JEEP GRAND CHEROKEE 2004 WK / 3.G User Guide

A WORD ABOUT YOUR KEYS
The keys for your new vehicle are enclosed in a plastic
bag with the key code number on it. If you received your
keys without the bag, ask your authorized dealer to give
you the number. The key code can also be obtained by
your authorized dealer from your vehicle invoice.
Ignition Key
Insert the key fully, then turn the switch to one of the four
illustrated positions. The key can be inserted or with-
drawn only in the LOCK position. The gearshift lever
must be in the P (Park) position.
To remove the ignition key, place the gearshift lever in P
(Park), turn the ignition key to LOCK and remove the
key.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 11
2

Key-In-Ignition Reminder
If the driver's door is opened when the key is in the
ignition and not turned to the ON position, a chime will
sound to remind you to remove the key.
CAUTION!
Always remove the key from the ignition, and lock
all doors when leaving the vehicle unattended.
SENTRY KEY IMMOBILIZER SYSTEM Ð IF
EQUIPPED
The Sentry Key Immobilizer System (SKIS) prevents
unauthorized operation of the vehicle by disabling the
engine. The system will shut the engine down after 2
seconds of running if an invalid key is used to start the
vehicle. This system utilizes ignition keys which have an
electronic chip (transponder) embedded into them. Onlykeys that have been programmed to the vehicle can be
used to start and operate the vehicle for longer than the
2 second validation time period.
The Sentry Key Immobilizer System does not need to be
armed or activated. Operation of the system is automatic
regardless of whether or not the vehicle is locked or
unlocked. During normal operation, the SKIS indicator
light will come on for 3 seconds immediately after the
ignition switch is turned on for a bulb check. Afterwards,
if the bulb remains on, this indicates a malfunction in the
electronics. If the bulb begins to flash immediately after
the ignition switch is turned on, this indicates that an
invalid key is being used to start the vehicle. Both of
these conditions will result in the engine being shut
down after 2 seconds of running. Keep in mind that a key
which has not been programmed is also considered an
invalid key even if it is cut to fit the ignition for that
vehicle.
12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

If the SKIS indicator light comes on during normal
vehicle operation (it has been running for longer than 10
seconds) a fault has been detected in the electronics and
the vehicle should be serviced as soon as possible.
NOTE:
²The Sentry Key Immobilizer System is not compatible
with remote starting systems. Use of these systems
may result in vehicle starting problems and loss of
security protection.
²Mobil SpeedpassŸ, additional Sentry Keys, or any
other transponder equipped components on the same
keychain will not cause a key-related (Transponder)
fault unless the additional part isphysically held
against the ignition keybeing used when starting the
vehicle. Also, cell phones, pagers, or other RF electron-
ics will not cause interference with this system.
All of the keys provided with your new vehicle have
been programmed to the vehicle electronics.
Important Note About Service
A four digit PIN number is needed to service the Sentry
Key Immobilizer System. This number can be obtained
from your authorized dealer. However, this number can
also be found on your customer invoice that you were
given upon receipt of your vehicle.
Replacement Keys
NOTE:Only keys that have been programmed to the
vehicle electronics can be used to start the vehicle. Once
a Sentry Key has been programmed to a vehicle, it cannot
be programmed to any other vehicle.
At the time of purchase, the original owner is provided
with a four digit PIN number. This number is required
for dealer replacement of keys. Duplication of keys may
be performed at an authorized dealer or by using the
Customer Key Programming procedure. This procedure
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 13
2

consists of programming a blank key to the vehicle
electronics. A blank key is one which has never been
programmed.
NOTE:When having the Sentry Key System serviced,
bring all vehicle keys to the dealer.
Customer Key Programming
You can program new keys to the system if you have two
valid keys by doing the following:
1. Cut the additional Sentry Key Transponder blank(s) to
match the ignition switch lock cylinder key code.
2. Insert the first valid key into the ignition switch and
turn the ignition switch ON for at least 3 seconds but no
longer than 15 seconds. Turn the ignition switch OFF and
remove the first key.
3. Insert the second valid key and turn the ignition
switch ON within 15 seconds. After ten seconds, a chimewill sound and the SKIS indicator light will begin to
flash. Turn the ignition switch OFF and remove the
second key.
4. Insert a blank Sentry Key into the ignition switch and
turn the ignition switch ON within 60 seconds. After 10
seconds, a single chime will sound. The SKIS indicator
light will stop flashing, turn on for 3 seconds; then turn
off.
The new Sentry Key has been programmed. Repeat this
process to program up to a total of 8 keys.
General Information
The Sentry Key Immobilizer System complies with FCC
rules part 15 and with RSS-210 of Industry Canada.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

