK/BK FUSED B(+)
39 X3 20GY/OR HORN RELAY CONTROL
40 F30 16RD FUSED CIGAR LIGHTER RELAY OUTPUT
41 F33 20PK/RD FUSED B(+)
42 - -
43 V23 20BR/PK FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
44 M1 20PK FUSED B(+)
45 Z132 20BK/OR GROUND
46 - -
47 - -
48 F70 20PK/BK FUSED B(+)
49 - -
50 G5 20DB/WT FUSED IGNITION SWITCH OUTPUT (RUN-START)
51 G5 20DB/WT FUSED IGNITION SWITCH OUTPUT (RUN-START)
52 F12 20DB/WT FUSED IGNITION SWITCH OUTPUT (RUN-START)
8W - 80 - 90 8W-80 CONNECTOR PIN-OUTWJ

LINE PRESSURE SENSOR (4.7L) - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 Z114 14BK/LB GROUND
2 T138 14GY/LB 5 VOLT SUPPLY
3 T130 14VT/TN LINE PRESSURE SENSOR SIGNAL
4- -
MANIFOLD ABSOLUTE PRESSURE SENSOR (4.0L) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 K4 18BK/LB SENSOR GROUND
2 K1 18DG/RD MAP SENSOR SIGNAL
3 K7 18OR 5 VOLT SUPPLY
MANIFOLD ABSOLUTE PRESSURE SENSOR (4.7L) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 K1 18DG/RD MAP SENSOR SIGNAL
2 K4 18BK/LB SENSOR GROUND
3 K7 18OR 5 VOLT SUPPLY
MANUAL TEMPERATURE CONTROL C1 (MTC) - WHITE 11 WAY
CAV CIRCUIT FUNCTION
1 C103 20DG A/C SWITCH SIGNAL
2 Z123 20BK/OR GROUND
3 C67 20RD/LB BLEND AIR DOOR POSITION CONTROL
4 C79 20BK/WT FUSED REAR WINDOW DEFOGGER RELAY OUTPUT
5 C81 20LB/WT REAR WINDOW DEFOGGER SWITCH SENSE
6 F22 20WT/PK FUSED IGNITION SWITCH OUTPUT (RUN)
7 E2 20OR PANEL LAMPS DRIVER
8 C4 16TN BLOWER MOTOR LOW DRIVER
9 C5 16LG BLOWER MOTOR M1 DRIVER
10 C6 14LB BLOWER MOTOR M2 DRIVER
11 - -
8W - 80 - 98 8W-80 CONNECTOR PIN-OUTWJ

PASSENGER BLEND DOOR MOTOR/ACTUATOR (RHD) (AZC) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
A C94 20WT/DG (RHD) PASSENGER BLEND DOOR DRIVER (A)
B C96 20WT/DB (RHD) PASSENGER BLEND DOOR DRIVER (B)
PASSENGER CURTAIN AIRBAG - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 R72 20LB/WT PASSENGER CURTAIN SQUIB LINE 2
2 R74 20LB/YL PASSENGER CURTAIN SQUIB LINE 1
PASSENGER DOOR LOCK MOTOR/AJAR SWITCH - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 G74 18TN/RD PASSENGER DOOR AJAR SWITCH SENSE
2 Z1 18BK GROUND
3 P36 18PK/VT DOOR UNLOCK DRIVER
4 P35 18OR/VT DOOR LOCK DRIVER
PASSENGER DOOR MODULE C1 - WHITE 15 WAY
CAV CIRCUIT FUNCTION
1 A146 12OR/WT FUSED B(+)
2 Q24 16DG PASSENGER REAR WINDOW DRIVER (DOWN)
3 Q14 16GY PASSENGER REAR WINDOW DRIVER (UP)
4 Z1 12BK GROUND
5 P35 18OR/VT DOOR LOCK DRIVER
6- -
7 P36 18PK/VT DOOR UNLOCK DRIVER
8- -
9 D25 20YL/VT PCI BUS
10 - -
11 G74 18TN/RD PASSENGER DOOR AJAR SWITCH SENSE
12 E20 20OR/DB PASSENGER REAR DOOR SWITCH ILLUMINATION
13 Q12 16BR PASSENGER WINDOW DRIVER (UP)
14 - -
15 Q22 16VT PASSENGER WINDOW DRIVER (DOWN)
8W - 80 - 102 8W-80 CONNECTOR PIN-OUTWJ

PASSENGER POWER SEAT RECLINER MOTOR (MIDLINE/PREMIUM) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
A P42 16BR/WT PASSENGER SEAT RECLINER DOWN DRIVER
B P44 16GY/LB PASSENGER SEAT RECLINER UP DRIVER
PASSENGER POWER SEAT SWITCH (MIDLINE/PREMIUM) - GREEN 10 WAY
CAV CIRCUIT FUNCTION
1 Z1 16BK GROUND
2 P44 16GY/LB PASSENGER SEAT RECLINER UP DRIVER
3 P16 16RD/YL PASSENGER SEAT HORIZONTAL REARWARD DRIVER
4 P42 16BR/WT PASSENGER SEAT RECLINER DOWN DRIVER
5 F37 16RD/LB FUSED B(+)
6 P14 16YL/LB PASSENGER SEAT HORIZONTAL FORWARD DRIVER
7 P18 16YL/LG (RHD) PASSENGER SEAT FRONT UP DRIVER
7 P20 16RD/LG (LHD) PASSENGER SEAT FRONT DOWN DRIVER
8 P10 16YL/WT (RHD) PASSENGER SEAT REAR UP DRIVER
8 P12 16RD/WT (LHD) PASSENGER SEAT REAR DOWN DRIVER
9 P12 16RD/WT (RHD) PASSENGER SEAT REAR DOWN DRIVER
9 P10 16YL/WT (LHD) PASSENGER SEAT REAR UP DRIVER
10 P20 16RD/LG (RHD) PASSENGER SEAT FRONT DOWN DRIVER
10 P18 16YL/LG (LHD) PASSENGER SEAT FRONT UP DRIVER
PASSENGER REAR POWER WINDOW MOTOR - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 Q124 16DG/WT WINDOW DRIVER (DOWN)
2 Q114 16GY/WT WINDOW DRIVER (UP)
PASSENGER REAR POWER WINDOW SWITCH - BLUE 6 WAY
CAV CIRCUIT FUNCTION
1 Q14 16GY PASSENGER REAR WINDOW DRIVER (UP)
2 Q114 16GY/WT WINDOW DRIVER (UP)
3 E21 20OR/RD PASSENGER REAR DOOR SWITCH ILLUMINATION
4 Q24 16DG PASSENGER REAR WINDOW DRIVER (DOWN)
5 Q124 16DG/WT WINDOW DRIVER (DOWN)
6 Z1 16BK GROUND
PASSENGER SEAT BELT SWITCH-2WAY
CAV CIRCUIT FUNCTION
1 R58 20GY PASSENGER SEAT BELT SWITCH SENSE
2 R60 20VT PASSENGER SEAT BELT SWITCH GROUND
8W - 80 - 106 8W-80 CONNECTOR PIN-OUTWJ