2. This device must accept any interference that may be
received, including interference that may cause undes-
ired operation.
ILLUMINATED ENTRY
The interior lights come on when you open any door.
They will remain on for about 30 seconds after all doors
are closed then fade to off.
The lights also will fade to off if you turn on the ignition
after you close all the doors.
DOOR AND LIFTGATE LOCKS
NOTE:The master key that is used to start the vehicle is
used to lock or unlock the driver's door. To unlock the
driver's door insert the key into the lock and turn.
To open the liftgate, pull out on the handle and lift.
WARNING!
Driving with the liftgate open can allow poisonous
exhaust gases into your vehicle. You and your pas-
sengers could be injured by these fumes. Keep the
liftgate closed when you are operating the vehicle.
Liftgate Flipper Glass
The liftgate flipper glass is also unlocked when the
liftgate is unlocked. To open the flipper glass, push up on
the window switch located on the liftgate. Once the
liftgate flipper glass has been opened, connection to the
rear window wiper is interrupted, preventing activation
of the rear wiper blade while the flipper glass is open.
NOTE:If a power malfunction to the power liftgate
latch should occur, an emergency liftgate latch release
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 15
2

can be used to open the liftgate. The emergency liftgate
latch release can be accessed through a snap-in cover
located on the liftgate trim panel.WARNING!
Driving with the flipper glass open can allow poi-
sonous exhaust gases into your vehicle. You and your
passengers could be injured by these fumes. Keep
the flipper glass closed when you are operating the
vehicle.
16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Door Locks
All doors are equipped with a slide-type interior door
lock. To manually lock a door, slide the lever rearward
(toward the rear of the vehicle) to the ªLockº position.
Once locked, the rear doors cannot be opened from the
inside until the lock lever has been released. However,
the front doors can be opened using the inside door
handle.
To manually unlock a door, slide the lever forward
(toward the front of the vehicle) to the ªUnlockº position.
WARNING!
For personal security reasons and safety in a colli-
sion, lock the vehicle doors when you drive and
when you park and leave the vehicle.
WARNING!
When leaving the vehicle always remove the key
from the ignition lock, and lock your vehicle. Do not
leave children unattended in the vehicle, or with
access to an unlocked vehicle. Unsupervised use of
vehicle equipment may cause severe personal inju-
ries and death.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 17
2

Child Protection Locks
The rear doors of your vehicle are equipped with child
protection locks. If you push up on the lever on the open
edge of the door it cannot be opened from the inside of
the vehicle. Push the lever down to disengage the child
protection locks.
WARNING!
Avoid trapping anyone in the vehicle in a collision.
Remember that the rear doors can only be opened
from the outside when the child protection locks are
engaged.
Power Door Lock System
The power door locks are on a paddle-type switch.
Pressing the switch toward the rear of the vehicle will
ªLockº all doors. Pressing the switch toward the front of
the vehicle will ªUnlockº all doors. The driver's and
passenger's switch locks and unlocks all doors and the
liftgate.
18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

As a safety feature, the power door lock switch will not
lock when the door is open and the key is in the ignition.
Once locked, the rear doors cannot be opened from the
inside until the lock lever has been released. However,
both front doors can be opened using the inside door
handle.Automatic Door Locks
If this feature is selected your door locks will lock
automatically if the vehicle speed is above 15 mph (24
km/h) and all doors are closed. It will reset whenever a
door is opened.
This feature is selectable and can be turned on or off.
Refer to ªOverhead Console Ð Customer Programmable
Featuresº in Section 3 of this manual or see your autho-
rized dealer.
Automatic Unlock on Exit Feature Ð Only
Available if Auto Lock is Enabled
This feature will unlock all the doors when the driver's
door is opened if the vehicle is stopped and in P (Park) or
N (Neutral). Refer to ªOverhead Console Ð Customer
Programmable Featuresº in Section 3 of this manual or
see your authorized dealer.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 19
2

REMOTE KEYLESS ENTRY
This system allows you to lock or unlock the doors and
liftgate or activate the panic alarm from distances up to
about 23 feet (7 meters) using a hand held radio trans-
mitter. The transmitter need not be pointed at the vehicle
to activate the system.
To Unlock the Doors and Liftgate
Press and release the ªUnlockº button on the key fob
once to unlock the driver's door, or twice (within 5
seconds) to unlock all doors and liftgate. The illuminated
entry system will also come on.
NOTE:The system can be programmed to do the
following:
²unlock all the doors on the first button press
²flash the turn signals with unlock
²On vehicles equipped with an overhead console these
functions can be selected at the overhead console
using the ªCustomer Programmable Features.º Refer
to ªOverhead Console Ð Customer Programmable
Featuresº in this section, otherwise see your autho-
rized dealer.
